Sida 1/11
Operation Guide 5561
E-9
Hand Home Position Adjustment .................................................................... E-70
To adjust home positions manually ............................................................... E-70
Moving the Hands for Easy Viewing of Digital Information .......................... E-72
To move the hands to view digital information ............................................. E-73
To return the hands to their normal positions ............................................... E-73
Other Settings .................................................................................................. E-75
To enable or disable the button operation tone ............................................ E-75
To enable or disable Power Saving............................................................... E-77
Troubleshooting ............................................................................................... E-78
Specifications ...................................................................................................E-85
Operating Precautions .....................................................................................E-88
User Maintenance ............................................................................................ E-98
E-8
Using the Countdown Timer ........................................................................... E-55
To enter the Countdown Timer Mode ........................................................... E-55
To specify the countdown start time ............................................................ E-55
To perform a countdown timer operation ..................................................... E-57
To stop the alarm .......................................................................................... E-57
Using the Alarm ................................................................................................ E-58
To enter the Alarm Mode .............................................................................. E-58
To set an alarm time ..................................................................................... E-59
To test the alarm ........................................................................................... E-60
To enable or disable an alarm or the Hourly Time Signal .............................. E-61
To stop a sounding alarm ............................................................................. E-61
Illumination ....................................................................................................... E-63
To turn on illumination manually ................................................................... E-63
To change the illumination duration .............................................................. E-64
To enable or disable the auto light switch .................................................... E-67
E-7
Configuring Home City Settings ..................................................................... E-40
To configure Home City settings .................................................................. E-40
To change the Daylight Saving Time (summer time) setting ......................... E-42
Configuring Current Time and Date Settings Manually ................................ E-44
To change the current time and date settings manually ............................... E-44
Using the World Time Mode ............................................................................ E-48
To enter the World Time Mode ..................................................................... E-48
To view the time in another time zone .......................................................... E-48
To specify standard time or daylight saving time (DST) for a city ................. E-49
To swap your Home Time and World Time Cities ......................................... E-50
Using the Stopwatch .......................................................................................E-52
To enter the Stopwatch Mode ...................................................................... E-52
To perform an elapsed time operation .......................................................... E-53
To pause at a split time ................................................................................. E-53
To measure two finishes ............................................................................... E-53
E-6
Contents
About This Manual ............................................................................................. E-1
Things to check before using the watch .......................................................... E-2
Charging the Watch .........................................................................................E-10
To recover from the sleep state .................................................................... E-18
Radio Controlled Atomic Timekeeping .......................................................... E-19
To get ready for a receive operation ............................................................. E-24
To perform manual receive ........................................................................... E-27
To check the latest signal reception results .................................................. E-31
To enable or disable auto receive ................................................................. E-32
Mode Reference Guide ....................................................................................E-35
Timekeeping ..................................................................................................... E-39
E-5
The watch is now ready for use.
x For details about the watch’s radio controlled timekeeping feature, see “Radio
Controlled Atomic Timekeeping” (page E-19).
E-4
2. Check the Home City and the daylight saving time (DST) setting.
Use the procedure under “To configure Home City settings” (page E-40) to configure
your Home City and daylight saving time settings.
Important!
x Proper time calibration signal reception and World Time Mode data depend on
correct Home City, time, and date settings in the Timekeeping Mode. Make sure
you configure these settings correctly.
3. Set the current time.
x To set the time using a time calibration signal
See “To get ready for a receive operation” (page E-24).
x To set the time manually
See “Configuring Current Time and Date Settings Manually” (page E-44).
E-3
Go to step 2.
The watch is charged.
For details about charging, see “Charging the Watch” (page E-10).
Power is low. Charge the watch by placing it in a location where it is exposed to
light. For details, see “Charging the Watch” (page E-10).
