Sida 1/7
Operation Guide 5535
E-9
To do t his: Enter t his mode: See:
Display a second time
Configure settings for a second time Dual Time Mode E-48
E-8
Mode Reference Guide
The mode you should select depends on what you want to do.
To do t his: Enter t his mode: See:
View the current time and date
Configure daylight saving time (DST) settings
Configure time and date settings
Start elapsed time measurement with a single
button press
Timekeeping Mode
E-16
E-17
E-25
Measure elapsed time
Record lap times (up to 120) Stopwatch Mode E-22
View data recorded in the Stopwatch Mode Data Recall Mode E-32
Use the countdown timer Countdown Timer Mode E-40
Set an alarm time
To turn an alarm or the hourly time signal on or off Alarm Mode E-43
E-7
To turn the auto light switch on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-55
Adjusting Hand Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-58
To adjust hand alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-59
Button Operation Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-61
To turn the button operation tone on and off . . . . . . . . . . . . . . . . . . . . . . . . . E-61
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-62
Main Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-63
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-64
Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-67
User Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-78
E-6
Using the Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-43
To enter the Alarm Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-43
To set an alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-44
To test the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-45
To turn an alarm and the Hourly Time Signal on and off . . . . . . . . . . . . . . . . . E-46
To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-47
Dual Time Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
To enter the Dual Time Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
To set the Dual Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
To swap Timekeeping Mode and Dual Time Mode times . . . . . . . . . . . . . . . . E-50
Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-51
To turn on illumination manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-51
To change the illumination duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-52
E-5
To perform an elapsed time operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-26
To perform lap time measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-26
Viewing Lap Time Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-32
To enter the Data Recall Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33
To select a desired date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33
To delete a session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-37
Countdown Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-40
To enter the Countdown Timer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-40
To configure the countdown timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-41
To perform a countdown timer operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-42
To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-42
E-4
Contents
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3
Mode Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-8
Timekeeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-16
Adjusting the Digital Time and Date Settings . . . . . . . . . . . . . . . . . . . . . . . . . E-17
To configure the digital time and date settings . . . . . . . . . . . . . . . . . . . . . . . . E-17
To change the Daylight Saving Time (summer time) setting . . . . . . . . . . . . . . E-21
Using the Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-22
To enter the Stopwatch Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-24
E-3
Features
Your watch provides you with the features and functions described below.
◆ Stopwatch ..................... Page E-22
Use the stopwatch to measure
elapsed times and lap times. Elapsed
time measurement can be started
with a single button press from the
Timekeeping Mode. Memory for up to
120 lap time records.
◆ Timer .............................. Page E-40
The timer counts down from a preset
start time. An alarm sounds when the
end of the countdown is reached.
◆ Alarm .............................. Page E-43
When the alarm time is reached, the
watch sounds an alert.
◆ Dual time ....................... Page E-48
You can view the current time in your
current location and in one more time
zone.
E-2
About This Manual
Depending on the model of your watch, display text
appears either as dark figures on a light background, or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
Button operations are indicated using the letters shown in
the illustration.
Note that the product illustrations in this manual are
intended for reference only, and so the actual product may
appear somewhat different than depicted by an illustration.
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
To ensure that this watch provides you with the years of service for which it is
designed, carefully read and follow the instructions in this manual, especially the
information under “Operating Precautions” and “User Maintenance”.
Be sure to keep all user documentation handy for future reference.
MA1710-EB
© 2017 CASIO COMPUTER CO., LTD.
Operation Guide 5535
E-19
3. When the timekeeping setting you want to change is flashing, use and/or D B
to change it as described below.
Screen To do this: Do this:
Reset the seconds to 00 Press D.
Toggle between 12-hour ( ) and 24-hour 12H
(24H) timekeeping Press D.
Change the hour or minute Use (+) and (–).D B
Change the year Use (+) and (–).D B
Change the month or day Use (+) and (–).D B
4. Press to exit the setting mode.A
E-18
2. Press to move the flashing in the sequence shown below to select the other C
settings.
Seconds
CDST
(page E-21)
C
12/24-Hour Format
C
Hour
C C
Illumination Duration
(page E-51) Minutes
C C
Button Operation Tone On/Off
(page E-61) C
Day
C
Month
C
Year
E-17
Adjusting the Digital Time and Date Settings
Use the procedure below to adjust the digital time and date settings.
To configure the digital time and date settings
1. In the Timekeeping Mode, hold down until the A
seconds digits start to flash (about two seconds).
x This enables setting of the seconds.
E-16
Timekeeping
Use the Timekeeping Mode to set and view the current
time and date.
x Press A to toggle the digital display between date/day
of the week and hour/minutes/seconds.
Date,
day of the week Hour, minute, second
A
PM indicator
Hour
Minutes
Day of the week
Month-Day
Seconds
E-15
2. Holding down again as you press will cause the hands to return to their L C
normal positions (normal timekeeping).
Note
x This operation can be performed in any mode. In the case of a setting mode
(setting flashing on the screen), the hour and minute hands will move out of the
way, and the second hand will move to 12 o’clock automatically even if you do not
perform the above operation.
x Watch button functions are the same regardless of whether the hands are move
out of the way or at their normal positions.
x Changing to another mode will cause the hands to move back to their normal
positions.
x The hands also will move back to their normal positions automatically if no
operation is performed for about one hour.
E-14
Moving the Hands Out of the Way for Better Viewing
You can use the procedure below to temporarily move the hour and minute hands
out of the way to better view what is on the display.
1. While holding down , press L C.
x The watch will beep twice and the hour and minute hands will move to a position
where they do not block the digital display.
Example: When the current time is 8:25
Flashes while the hands are
moved out of the way.
