Sida 1/4
© 2017 CASIO COMPUTER CO., LTD.
MA2107-A
User’s Guide
Watch
ANA (I3H-2) EN
5547 5563 5572 5653 5687
Stopwatch functions
30
Click 2
Click 1
Day Indicator
24 Hour Hand
Second Hand
Hour Hand
Minute Hand
Stopwatch Second Hand
Stopwatch Minute Hand Crown
To change the day indicator setting
To adjust the time setting
Pull the out to Click 1. Crown
Push the back in. Crown
Rotate the to change the Crown
time setting.
When the second hand is at
12 o’clock, pull the Crown out to
Click 2.
Rotate the towards you to Crown
set the day.
Note
• The day indicator setting uses a
31-day month. Make adjustments for
months of shorter lengths.
• Avoid changing the day indicator
setting between the hours of 9
p.m. and 1 a.m. Otherwise, the day
indicator may not change correctly
at midnight.
Crown Operations
Some water-resistant models (10BAR, 20BAR) have a screw-in
crown. When you need to perform a crown operation, rotate
it towards you to unscrew it. Then pull the crown out. Avoid
applying undue force when pulling. The watch loses its water
resistance while the crown is unscrewed. After performing a
crown operation, fully screw the crown back in.
Crown
Loosen
If your watch has a rotary bezel...
You can rotate the bezel to align its ▼ mark with the
minute hand. Then you will be able to tell how much
time has elapsed since aligning the ▼ mark.
Start
Elapsed time
Current
Low Battery Alert
•
The second hand will jump at two-second intervals to alert you when battery power
is low.
•
Have the battery replaced as soon as possible after low battery alert is indicated.
•
Stopwatch operation is disabled during low battery alert.
• If low battery alert occurs during a stopwatch operation, the stopwatch will
automatically reset to all zeros and stop.
Push the back in on a time Crown
signal to resume timekeeping.
Note
• Take care that you set the correct AM
or PM time.
• When changing the time, move the
minute hand four or five minutes past
your final setting, and then back it up
to the setting you want.
• Your watch may differ somewhat from the one shown in the illustration.
Congratulations upon your selection of this CASIO watch.
To ensure that this watch provides you with the years of service for which it is designed,
carefully read and follow the instructions in this manual, especially the information under
“Operating Precautions” and “User Maintenance”.
Specifications
Accuracy at normal temperature: ±20 seconds a month
Stopwatch: Measuring Capacity: 9'59" (10 minutes)
Measuring Unit: 1 second
Measurements: Elapsed time; split time; two finishes
Other: Low battery alert
Battery: One silver oxide battery (Type: SR920SW)
Battery Life: Approximately 3 years
Specifications are subject to change without notice.
Perform the following procedure if the stopwatch hands do not return to their 0 (zero)
positions when you reset the stopwatch.
Correcting the 0 Positions of the Hands
Pull the out to Click 2. Crown
Use A (clockwise) and (counterclockwise) to move the B
Stopwatch Second Hand to 12 o’clock and the Stopwatch Minute Hand to 0.
• Holding down either button will move the second hand at high speed, until you
release the button.
• The Stopwatch Minute Hand is synchronized with the Stopwatch Second Hand .
After all of the hands are the way you want, push the back in. Crown
Important!
• Timekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
Using the Stopwatch
Important!
• Do not operate the stopwatch with the crown pulled out.
Note
• An elapsed time operation will stop automatically at the end of 10 minutes.
The stopwatch measures elapsed time in 1-second increments up to 9minutes,
59seconds.
Elapsed time
A A A A B
Start Stop Resume Stop Reset
Split time
A B B A B
Start Split Stop ResetSplit release
Two finishes
A B A B B
Start Split
First runner
finishes.
Display time of
first runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Reset
Operating Precautions
Water Resistance
• The information below applies to watches with WATER RESIST or WATER RESISTANT
marked on the back cover.
Water
Resistance
Under Daily
Use
Enhanced Water Resistance Under Daily
Use
5
Atmospheres
10
Atmospheres
20
Atmospheres
Marking On watch front or on
back cover
No
BAR mark 5BAR 10BAR 20BAR
Example of
Daily Use
Hand washing, rain Yes Yes Yes Yes
Water-related work,
swimming No Yes Yes Yes
Windsurfing No No Yes Yes
Skin diving No No Yes Yes
•
Do not use your watch for scuba diving or other types of diving that requires air tanks.
• Watches that do not have WATER RESIST or WATER RESISTANT marked on the back
cover are not protected against the effects of sweat. Avoid using such a watch under
conditions where it will be exposed to large amounts of sweat or moisture, or to direct
splashing with water.
• Even if a watch is water resistant, note the usage precautions described below. Such
types of use reduce water resistance performance and can cause fogging of the glass.
− Do not operate the crown or buttons while your watch is submersed in water or
wet.
− Avoid wearing your watch while in the bath.
− Do not wear your watch while in a heated swimming pool, sauna, or any other high
temperature/high humidity environment.
− Do not wear your watch while washing your hands or face, while doing housework,
or while performing any other task that involves soaps or detergents.
• After submersion in seawater, use plain water to rinse all salt and dirt from your watch.
• To maintain water resistance, have the gaskets of your watch replaced periodically (about
once every two or three years).
