Operation Guide 3221

MO1006-EA

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out of your

purchase, be sure to read this manual carefully.

Keep the watch exposed to bright light

The electricity generated by the solar cell of the watch is

stored by a rechargeable battery. Leaving or using the

watch where it is not exposed to light causes the battery

to run down. Make sure the watch is exposed to light as

much as possible.

• When you are not wearing the watch on your wrist,

position the face so it is pointed at a source of bright

light.

• You should try to keep the watch outside of your sleeve

as much as possible. Charging is reduced significantly if

the face is covered only partially.

Bright Light

Solar cell

All

functions

enabled

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Charge

Rechargeable battery

Bright Light

Electrical

energy

Solar cell

(Converts light to

electrical power.)

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Some or all

functions

disabled

Dis-

charge

Battery charges in the light. Battery discharges in the dark.

• The watch continues to operate, even when it is not exposed to light. Leaving the

watch in the dark can cause the battery to run down, which will result in some watch

functions to be disabled. If the battery goes dead, you will have to re-configure watch

settings after recharging. To ensure normal watch operation, be sure to keep it

exposed to light as much as possible.

• The actual level at which some functions are disabled depends on the watch model.

• Frequent display illumination can run down the battery quickly and require charging.

The following guidelines give an idea of the charging time required to recover from a

single illumination operation.

Approximately 5 minutes exposure to bright sunlight coming in through a window

Approximately about 8 hours exposure to indoor fluorescent lighting

• Be sure to read “Power Supply” for important information you need to know

when exposing the watch to bright light.

If the display of the watch is blank...

If the display of the watch is blank, it means that the watch’s Power Saving function

has turned off the display to conserve power.

• See “Power Saving Function” for more information.

About This Manual

• Depending on the model of your watch, display text appears either as dark figures

on a light background or light figures on a dark background. All sample displays in

this manual are shown using dark figures on a light background.

• Button operations are indicated using the letters shown in the illustration.

• Each section of this manual provides you with the information you need to perform

operations in each mode. Fur ther details and technical information can be found in

the “Reference” section.

General Guide

• Press C to change from mode to mode.

• In any mode (except when a setting screen is on the display), press B to illuminate

the display.

Timekeeping Mode

Press C.

Countdown Timer Mode Stopwatch Mode

Alarm Mode

▲

World Time Mode

▲

Timekeeping

Press the button to toggle the upper display betweenA

the day of the week and date, and the currently selected

World Time city and time (Dual Time).

Use the Timekeeping Mode to set and view the current

time and date.

Read This Before You Set the Time and Date!

This watch is preset with a number of city codes, each of

which represents the time zone where that city is located.

When setting the time, it is important that you first select

the correct city code for your Home City (the city where

you normally use the watch). If your location is not

included in the preset city codes, select the preset city

code that is in the same time zone as your location.

• Note that all of the times for the World Time Mode city

codes are displayed in accordance with the time and

date settings you configure in the Timekeeping Mode.

Current Time

PM indicator

Hour : Minutes

Seconds

Day of week

Dual Time

Month – Day

▲

Dual timeCity code

To set the time and date

1. In the Timekeeping Mode, hold down A until the city

code starts to flash, which indicates the setting screen.

2. Press D B and to select the city code you want.

• Make sure you select your Home City code before

changing any other setting.

• For full information on city codes, see the “City Code

Table”.

3. Press C to move the flashing in the sequence shown below to select the other

settings.

Seconds

12/24-Hour

Format Hour Minutes

DST

Month Year

City Code

DayPower Saving Illumination

Duration

Button

Operation Tone

• The following steps explain how to configure timekeeping settings only.

4. When the timekeeping setting you want to change is flashing, press D or B

change it as described below.

Change the city code

Toggle between Daylight Saving Time

(ON) and Standard Time (OFF).

Toggle between 12-hour ( ) and 24-

hour ( ) timekeeping

Reset the seconds to

Change the hour and minutes

Press D (east) and B

(west).

Press D.

Press D (+) and B (–).

Screen: To do this: Do this:

5. Press A to exit the setting screen.

• The day of the week is displayed automatically in accordance with the date (year,

month, and day) settings.

