Operation Guide 3230/3232

E-9

To switch the backlight function on and off

In the Timekeeping Mode, hold down for about two seconds to switch the backlight E

function on and off. When you switch the backlight function on, an indicator appears

on the display as shown.

Backlight function on indicator

The backlight function indicator remains on the display in all modes until you switch x

the backlight function off.

The above operation controls operation of the backlight function only. It does not x

affect operation of audible tones and signals.

E-8

About the backlight

When you switch the backlight function on, the backlight of the watch ﬂ ashes

whenever alarm (page E-10), countdown timer or hourly time signal is sounding.

Pressing xD in any mode illuminates the display, regardless of the backlight’s on/

off setting.

The backlight of this watch employs an electro-luminescent (EL) light, which loses its x

illuminating power after very long term use.

Frequent use of the backlight shortens the battery life. x

The watch will emit an audible sound whenever the display is illuminated. This is x

caused by a transistor that vibrates when the EL panel lights up. It does not indicate

malfunction of the watch.

The illumination provided by the backlight may be hard to see when viewed under x

direct sunlight.

The backlight automatically stops illuminating whenever an alarm sounds. x

E-7

While any other digits (besides seconds) are selected (ﬂ ashing), press 4. to E

increase the number. Holding down changes the number at high speed.E

xTo switch between the 12-hour and 24-hour formats, press

while some

digits are ﬂ ashing.

After you set the time and date, press 5. to return to the Timekeeping Mode.A

The day of the week is automatically set in accordance with the date. x

The date can be set within the range of January 1, 2000 to December 31, 2099. x

If you do not operate any button for a few minutes while a selection is ﬂ ashing, the x

ﬂ ashing stops and the watch goes back to the Timekeeping Mode automatically.

E-6

Timekeeping

To set the time and date

Press 1. while in the Timekeeping Mode. The seconds A

digits ﬂ ash on the display because they are selected.

Press 2. to change the selection in the following C

sequence.

MinutesSeconds

Year

Hour

MonthDay

While the seconds digits are selected (ﬂ ashing), press 3. E E to reset the seconds to “00”. If you press while the

seconds count is in the range of 30 to 59, the seconds

are reset to “00” and 1 is added to the minutes. If the

seconds count is in the range of 00 to 29, the minutes

count is unchanged.

Day of week

Month

Day

Hour : Minutes Seconds

PM indicator

E-5

Press xC to change from mode to mode. After you perform an operation in any

mode, pressing returns to the Timekeeping.C

Press xD in any mode to illuminate the display. Illumination turns off about two

seconds after you release .D

StopwatchCountdown Timer

E-4

General Guide

All of the illustrations in this manual show Module 3230. x

Timekeeping Alarm

Press .C

E-3

Procedure Lookup

The following is a handy reference list of all the operational procedures contained in

this manual.

To set the time and date ......................................................................................... E-6

To switch the backlight function on and off ......................................................... E-9

To set the alarm time ............................................................................................. E-12

To stop the alarm .................................................................................................. E-13

To switch an alarm and Hourly Time Signal on and off ..................................... E-13

To set the countdown time ................................................................................... E-14

To use the countdown timer ................................................................................. E-15

To switch auto repeat timing on and off ............................................................. E-16

To measure elapsed time ...................................................................................... E-17

To record split times ............................................................................................ E-18

To time ﬁ rst and second place ﬁ nishes .............................................................. E-18

E-2

Contents

General Guide .......................................................................................................... E-4

Timekeeping ............................................................................................................. E-6

Alarm ...................................................................................................................... E-10

Countdown Timer .................................................................................................. E-14

Stopwatch ..............................................................................................................E-17

Speciﬁ cations ........................................................................................................E-19

E-1

About This Manual

Depending on the model of your watch, display text appears either as dark ﬁ gures x

on a light background or light ﬁ gures on a dark background. All sample displays in

this manual are shown using dark ﬁ gures on a light background.

