Operation Guide 5580

E-9

Configuring Home City Settings ……………………………………………………E-42

To configure Home City settings ………………………………………………E-42

To change the Daylight Saving Time (summer time) setting ………………E-45

Configuring Current Time and Date Settings Manually …………………………E-48

To change the current time and date settings manually ……………………E-48

Using the World Time Mode …………………………………………………………E-53

To enter the World Time Mode ………………………………………………E-53

To view the time in another time zone ………………………………………E-53

To specify standard time or daylight saving time (DST) for a city …………E-54

To swap your Home Time and World Time Cities …………………………E-55

Using the Stopwatch …………………………………………………………………E-57

To enter the Stopwatch Mode …………………………………………………E-57

To perform an elapsed time operation ………………………………………E-58

To pause at a split time …………………………………………………………E-58

To measure two finishes ………………………………………………………E-58

E-8

Contents

About This Manual …………………………………………………………………… E-2

Things to check before using the watch ………………………………………… E-4

Charging the Watch ……………………………………………………………………E-12

To recover from the sleep state ………………………………………………E-20

Radio Controlled Atomic Timekeeping ……………………………………………E-21

To get ready for a receive operation …………………………………………E-26

To perform manual receive ……………………………………………………E-29

To check the latest signal reception results …………………………………E-33

To turn auto receive on and off ………………………………………………E-34

Mode Reference Guide ………………………………………………………………E-37

Timekeeping ……………………………………………………………………………E-41

E-7

The watch is now ready for use.

• For details about the watch’s radio controlled timekeeping feature, see “Radio

Controlled Atomic Timekeeping” (page E-21).

E-6

2. Check the Home City and the daylight saving time (DST) setting.

Use the procedure under “To configure Home City settings” (page E-42) to configure your

Home City and daylight saving time settings.

Important!

• Proper time calibration signal reception and World Time Mode data depend on

correct Home City, time, and date settings in the Timekeeping Mode. Make sure

you configure these settings correctly.

3. Set the current time.

• To set the time using a time calibration signal

See “To get ready for a receive operation” (page E-26).

• To set the time manually

See “Configuring Current Time and Date Settings Manually” (page E-48).

E-5

Go to step 2.

The watch is charged.

For details about charging, see “Charging the Watch” (page E-12).

Power is low.

Charge the watch by placing it in a location where it is exposed to

light. For details, see “Charging the Watch” (page E-12).

E-4

Things to check before using the watch

1. Check the battery power level.

Is H or M

indicated as the battery power indicator (page E-15)?

Battery power

indicator

YES

E-3

• Note that the product illustrations in this manual are intended for reference only,

and so the actual product may appear somewhat different than depicted by an

illustration.

E-2

About This Manual

• Depending on the model of your watch, display text appears either as dark figures

on a light background, or light figures on a dark background. All examples in this

manual are shown using dark figures on a light background.

• Button operations are indicated using the letters shown in the illustration.

E-1

ENGLISH

Congratulations upon your selection of this CASIO watch.

To ensure that this watch provides you with the years of service for which it is

designed, carefully read and follow the instructions in this manual, especially the

information under “Operating Precautions” and “User Maintenance”.

Keep all user documentation handy for future reference.

Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage

or loss suffered by you or any third party arising through the use of your watch or its

malfunction.

Operation Guide 5580

E-19

• The above exposure times all are for reference only. Actual exposure times depend

on lighting conditions.

• For details about the operating time and daily operating conditions, see the “Power

Supply” (page E-95) section of the Specifications.

Power Saving

When turned on, Power Saving enters a sleep state automatically whenever the watch

is left for a certain period in an area where it is dark. The table below shows how

watch functions are affected by Power Saving.

• For information about enabling and disabling power saving, see “To turn Power

Saving on and off” (page E-84).

• There actually are two sleep state levels: “display sleep” and “function sleep”.

E-18

Charging Times

Exposure Level

(Brightness)

Daily

Operation

Level Change *2

Level 5 Level 4 Level 3 Level 2 Level 1

Outdoor sunlight

(50,000 lux) 8 min. 3 hours 24 hours 7 hours

Window sunlight

(10,000 lux) 30 min. 7 hours 89 hours 24 hours

Window sunlight on

cloudy day (5,000 lux) 48 min. 11 hours

143 hours

39 hours

Indoor fluorescent

lighting (500 lux) 8 hours 139 hours – – – – – –

*1 Approximate exposure each day to generate power for normal daily operation.

