Operation Guide 5633
E-9
Charging Time
The times below are general guidelines for reference only.
Charging Time to Support Daily Use
Exposure Level (Brightness) Approximate Charging Time
Outdoor sunlight (50,000 lux) 8 minutes
Sunlight through a window (10,000 lux) 30 minutes
Daylight through a window on an overcast day
(5,000 lux) 48 minutes
Indoor fluorescent lighting (500 lux) 8 hours
E-8
Low Battery Alert
The second hand will jump at two-second intervals to alert you when the charge is
low.
2-second jump
E-7
Approximate Battery Operating Time
HAt least five months Good (high charge)
MTwo days to five months Good (medium charge)
LNo more than two days Low
Low Charge and Dead Battery Conditions
An alert operation is performed when the battery charge goes low.
E-6
Caution!
x The case of the watch may become quite hot when charging. Guard against burn
injury after charging.
x Avoid charging in the following locations, and anywhere else where the watch may
become very hot.
− On the dashboard of an automobile parked in the sun
− Close to an incandescent light source or other sources of heat
− Locations exposed to direct sunlight for long periods
Battery Indicator
The battery level/stopwatch minute hand normally indicates the approximate amount
of remaining operating time of the battery will provide.
xBattery operating time is not indicated while the stopwatch is in use.
xAfter resetting the stopwatch to all zeros, the stopwatch minute hand will go back
to indicating battery operating time if you press or if you do not perform any B
operation for 60 seconds.
E-5
Solar Charging
A solar panel generates electrical power that charges a built-in (secondary) battery.
The entire face is a solar panel, so power is generated when the face is exposed to
light. Keep the watch exposed to light as much as possible.
Charging the Battery
When you are not wearing the watch, leave it where it is
exposed to light. For stable operation, expose the watch to at
least a half day of light per month.
When wearing the watch, try to keep your clothing from
blocking its face (solar panel). Charging efficiency is reduced
significantly even if the face is blocked only partially.
E-4
Contents
Before Using the Watch for the First Time .......................................... E-2
Solar Charging .................................................................................... E-5
Indicators and Crown Operation ....................................................... E-11
Setting the Current Time and Day .................................................... E-12
To adjust the time setting ...........................................................................E-12
To change the day indicator setting ............................................................E-13
Using the Stopwatch ........................................................................ E-14
Abnormal Hand Movement or Function ............................................. E-18
Specifications................................................................................... E-19
E-3
Crown Operations
Some water-resistant models (100meters, 200meters)
have a screw-in crown. When you need to perform a crown
operation, rotate it towards you to unscrew it. Then pull
the crown out. Avoid applying undue force when pulling.
The watch loses its water resistance while the crown is
unscrewed. After performing a crown operation, fully screw
the crown back in.
Crown
Loosen
If your watch has a rotary bezel...
You can rotate the bezel to align its mark with
the minute hand. Then you will be able to tell how
much time has elapsed since aligning the mark.
Start
Elapsed time
Current
E-2
Before Using the Watch for the First Time
Crown
Spacer
x Depending on your watch model, there may be a spacer
installed at the factory around the crown. If your watch has
a spacer, you should remove the spacer before using the
watch.
x After removing the spacer, use the procedures in “Crown
Operations” (page E-3) and “To adjust the time setting”
(page E-12) to set up the watch for use.
E-1
ENGLISH
x Your watch may differ somewhat from the one shown in the illustration.
MA1910-EA © 2019 CASIO COMPUTER CO., LTD.
Operation Guide 5633
E-19
Specifications
Accuracy at normal temperature: ±20 seconds a month
Stopwatch: Measuring Capacity: 29'59" (30minutes)
Measuring Unit: 1 second
Measurements: Elapsed time; split time; two finishes
Other: Low battery alert
Power Supply: Solar panel and one rechargeable battery
Approximate battery operating time: 6months (no exposure to light after a full
charge)
Specifications are subject to change without notice.
E-18
Abnormal Hand Movement or Function
Should the watch ever exhibit abnormal hand movement or function, or if the second
hand does not move normally (one-second increments) even after the watch is fully
charged, perform the procedure below to perform a system reset.
1. Pull the Crown out to Click 2.
2. Hold down both and for at least two seconds.A B
3. Push the Crown back in.
x The second hand will start to move.
4. As required, correct the current time and day settings (page E-12), and
correct stopwatch hand alignment if necessary (page E-16).
Important!
x Timekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
E-17
Important!
x Timekeeping stops while the crown is pulled out. Correct the current time setting
after performing the above operation.
E-16
Correcting Stopwatch Hand Alignment
Perform the following procedure if the stopwatch hands do not return to their home
positions (12 o’clock or ) when you reset the stopwatch.L
1. When the second hand is at 12o’clock, pull the Crown out to Click 2.
2. Hold down for at least two seconds.A
x The will rotate to indicate the minute hand setting mode. Stopwatch Minute Hand
x If the hand does not align with , use the button to adjust it.LB
x Holding down moves the current hand at high speed.B
3. Press A.
x The will perform one full rotation to indicate the second Stopwatch Second Hand
hand setting mode.
x If the hand does not align with 12o’clock, use the button to adjust it.B
x Holding down moves the current hand at high speed.B
4. After all of the hands are the way you want, push the Crown back in.
E-15
Two finishes
A B A B B
Start Split
First runner
finishes.
Display time of
first runner.
Stop
Second runner
finishes.
Split release
Display time of
second runner.
Reset
Important!
x Do not operate the stopwatch with the crown pulled out.
Note
x An elapsed time operation will stop automatically at the end of 30minutes.
E-14
Using the Stopwatch
The stopwatch measures elapsed time in 1-second increments up to 29minutes,
59seconds.
Elapsed time
A A A A B
Start Stop Resume Stop Reset
Split time
A B B A B
Start Split Split release Stop Reset
E-13
To change the day indicator setting
1. Pull the out to Click 1. Crown
2. Rotate the away from you to set the day. Crown
3. Push the back in. Crown
Note
x The day indicator setting uses a 31-day month. Make adjustments for months of
shorter lengths.
x Avoid changing the day indicator setting between the hours of 9 p.m. and 1 a.m.
Otherwise, the day indicator may not change correctly at midnight.
E-12
Setting the Current Time and Day
To adjust the time setting
1. When the second hand is at 12o’clock, pull the out to Click 2. Crown
2. Rotate the Crown to change the time setting.
3. Push the back in on a time signal to resume timekeeping. Crown
Note
x Take care that you set the correct AM or PM time.
x When changing the time, move the minute hand four or five minutes past your final
setting, and then back it up to the setting you want.
E-11
Indicators and Crown Operation
30
A
B
Click 2
Click 1
Crown
Day Indicator
Hour Hand
Minute Hand
Battery Level Hand / Stopwatch Minute Hand
Stopwatch functions
Second Hand
Stopwatch Second Hand
E-10
Charging Time Required to Restore Operation from a Dead Battery
Exposure Level
(Brightness)
Approximate Charging
Time to 1-second
Hand Movement
Approximate Time to
Full Charge
Outdoor sunlight (50,000 lux) 4 hours 14 hours
Sunlight through a window
(10,000 lux) 11 hours 66 hours
Daylight through a window on
an overcast day (5,000 lux) 14 hours 114 hours
Indoor fluorescent lighting
(500 lux) 195 hours – – –
Note
x Actual charging time depends on environmental conditions.