To do this: Do this:

Change the year, month, or day

Toggle the button operation tone between

(on) and (off)

Toggle the illumination duration between

(approximately 1.5 seconds) and

(approximately 3 seconds).

Toggle between Power Saving on ( )

and off ( )

Press D (+) and B (–).

Press D.

Screen:

12-hour and 24-hour timekeeping

• With the 12-hour format, the P (PM) indicator appears to the left of the hour digits for

times in the range of noon to 11:59 p.m. and no indicator appears to the left of the

hour digits for times in the range of midnight to 11:59 a.m.

• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without

any indicator.

• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all other modes.

Daylight Saving Time (DST)

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down A until the city

code starts to flash, which indicates the setting screen.

2. Press C and the DST setting screen appears.

3. Press D to toggle the DST settings ON

and

OFF.

DST off (

OFF

) DST on (

)

4. When the setting you want is selected, press A to exit

the setting screen.

• The DST indicator appears to indicate that Daylight

Saving Time is turned on.

DST indicator

Operation Guide 3221

World Time

World Time shows the current time in 48 cities (31 time

zones) around the world.

• The times kept in the World Time Mode are

synchronized with the time being kept in the

Timekeeping Mode. If you feel that there is an error in

any World Time Mode time, check to make sure you

have the correct city selected as your Home City. Also

check to make sure that the current time as shown in

the Timekeeping Mode is correct.

• Select a city code in the World Time Mode to display the

current time in any particular time zone around the

globe. See the “City Code Table” for information about

the UTC differential settings that are supported.

Current time in

selected city

City code

• All of the operations in this section are performed in the World Time Mode, which

you enter by pressing C.

To view the time in another city

While in the World Time Mode, press the (eastward) to scroll through the cityD

codes (time zones).

• Pressing the D B and at the same time will jump to the UTC time zone.

To toggle a city code time between Standard Time and Daylight Saving Time

1. In the World Time Mode, press D to display the city

code (time zone) whose Standard Time/Daylight Saving

Time setting you want to change.

2. Hold down A to toggle between Daylight Saving Time

(DST indicator displayed) and Standard Time (DST

indicator not displayed).

• The DST indicator is shown on the World Time Mode

screen while Daylight Saving Time is turned on.

• Note that the Standard Time/Daylight Saving Time

setting affects only the currently displayed city code.

Other city codes are not affected.

• Note that you cannot switch between Standard Time

and Daylight Saving Time while UTC is selected as the

city code.

DST indicator

Alarms

The Alarm Mode gives you a choice of four one-time

alarms and one snooze alarm.

Also use the Alarm Mode to turn the Hourly Time Signal

(SIG) on and off.

• There are five alarm screens numbered AL1 AL2, ,

AL3 AL and 4 for the one-time alarm, and a snooze

alarm screen indicated by SNZ. The Hourly Time

Signal screen is indicated by SIG.

• All of the operations in this section are performed in the

Alarm Mode, which you enter by pressing C.

Alarm number

Alarm time

(Hour : Minutes)

To set an alarm time

1. In the Alarm Mode, press D to scroll through the alarm

screens until the one whose time you want to set is

displayed.

• To set a one-time alarm, display alarm screen AL1, , .AL2 AL3 or AL4

To set the snooze alarm, display the SNZ screen.

• The snooze alarm repeats every five minutes.

2. After you select an alarm, hold down A until the hour setting of the alarm time

starts to flash, which indicates the setting screen.

• This operation turns on the alarm automatically.

3. Press C to move the flashing between the hour and minute settings.

4. While a setting is flashing, press D B (+) and (–) to change it.

• With the 12-hour format, set the time correctly as a.m. or p.m. ( indicator).P

5. Press A to exit the setting screen.

Alarm Operation

The alarm tone sounds at the preset time for 10 seconds, regardless of the mode the

watch is in. In the case of the snooze alarm, the alarm operation is performed a total

of seven times, every five minutes, until you turn the alarm off.

• Alarm and Hourly Time Signal operations are performed in accordance with the

Timekeeping Mode time.

• To stop the alarm tone after it starts to sound, press any button.

• Performing any one of the operations below during a 5-minute interval between

snooze alarms cancels the current snooze alarm operation.

