Sida 1/11

E-1

ENGLISH

Congratulations upon your selection of this CASIO watch.

Operation Guide 3261 3281

MO1405-EB

E-2

Warning !

• The measurement functions built into this watch are not intended for taking

measurements that require professional or industrial precision. Values

produced by this watch should be considered as reasonable representations

only.

• The Moon phase indicator that appears on the display of this watch is not

intended for navigation purposes. Always use proper instruments and

resources to obtain data for navigation purposes.

• When engaging in mountain climbing or other activities in which losing your

way can create a dangerous or life-threatening situation, always use a second

compass to confirm direction readings.

• Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any

damage or loss suffered by you or any third party arising through the use of

this product or its malfunction.

E-3

About This Manual

• Depending on the model of your watch, display text appears either as dark figures

on a light background (Module 3261), or light figures on a dark background

(Module 3281). All of the illustrations in this manual show Module 3261.

• Button operations are indicated using the letters shown in the illustration.

• Note that the product illustrations in this manual are intended for reference only,

and so the actual product may appear somewhat different than depicted by an

illustration.

Module 3261 Module 3281

E-4

Things to check before using the watch

1. Check the battery power level.

Is “ ” or “ ” displayed for the battery power indicator H M

(page E-14)?

Go to step 2.

Power is low. Charge the watch by placing it in a

location where it is exposed to light. For details,

see “Charging the Watch” (page E-12).

NO YES

YES

Does any one of the following conditions exist?

• Battery power indicator shows “

L” and “LOW” is

displayed in the upper right corner of the screen.

• “CHG” is displayed in the upper right corner of the screen.

• The face is blank.

The watch is charged

sufficiently.

For details about

charging, see

“Charging the Watch”

(page E-12).

Battery power

indicator

E-5

2. Check the Home City and the daylight saving time (DST) setting.

Use the procedure under “To configure Home City settings” (page E-26) to configure

your Home City and daylight saving time settings.

Important!

World Time Mode data depend on correct Home City, time, and date settings in the

Timekeeping Mode. Make sure you configure these settings correctly.

3. Set the current time.

See “Configuring Current Time and Date Settings” (page E-29).

The watch is now ready for use.

