Basic Operations

This section provides an overview of the watch

and its operations.

Note

●The illustrations included in this

manual have been created to

facilitate explanation. An illustration

may differ somewhat from the item it

represents.

General Guide

③① ②

⑤

④

⑥ ⑦ ⑧

⑨

AHour hand

BSecond hand

CMinute hand

D24-hour hand

ESmall minute hand

FSmall hour hand

GMode hand

HDay indicator

ICrown

Watch Face Items

①

②

③

④

⑤

⑥

⑦

⑨

⑧

⑩

⑪

⑫

⑬

ASignal receive result

BAlarm off

CAlarm on

DTime calibration reception in progress

EGPS signal time information and position

information acquisition in progress

FGPS signal time information reception in

progress

GSummer time setting

HApproximate latitude

(N side: North latitude, S side: South

latitude)

IDay of the week

JAirplane Mode

KStopwatch Mode

LTimer Mode

MAlarm Mode

Navigating Between Modes

Your watch has four modes.

You tell which mode the watch is currently in

by checking the position of the mode hand.

●Timekeeping Mode (normal timekeeping):

Current day of the week

●Stopwatch Mode: ST (STW)

●Timer Mode: TR

●Alarm Mode: AL

Timekeeping Mode

Mode hand

Alarm Mode

Timer Mode

Stopwatch Mode

Use the (C) button to navigate between

modes.

●Hold down (C) for at least two seconds to

return to the Timekeeping Mode.

●Holding down (C) for four seconds or longer

will enter or exit the Airplane Mode. The

mode hand points to h while the watch is in

the Airplane Mode.

l Using the Watch on an Aircraft

Using the Crown

The watch’s crown is a screw-in (screw lock)

type. To use the crown, you first need to rotate

it towards you (leftwards) to loosen it.

Loosen

Crown

Important!

●To prevent loss of water resistance

and/or damage due to impact, be

sure to push the crown in and lock it

when not in use.

●When pushing the crown back in,

take care not to apply too much

force.

●Fast Forward/Fast Reverse

Normal position

Second click

First click

Crown

After pulling out the crown to the first or second

click, rotating it quickly in succession in either

direction will start a fast forward or fast reverse

operation. While a fast forward operation is in

progress, quickly rotating the crown in

succession again will increase the speed even

further.

●The fast reverse operation speed is fixed

and cannot be changed.

●Stopping Fast Forward/Fast Reverse

Rotate the crown in the direction opposite that

of the ongoing operation or press any button.

Note

●If you do not perform any operation

for about two minutes after pulling

out the crown, crown operations will

automatically become disabled. If

that happens, push the crown back

in and then pull it out again.

Operation Guide 5411

Solar Charging

What is solar charging?

This watch runs on power supplied from a

rechargeable (secondary) battery that is

charged by a solar panel. The solar panel is

integrated into the face of the watch, and

power is generated whenever the face is

exposed to light.

●This watch uses a special rechargeable

(secondary) battery.

ーThe watch’s battery will not charge if the

watch’s temperature is less than

approximately -10°C (14°F) or greater

than approximately 60°C (140°F).

ーOver-discharge will occur if the watch is

not charged within approximately three

months after it stops operation due to low

battery power. Charging may not be

possible after over-discharge occurs.

Charging the Watch

When you are not wearing the watch, put it in

a location where it is exposed to bright light.

While you are wearing the watch, make sure

that its face (solar panel) is not blocked from

the light by the sleeve of your clothing. Power

generation efficiency is reduced even when

the face of the watch is blocked only partially.

NOYES

Important!

●If the second hand stops for some

time after the watch is continuously

exposed to light, it could mean that

charging is not possible due to over-

discharge. Request chargeable

(secondary) battery replacement by

your original retailer or authorized

CASIO service center.

●Depending on light intensity and

local conditions, the watch may

become hot to the touch when

exposed to light for charging. Take

care to avoid burn injury after

charging. Also, avoid charging the

watch under high-temperature

conditions like the ones described

below.

ーOn the dashboard of a vehicle

parked in the sun

ーNear an incandescent light bulb or

other source of heat

ーUnder direct sunlight or in other

hot areas for long periods

Note

●Exposing the watch face to light after

the battery goes dead will cause the

second hand to revolve

counterclockwise until it stops at

second 57. This indicates charging

has started.

●A fully charged watch can operate

for approximately seven months

without further charging. Watch

operation will stop approximately 20

days after the battery goes low.