*2 Approximate exposure time (in hours) required to take power up one level.

E-17

Power Recovery Mode

• Performing multiple illumination, beeper, and/or high-speed hand movement

operation during a short period may cause all of the battery power indicators (H

, M,

and L) to start flashing in the lower digital dial. This indicates that the watch is in the

power recovery mode. Illumination, alarm, countdown timer alarm, and hourly time

signal operations will be disabled until battery power recovers.

• Battery power will recover in about 15 minutes. At this time, the battery power

indicators (H, M, L) will stop flashing. This indicates that the functions listed above

are enabled again.

• If all of the battery power indicators (H, M, L) are flashing and the

CHG (charge)

message also is flashing, it means the battery level is very low. Expose the watch to

bright light as soon as possible.

• Frequent flashing of all of the battery power indicators (

H, M, L) probably means

that remaining battery power is low. Leave the watch in bright light to allow it to

charge.

E-16

• At Level 5, all functions are disabled and settings return to their initial factory

defaults. Once the battery reaches Level 2 (

M) after falling to Level 5, reconfigure

the current time, date, and other settings.

• Display indicators reappear as soon as the battery is charged from Level 5 to Level

2 (M).

• Leaving the watch exposed to direct sunlight or some other very strong light source

can cause the battery power indicator to show a reading temporarily that is higher

than the actual battery level. The correct battery level should be indicated after a

few minutes.

• The current time and all other settings return to their initial factory defaults whenever

battery power drops to Level 5 and when you have the battery replaced.

E-15

Level Battery Power Indicator Function Status

(H) All functions enabled.

(M) All functions enabled.

(L and

LOW)

Auto and manual receive, illumination, and beeper

disabled.

Except for Timekeeping Mode, all other modes

disabled.

(CHG)

All functions and display indicators disabled except

for timekeeping and display of

CHG (charge) in the

lower digital dial.

Hour and minute hands stopped at 12 o’clock.

5 All functions disabled.

• The flashing LOW message at Level 3 (

L) tells you that battery power is very low,

and that exposure to bright light for charging is required as soon as possible.

E-14

• Storing the watch for long periods in an area where there is no light or wearing it in

such a way that it is blocked from exposure to light can cause power to run down.

Expose the watch to bright light whenever possible.

Power Levels

You can get an idea of the watch’s power level by observing the battery power

indicator in the lower digital dial.

Battery power indicator

E-13

Warning!

Leaving the watch in bright light for charging can cause it to become quite hot.

Take care when handling the watch to avoid burn injury. The watch can become

particularly hot when exposed to the following conditions for long periods.

• On the dashboard of a car parked in direct sunlight

• Too close to an incandescent lamp

• Under direct sunlight

Important!

• Allowing the watch to become very hot can cause the digital displays to black out.

The appearance of the LCD should become normal again when the watch returns

to a lower temperature.

• Turn on the watch’s Power Saving function (page E-19) and keep it in an area normally

exposed to bright light when storing it for long periods. This helps to ensure that

power does not run down.

E-12

Charging the Watch

The face of the watch is a solar panel that generates power from light. The generated

power charges a built-in rechargeable battery, which powers watch operations. The

watch charges whenever it is exposed to light.

Charging Guide

Whenever you are not

wearing the watch, leave it

in a location where it is

exposed to light.

• Best charging

performance is achieved

by exposing the watch to

the strongest light

available.

When wearing the watch,

make sure that its face is

not blocked from light by the

sleeve of your clothing.

• The watch may enter a

sleep state (page E-19) if its

face is blocked by your

sleeve even only partially.