Displaying the Timekeeping Mode setting screen

Displaying the

SNZ

setting screen

To test the alarm

In the Alarm Mode, hold down to sound the alarm.D

To turn an alarm on and off

1. In the Alarm Mode, press to select an alarm.D

2. Press to toggle it on and off.A

• Turning on an alarm (AL1 AL2 AL3 AL, , , 4 or

SNZ) displays the alarm on indicator on its Alarm Mode

screen.

• In all modes, the alarm on indicator is shown for any

alarm that currently is turned on.

• The alarm on indicator flashes while the alarm is

sounding.

• The snooze alarm indicator flashes while the snooze

alarm is sounding and during the 5-minute intervals

between alarms.

Alarm on indicator

Snooze alarm

indicator

To turn the Hourly Time Signal on and off

1. In the Alarm Mode, press D to select the Hourly Time

Signal (SIG).

2. Press to toggle it on and off.A

• The Hourly Time Signal on indicator is shown on the

display in all modes while this function is turned on.

Hourly time signal

on indicator

Stopwatch

The stopwatch lets you measure elapsed time, split times,

and two finishes.

• The display range of the stopwatch is 23 hours, 59

minutes, 59.99 seconds.

• The stopwatch continues to run, restarting from zero

after it reaches its limit, until you stop it.

• The stopwatch measurement operation continues even

if you exit the Stopwatch Mode.

• Exiting the Stopwatch Mode while a split time is frozen

on the display clears the split time and returns to

elapsed time measurement.

• All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing C.

1/100 second

Hours

Seconds

Minutes

To measure times with the stopwatch

Elapsed Time

Split Time

Two Finishes

Start

Stop Re-start Stop

Split

(SPL displayed)

Split release Stop

Split

First runner finishes.

Display time of first

runner.

Stop

Second runner

finishes.

Split release

Display time of

second runner.

D AA

➤➤➤

➤

Clear

Countdown Timer

You can set the countdown timer within a range of one

minute to 24 hours. An alarm sounds when the countdown

reaches zero.

• All of the operations in this section are performed in the

Countdown Timer Mode, which you enter by pressing

Countdown End Beeper

The countdown end beeper lets you know when the

countdown reaches zero. The beeper stops after about 10

seconds or when you press any button.

Minutes

Seconds

Hours

To configure the countdown timer

1. While the countdown start time is on the display in the

Countdown Timer Mode, hold down A until the current

countdown start time starts to flash, which indicates the

setting screen.

• If the countdown start time is not displayed, use the

procedure under “To use the countdown timer” to

display it.

2. Press C to move the flashing in the sequence shown

below to select other settings.

Hours Minutes

3. When the setting you want to change is flashing, press D B and to change it as

described below.

•To specify a countdown start time of 24 hours, set .

4. Press A to exit the setting screen.

To use the countdown timer

Press D while in the Countdown Timer Mode to start the

countdown timer.

• The countdown timer operation continues even if you

exit the Countdown Timer Mode.

• Press D while a countdown operation is in progress to

pause it. Press again to resume the countdown.D

• To stop a countdown operation completely, first pause it

(by pressing ), and then press . This returns theD A

countdown time to its starting value.

Current timer

time

Timer start time

Button Operation

Press D (+) and B (–) to change the setting.

Setting

Hours, Minutes

Screen

Illumination

This watch has an EL (electro-luminescent) panel that

causes the entire display to glow for easy reading in the

dark. The watch’s auto light switch turns on illumination

automatically when you angle the watch towards your

face.

• The auto light switch must be turned on (indicated by

the auto light switch on indicator) for it to operate.

• See “Illumination Precautions” for other important

information about using illumination.

To illuminate the display manually

In any mode (except when a setting screen is on the display), press to turn onB

illumination.

• The above operation turns on illumination regardless of the current auto light switch

setting.

Auto light switch on

indicator

• You can use the procedure below to select either 1.5 seconds or 3 seconds as the

illumination duration. When you press , the illumination will remain on for aboutB

1.5 seconds or 3 seconds, depending on the current illumination duration setting.

Operation Guide 3221

To specify the illumination duration

1. In the Timekeeping Mode, hold down A until the

display contents start to flash. This is the setting screen.

2. Press C 10 times until the current illumination duration

setting ( or ) appears.