Charging Time Guidelines

The table below shows guidelines for

approximate charging times.

Required Charging Time for 1-day Use

Light Intensity Approximate Charging Time

High

Low

A8 minutes

B30 minutes

C48 minutes

D8 hours

Time Required to Achieve Next Charge

Level

Light Intensity

Approximate Charging Time

Charge Level

High

Low

A8 hours 37 hours

B26 hours 139 hours

C40 hours 225 hours

D449 hours -

Light Intensity

ASunny day, outdoors (50,000 lux)

BSunny day, near a window (10,000 lux)

COvercast day, near a window (5,000 lux)

DIndoor fluorescent lighting (500 lux)

Charge Level 1 :

Time from dead battery until hand movement

starts

Charge Level 2 :

Time from hand movement starts until a full

charge

Note

●Actual charging time depends on the

local charging environment.

Checking the Charge Level

The charge level is indicated by watch hand

movement. Functions become disabled as

battery power goes low.

Important!

●Should battery go low or go dead,

expose the face (solar panel) to light

as soon as possible.

Immediately after pressing (C) to enter to the

Timekeeping Mode, the second hand will

move to one of the positions below to indicate

the battery charge level.

●Battery Charged

2 o'clock12 o'clock

Operation Guide 5411

●Low Battery Power

6 o'clock4 o'clock

Also, the second hand jumps at two-second

or five-second intervals.

Second hand

Two-second intervals Five-second intervals

●Above right figures indicate a lower battery

charge.

●Dead Battery

All hands are stopped.

Power Saving Function

Leaving the watch in a dark location for about

one hour between the hours of 10 p.m. and 6

a.m. will cause the second hand to stop, and

the watch will enter Level 1 power saving. If

the watch is left in this condition for six or

seven days, all hands will stop and the watch

will enter Level 2 power saving.

Level 1 :

Basic timekeeping functions are operational.

Level 2 :

Only the day indicator is operational.

Note

●Note that the watch also may enter

the power saving state if its face is

blocked from light by your sleeve

while you are wearing it.

●The watch will enter power saving

from the Timekeeping Mode only.

●Recovering from Power Saving

Operation

Press any button or place the watch in a well-

lit area to recover from power saving.

Time Adjustment (GPS,

Time Calibration

Signal)

The watch’s time, day, and Home City (time

zone) settings can be configured in

accordance with a received GPS signal or

time calibration signal.

●GPS signal position information: Used to

update Home City (time zone), time, and

day settings.

●GPS signal time information: Used to

update time and day settings.

●Time calibration signal: Used to update time

and day settings.

Important!

●Before trying to receive GPS signal

time information and/or a time

calibration signal, first use GPS to

acquire position information and

configure Home Time (time zone)

settings.

●Put the watch into the Airplane Mode

whenever you are inside an aircraft

or in any other area where radio

wave reception is prohibited or

restricted.

l Using the Watch on an Aircraft

Note

●Areas where time calibration signal

reception is supported are limited.

When the watch in an area where

time calibration signal reception is

not supported, adjust time and day

settings based on GPS signals.

l Time Calibration Signal

Reception Ranges

Time Adjustment Using GPS

Appropriate Signal Reception

Location

GPS signal reception is possible outdoors

where the sky is visible and not blocked by

buildings, trees, or other objects.

Note

●In areas where reception is poor,

keep the watch face oriented

upwards and do not move the watch.

●When the watch is set up for auto

receive, take care to avoid covering

the watch face with the sleeve of

your clothing.

●GPS signal reception is not possible

in the areas described below.

ーWhere the sky is not visible

ーIndoors (Reception may be

possible near a window.)

ーNear wireless communication

equipment or other devices that

generate magnetism.

●You may experience GPS signal

reception problems in the areas

described below.

ーWhere the view of the sky above

is narrow

ーNear trees or buildings

ーNear a train station, airport, or

other congested areas

Acquiring GPS Position Information

Manually

You can use a button operation to acquire

GPS position information and adjust your

Home City (time zone), time, and day settings

in accordance with your current location.

Note

●GPS signal reception requires large

amounts of power. Perform it only

when necessary.

Operation Guide 5411

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	G-Shock MRG-G1000B-1A4DR

Behöver du hjälp?

Om du behöver hjälp med Casio G-Shock MRG-G1000B-1A4DR ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
