Operation Guide 3526
EN-9
To enable or disable Flash Alert
In the Timekeeping Mode, hold down for about two seconds to toggle Flash B
Alert between enabled and disabled. An indicator on the display shows when Flash
Alert is enabled.
Flash Alert indicator
x The Flash Alert indicator is shown in all modes until you disable Flash Alert.
EN-8
Backlight
The backlight illuminates the display. Enabling Flash Alert causes the backlight to
flash while the alarm (page EN-10), countdown timer alarm, or hourly time signal is
sounding.
x Pressing D at any time illuminates the display regardless of the Flash Alert
enabled/disabled setting.
x Frequent use of the backlight shortens battery life.
x Illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
x Display illumination will automatically turn off if an alarm starts to sound.
EN-7
3. While the seconds digits are selected (flashing), press to reset the seconds B
to “00”. If you press while the seconds count is in the range of 30 to 59, the B
seconds are reset to “00” and 1 is added to the minutes. If the seconds count is
in the range of 00 to 29, the minutes count is unchanged.
4. While any other digits (besides seconds) are selected (flashing), press to B
increase the number. Holding down changes the number at high speed.B
x To switch between the 12-hour and 24-hour formats, press D
D
D
D
D
while
some digits are flashing.
5. After you set the time and date, press to return to the Timekeeping Mode.A
x The day of the week is automatically set in accordance with the date.
x The date can be set within the range of January 1, 2000 to December 31, 2099.
x If you do not operate any button for a few minutes while a selection is flashing,
the flashing stops and the watch goes back to the Timekeeping Mode
automatically.
EN-6
Timekeeping
To set the time and date
1. Press while in the Timekeeping Mode. The A
seconds digits flash on the display because they
are selected.
2. Press to change the selection in the following C
sequence.
MinuteHourSecond
MonthDay
C
C
C C
C
Year
C
Day of week
Month
Day
Minute
PM indicator
Hour Second
EN-5
C
Stopwatch Mode Timer Mode
C
x After you perform an operation in any mode, pressing C returns to the
Timekeeping Mode.
x Press D in any mode to illuminate the display. Illumination turns off about two
seconds after you release D.
EN-4
General Guide
x Press C to change from mode to mode.
Timekeeping Mode Alarm Mode
CC
EN-3
Timer .............................................................................................................. EN-14
To set the countdown time .........................................................................EN-14
To use the countdown timer .......................................................................EN-15
To switch auto repeat timing on and off .....................................................EN-16
Stopwatch ...................................................................................................... EN-18
To measure elapsed time............................................................................EN-18
To record split times ..................................................................................EN-19
To time first and second place finishes.......................................................EN-19
Specifications ................................................................................................ EN-20
Operating Precautions .................................................................................. EN-23
User Maintenance ......................................................................................... EN-33
EN-2
Contents
About This Manual .......................................................................................... EN-1
General Guide .................................................................................................. EN-4
Timekeeping .................................................................................................... EN-6
To set the time and date ...............................................................................EN-6
To enable or disable Flash Alert....................................................................EN-9
Alarm .............................................................................................................. EN-10
To set the alarm time ..................................................................................EN-11
To stop the alarm .......................................................................................EN-13
To switch an alarm and Hourly Time Signal on and off ...............................EN-13
EN-1
About This Manual
x Button operations are indicated using the letters shown
in the illustration.
x Note that the product illustrations in this manual are
intended for reference only, and so the actual product
may appear somewhat different than depicted by an
illustration.
EN
ENGLISH
Congratulations upon your selection of this CASIO watch.
To ensure that this watch provides you with the years of service for which it is
designed, carefully read and follow the instructions in this manual, especially the
information under “Operating Precautions” and “User Maintenance”.
MA2304-EA © 2023 CASIO COMPUTER CO., LTD.
Operation Guide 3526
EN-19
To record split times
1. Press to start the stopwatch.B
2. Press to display the timing up to that point. Stopwatch timing continues A
internally.
3. Press A to clear the split time and to continue time measurement on the display.
x You can repeat steps 2 and 3 as many times as you want.