Button operations are indicated using the letters shown in the illustration. x

[Module 3230] [Module 3232]

MA1010-EA

Operation Guide 3230/3232

E-19

Speciﬁ cations

Accuracy at normal temperature: ±15 seconds a month

Timekeeping: Hour, minutes, seconds, pm (P), month, day, the day of the week

Time system: Switchable between 12-hour and 24-hour formats

Calendar system: Auto-calendar pre-programmed from the year 2000 to 2099

Alarm: Multi-function alarm, hourly time signal

Countdown Timer

Measuring unit: 1 second

Input range: from 1 second to 24 hours

Other: Auto-repeat function

Stopwatch

Measuring units: 1/100 second (for the ﬁ rst 60 minutes)

1 second (after 60 minutes)

Measuring capacity: 23 hours, 59 minutes, 59 seconds

Measuring modes: Elapsed time, split time and two ﬁ nishes

Illumination: EL (electro-luminescent) backlight

E-18

To record split times

Press 1. to start the stopwatch.E

Press 2. to display the timing up to that point. Stopwatch timing continues B

internally.

Press 3. to clear the split time and to continue time measurement on the display.B

You can repeat steps 2 and 3 as many times as you want. x

Press 4. to stop the time measurement.E

Press 5. to clear the stopwatch to all zeros.B

To time ﬁ rst and second place ﬁ nishes

Press 1. to start the stopwatch.E

Press 2. when the ﬁ rst ﬁ nisher crosses the line, and record the time.B

Press 3. when the second ﬁ nisher crosses the line.E

Press 4. to display the ﬁ nishing time of the second ﬁ nisher.B

Press 5. again to clear the stopwatch to all zeros.B

E-17

Stopwatch

The Stopwatch Mode lets you measure elapsed time, split

times, and two ﬁ nishes. The range of the stopwatch is

23 hours, 59 minutes, 59 seconds.

To measure elapsed time

Press 1. to start the stopwatch.E

Press 2. to stop the stopwatch.E

You can resume the measurement operation by x

pressing again. E

Press 3. to clear the stopwatch to all zeros.B

For the ﬁ rst 60 minutes, the display shows minutes, x

seconds, and 1/100 second. After 60 minutes, the display

format changes to show hours, minutes, and seconds.

Mode indicator

Current time

Minutes

Seconds

1/100 second

E-16

To switch auto repeat timing on and off

Press 1. while in the Countdown Timer Mode. The A

hours digit ﬂ ashes on the display because it is selected.

Press 2. to switch auto repeat on and off.D

Press 3. to return to the Countdown Timer Mode.A

When the end of the countdown is reached while x

auto repeat is on, the alarm sounds, but the starting

countdown time is reset and countdown timing starts

again automatically whenever the countdown reaches

zero. You can stop timing by pressing , and manually E

reset to the starting countdown time by pressing .A

Auto repeat on indicator

E-15

After you set the countdown time, press 4. to return to the Countdown Timer A

Mode.

If you do not operate any button for a few minutes while a selection is ﬂ ashing, x

the ﬂ ashing stops and the watch goes back to the Countdown Timer Mode

automatically.

To use the countdown timer

Press 1. while in the Countdown Timer Mode to start the countdown timer.E

Press 2. again to stop the countdown timer.E

You can continue countdown timer operation by pressing xE.

Stop the timer and then press 3. until the countdown time is reset to its starting A

value.

When the end of the countdown is reached and auto repeat timing is off, the alarm x

sounds for 10 seconds or until you stop the alarm by pressing any button.

Countdown timing stops, and the countdown time is automatically reset to its starting

value after the alarm stops.

E-14

Countdown Timer

The countdown timer can be set within a range of 1 second

to 24 hours. When the countdown reaches zero, an alarm

sounds for 10 seconds or until you press any button.

To set the countdown time

Press 1. while in the Countdown Timer Mode. The A

hours digit ﬂ ashes on the display because it is selected.

Press 2. to change the selection in the following C

sequence.

SecondsHours Minutes

Press 3. to increase the selected number. Holding down changes the number E E

at high speed.

To set the starting value of the countdown time to 24 hours, set x0:00'00.