E-13
x Scrolling
The and buttons are used on the setting mode to scroll through data on the B D
display. In most cases, holding down these buttons during a scroll operation scrolls
through the data at high speed.
E-12
x In the Timekeeping Mode, press to enter the Stopwatch Mode.D
x For more information about using the Stopwatch Mode, see “To enter the
Stopwatch Mode” (page E-24).
General Functions (All Modes)
The functions and operations described in this section can be used in all of the
modes.
x Auto Return Features
If you do not perform any operation for two or three minutes while configuring time
or other settings (with a setting flashing), or while adjusting hand positions (page E-58),
the watch will automatically exit the setting or adjustment mode.
The watch will automatically return to the Timekeeping Mode if you do not perform
any operation for a certain amount of time, as described below.
Mode Approximate Elapsed Time
Alarm 3 minutes
Data Recall 3 minutes
E-11
x To return to the Timekeeping Mode from any other mode, hold down C for about
two seconds.
x In any mode (except a setting mode), press to illuminate the display.B
Countdown Timer Mode Alarm Mode Dual Time Mode
C
C C
E-10
Selecting a Mode
x Press C to cycle between the modes as shown below.
Timekeeping Mode Data Recall Mode Stopwatch Mode
C C C
Operation Guide 5535
E-29
Memory
The watch has enough memory to hold up to 121records for session start
information (date and time), and lap time records. You can record up to 120lap
times.
x Session start information (date and time) requires one record for each session. A
session is from the start of measurement up the point the stopwatch is reset.
x Each lap time uses one record.
Example 1: Single session (from start to reset)
Start information (date and time) record + 120lap time records =
121records in total
Example 2: Multiple sessions
Session 1: Start information (date and time) record + 60lap time
records = 61records
Session 2: Start information (date and time) record + 59lap time
records = 60records
Total: 121records
E-28
Note
x The watch will exit the lap time screen automatically after about eight seconds.
x An ongoing elapsed time measurement operation will continue internally even if
you change to another mode. However, if you exit the Stopwatch Mode while a
lap time is displayed, the lap time will not be displayed when you return to the
Stopwatch Mode.
E-27
LAP indicator
LAP time
x Each press of B records the current lap time. Memory can hold up to 120lap
time records.
x Recording a lap time while there are 120records in memory will automatically
delete the oldest record to make room for the new one.
x The final lap time (time displayed when the elapsed time operation is stopped) is
recorded in memory when the stopwatch is reset to all zeros.
E-26
Entering from Another Mode (including the Timekeeping Mode)
Use to select the Stopwatch Mode as shown on page E-10.C
x To enter from the Timekeeping Mode using this method, press once.C
x This will display the stopwatch screen in the same status as it was the last time you
exited the Stopwatch Mode.
To perform an elapsed time operation
D D D D B
Start Stop (Resume) (Stop) Reset
To perform lap time measurement
D B B . . . . . . D B
Start Lap (LAP1) Lap (LAP2) Stop Reset
E-25
Entering Directly from the Timekeeping Mode
If the stopwatch was reset to all zeros the last time you used it, a new elapsed time
operation will start as soon as you enter the Stopwatch Mode.
See page E-26 for information about measuring an elapsed time.
1. In the Timekeeping Mode, press D.
This will result in one of the following, depending on the status of the stopwatch the
last time you exited the Stopwatch Mode.
x Stopwatch reset: Timing starts.
One-press timing start from the Timekeeping Mode (direct timing start from the
Timekeeping Mode).
x If an ongoing timing operation is paused: Timing remains paused.
x If an ongoing timing operation is in progress*: Timing continues to be performed.
* An ongoing stopwatch timing operation continues even if you navigate to
another mode from the Stopwatch Mode.
2. Now you can perform the same operations as those shown on page E-26.
E-24
What is a lap time?
A lap time is the time elapsed over a specific segment of a race.
Example: Car race on an oval track
Start Lap 1
Lap 2
Lap 3
To enter the Stopwatch Mode
You can enter the Stopwatch Mode using any one of the methods below.
E-23
Time Range Display Switching
Whenever the elapsed time exceeds 1 hour, the measurement changes from
1/100-second units to 1-second units.
Seconds Minutes
Minutes Hour
1/100 seconds Seconds
E-22
Using the Stopwatch
The stopwatch measures elapsed time and lap times. Up
to 120lap times can be stored in memory.
x The measurement range of the stopwatch is 23hours,
59minutes, 59seconds. When the measurement range
is exceeded, measurement stops (display becomes0).
Seconds
Minutes
Measurement
in progress
1/100 seconds
E-21
To change the Daylight Saving Time (summer time) setting
1. In the Timekeeping Mode, hold down until the A
seconds digits start to flash (about two seconds).
x This enables setting of the seconds.
2. Press to display the DST setting mode.C
3. Press to toggle between Daylight Saving Time (DON)
and Standard Time ( ).OFF
4. After the setting is the way you want, press toA
return to the Timekeeping Mode.
x The DST indicator appears to indicate that Daylight
Saving Time is turned on.
Note
x Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
DST indicator
E-20
Note
x Resetting the seconds to 00 while the current count is in the range of 30 to
59causes the minutes to be increased by 1.
x The watch’s built-in full automatic calendar makes allowances for different month
lengths and leap years. Once you set the date, there should be no reason to
change it except after you have the watch’s battery replaced.
x The day of the week changes automatically when the date changes.
x While the 12-hour format is selected for timekeeping, a (PM) indicator will appear P
for times from noon to 11:59 p.m. No indicator appears for times from midnight to
11:59 a.m. With 24-hour format, time is displayed from 0:00 to 23:59, without any
P (PM) indicator.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | G-Shock GA-810B-1A4ER |
Behöver du hjälp?
Om du behöver hjälp med Casio G-Shock GA-810B-1A4ER ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