3. Press D to toggle the setting between

(approximately 1.5 seconds) and (approximately

3 seconds).

4. Press to exit the setting screen.A

About the Auto Light Switch

Turning on the auto light switch causes illumination to turn on, whenever you position

your wrist as described below in any mode. Note that this watch features a “Full Auto

EL Light”, so the auto light switch operates only when available light is below a cer tain

level. It does not turn on the backlight under bright light.

Moving the watch to a position that is parallel to the ground and then tilting it towards

you more than 40 degrees causes illumination to turn on.

• Wear the watch on the outside of your wrist.

Parallel to

ground More than 40°

Warning!

•••• • Always make sure you are in a safe place whenever you are reading the

display of the watch using the auto light switch. Be especially careful when

running or engaged in any other activity that can result in accident or injury.

Also take care that sudden illumination by the auto light switch does not

startle or distract others around you.

•••• • When you are wearing the watch, make sure that its auto light switch is turned

off before riding a bicycle or operating a motorcycle or any other motor

vehicle. Sudden and unintended operation of the auto light switch can create a

distraction, which can result in a traffic accident and serious personal injury.

To turn the auto light switch on and off

In the Timekeeping Mode, hold down B for about three seconds to toggle the auto

light switch on (auto light switch on indicator displayed) and off (auto light switch on

indicator not displayed).

• The auto light switch on indicator is on the display in all modes while the auto light

switch is turned on.

Power Supply

This watch is equipped with a solar cell and a rechargeable batter y that is charged by

the electrical power produced by the solar cell. The illustration shown below shows

how you should position the watch for charging.

Example: Orient the watch so its face is

pointing at a light source.

• The illustration shows how to position a

watch with a resin band.

• Note that charging efficiency drops when

any part of the solar cell is blocked by

clothing, etc.

• You should try to keep the watch outside of

your sleeve as much as possible. Charging

is reduced significantly if the face is

covered only partially.

Solar cell

Important!

• Storing the watch for long periods in an area where there is no light or wearing it in

such a way that it is blocked from exposure to light can cause rechargeable battery

power to run down. Be sure that the watch is exposed to bright light whenever

possible.

• This watch uses a rechargeable battery to store power produced by the solar cell, so

regular battery replacement is not required. However, after very long use, the

rechargeable battery may lose its ability to achieve a full charge. If you experience

problems getting the rechargeable battery to charge fully, contact your dealer or

CASIO distributor about having it replaced.

• Never tr y to remove or replace the watch’s rechargeable batter y yourself. Use of the

wrong type of battery can damage the watch.

• All data stored in memory is deleted, and the current time and all other settings

return to their initial factory defaults whenever battery power drops to Level 5 and

when you have the batter y replaced.

• Turn on the watch’s Power Saving function and keep it in an area normally exposed

to bright light when storing it for long periods. This helps to keep the rechargeable

battery from going dead.

Level

Battery Power Indicator

(Charge Soon Alert)

Function Status

All functions enabled.

Illumination, and beeper

disabled.

Except for timekeeping and

the CHG (charge) indicator,

all functions and display

indicators disabled.

All functions disabled.

Battery Power Indicator and Recover Indicator

The battery power indicator on the display shows you the current status of the

rechargeable battery’s power.

Battery power

indicator

• The flashing LOW indicator at Level 3 tells you that battery power is very low, and

that exposure to bright light for charging is required as soon as possible.

• At Level 5, all functions are disabled and settings return to their initial factory

defaults. Once the battery reaches Level 2 after falling to Level 5, reconfigure the

current time, date, and other settings.

• The watch’s Home City code setting will change automatically to TYO (Tokyo)

whenever the battery drops to Level 5.

•

Display indicators reappear as soon as the batter y is charged from Level 5 to Level 2.

• Leaving the watch exposed to direct sunlight or some other very strong light source

can cause the battery power indicator to show a reading temporarily that is higher

than the actual battery level. The correct battery level should be indicated after a few

minutes.

• Performing illumination, or beeper operations during a

short period may cause the recover indicator to appear

on the display.

After some time, battery power will recover and the

recover indicator will disappear, indicating that the above

functions are enabled again.