4. Press to stop the time measurement.B
5. Press to clear the stopwatch to all zeros.A
To time first and second place finishes
1. Press to start the stopwatch.B
2. Press when the first finisher crosses the line, and record the time.A
3. Press when the second finisher crosses the line.B
4. Press to display the finishing time of the second finisher.A
5. Press again to clear the stopwatch to all zeros.A
EN-18
Stopwatch
The Stopwatch Mode lets you measure elapsed
time, split times, and two finishes. The range of the
stopwatch is 23 hours, 59 minutes, 59 seconds.
To measure elapsed time
1. Press to start the stopwatch.B
2. Press to stop the stopwatch.B
x You can resume the measurement operation by
pressing again.B
3. Press to clear the stopwatch to all zeros.A
x For the first 60 minutes, the display shows
minutes, seconds, and 1/100 second. After
60minutes, the display format changes to show
hours, minutes, and seconds.
Minutes
1/100 second
Current time
Mode indicator
Seconds
EN-17
3. Press to return to the Timer Mode.A
x When the end of the countdown is reached while auto repeat is on, the alarm
sounds, but the starting countdown time is reset and countdown timing starts
again automatically whenever the countdown reaches zero. You can stop timing
by pressing B, and manually reset to the starting countdown time by pressing
A.
EN-16
3. Stop the timer and then press until the countdown time is reset to its starting A
value.
x When the end of the countdown is reached and auto repeat timing is off, the
alarm sounds for 10 seconds or until you stop the alarm by pressing any button.
Countdown timing stops, and the countdown time is automatically reset to its
starting value after the alarm stops.
To switch auto repeat timing on and off
1. Press while in the Timer Mode. The hours digit A
flashes on the display because it is selected.
2. Press to switch auto repeat on and off.D
Auto repeat on indicator
EN-15
3. Press to increase the selected number. Holding down changes the B B
number at high speed.
x To set the starting value of the countdown time to 24 hours, set 0:00' 00.
4. After you set the countdown time, press to return to the Timer Mode.A
x If you do not operate any button for a few minutes while a selection is flashing,
the flashing stops and the watch goes back to the Timer Mode automatically.
To use the countdown timer
1. Press while in the Timer Mode to start the countdown timer.B
2. Press again to stop the countdown timer.B
x You can continue countdown timer operation by pressing B.
EN-14
Timer
The countdown timer can be set within a range of
1second to 24 hours. When the countdown reaches
zero, an alarm sounds for 10 seconds or until you
press any button.
To set the countdown time
1. Press while in the Timer Mode. The hours digit A
flashes on the display because it is selected.
2. Press to change the selection in the following C
sequence.
MinutesHours Seconds
C C
C
Minutes
Current time
Mode indicator
Hours Seconds
EN-13
To stop the alarm
Press any button to stop the alarm after it starts to sound.
To switch an alarm and Hourly Time Signal on and off
Press while in the Alarm Mode to change the status of an alarm (see “Alarm B
Types” on page EN-10) and Hourly Time Signal in the following sequence.
Both on
Both off Alarm only
BHourly Time
Signal only
B
B B
Alarm on indicator
Hourly time signal on indicator
EN-12
2. Press to change the selection in the following sequence.C
MinuteHour
Day
C
Month
CC
C
3. Press to increase the selected digits. Holding down changes the number B B
at high speed.
x The format (12-hour and 24-hour) of the alarm time matches the format you
select for normal timekeeping.
x When setting the alarm time using the 12-hour format, take care to set the time
correctly as morning or afternoon.
4. After you set the alarm time, press to return to the Alarm Mode.A
x If you do not operate any button for a few minutes while a selection is flashing,
the flashing stops and the watch goes back to the Alarm Mode automatically.
EN-11
x To set a date alarm
Set the month, day, hour and minute for the alarm time. This type of setting causes
the alarm to sound at the specific time, on the specific date you set.
x To set a 1-month alarm
Set the month, hour and minute for the alarm time. Set “– –” for the day (see step 3
under “To set the alarm time”). This type of setting causes the alarm to sound every
day at the time you set, only during the month you set.
x To set a monthly alarm
Set the day, hour and minute for the alarm time. Set “–” for the month (see step 3
under “To set the alarm time”). This type of setting causes the alarm to sound every
month at the time you set, on the day you set.
