Sida 1/8
Operation Guide 5445/5525
E-9
Using the Alarm ................................................................................................E-45
To enter the Alarm Mode .............................................................................. E-45
To set an alarm time ..................................................................................... E-46
To test the alarm ........................................................................................... E-47
To turn an alarm and the Hourly Time Signal on and off ............................... E-48
To stop the alarm .......................................................................................... E-48
Illumination ....................................................................................................... E-50
To turn on illumination manually ................................................................... E-50
To change the illumination duration .............................................................. E-51
To turn the auto light switch on and off ........................................................ E-54
Hand Home Position Adjustment .................................................................... E-57
To adjust home positions manually ............................................................... E-57
Moving the Hands for Easy Viewing of the Digital Dials ...............................E-60
To move the hands to view a digital dial ....................................................... E-61
To return the hands to their normal positions ............................................... E-62
E-8
Using the World Time Mode ............................................................................ E-36
To enter the World Time Mode ..................................................................... E-36
To view the time in another time zone .......................................................... E-36
To specify standard time or daylight saving time (DST) for a city ................. E-37
To swap your Home Time and World Time Cities ......................................... E-38
Using the Stopwatch .......................................................................................E-39
To enter the Stopwatch Mode ...................................................................... E-39
To perform an elapsed time operation .......................................................... E-40
To pause at a split time ................................................................................. E-40
To measure two finishes ............................................................................... E-40
Using the Countdown Timer ........................................................................... E-42
To enter the Countdown Timer Mode ........................................................... E-42
To specify the countdown start time ............................................................ E-42
To perform a countdown timer operation ..................................................... E-44
To stop the alarm .......................................................................................... E-44
E-7
Contents
About This Manual ............................................................................................. E-2
Things to check before using the watch ..........................................................E-4
Charging the Watch .........................................................................................E-11
To recover from the sleep state .................................................................... E-20
Mode Reference Guide .................................................................................... E-21
Timekeeping ..................................................................................................... E-25
Configuring Home City Settings .....................................................................E-26
To configure Home City settings .................................................................. E-26
To change the Daylight Saving Time (summer time) setting ......................... E-29
Configuring Current Time and Date Settings................................................. E-31
To change the current time and date settings .............................................. E-31
E-6
2. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under “To configure Home City settings” (page E-26) to configure
your Home City and daylight saving time settings.
Important!
x Proper World Time Mode data depends on correct Home City, time, and date
settings in the Timekeeping Mode. Make sure you configure these settings
correctly.
3. Set the current time.
x To set the time
See “Configuring Current Time and Date Settings” (page E-31).
The watch is now ready for use.
E-5
Go to step 2.
The watch is charged.
For details about charging, see “Charging the Watch” (page E-11).
Power is low. Charge the watch by placing it in a location where it is exposed to
light. For details, see “Charging the Watch” (page E-11).
NEXT
E-4
Things to check before using the watch
1. Check the battery power level.
Is or indicated as the battery power indicator (page E-15)?H M
Battery power
indicator
YES
NO
E-3
x Note that the product illustrations in this manual are intended for reference only,
and so the actual product may appear somewhat different than depicted by an
illustration.
E-2
About This Manual
x The operational procedures for Modules 5445 and 5525 are identical. All of the
illustrations in this manual show Module 5445.
x Depending on the model of your watch, display text appears either as dark figures
on a light background, or light figures on a dark background. All examples in this
manual are shown using dark figures on a light background.
x Button operations are indicated using the letters shown in the illustration.
Module 5445 Module 5525
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
MA1702-EA © 2015 CASIO COMPUTER CO., LTD.
Operation Guide 5445/5525
E-19
x The above exposure times all are for reference only. Actual exposure times depend
on lighting conditions.
x For details about the operating time and daily operating conditions, see the “Power
Supply” (page E-70) section of the Specifications.
Power Saving
When turned on, Power Saving enters a sleep state automatically whenever the
watch is left for a certain period in an area where it is dark. The table below shows
how watch functions are affected by Power Saving.
x For information about enabling and disabling power saving, see “To turn Power
Saving on and off” (page E-65).
x There actually are two sleep state levels: “display sleep” and “function sleep”.
E-18
Charging Times
Exposure Level
(Brightness)
Daily
Operation
*1
Level Change *2
Level 5 Level 4 Level 3 Level 2 Level 1
Outdoor sunlight
(50,000 lux) 8 min. 3 hours *3, *4 27 hours *3
29 hours *4
8 hours
*3, *4
Window sunlight
(10,000 lux) 30 min. 8 hours *3
9 hours *4
102 hours *3
108 hours *4
28 hours *3
29 hours *4
Window sunlight on
cloudy day (5,000 lux) 48 min. 13 hours *3, *4
165 hours *3
174 hours *4
44 hours *3
47 hours *4
Indoor fluorescent
lighting (500 lux) 8 hours 181 hours *3
185 hours *4 – – – – – –
*1 Approximate exposure each day to generate power for normal daily operation.