E-11

Hand Home Position Adjustment …………………………………………………E-76

To adjust home positions manually……………………………………………E-76

Moving the Hands for Easy Viewing of the Digital Dials ………………………E-79

To move the hands to view a digital dial ……………………………………E-80

To return the hands to their normal positions ………………………………E-81

Other Settings …………………………………………………………………………E-82

To turn the button operation tone on and off …………………………………E-82

To turn Power Saving on and off ………………………………………………E-84

Troubleshooting ………………………………………………………………………E-86

Specifications …………………………………………………………………………E-93

Operating Precautions ………………………………………………………………E-96

User Maintenance ………………………………………………………………… E-106

E-10

Using the Countdown Timer …………………………………………………………E-60

To enter the Countdown Timer Mode …………………………………………E-60

To specify the countdown start time …………………………………………E-60

To perform a countdown timer operation ……………………………………E-62

To stop the alarm ………………………………………………………………E-62

Using the Alarm ………………………………………………………………………E-63

To enter the Alarm Mode ………………………………………………………E-63

To set an alarm time ……………………………………………………………E-64

To test the alarm ………………………………………………………………E-65

To turn an alarm and the Hourly Time Signal on and off……………………E-66

To stop the alarm ………………………………………………………………E-66

Illumination ……………………………………………………………………………E-68

To turn on illumination manually ………………………………………………E-68

To change the illumination duration …………………………………………E-69

To turn the auto light switch on and off ………………………………………E-73

Operation Guide 5580

E-29

• You can use the procedure under “To turn auto receive on and off” (page E-34) to

enable or disable auto receive.

To perform manual receive

In the Timekeeping Mode, hold down D until the watch

beeps.

• A signal level indicator (L1, L2, or L3, see page E-32)

appears in the lower digital dial after reception starts.

Do not move the watch or perform any button operation

until GET or ERR appears in the right digital dial.

RCVD indicator

Receiving

E-28

3. What you should do next depends on whether you are using Auto Receive or

Manual Receive.

• Auto Receive: Leave the watch over night in the location you selected in step 2.

See “Auto Receive” below for details.

• Manual Receive: Perform the operation under “To perform manual receive” on

page E-29.

Auto Receive

• With Auto Receive, the watch performs the receive operation each day

automatically up to six times (up to five times for the Chinese calibration signal)

between the hours of midnight and 5 a.m. (according to the Timekeeping Mode

time). When any receive operation is successful, none of the other receive

operations for that day are performed.

• When a calibration time is reached, the watch will perform the receive operation

only if it is in the Timekeeping Mode or World Time Mode. The receive operation is

not performed if a calibration time is reached while you are configuring settings,

while a countdown timer operation is in progress, or while the hands have been

moved for easier viewing of the digital dials (page E-80).

E-27

• Signal reception may be difficult or even impossible under the conditions described

below.

Inside or

among

buildings

Inside a

vehicle

Near

household

appliances,

office

equipment,

or a mobile

phone

Near a

construction

site, airport,

or other

sources of

electrical

noise

Near

high-tension

power lines

Among or

behind

mountains

E-26

To get ready for a receive operation

1. Confirm that the watch is in the Timekeeping Mode. If it isn’t, use C to enter the

Timekeeping Mode (page E-38).

2. The antenna of this watch is located on its 12 o’clock side. Position the watch with

12 o’clock facing towards a window as shown in the nearby illustration. Make sure

there are no metal objects nearby.

• Signal reception normally is better at

night.

• The receive operation takes from three

to eight minutes, but in some cases it

can take as long as 16 minutes. Take

care that you do not perform any

button operation or move the watch

during this time.

12 o’clock

E-25

• Even when the watch is within range of a transmitter, signal reception may be

impossible due to the effects of geographic contours, structures, weather, the time

of year, the time of day, radio interference, etc. The signal becomes weaker at

distances of approximately 500 kilometers, which means that the influence of the

conditions listed above becomes even greater.

• Signal reception may not be possible at the distances noted below during certain

times of the year or day. Radio interference may also cause problems with

reception.

–

Mainflingen (Germany) or Anthorn (England) transmitters: 500 kilometers (310 miles)

– Fort Collins (United States) transmitter: 600 miles (1,000 kilometers)

– Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310 miles)

– Shangqiu (China) transmitter: 500 kilometers (310 miles)

• As of July 2016, China does not use Daylight Saving Time (DST). If China does go

to the Daylight Saving Time system in the future, some functions of this watch may

no longer operate correctly.

E-24

Japanese Signals Chinese Signal

Fukushima

500 kilometers

1,000 kilometers

Fukuoka/Saga

Signals are receivable in the Taiwan area

when reception conditions are good.

1,500 kilometers

Changchun500 kilometers

Beijing

Shangqiu

Shanghai

Chengdu

Hong Kong

E-23

Approximate Reception Ranges

UK and German Signals North American Signal

Anthorn

500 kilometers

1,500 kilometers

Mainflingen

The Anthorn signal is receivable

within this area.