To set the alarm time
1. Press while in the Alarm Mode until the hour digits start to flash on the A
display. The hour digits flash because they are selected.
x At this time, the alarm is automatically switched on.
EN-10
Alarm
You can set an alarm with hour, minute, month, and
day. When the alarm is on, the alarm sounds for 20
seconds at the preset time. When the Hourly Time
Signal is on, the watch beeps every hour on the hour.
Alarm Types
The types of alarm you get depends on the
information you set.
x To set a daily alarm
Set the hour and minute for the alarm time. Set “–”
for the month and “– –” for the day (see step 3 under
“To set the alarm time”). This type of setting causes
the alarm to sound every day at the time you set.
Alarm on
indicator
Mode
indicator
Month
MinuteHour
Hourly time signal on indicator
Day
Operation Guide 3526
EN-29
Storage
x If you do not plan to use your watch for a long time, thoroughly wipe it free of all
dirt, sweat, and moisture, and store it in a cool, dry place.
Resin Components
x Allowing your watch to remain in contact with other items or storing it together with
other items for long periods while it is wet can cause color on resin components
to transfer to the other items, or the color of the other items to transfer to the resin
components of your watch. Be sure to dry off your watch thoroughly before storing
it and make sure it is not in contact with other items.
x Leaving your watch where it is exposed to direct sunlight (ultraviolet rays) for long
periods or failure to clean dirt from your watch for long periods can cause it to
become discolored.
x Friction caused by certain conditions (strong external force, sustained rubbing,
impact, etc.) can cause discoloration of painted components.
x If there are printed figures on the band, strong rubbing of the printed area can
cause discoloration.
EN-28
Magnetism
x Though a digital watch normally is not affected by magnetism, very strong
magnetism (from medical equipment, etc.) should be avoided because it can cause
malfunction and damage to electronic components.
Electrostatic Charge
x Exposure to very strong electrostatic charge can cause your watch to display
the wrong time. Very strong electrostatic charge even can damage electronic
components.
x Electrostatic charge can cause the display to go blank momentarily or cause a
rainbow effect on the display.
Chemicals
x Do not allow your watch to come into contact with thinner, gasoline, solvents,
oils, or fats, or with any cleaners, adhesives, paints, medicines, or cosmetics that
contain such ingredients. Doing so can cause discoloration of or damage to the
resin case, resin band, leather, and other parts.
EN-27
Temperature
x Never leave your watch on the dashboard of a car, near a heater, or in any other
location that is subject to very high temperatures. Do not leave your watch where
it will be exposed to very low temperatures. Temperature extremes can cause your
watch to lose or gain time, to stop, or otherwise malfunction.
x Leaving your watch in an area hotter than +60°C (140°F) for long periods can lead
to problems with its LCD. The LCD may become difficult to read at temperatures
lower than 0°C (32°F) and greater than +40°C (104°F).
Impact
x Your watch is designed to withstand impact incurred during normal daily use and
during light activity such as playing catch, tennis, etc. Dropping your watch or
otherwise subjecting it to strong impact, however, can lead to malfunction. Note
that watches with shock-resistant designs (G-SHOCK, BABY-G, G-MS) can be
worn while operating a chain saw or engaging in other activities that generate
strong vibration, or while engaging in strenuous sports activities (motocross, etc.)
EN-26
Band
x Tightening the band too tightly can cause you to sweat and make it difficult for air
to pass under the band, which can lead to skin irritation. Do not fasten the band too
tightly. There should be enough room between the band and your wrist so you can
insert your finger.
x Deterioration, rust, and other conditions can cause the band to break or come off
of your watch, which in turn can cause band pins to fly out of position or to fall out.
This creates the risk of your watch falling from your wrist and becoming lost, and
also creates the risk of personal injury. Always take good care of your band and
keep it clean.
x Immediately stop using a band if you even notice any of the following: loss of band
flexibility, band cracks, band discoloration, band looseness, band connecting
pin flying or falling out, or any other abnormality. Take your watch to your original
retailer or to a CASIO service center for inspection and repair (for which you will be
charged) or to have the band replaced (for which you will be charged).