• A trained technician will inspect your watch for proper water resistance whenever you have
its battery replaced. Battery replacement requires the use of special tools. Always request
battery replacement from your original retailer or from an authorized CASIO service center.
• Some water-resistant watches come with fashionable leather bands. Avoid swimming,
washing, or any other activity that causes direct exposure of a leather band to water.
• The inside surface of the watch glass may fog when the watch is exposed to a sudden
drop in temperature. No problem is indicated if the fogging clears up relatively quickly.
Sudden and extreme temperature changes (such as coming into an air conditioned
room in the summer and standing close to an air conditioner outlet, or leaving a heated
room in the winter and allowing your watch to come into contact with snow) can cause
it to take longer for glass fogging to clear up. If glass fogging does not clear up or if you
notice moisture inside of the glass, immediately stop using your watch and take it to
your original retailer or to an authorized CASIO service center.
• Your water-resistant watch has been tested in accordance with International Organization
for Standardization regulations.
Band
• Tightening the band too tightly can cause you to sweat and make it difficult for air to pass
under the band, which can lead to skin irritation. Do not fasten the band too tightly. There
should be enough room between the band and your wrist so you can insert your finger.
• Deterioration, rust, and other conditions can cause the band to break or come off of your
watch, which in turn can cause band pins to fly out of position or to fall out. This creates
the risk of your watch falling from your wrist and becoming lost, and also creates the risk
of personal injury. Always take good care of your band and keep it clean.
• Immediately stop using a band if you even notice any of the following: loss of band
flexibility, band cracks, band discoloration, band looseness, band connecting pin flying
or falling out, or any other abnormality. Take your watch to your original retailer or to a
CASIO service center for inspection and repair (for which you will be charged) or to have
the band replaced (for which you will be charged).
Temperature
• Never leave your watch on the dashboard of a car, near a heater, or in any other location
that is subject to very high temperatures. Do not leave your watch where it will be exposed
to very low temperatures. Temperature extremes can cause your watch to lose or gain
time, to stop, or otherwise malfunction.
Impact
• Your watch is designed to withstand impact incurred during normal daily use and during
light activity such as playing catch, tennis, etc. Dropping your watch or otherwise
subjecting it to strong impact, however, can lead to malfunction. Note that watches with
shock-resistant designs (G-SHOCK, BABY-G, G-MS) can be worn while operating a chain
saw or engaging in other activities that generate strong vibration, or while engaging in
strenuous sports activities (motocross, etc.)
Magnetism
• The hands of analog and combination (analog-digital) watches are moved by a motor
that uses magnetic force. When such a watch is close to a device (audio speakers,
magnetic necklace, cell phone, etc.) that emits strong magnetism, the magnetism can
cause timekeeping to slow down, speed up, or stop, resulting in the incorrect time
being displayed.
• Very strong magnetism (from medical equipment, etc.) should be avoided because it can
cause malfunction of your watch and damage to electronic components.
Electrostatic Charge
• Exposure to very strong electrostatic charge can cause your watch to display the wrong
time. Very strong electrostatic charge even can damage electronic components.
Chemicals
• Do not allow your watch to come into contact with thinner, gasoline, solvents, oils, or
fats, or with any cleaners, adhesives, paints, medicines, or cosmetics that contain such
ingredients. Doing so can cause discoloration of or damage to the resin case, resin
band, leather, and other parts.
Storage
• If you do not plan to use your watch for a long time, thoroughly wipe it free of all dirt,
sweat, and moisture, and store it in a cool, dry place.
Resin Components
• Allowing your watch to remain in contact with other items or storing it together with other
items for long periods while it is wet can cause color on resin components to transfer
to the other items, or the color of the other items to transfer to the resin components of
your watch. Be sure to dry off your watch thoroughly before storing it and make sure it
is not in contact with other items.
• Leaving your watch where it is exposed to direct sunlight (ultraviolet rays) for long periods
or failure to clean dirt from your watch for long periods can cause it to become discolored.
• Friction caused by certain conditions (strong external force, sustained rubbing, impact,
etc.) can cause discoloration of painted components.
• If there are printed figures on the band, strong rubbing of the printed area can cause
discoloration.
• Leaving your watch wet for long periods can cause fluorescent color to fade. Wipe the
watch dry as soon as possible after it becomes wet.
• Semi-transparent resin parts can become discolored due to sweat and dirt, and if exposed
to high temperatures and humidity for long periods.
• Daily use and long-term storage of your watch can lead to deterioration, breaking, or
bending of resin components. The extent of such damage depends on usage conditions
and storage conditions.
Leather Band
• Allowing your watch to remain in contact with other items or storing it together with other
items for long periods while it is wet can cause the color of the leather band to transfer
to the other items or the color of the other items to transfer to the leather band. Be sure
to dry off your watch thoroughly with a soft cloth before storing it and make sure it is
not in contact with other items.
• Leaving a leather band where it is exposed to direct sunlight (ultraviolet rays) for long periods
or failure to clean dirt from a leather band for long periods can cause it to become discolored.
CAUTION: Exposing a leather band to rubbing or dirt can cause color transfer and
discoloration.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | Edifice EFR-556D-1AV |
Behöver du hjälp?
Om du behöver hjälp med Casio Edifice EFR-556D-1AV ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