*2 Approximate exposure time (in hours) required to take power up one level.
*3 Module 5445
*4 Module 5525
E-17
Power Recovery Mode
x Performing multiple illumination, beeper, and/or high-speed hand movement
operation during a short period may cause all of the battery power indicators (H,
M L, and ) to start flashing in the lower digital dial. This indicates that the watch is in
the power recovery mode. Illumination, alarm, countdown timer alarm, and hourly
time signal operations will be disabled until battery power recovers.
x Battery power will recover in about 15 minutes. At this time, the battery power
indicators ( , , ) will stop flashing. This indicates that the functions listed aboveH M L
are enabled again.
x If all of the battery power indicators ( , , ) are flashing and the (charge)H M L CHG
message also is flashing, it means the battery level is very low. Expose the watch
to bright light as soon as possible.
x Frequent flashing of all of the battery power indicators ( , , ) probably meansH M L
that remaining battery power is low. Leave the watch in bright light to allow it to
charge.
E-16
x At Level 5, all functions are disabled and settings return to their initial factory
defaults. Once the battery reaches Level 2 ( ) after falling to Level 5, reconfigure M
the current time, date, and other settings.
x Display indicators reappear as soon as the battery is charged from Level 5 to
Level 2 ( ).M
x Leaving the watch exposed to direct sunlight or some other very strong light
source can cause the battery power indicator to show a reading temporarily that
is higher than the actual battery level. The correct battery level should be indicated
after a few minutes.
x The current time and all other settings return to their initial factory defaults
whenever battery power drops to Level 5 and when you have the battery replaced.
E-15
Level
Battery Power Indicator
Function Status
1
(H) All functions enabled.
2
(M) All functions enabled.
3
(L and
LOW)
Illumination and beeper disabled.
Except for Timekeeping Mode, all other modes
disabled.
4
(CHG)
All functions and display indicators disabled except
for timekeeping and display of (charge) in the CHG
lower digital dial.
Hour and minute hands stopped at 12 o’clock.
5 All functions disabled.
x The flashing message at Level 3 ( ) tells you that battery power is very low, LOW L
and that exposure to bright light for charging is required as soon as possible.
E-14
Power Levels
You can get an idea of the watch’s power level by observing the battery power
indicator in the lower digital dial.
Battery power indicator
E-13
Important!
x Allowing the watch to become very hot can cause the digital displays to black out.
The appearance of the LCD should become normal again when the watch returns
to a lower temperature.
x Turn on the watch’s Power Saving function (page E-19) and keep it in an area normally
exposed to bright light when storing it for long periods. This helps to ensure that
power does not run down.
x Storing the watch for long periods in an area where there is no light or wearing it in
such a way that it is blocked from exposure to light can cause power to run down.
Expose the watch to bright light whenever possible.
E-12
Warning!
Leaving the watch in bright light for charging can cause it to become quite
hot. Take care when handling the watch to avoid burn injury. The watch can
become particularly hot when exposed to the following conditions for long
periods.
x On the dashboard of a car parked in direct sunlight
x Too close to an incandescent lamp
x Under direct sunlight
E-11
Charging the Watch
The face of the watch is a solar panel that generates power from light. The
generated power charges a built-in rechargeable battery, which powers watch
operations. The watch charges whenever it is exposed to light.
Charging Guide
Whenever you are not
wearing the watch, leave
it in a location where it is
exposed to light.
x Best charging
performance is achieved
by exposing the watch
to the strongest light
available.
When wearing the watch,
make sure that its face is
not blocked from light by
the sleeve of your clothing.
x The watch may enter a
sleep state (page E-19) if its
face is blocked by your
sleeve even only partially.
E-10
Other Settings .................................................................................................. E-63
To turn the button operation tone on and off ................................................ E-63
To turn Power Saving on and off .................................................................. E-65
Troubleshooting ............................................................................................... E-67
Specifications ................................................................................................... E-69
Operation Guide 5445/5525
E-29
To change the Daylight Saving Time (summer time) setting
1. In the Timekeeping Mode, hold down for about A
two seconds until appears in the right digital dial. ADJ
When you release , the city code and city name will A
scroll across the right digital dial. This is the setting
mode.
x Whenever you enter a setting mode, the analog hands
will automatically move to positions that allow easier
viewing of the digital dials. This is the setting mode.