EN-25
x A trained technician will inspect your watch for proper water resistance whenever
you have its battery replaced. Battery replacement requires the use of special tools.
Always request battery replacement from your original retailer or from an authorized
CASIO service center.
x Some water-resistant watches come with fashionable leather bands. Avoid
swimming, washing, or any other activity that causes direct exposure of a leather
band to water.
x The inside surface of the watch glass may fog when the watch is exposed to a
sudden drop in temperature. No problem is indicated if the fogging clears up
relatively quickly. Sudden and extreme temperature changes (such as coming into
an air conditioned room in the summer and standing close to an air conditioner
outlet, or leaving a heated room in the winter and allowing your watch to come into
contact with snow) can cause it to take longer for glass fogging to clear up. If glass
fogging does not clear up or if you notice moisture inside of the glass, immediately
stop using your watch and take it to your original retailer or to an authorized CASIO
service center.
x Your water-resistant watch has been tested in accordance with International
Organization for Standardization regulations.
EN-24
x Watches that do not have WATER RESIST or WATER RESISTANT marked on
the back cover are not protected against the effects of sweat. Avoid using such
a watch under conditions where it will be exposed to large amounts of sweat or
moisture, or to direct splashing with water.
x Even if a watch is water resistant, note the usage precautions described below.
Such types of use reduce water resistance performance and can cause fogging of
the glass.
− Do not operate the crown or buttons while your watch is submersed in water or
wet.
− Avoid wearing your watch while in the bath.
− Do not wear your watch while in a heated swimming pool, sauna, or any other
high temperature/high humidity environment.
− Do not wear your watch while washing your hands or face, while doing
housework, or while performing any other task that involves soaps or detergents.
x After submersion in seawater, use plain water to rinse all salt and dirt from your
watch.
x To maintain water resistance, have the gaskets of your watch replaced periodically
(about once every two or three years).
EN-23
Operating Precautions
Water Resistance
x The information below applies to watches with WATER RESIST or WATER
RESISTANT marked on the back cover.
Water
Resistance
Under Daily
Use
Enhanced Water Resistance Under
Daily Use
5
Atmospheres
10
Atmospheres
20
Atmospheres
Marking On watch front or on
back cover
No
BAR mark 5BAR 10BAR 20BAR
Example of
Daily Use
Hand washing, rain Yes Yes Yes Yes
Water-related work, swimming
No Yes Yes Yes
Windsurfing No No Yes Yes
Skin diving No No Yes Yes
x
Do not use your watch for scuba diving or other types of diving that requires air tanks.
OPUM-H
EN-22
Battery:
One lithium battery (Type: CR2016)
Battery life: Approximately 3 years
Conditions:
– Alarm: Once (20 seconds)/day (with flash alert)
– Illumination: Once (3.5 seconds)/day
Specifications are subject to change without notice.
EN-21
Timer:
Countdown unit: 1 second
Countdown range: 24 hours
Setting unit: 1 second
Other: Auto-repeat function
10-second beeper when the end of the countdown is reached
Stopwatch:
Measuring units: 1/100 second (first hour); 1 second (after first hour)
Measuring capacity: 23:59’59” (24 hours)
Measurement functions: Elapsed time, cumulative elapsed time, split times, 1st and
2nd place finisher times
Other:
Auto return to Timekeeping Mode, 12/24-hour display switching, LED backlight
(Super illuminator, afterglow), Flash Alert
EN-20
Specifications
Accuracy:
±15 seconds per month average
Basic Functions:
Hour, minute, second, year, month, day, day of the week
a.m./p.m.(PM)/24-hour (24H) timekeeping
Full Auto Calendar (2000 to 2099)*
* The year is displayed only while configuring settings.
Alarm:
Setting units: month, day, hour, minute
Beeper: 20 seconds
Hourly time signal: Watch beeps every hour on the hour.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | G-shock DWE-5600 |
Behöver du hjälp?
Om du behöver hjälp med Casio G-shock DWE-5600 ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