2,000 miles

(3,000 kilometers)

600 miles

(1,000 kilometers)

Fort Collins

E-22

If your Home City Code setting is this: The watch can receive the signal from the

transmitter located here:

LIS, LON, MAD, PAR, ROM, BER, STO, ATH,

MOW Anthorn (England), Mainflingen (Germany)

HKG, BJS Shangqiu City (China)

TPE, SEL, TYO Fukushima (Japan), Fukuoka/Saga (Japan)

HNL, ANC, YVR, LAX, YEA, DEN, MEX, CHI,

NYC, YHZ, YYT Fort Collins, Colorado (United States)

Important!

• The areas covered by MOW, HNL and

ANC are quite far from the calibration signal

transmitters, so certain conditions may cause reception problems.

• When HKG or BJS is selected as the Home City, only the time and date are

adjusted according to the time calibration signal. You need to switch manually

between standard time and daylight saving time (DST) if required. See “To

configure Home City settings” (page E-42) for information about how to do this.

E-21

Radio Controlled Atomic Timekeeping

This watch receives a time calibration signal and updates its time setting accordingly.

However, when using the watch outside of areas covered by time calibration signals,

you will have to adjust the settings manually as required. See “Configuring Current

Time and Date Settings Manually” (page E-48) for more information.

This section explains how the watch updates its time settings when the city code

selected as the Home City is in Japan, North America, Europe, or China, and is one

that supports time calibration signal reception.

E-20

Elapsed Time in Dark Digital Dials Operation

60 to 70 minutes (display sleep) Blank Digital dials are off, but all functions are

enabled.

6 or 7 days (function sleep) Blank

Hour and minute hands stop at

12 o’clock. All functions are disabled,

but timekeeping is maintained.

• The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is

already in a sleep state when 6:00 AM arrives, however, it will remain in the sleep

state.

• The watch will not enter a sleep state while it is in the Stopwatch Mode or

Countdown Timer Mode.

To recover from the sleep state

Move the watch to a well-lit area or press any button.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	G-Shock GST-W330AC-2AER
Enhetsplacering:	Vrijstaand
Typ av operation:	Draaiknop
Färg på produkten:	Wit
Dörrgångjärn:	Links
Inbyggd display:	Ja
Vikt:	68000 g
Bredd:	598 mm
Djup:	550 mm
Höjd:	848 mm
Nettoskatt:	2300 W
Typ av laddare:	Voorbelading
Dörrfärg:	Wit
Sladdlängd:	1.6 m
Trumminnehåll:	55 l
Fördröjd starttimer:	Ja
Startfördröjning:	24 uur
Indikering av återstående tid:	Ja
Barnlås:	Ja
Avtagbar topp:	Ja
Energie-efficiëntieklasse:	C
Tvätt energiförbrukning:	0.63 kWu
Vattenförbrukning per cykel:	48 l
Centrifuger läkemedelsklass:	B
Ljudnivå (tvätt):	52 dB
Övervakning av lödderskum:	Ja
Obalans kontrollsystem:	Ja
Justerbar centrifughastighet:	Ja
Maximal centrifugeringshastighet:	1400 RPM
Nuvarande:	10 A
Bulleremissionsklass:	B
Ljudnivå under centrifugering:	74 dB
Cykeltid (max):	215 min
Energiförbrukning per 100 cykler:	63 kWu
Djup när dörren är öppen:	1017 mm
Doseringsassistent:	Ja
AquaStop-funktion:	Nee
Strömförbrukning (i standby):	0.5 W
Certifiering:	CE, VDE
Minsta centrifugeringshastighet:	400 RPM
Belysning i trumma:	Nee
Överdosindikation:	Ja
Genomgående öppningsvinkel:	180 °
Dörrdiameter:	300 mm
Öppen dörr:	Opening aan zijkant
Vatten Plus:	Ja
Nominell kapacitet:	8 kg
AC-ingångsspänning:	220-240 V
AC-ingångsfrekvens:	50 Hz
Type beeldscherm:	LED
Energieffektivitetsskala:	A tot G
Wasprogramma's:	Black, Delicate/silk, Hand/wool, Mix, Quick, Rinse, Spin/drain