2. Press to enter the DST setting mode.C
3. Press to toggle the DST setting between Daylight D
Saving Time ( ) and Standard Time ( ).ON OFF
DST indicator
E-28
5. After the setting is the way you want, press to return to the Timekeeping A
Mode.
x The indicator appears to indicate that Daylight Saving Time is turned on.DST
x Exiting a setting mode will normally cause the hands to return to regular
timekeeping automatically. However, if you manually move the hands (page
E-61) and then enter a setting mode, they will not return to regular timekeeping
automatically when you exit the setting mode. In this case, you will need to
return the hands to their normal positions manually (page E-62).
Note
x After you specify a city code, the watch will use UTC* offsets in the World Time
Mode to calculate the current time for other time zones based on the current time
in your Home City.
* Coordinated Universal Time, the world-wide scientific standard of timekeeping.
The reference point for UTC is Greenwich, England.
E-27
2. Use (East) and (West) to scroll through the city D B
codes in the right digital dial until the one you want to
use as your Home City is displayed.
3. Press so the DST indicator is flashing in the left C
digital dial, which indicates the DST setting mode.
4. Press to toggle the DST setting between Daylight D
Saving Time ( ) and Standard Time ( ) in the right ON OFF
digital dial.
x Note that you cannot switch between standard time
and daylight saving time (DST) while UTC is selected
as your Home City.
DST indicator
E-26
Configuring Home City Settings
There are two Home City settings: actually selecting the Home City, and selecting
either standard time or daylight saving time (DST).
To configure Home City settings
1. In the Timekeeping Mode, hold down for about A
two seconds until appears in the right digital dial. ADJ
When you release , the city code and city name will A
scroll across the right digital dial. This is the setting
mode.
x The watch will exit the setting mode automatically if
you do not perform any operation for about two or
three minutes.
x For details about city codes, see the “City Code Table” at the back of this
manual.
x Whenever you enter a setting mode, the analog hands will automatically move to
positions that allow easier viewing of the digital dials.
City code
E-25
Timekeeping
Use the Timekeeping Mode to set and view the current
time and date.
x When viewing a digital dial, you can move the analog
hands for an unobstructed view.
x Press A to toggle the left digital dial between month/
day and hour/minutes.
A
Hour
Minutes
Day of week
Seconds
Month Day
E-24
General Functions (All Modes)
The functions and operations described in this section can be used in all of the
modes.
Auto Return Features
x The watch returns to the Timekeeping Mode automatically if you do not perform
any button operation for two or three minutes in the Alarm Mode.
x If you leave the watch in a setting mode (with flashing digits) for two or three
minutes without performing any operation, the watch will exit the setting mode
automatically.
Initial Screens
When you enter the World Time or Alarm Mode, the data you were viewing when
you last exited the mode appears first.
Scrolling
The and buttons are used in the setting mode to scroll through data. In most B D
cases, holding down these buttons during a scroll operation scrolls through the
data at high speed.
E-23
Countdown Timer Mode
C
Alarm Mode Stopwatch Mode
C C
E-22
Selecting a Mode
x The illustration below shows which buttons you need to press to navigate between
modes.
x To return to the Timekeeping Mode from any other mode, hold down for atC
least four seconds.
Timekeeping Mode World Time Mode
C C
E-21
Mode Reference Guide
Your watch has “five modes”. The mode you should select depends on what you
want to do.
To do this: Enter this mode: See:
x View the current date in the Home City
x Configure Home City and daylight saving time (DST)
settings
x Configure time and date settings
x Switch between 12-hour and 24-hour timekeeping
x Display an alarm countdown
Timekeeping Mode E-25
View the current time in one of 48 cities (31 time zones)
around the globe World Time Mode E-36
Use the stopwatch to measure elapsed time Stopwatch Mode E-39
Use the countdown timer Countdown Timer Mode E-42
Set an alarm time Alarm Mode E-45
E-20
Elapsed Time in Dark Digital Dials Operation
60 to 70 minutes (display sleep) Blank Digital dials are off, but all functions
are enabled.
6 or 7 days (function sleep) Blank
Hour and minute hands stop at
12o’clock. All functions are disabled,
but timekeeping is maintained.
x The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch
is already in a sleep state when 6:00 AM arrives, however, it will remain in the sleep
state.
x The watch will not enter a sleep state while it is in the Stopwatch Mode or
Countdown Timer Mode.
To recover from the sleep state
Move the watch to a well-lit area or press any button.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | G-Shock GST-S310 |
Behöver du hjälp?
Om du behöver hjälp med Casio G-Shock GST-S310 ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