E-6

Contents

E-3 About This Manual

E-4 Things to check before using the watch

E-12 Charging the Watch

E-19 To recover from the sleep state

E-20 To turn Power Saving on and off

E-21 Mode Reference Guide

E-25 Timekeeping

E-26 Configuring Home City Settings

E-26 To configure Home City settings

E-28 To change the Daylight Saving Time (summer time) setting

E-7

E-29 Configuring Current Time and Date Settings

E-29 To change the current time and date settings

E-33 Digital Compass

E-34 To take a digital compass reading

E-40 To perform magnetic declination correction

E-42 To perform bidirectional calibration

E-43 To perform northerly calibration

E-46 To store a direction angle reading in Bearing Memory

E-48 To set a map and find your current location

E-50 To find the bearing to an objective

E-52 To determine the direction angle to an objective on a map and head in

that direction

E-8

E-57 Thermometer

E-57 To enter and exit the Digital Compass/Thermometer Mode

E-59 To calibrate the temperature sensor

E-61 Specifying Temperature Unit

E-61 To specify temperature unit

E-63 Temperature Reading Precautions

E-64 Using the Moon Data

E-64 To enter the Moon Data Mode

E-67 To reverse the displayed Moon phase

E-71 Checking the Current Time in a Different Time Zone

E-71 To enter the World Time Mode

E-72 To view the time in another time zone

E-72 To specify standard time or daylight saving time (DST) for a city

E-9

E-74 Using the Stopwatch

E-74 To enter the Stopwatch Mode

E-74 To perform an elapsed time operation

E-75 To pause at a split time

E-75 To measure two finishes

E-77 Using the Countdown Timer

E-77 To enter the Countdown Timer Mode

E-78 To specify the countdown start time

E-79 To perform a countdown timer operation

E-79 To stop the alarm

Operation Guide 3261 3281

E-10

E-80 Using the Alarm

E-80 To enter the Alarm Mode

E-81 To set an alarm time

E-82 To test the alarm

E-82 To turn an alarm and the Hourly Time Signal on and off

E-83 To stop the alarm

E-84 Illumination

E-84 To turn on illumination manually

E-85 To change the illumination duration

E-88 To turn the auto light switch on and off

E-91 Graphic Area

E-92 Button Operation Tone

E-93 To turn the button operation tone on and off

E-11

E-94 Troubleshooting

E-99 Specifications

E-12

Charging the Watch

The face of the watch is a solar cell that generates power from light. The generated

power charges a built-in rechargeable battery, which powers watch operations. The

watch charges whenever it is exposed to light.

Charging Guide

Whenever you are not

wearing the watch, leave it in

a location where it is exposed

to light.

• Best charging performance

is achieved by exposing the

watch to the strongest light

available.

When wearing the watch,

make sure that its face is not

blocked from light by the

sleeve of your clothing.

• The watch may enter a

sleep state (page E-18) if its

face is blocked by your

sleeve even only partially.

E-13

Warning!

Leaving the watch in bright light for charging can cause it to become quite hot.

Take care when handling the watch to avoid burn injury. The watch can become

particularly hot when exposed to the following conditions for long periods.

• On the dashboard of a car parked in direct sunlight

• Too close to an incandescent lamp

• Under direct sunlight

Important!

• Allowing the watch to become very hot can cause its liquid crystal display to black

out. The appearance of the LCD should become normal again when the watch

returns to a lower temperature.

• Turn on the watch’s Power Saving function (page E-18) and keep it in an area

normally exposed to bright light when storing it for long periods. This helps to

ensure that power does not run down.

• Storing the watch for long periods in an area where there is no light or wearing it in

such a way that it is blocked from exposure to light can cause power to run down.

Expose the watch to bright light whenever possible.

E-14

Power Levels

You can get an idea of the watch’s power level by observing the battery power

indicator on the display.

Level Battery Power

Indicator Function Status

(H) All functions enabled.

(M) All functions enabled.

(L)

Illumination, beeper, and sensor

operation disabled.

(C)

Except for the CHG (charge)

indicator, all functions and display

indicators disabled.

5 All functions disabled.

Battery power

indicator

Battery power

indicator

E-15

• The flashing LOW indicator at Level 3 (

L) tells you that battery power is very low,

and that exposure to bright light for charging is required as soon as possible.

• At Level 4 or Level 5, all functions are disabled and settings return to their initial

factory defaults. Once the battery reaches Level 2 (

M) after falling to Level 4 or

Level 5, reconfigure the current time, date, and other settings.

• If charging starts from Level 5, CHG will start flashing on the display when Level 4

is reached. Note, however, that watch functions are not restored at this time. Leave

the watch exposed to sufficiently strong light until the battery level reaches Level 2

or Level 1 before using it.

• Leaving the watch exposed to direct sunlight or some other very strong light source

can cause the battery power indicator to show a reading temporarily that is higher

than the actual battery level. The correct battery level should be indicated after a

few minutes.

• All data stored in memory is deleted, and the current time and all other settings

return to their initial factory defaults whenever battery power drops to Level 4 or

Level 5, and when you have the battery replaced.

E-16

Power Recovery Mode

• Performing multiple sensor, illumination, or beeper operations during a short period

may cause all of the battery power indicators (H,M

, and L) to start flashing on the

display. This indicates that the watch is in the power recovery mode. Illumination,

alarm, countdown timer alarm, hourly time signal, and sensor operations will be

disabled until battery power recovers.

• Battery power will recover in about 15 minutes. At this time, the battery power

indicators (H,M,L) will stop flashing. This indicates that the functions listed above

are enabled again.