Mode indicator

Current time

Hours : Minutes Seconds

E-13

To stop the alarm

Press any button to stop the alarm after it starts to sound.

To switch an alarm and Hourly Time Signal on and off

Press while in the Alarm Mode to change the status of an alarm (see “Alarm E

Types” on page E-10) and Hourly Time Signal in the following sequence.

Both ON Both OFF Alarm Only Hourly Time

Signal only

Alarm on indicator

Hourly time signal on indicator

E-12

To set the alarm time

Press 1. while in the Alarm Mode until the hour digits start to ﬂ ash on the display. A

The hour digits ﬂ ash because they are selected.

At this time the alarm is automatically switched on. x

Press 2. to change the selection in the following sequence.C

MonthHour Minutes Day

Press 3. to increase the selected digits. Holding down changes the number at E E

high speed.

The format (12-hour and 24-hour) of the alarm time matches the format you select x

for normal timekeeping.

When setting the alarm time using the 12-hour format, take care to set the time x

correctly as morning or afternoon.

After you set the alarm time, press 4. to return to the Alarm Mode. A

If you do not operate any button for a few minutes while a selection is ﬂ ashing, the x

ﬂ ashing stops and the watch goes back to the Alarm Mode automatically.

E-11

To set a date alarm x

Set the month, day, hour and minutes for the alarm time. This type of setting causes

the alarm to sound at the speciﬁ c time, on the speciﬁ c date you set.

xTo set a 1-month alarm

Set the month, hour and minutes for the alarm time. Set “– –” for the day (see step 3

under “To set the alarm time”). This type of setting causes the alarm to sound every

day at the time you set, only during the month you set.

xTo set a monthly alarm

Set the day, hour and minutes for the alarm time. Set “–” for the month (see step 3

under “To set the alarm time”). This type of setting causes the alarm to sound every

month at the time you set, on the day you set.

E-10

Alarm

You can set an alarm with hour, minutes, month, and day.

When the alarm is on, the alarm sounds for 20 seconds

at the preset time. When the Hourly Time Signal is on, the

watch beeps every hour on the hour.

Alarm Types

The types of alarm you get depends on the information

you set.

To set a daily alarm x

Set the hour and minutes for the alarm time. Set “–” for the

month and “– –” for the day (see step 3 under “To set the

alarm time”). This type of setting causes the alarm to sound

every day at the time you set.

Mode indicator

Month

Day

Hour : Minutes

Hourly time signal on

indicator

Alarm on indicator

Operation Guide 3230/3232

E-20

Battery: One lithium battery (Type: CR2016)

Approximately 2 years on type CR2016 (assuming backlight operation

3.5 sec./day and alarm operation 20 sec./day)

Note: Frequent use of the backlight shortens the battery life noted above.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	G-Shock DW-6900SP-7ER
Färg på produkten:	Zwart
Inbyggd display:	Ja
Vikt:	750 g
Bredd:	191 mm
Djup:	89 mm
Höjd:	78 mm
Förpackningens vikt:	826 g
Förpackningens bredd:	214 mm
Djuppackning:	128 mm
Förpackningshöjd:	92 mm
Integrerad klocka:	Ja
Användarmanual:	Ja
Kraftkälla:	AC
Garantikort:	Ja
Varningssignal:	Ja
Dagordning:	Ja
Snooze-funktion:	Ja
Inbyggda högtalare:	Ja
Volymkontroll:	Draaiknop
Typ av tuner:	Analoog
Inspänning:	220 V
Väckarklocka:	Ja
Bakgrundsbelysning:	Ja
Bakgrundsbelysning-färg:	Oranje
Termometer:	Ja
Spela MP3:	Nee
Frekvensband som stöds:	AM, FM
Radio:	Klok
Apple dockningskompatibilitet:	Niet ondersteund
FM-band:	64 - 108 MHz
AC-ingångsfrekvens:	50 Hz
Strömförbrukning (typiskt):	5 W
Slaaptimer:	Ja
AM-bandintervall:	531 - 1629 kHz
Projektionsfunktion:	Tijd
