Operation Guide 5619

Stopwatch functions

Be sure to keep all user documentation handy for future reference.

Your watch may differ somewhat from the one shown in the illustration.

To adjust the time setting

When the second hand is at 12 o’clock, pull

the Crown out to Click 2.

Rotate the to change the time setting. Crown

Push the back in on a time signal to Crown

resume timekeeping.

Note

x Take care that you set the

correct AM or PM time.

x When changing the time,

move the minute hand

four or five minutes past

your final setting, and then

back it up to the setting

you want.

To change the day indicator setting

Pull the out to Click 1. Crown

Rotate the away from you to set the Crown

day.

Push the back in. Crown

Note

x The day indicator setting

uses a 31-day month.

Make adjustments for

months of shorter lengths.

x Avoid changing the day

indicator setting between

the hours of 9:00 p.m.

and 1:00 a.m. Otherwise,

the day indicator may

not change correctly at

midnight.

Low Battery Alert

The second hand will jump at two-second intervals to alert you when the charge is low.

Have the battery replaced as soon as possible after low battery alert is indicated.

Stopwatch operation is disabled during low battery alert.

If low battery alert occurs during a stopwatch operation, the stopwatch will

automatically reset to all zeros and stop.

Click 2

Click 1

Crown

Day Indicator

Minute Hand

Hour Hand

Second Hand

Stopwatch Minute Hand

Stopwatch Second Hand

Crown Operations

Some water-resistant models (100 meters, 200 meters) have a

screw-in crown. When you need to perform a crown operation,

rotate it towards you to unscrew it. Then pull the crown out.

Avoid applying undue force when pulling. The watch loses its

water resistance while the crown is unscrewed. After performing

a crown operation, fully screw the crown back in.

Crown

Loosen

If your watch has a rotary bezel...

You can rotate the bezel to align its ▼ mark with the

minute hand. Then you will be able to tell how much

time has elapsed since aligning the ▼ mark.

Start

Elapsed time

Current

Specifications

Module No. Accuracy at normal

temperature (per month) Battery type

Battery life

(30 minutes stopwatch

operation per day)

5619 ±20 seconds SR927SW Approx. 5 years

Stopwatch: Measuring Capacity: 29'59" (30 minutes)

Measuring Unit: 1 second

Measurements: Elapsed time; split time

Other: Low battery alert

Specifications are subject to change without notice.

Using the Stopwatch

Important!

Do not operate the stopwatch with the crown pulled out.

Note

An elapsed time operation will stop automatically at the end of 30minutes.

The stopwatch measures elapsed time in 1-second increments up to 29minutes,

59seconds.

Elapsed time

A A A A B

Start Stop Resume Stop Reset

Split time

A B B A B

Start Split Split release Stop Reset

Perform the following procedure if the stopwatch hands do not return to their 0 (zero)

positions when you reset the stopwatch.

Correcting the 0 Positions of the Hands

Pull the out to Click 2. Crown

Use A to align the Stopwatch Second Hand with 12 o’clock, and B to align

the Stopwatch Minute Hand

with 12 o’clock.

After all of the hands are the way you want, push the back in. Crown

Important!

Timekeeping stops while the crown is pulled out. Correct the current time setting

after performing the above operation.