• If all of the battery power indicators (

H,M,L) are flashing and the

CHG (charge)

indicator also is flashing, it means the battery level is very low. Expose the watch to

bright light as soon as possible.

• Even if battery power is at Level 1 (

H) or Level 2 (M

), the Digital Compass/

Thermometer Mode sensor may be disabled if there is not enough voltage available

to power it sufficiently. This is indicated when all of the battery power indicators (

M,L) are flashing.

• Frequent flashing of all of the battery power indicators (

H,M,L) probably means

that remaining battery power is low. Leave the watch in bright light to allow it to

charge.

E-17

Charging Times

Exposure Level

(Brightness)

Daily

Operation

Level Change *2

Level 5 Level 4 Level 3 Level 2 Level 1

Outdoor sunlight

(50,000 lux) 5 min. 2 hours 16 hours 5 hours

Sunlight through a window

(10,000 lux) 24 min. 6 hours 79 hours 21 hours

Daylight through a window

on a cloudy day (5,000 lux) 48 min. 12 hours

159 hours

43 hours

Indoor fluorescent lighting

(500 lux) 8 hours 168 hours – – – – – –

*1 Approximate amount of exposure time required each day to generate enough

power for normal daily operation.

*2 Approximate amount of exposure time (in hours) required to take power from one

level to the next.

E-18

• The above exposure times all are for reference only. Actual exposure times depend

on lighting conditions.

• For details about the operating time and daily operating conditions, see the “Power

Supply” section of the Specifications (page E-101).

Power Saving

When turned on, Power Saving enters a sleep state automatically whenever the watch

is left for a certain period in an area where it is dark. The table below shows how

watch functions are affected by Power Saving.

• There actually are two sleep state levels: “display sleep” and “function sleep”.

Elapsed Time in Dark Display Operation

60 to 70 minutes

(display sleep) Blank, with PS flashing Display is off, but all functions are

enabled.

6 or 7 days

(function sleep) Blank, with PS not flashing All functions are disabled, but

timekeeping is maintained.

E-19

• The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is

already in a sleep state when 6:00 AM arrives, however, it will remain in the sleep

state.

• The watch will not enter a sleep state while it is in the Stopwatch Mode or

Countdown Timer Mode.

To recover from the sleep state

Move the watch to a well-lit area, press any button, or angle the watch towards your

face for reading (page E-86).

Operation Guide 3261 3281

E-20

To turn Power Saving on and off

1. In the Timekeeping Mode, hold down A until SET

starts to flash and the city name starts to scroll on the

display.

• This is the setting screen.

2. Use D to display the Power Saving On/Off screen

shown nearby.

3. Press E to toggle Power Saving on (On) and off (OFF).

4. Press A to exit the setting screen.

• The Power Saving on indicator (PS) is on the display

in all modes while Power Saving is turned on.

Power saving

on indicator

Power saving

on indicator

E-21

Mode Reference Guide

Your watch has 7 “modes”. The mode you should select depends on what you want to do.

To do this: Enter this mode: See:

• View the current date in the Home City

• Configure Home City and daylight saving time (DST) settings

• Configure time and date settings

Timekeeping Mode E-25

•

Determine your current bearing or the direction from your current

location to a destination as a direction indicator and angle value

• Determine your current location using the watch and a map

Digital Compass/

Thermometer Mode E-33

• View the temperature at your current location Digital Compass/

Thermometer Mode E-57

View the current time in one of 48 cities (31 time zones) around the globe

World Time Mode E-71

Use the stopwatch to measure elapsed time Stopwatch Mode E-74

Use the countdown timer

Countdown Timer Mode

E-77

Set an alarm time Alarm Mode E-80

E-22

Selecting a Mode

World Time Mode

Stopwatch Mode

Moon Data Mode

Countdown Timer

Mode

Alarm Mode

Timekeeping Mode

World Time Mode

Stopwatch Mode

Moon Data Mode

Countdown Timer

Mode

Alarm Mode

Timekeeping Mode

E-23

Digital Compass/

Thermometer Mode

Press

Digital Compass/

Thermometer Mode

Press

• The illustration below shows which buttons you need to press to navigate between

modes.

