Operation Guide ANA(G3H-3)
E-9
Charging Time
The times below are general guidelines for reference only.
Charging Time to Support Daily Use
Exposure Level (Brightness) Approximate Charging Time
Outdoor sunlight (50,000 lux) 6 minutes
Sunlight through a window (10,000 lux) 23 minutes
Daylight through a window on an overcast day
(5,000 lux) 36 minutes
Indoor fluorescent lighting (500 lux) 6 hours
E-8
Low Battery Alert
The second hand will jump at two-second intervals to alert you when the charge is
low.
2-second jump
E-7
Low Charge and Dead Battery Conditions
An alert operation is performed when the battery charge goes low.
E-6
Caution!
x The case of the watch may become quite hot when charging. Guard against burn
injury after charging.
x Avoid charging in the following locations, and anywhere else where the watch may
become very hot.
− On the dashboard of an automobile parked in the sun
− Close to an incandescent light source or other sources of heat
− Locations exposed to direct sunlight for long periods
Battery Indicator
While the crown is pushed in, holding down the button for about one second will B
cause the stopwatch second hand to move to a position that indicates the current
battery level (about how long the watch can continue operating).
H : At least four months
M : Two to four months
L : No more than two months
After about two seconds, the hand will return to 12o’clock.
E-5
Solar Charging
A solar panel generates electrical power that charges a built-in (secondary) battery.
The entire face is a solar panel, so power is generated when the face is exposed to
light. Keep the watch exposed to light as much as possible.
Charging the Battery
When you are not wearing the watch, leave it where it is
exposed to light. For stable operation, expose the watch to at
least a half day of light per month.
When wearing the watch, try to keep your clothing from
blocking its face (solar panel). Charging efficiency is reduced
significantly even if the face is blocked only partially.
E-4
Contents
Before Using the Watch for the First Time .......................................... E-2
Solar Charging .................................................................................... E-5
Indicators and Crown Operation ....................................................... E-11
Setting the Current Time and Day .................................................... E-13
To adjust the time setting ...........................................................................E-13
To change the day indicator setting ............................................................E-14
Using the Stopwatch ........................................................................ E-15
Specifications................................................................................... E-18
E-3
Crown Operations
Some water-resistant models (100meters, 200meters)
have a screw-in crown. When you need to perform a crown
operation, rotate it towards you to unscrew it. Then pull
the crown out. Avoid applying undue force when pulling.
The watch loses its water resistance while the crown is
unscrewed. After performing a crown operation, fully screw
the crown back in.
Crown
Loosen
If your watch has a rotary bezel...
You can rotate the bezel to align its ▼ mark with
the minute hand. Then you will be able to tell how
much time has elapsed since aligning the ▼ mark.
Start
Elapsed time
Current
E-2
Before Using the Watch for the First Time
Crown
Spacer
x Depending on your watch model, there may be a spacer
installed at the factory around the crown. If your watch has
a spacer, you should remove the spacer before using the
watch.
x After removing the spacer, use the procedures in “Crown
Operations” (page E-3) and “To adjust the time setting” (page E-13)
to set up the watch for use.
E-1
ENGLISH
x Your watch may differ somewhat from the one shown in the illustration.
MA1901-EA © 2017 CASIO COMPUTER CO., LTD.
Operation Guide ANA(G3H-3)
E-18
Specifications
Accuracy at normal temperature: ±20 seconds a month
Stopwatch: Measuring Capacity: 29'59" (30minutes)
Measuring Unit: 1 second
Measurements: Elapsed time; split time; two finishes
Other: Low battery alert
Power Supply: Solar panel and one rechargeable battery
Approximate battery operating time: 5months (no exposure to light after a full
charge)
Specifications are subject to change without notice.
E-17
Correcting the 0 Positions of the Hands
Perform the following procedure if the stopwatch hands do not return to their 0 (zero)
positions when you reset the stopwatch.
1. Pull the Crown out to Click 2.
2. Use (clockwise) and (counterclockwise) to move the A B
Stopwatch Second Hand and Stopwatch Minute Hand to 12o’clock.
x Holding down either button will move the second hand at high speed, until you
release the button.
x The Stopwatch Minute Hand is synchronized with the Stopwatch Second Hand .
3. After all of the hands are the way you want, push the Crown back in.
Important!
x Timekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
E-16
Two finishes
A B A B B
Start Split
First runner
finishes.
Display time of
first runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Reset
Important!
x Do not operate the stopwatch with the crown pulled out.
Note
x An elapsed time operation will stop automatically at the end of 30minutes.
E-15
Using the Stopwatch
The stopwatch measures elapsed time in 1-second increments up to 29minutes,
59seconds.
Elapsed time
A A A A B
Start Stop Resume Stop Reset
Split time
A B B A B
Start Split Split release Stop Reset
E-14
To change the day indicator setting
1. Pull the Crown out to Click 1.
2. Rotate the towards you to set the day. Crown
3. Push the back in. Crown
Note
x The day indicator setting uses a 31-day month. Make adjustments for months of
shorter lengths.
x Avoid changing the day indicator setting between the hours of 9 p.m. and 1 a.m.
Otherwise, the day indicator may not change correctly at midnight.
E-13
Setting the Current Time and Day
To adjust the time setting
1. When the second hand is at 12 o’clock, pull the out to Click 2. Crown
2. Rotate the to change the time setting. Crown
3. Push the back in on a time signal to resume timekeeping. Crown
Note
x Take care that you set the correct AM or PM time.
x When changing the time, move the minute hand four or five minutes past your final
setting, and then back it up to the setting you want.
E-12
Module 5557 5564 5622
30
A
B
24 Hour Hand
Stopwatch functions
Second Hand
Hour Hand Minute Hand
Stopwatch Second Hand
Day Indicator
Crown
Click 2
Click 1
Stopwatch Minute Hand
E-11
Indicators and Crown Operation
Module 5529 5530 5585
30
A
B
Click 2
Click 1
Crown
Day Indicator
24 Hour Hand
Second Hand
Hour Hand Minute Hand
Stopwatch Minute Hand
Stopwatch Second Hand
Stopwatch functions
E-10
Charging Time to Recover from Dead Battery
Exposure Level
(Brightness)
Approximate Charging
Time to 1-second
Hand Movement
Approximate Time to
Full Charge
Outdoor sunlight (50,000 lux) 2 hours 21 hours
Sunlight through a window
(10,000 lux) 6 hours 78 hours
Daylight through a window on
an overcast day (5,000 lux) 10 hours 125 hours
Indoor fluorescent lighting
(500 lux) 96 hours – – –
Note
x Actual charging time depends on environmental conditions.
