Operation Guide 4369

MA0508-EA

To set the day

1. Pull the crown out to the first click.

2. Set the day by rotating the crown towards you.

3. Push the crown back in to the normal position.

•Avoid changing the date setting while the current time is between 9:00 p.m. and

1:00 a.m.

Using the Stopwatch

The stopwatch lets you measure elapsed time up to 11 hours, 59 minutes, 59.95

seconds.

To measure elapsed time

1. Press A to start the stopwatch.

2. Press A to stop the stopwatch.

•You can resume the measurement operation by pressing again.A

The stopwatch 1/20 second hand rotates and indicates the 1/20 second count

during the first 30 seconds.

3. Check the elapsed time.

•The example below shows an elapsed time of two minutes, 18.80 seconds.

•Press B to reset the stopwatch.

This will enter the Timekeeping Mode.

To return the function of the stopwatch 1/20 second hand to the timekeeping

seconds hand (indicating the current seconds count), press B again.

Notes:

•Do not try to perform stopwatch operations while the crown is pulled out either to

the first or second click. If you try to press a button, you might accidentally cause

the crown to rotate and change the current time or day setting.

•If the starting positions of the stopwatch second hand and 1/20 second hand

become misaligned, use the following procedures to adjust the positions of the

hands so they point to 12 o’clock when the stopwatch is reset.

To adjust the positions of the stopwatch hands

1. Press B to reset the stopwatch, and check the alignment of the stopwatch

second hand and 1/20 second hand.

2. Pull out the crown to the second click.

3. Press A to move the stopwatch second hand.

4. Press B.

5. If the stopwatch 1/20 second hand is aligned correctly, proceed to step 6. If the

stopwatch 1/20 second hand is also misaligned, press to move the stopwatchB

1/20 second hand.

6. After making the adjustments you want, push the crown back in to its normal position.

•Note that pulling the crown out also stops the timekeeping second hand. After

performing the above procedure, you should also adjust the timekeeping setting.

To set the time

1. Pull the crown out to the second

click.

•At this time, the second hand will

move to the 12 o’clock position and

stop there.

2. Set the hands by rotating the crown.

Rotate the crown to move the hands

clockwise. Move the minute hand

four or five minutes past the time you

want to set, and then back it up to

the proper setting.

•Carefully set the time, making sure

to distinguish between AM and PM.

3. Push the crown back in to the normal

position to restart timekeeping.

■For a watch with an elapsed time bezel

Rotate the elapsed time bezel to align the mark with the

minute hand.

After certain amount of time elapsed, read the graduation on

the elapsed time bezel which the minute hand points to.

The elapsed time is indicated.

•Some water resistant models are equipped with a screw lock

crown.

•With such models, you must unscrew the crown in the

direction noted in the illustration to loosen it before you can

pull it out. Do not pull too forcibly on such crowns.

•Also note that such watches are not water resistant while

their crowns are loosened. Be sure to screw the crowns

back in as far as they will go after making any setting.

Elapsed time bezel

Minute hand

Hour hand

First click

(Setting day)

Second click

(Setting time)

Crown

(Normal position)

Day Second hand

Stopwatch minute hand

[2 minutes]

Stopwatch 1/20 second hand

[80]

Stopwatch second hand

[18 seconds]

Stopwatch minute hand

Stopwatch second hand

Stopwatch 1/20 second hand

This hand rotates and

indicates the 1/20 second

count during the first 30

seconds.

Stopwatch hour hand