NEXT
E-2
Things to check before using the watch
1. Check the battery power level.
Is H or indicated as the battery power indicator (page E-13)?M
Battery power indicator
YES
NO
E-1
About This Manual
x Depending on the model of your watch, display text
appears either as dark figures on a light background,
or light figures on a dark background. All examples
in this manual are shown using dark figures on a light
background.
x Button operations are indicated using the letters shown
in the illustration.
x Note that the product illustrations in this manual are
intended for reference only, and so the actual product
may appear somewhat different than depicted by an
illustration.
E
ENGLISH
Congratulations upon your selection of this CASIO watch.
To ensure that this watch provides you with the years of service for which it is
designed, carefully read and follow the instructions in this manual, especially the
information under “Operating Precautions” and “User Maintenance”.
Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss suffered by you or any third party arising through the use of your
watch or its malfunction.
MA1711-EA © 2017 CASIO COMPUTER CO., LTD.
Operation Guide 5561
E-19
Radio Controlled Atomic Timekeeping
This watch receives a time calibration signal and updates its time setting
accordingly. However, when using the watch outside of areas covered by time
calibration signals, you will have to adjust the settings manually as required.
See “Configuring Current Time and Date Settings Manually” (page E-44) for more
information.
This section explains how the watch updates its time settings when the city code
selected as the Home City is in Japan, North America, Europe, or China, and is one
that supports time calibration signal reception.
E-18
x The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch
is already in a sleep state when 6:00 AM arrives, however, it will remain in the sleep
state.
x The watch will not enter a sleep state while it is in the Stopwatch Mode or
Countdown Timer Mode.
To recover from the sleep state
Move the watch to a well-lit area, press any button, or angle the watch towards
your face for reading (page E-65).
E-17
x For details about the operating time and daily operating conditions, see the “Power
Supply” (page E-87) section of the Specifications.
Power Saving
When enabled, Power Saving enters a sleep state automatically whenever the
watch is left for a certain period in an area where it is dark. The table below shows
how watch functions are affected by Power Saving.
x For information about enabling and disabling power saving, see “To enable or
disable Power Saving” (page E-77).
x There actually are two sleep state levels: “display sleep” and “function sleep”.
Elapsed Time in Dark Digital Displays Operation
60 to 70 minutes (display sleep) Blank Digital display is disabled, but all
functions are enabled.
6 or 7 days (function sleep) Blank
Hour and minute hands stop at
12o’clock. All functions are disabled,
but timekeeping is maintained.
E-16
Charging Times
Exposure Level
(Brightness)
Daily
Operation
*1
Level Change *2
Level 5 Level 4 Level 3 Level 2 Level 1
Outdoor sunlight
(50,000 lux) 8 min. 3 hours 24 hours 7 hours
Window sunlight
(10,000 lux) 30 min. 7 hours 90 hours 25 hours
Window sunlight on
cloudy day (5,000 lux) 48 min. 11 hours
146 hours
39 hours
Indoor fluorescent
lighting (500 lux) 8 hours 142 hours – – – – – –
* 1 Approximate exposure each day to generate power for normal daily operation.
* 2 Approximate exposure time (in hours) required to take power up one level.
x The above exposure times all are for reference only. Actual exposure times depend
on lighting conditions.
E-15
Power Recovery Mode
x Performing multiple illumination, beeper, and/or high-speed hand movement
operations during a short period may cause all of the battery power indicators
(H, M, and L) to start flashing. This indicates that the watch is in the power
recovery mode. Illumination, alarm, countdown timer alarm, and hourly time signal
operations will be disabled until battery power recovers.
x Battery power will recover in about 15 minutes. At this time, the battery power
indicators (H, , ) will stop flashing. This indicates that the functions listed aboveM L
are enabled again.
x If all of the battery power indicators ( , , ) are flashing and the (charge)H M L CHG
message also is flashing, it means the battery level is very low. Expose the watch
to bright light as soon as possible.
x Frequent flashing of all of the battery power indicators ( , , ) probably meansH M L
that remaining battery power is low. Leave the watch in bright light to allow it to
charge.