• If the recover indicator appears frequently, it probably

means that remaining battery power is low. Leave the

watch in bright light to allow it to charge.

Recover indicator

Charging Precautions

Certain charging conditions can cause the watch to become very hot. Avoid leaving

the watch in the areas described below whenever charging its rechargeable battery.

Also note that allowing the watch to become ver y hot can cause its liquid crystal

display to black out. The appearance of the LCD should become normal again when

the watch returns to a lower temperature.

Warning!

Leaving the watch in bright light to charge its rechargeable battery can cause it

to become quite hot. Take care when handling the watch to avoid burn injury.

The watch can become particularly hot when exposed to the following

conditions for long periods.

• On the dashboard of a car parked in direct sunlight

• Too close to an incandescent lamp

• Under direct sunlight

Exposure Level (Brightness)

Outdoor Sunlight (50,000 lux)

Sunlight Through a Window (10,000 lux)

Daylight Through a Window on a Cloudy Day (5,000 lux)

Indoor Fluorescent Lighting (500 lux)

Approximate

Exposure Time

5 minutes

24 minutes

48 minutes

8 hours

Charging Guide

The following table shows the amount of time the watch needs to be exposed to light

each day in order to generate enough power for normal daily operations.

• For details about the battery operating time and daily operating conditions, see the

“Power Supply” section of the Specifications.

• Stable operation is promoted by frequent exposure to light.

Recovery Times

The table below shows the amount exposure that is required to take the battery from

one level to the next.

Approximate Exposure Time

Level 5 Level 4 Level 3 Level 2 Level 1

2 hours 20 hours 6 hours

8 hours 98 hours 27 hours

15 hours 199 hours 53 hours

169 hours - - - - - - - - - - - - - - - -

Exposure Level

(Brightness)

Outdoor Sunlight

(50,000 lux)

Sunlight Through a

Window (10,000 lux)

Daylight Through a

Window on a Cloudy

Day (5,000 lux)

Indoor Fluorescent

Lighting (500 lux)

• The above exposure time values are all for reference only. Actual required exposure

times depend on lighting conditions.

▲

Reference

This section contains more detailed and technical information about watch operation.

It also contains important precautions and notes about the various features and

functions of this watch.

Button Operation Tone

The button operation tone sounds any time you press one

of the watch’s buttons. You can turn the button operation

tone on or off as desired.

• Even if you tur n off the button operation tone, alarms,

the Hourly Time Signal, and other beepers all operate

normally.

Mute indicator

To turn the button operation tone on and off

1. In the Timekeeping Mode, hold down A until the city

code starts to flash, which indicates the setting screen.

2. Press C nine times until the current button operation

tone setting ( or ) appears.

3. Press D to toggle the setting between (tone on)

and (tone off).

4. Press to exit the setting screen.A

• The mute indicator is displayed in all modes when the

button operation tone is turned off.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	G-Shock GX-56BBGRLR-1ER
Typ av operation:	Knoppen
Färg på produkten:	Grey, White
Antal effektnivåer:	2
Inbyggd display:	Ja
Timer:	Ja
Vikt:	1800 g
Bredd:	210 mm
Djup:	150 mm
Höjd:	300 mm
Förpackningens bredd:	225 mm
Djuppackning:	165 mm
Förpackningshöjd:	315 mm
Snäll:	Ventilator elektrisch verwarmingstoestel
Avfrostningsfunktion:	Ja
Användarmanual:	Ja
Husmaterial:	Kunststof
Mobila operativsystem som stöds:	Android, iOS
På / Av knapp:	Ja
Beeldscherm:	LCD
Temperatur (min):	7 °C
Lämplig för:	Binnen
Justerbar termostat:	Ja
Temperatur (max):	38 °C
Fjärrstöd för smartphone:	Ja
Fjärrstyrd:	Ja
Wifi:	Ja
AC-ingångsspänning:	220 - 240 V
AC-ingångsfrekvens:	50 Hz
Timerlängd (max):	24 uur
Värmekraft:	2000 W
Placeringsalternativ:	Desk, Table
Värmeeffekt (min):	900 W
Sommarventilation:	Ja
Autosvängning:	Ja
Anti-lutningsskydd:	Ja
Anti-vorstmodus:	Ja