• Press D to change from mode to mode.

• Hold down D for about two seconds to return to the Timekeeping Mode from any

other mode.

• In any mode, press C to enter the Digital Compass/Thermometer Mode. Press

in the Digital Compass/Thermometer Mode to return to the mode you entered from.

• In any mode (except when a setting screen is on the display), press

B to illuminate

the display.

E-24

General Functions (All Modes)

The functions and operations described in this section can be used in all of the modes.

Auto Return Features

• The watch returns to the Timekeeping Mode automatically if you do not perform any

button operation for two or three minutes in the Alarm, or Moon Data Mode.

• If you leave a screen with flashing digits on the display for two or three minutes

without performing any operation, the watch exits the setting screen automatically.

Initial Screens

When you enter the World Time or Alarm Mode, the data you were viewing when you

last exited the mode appears first.

Scrolling

The E and B buttons are used on the setting screen to scroll through data on the

display. In most cases, holding down these buttons during a scroll operation scrolls

through the data at high speed.

E-25

Timekeeping

Use the Timekeeping Mode to set and view the current time and date.

• Press A to toggle between the day of the week and date (Date screen), and the

currently selected World Time (Dual Time).

Day of week

Month – Day Dual time

PM indicator

Hour : Minutes Seconds

Date Screen Dual Time Screen

E-26

Configuring Home City Settings

There are two Home City settings: actually selecting the

Home City and selecting either standard time or daylight

saving time (DST).

To configure Home City settings

1. In the Timekeeping Mode, hold down A until SET

starts to flash and the city name starts to scroll on the

display.

• This is the setting screen.

• The watch will exit the setting mode automatically if

you do not perform any operation for about two or

three minutes.

• For details about city names, see the “City Code

Table” at the back of this manual.

PM indicator

City name

Seconds

Hour : Minutes

PM indicator

City name

Seconds

Hour : Minutes

E-27

2. Press E (East) and B (West) to select the city name you want to use as your

Home City.

• Keep pressing E or

B until the city name you want to select as your Home

City appears on the display.

3. Press D to display the DST setting screen.

4. Use E to toggle the DST settings between OFF and On.

• Note that you cannot switch between standard time and daylight saving time

(DST) while UTC is selected as your Home City.

5. After all the settings are the way you want, press

A to return to the Timekeeping

Mode.

• The DST indicator appears to indicate that Daylight Saving Time is turned on.

Note

• After you specify a city name, the watch will use UTC* offsets in the World Time

Mode to calculate the current time for other time zones based on the current

time in your Home City.

* Coordinated Universal Time, the world-wide scientific standard of timekeeping.

The reference point for UTC is Greenwich, England.

E-28

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down A until SET

starts to flash and the city name starts to scroll on the

display.

• This is the setting screen.

2. Press D to display the DST setting screen.

3. Use E to toggle the DST settings between OFF and

On.

4. After all the settings are the way you want, press

A to

return to the Timekeeping Mode.

• The DST indicator appears to indicate that Daylight

Saving Time is turned on.

E-29

Configuring Current Time and Date Settings

You can use the procedure below to adjust the Timekeeping Mode time and date

settings if they are off.

To change the current time and date settings

1. In the Timekeeping Mode, hold down A until SET

starts to flash and the city name starts to scroll on the

display.

• This is the setting screen.

2. Use E and B to select the city name you want.

• Select your Home City name before changing any

other setting.

• For full information on city names, see the “City

Code Table” at the back of this manual.

PM indicator

City name

Seconds

Hour : Minutes

PM indicator

City name

Seconds

Hour : Minutes

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	G-Shock G-9300

Behöver du hjälp?

Om du behöver hjälp med Casio G-Shock G-9300 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