E-14
x At Level 5, all functions are disabled and settings return to their initial factory
defaults. Once the battery reaches Level 2 ( ) after falling to Level 5, reconfigure M
the current time, date, and other settings.
x Display indicators reappear as soon as the battery is charged from Level 5 to
Level 2 ( ).M
x Leaving the watch exposed to direct sunlight or some other very strong light
source can cause the battery power indicator to show a reading temporarily that
is higher than the actual battery level. The correct battery level should be indicated
after a few minutes.
x The current time and all other settings return to their initial factory defaults
whenever battery power drops to Level 5 and when you have the battery replaced.
E-13
Level
Battery Power Indicator
Function Status
1
(H) All functions enabled.
2
(M) All functions enabled.
3
(L and
LOW)
Auto and manual receive, illumination, and beeper
disabled.
Except for Timekeeping Mode, all other modes
disabled.
4
(CHG)
All functions and display indicators disabled except
for timekeeping and display of the (charge) CHG
indicator.
Hour and minute hands stopped at 12 o’clock.
5 All functions disabled.
x The flashing message at Level 3 ( ) tells you that battery power is very low, LOW L
and that exposure to bright light for charging is required as soon as possible.
E-12
x Storing the watch for long periods in an area where there is no light or wearing it in
such a way that it is blocked from exposure to light can cause power to run down.
Expose the watch to bright light whenever possible.
Power Levels
You can get an idea of the watch’s power level by observing the battery power
indicator.
Battery power indicator
E-11
Warning!
Leaving the watch in bright light for charging can cause it to become quite
hot. Take care when handling the watch to avoid burn injury. The watch can
become particularly hot when exposed to the following conditions for long
periods.
x On the dashboard of a car parked in direct sunlight
x Too close to an incandescent lamp
x Under direct sunlight
Important!
x Allowing the watch to become very hot can cause the digital displays to black out.
The appearance of the LCD should become normal again when the watch returns
to a lower temperature.
x Enable the watch’s Power Saving function (page E-17) and keep it in an area normally
exposed to bright light when storing it for long periods. This helps to ensure that
power does not run down.
E-10
Charging the Watch
The face of the watch is a solar panel that generates power from light. The
generated power charges a built-in rechargeable battery, which powers watch
operations. The watch charges whenever it is exposed to light.
Charging Guide
Whenever you are not
wearing the watch, leave
it in a location where it is
exposed to light.
x Best charging
performance is achieved
by exposing the watch
to the strongest light
available.
When wearing the watch,
make sure that its face is
not blocked from light by
the sleeve of your clothing.
x The watch may enter a
sleep state (page E-17) if its
face is blocked by your
sleeve even only partially.
Operation Guide 5561
E-29
x If the current reception fails but a previous reception
(within the last 24 hours) was successful, RCVD
and will be displayed. If only is displayed ERR ERR
(without RCVD), it means that all of the receive
operations over the past 24 hours have failed. The
watch will return to the Timekeeping Mode without
changing the time setting if you press or if you do D
not perform any button operation for about one or
two minutes.
Note
x To interrupt a receive operation and return to the
Timekeeping Mode, press any button.
If there was a previously
successful reception
Receive failed
E-28
x If the receive operation is successful, the reception
date and time will appear. The watch will return to
the Timekeeping Mode if you press or if you do D
not perform any button operation for about one or
two minutes.
Receive successful
RCVD indicator
E-27
x You can use the procedure under “To enable or disable auto receive” (page E-32) to
enable or disable auto receive.
To perform manual receive
In the Timekeeping Mode, hold down until the watch D
beeps.
x A signal level indicator (page E-30) appears after reception
starts. Do not move the watch or perform any button
operation until or appears.GET ERR
Signal level indicator
Receiving
E-26
3. What you should do next depends on whether you are using Auto Receive or
Manual Receive.
x Auto Receive: Leave the watch over night in the location you selected in step 2.
See “Auto Receive” below for details.
x Manual Receive: Perform the operation under “To perform manual receive” on
page E-27.
Auto Receive
x With Auto Receive, the watch performs the receive operation each day
automatically up to six times (up to five times for the Chinese calibration signal)
between the hours of midnight and 5 a.m. (according to the Timekeeping Mode
time). When any receive operation is successful, none of the other receive
operations for that day are performed.
x When a calibration time is reached, the watch will perform the receive operation
only if it is in the Timekeeping Mode or World Time Mode. The receive operation
is not performed if a calibration time is reached while you are configuring settings,
while a countdown timer operation is in progress, or while the hands have been
moved for easier viewing of digital information (page E-73).
E-25
x Signal reception may be difficult or even impossible under the conditions
described below.
Inside or
among
buildings
Inside a
vehicle
Near
household
appliances,
office
equipment,
or a mobile
phone
Near a
construction
site, airport,
or other
sources of
electrical
noise
Near
high-tension
power lines
Among
or behind
mountains
E-24
To get ready for a receive operation
1. Confirm that the watch is in the Timekeeping Mode. If it isn’t, use to enter the C
Timekeeping Mode (page E-36).
2. The antenna of this watch is located on its 12 o’clock side. Position the watch
with 12 o’clock facing towards a window as shown in the nearby illustration.
Make sure there are no metal objects nearby.
12 o’clock
or
x Signal reception normally is better
at night.
x The receive operation takes from three
to eight minutes, but in some cases
it can take as long as 16 minutes.
Take care that you do not perform any
button operation or move the watch
during this time.
E-23
x Even when the watch is within range of a transmitter, signal reception may be
impossible due to the effects of geographic contours, structures, weather, the time
of year, the time of day, radio interference, etc. The signal becomes weaker at
distances of approximately 500 kilometers, which means that the influence of the
conditions listed above becomes even greater.
x Signal reception may not be possible at the distances noted below during certain
times of the year or day. Radio interference may also cause problems with
reception.
− Mainflingen (Germany) or Anthorn (England) transmitters: 500 kilometers
(310 miles)
− Fort Collins (United States) transmitter: 600 miles (1,000 kilometers)
− Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310 miles)
− Shangqiu (China) transmitter: 500 kilometers (310 miles)
x As of January 2017, China does not use Daylight Saving Time (DST). If China does
go to the Daylight Saving Time system in the future, some functions of this watch
may no longer operate correctly.
E-22
Japanese Signals Chinese Signal
Fukushima
500 kilometers
1,000 kilometers
Fukuoka/Saga
Signals are receivable in the Taiwan area
when reception conditions are good.
1,500 kilometers
Changchun500 kilometers
Beijing
Shangqiu
Shanghai
Chengdu
Hong Kong
E-21
Approximate Reception Ranges
UK and German Signals North American Signal
Anthorn
500 kilometers
1,500 kilometers
Mainflingen
The Anthorn signal is receivable
within this area.
2,000 miles
(3,000 kilometers)
600 miles
(1,000 kilometers)
Fort Collins
E-20
If your Home City Code setting is this: The watch can receive the signal from the
transmitter located here:
LIS, LON, MAD, PAR, ROM, BER, STO,
ATH, MOW Anthorn (England), Mainflingen (Germany)
HKG, BJS Shangqiu City (China)
TPE, SEL, TYO Fukushima (Japan), Fukuoka/Saga (Japan)
HNL, ANC, YVR, LAX, YEA, DEN, MEX,
CHI, NYC, YHZ, YYT Fort Collins, Colorado (United States)
Important!
x The areas covered by , are quite far from the calibrationMOW HNL and ANC
signal transmitters, so certain conditions may cause reception problems.
x When or is selected as the Home City, only the time and date areHKG BJS
adjusted according to the time calibration signal. You need to switch manually
between standard time and daylight saving time (DST) if required. See “To
configure Home City settings” (page E-40) for information about how to do this.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | G-Shock GWG-100-1A8ER |
Behöver du hjälp?
Om du behöver hjälp med Casio G-Shock GWG-100-1A8ER ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
