Operation Guide 5081

MO0911-EA

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out of your

purchase, be sure to read this manual carefully.

About This Manual

•Depending on the model of your watch, display text appears either as dark figures

on a light background or light figures on a dark background. All sample displays in

this manual are shown using dark figures on a light background.

•Button operations are indicated using the letters shown in the illustration.

•Each section of this manual provides you with the information you need to perform

operations in each mode. Further details and technical infor mation can be found in

the “Reference” section.

Alarm Mode

Countdown Timer Mode

World Time Mode

Stopwatch Mode

▲

General Guide

•Press C to change from mode to mode.

•In any mode (except a setting mode), press to illuminate the display.B

Timekeeping Mode

Press .C

▲

Timekeeping

You can adjust the Home Time city date and time in the Timekeeping Mode.

•Pressing D in the Timekeeping Mode will toggle lower left display between the

screens shown below.

Home City Date Home City Time

▲

Date Seconds

Day of the week

Hour

Minutes

SecondsPM indicator

Day of the week

To set the time and date

1. In the Timekeeping Mode, hold down A for about three

seconds until the city code flashes on the lower right

display. This is the setting mode.

2. Use D and B to select the city code you want.

•Make sure you select your Home City code before

changing any other setting.

•For full information on city codes, see the “City Code

Table”.

Hour

Minutes

City code

PM indicator Seconds

3. Press C to change the flashing screen content in the sequence shown below to

select the other setting.

Seconds

12/24-Hour

Format Hour

Minutes

DST

Month Year

City Code

Day

Illumination

Duration

4. When the timekeeping setting you want to change is flashing, use D or B to

change it as described below.

Change the city code

Toggle the DST setting between

Daylight Saving Time ( ) and

Standard Time ( ).

Use D (east) and B

(west).

Press D.

To do this: Do this:Screen:

5. Press A to exit the setting mode.

•The day of the week is displayed automatically in accordance with the date (year,

month, and day) settings.

Toggle between 12-hour ( ) and

24-hour ( ) timekeeping

Reset the seconds to

Change the hour and minutes

Change the year, month, or day

Toggle the display illumination

duration between 1.5 seconds ( )

and three seconds ( )

Press D.

Use D (+) and B (–).

Press D.

Daylight Saving Time (DST)

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down A for about three

seconds until the city code flashes on the lower right

display. This is the setting mode.

2. Press C. This will display the DST setting screen.

3. Use D to toggle the DST setting on and off.

DST off ( ) DST on ( )

•The default DST setting is OFF ( ).

4. When the setting you want is selected, press A to exit

the setting mode.

• The DST indicator appears to indicate that Daylight

Saving Time is tur ned on.

DST indicator

12-hour and 24-hour timekeeping

•With the 12-hour format, the PM indicator appears above the hour digits for times in

the range of noon to 11:59 p.m. and no indicator appears for times in the range of

midnight to 11:59 a.m.

•With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without

the PM indicator.

•The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all other modes.

Stopwatch

You can use the stopwatch to measure elapsed time, lap

times and split times. If you specify a distance value, the

stopwatch also will calculate and display speeds.

•The digital display range of the stopwatch is 99 hours,

59 minutes, 59.999 seconds. The stopwatch continues

to run until you stop it. If it reaches the above limit, it will

restart the time measurement from zero.

•The stopwatch operation continues even if you exit the

Stopwatch Mode. If you exit the Stopwatch Mode while a

stopwatch operation is in progress, the segments in the

upper right dial will appear and disappear sequentially

as stopwatch seconds are counted. This is to let you

know that a stopwatch operation is in progress.

•All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing C.

Speed hand

Important!

•Check to make sure that the speed hand is not moving before you perform any

Stopwatch Mode button operation.

Specifying a Distance Value

You can use the procedure below to specify a distance value, if you want. If you

specify a distance value, the watch will calculate and indicate speed for certain

stopwatch operations.

•The distance value represents kilometers, miles, or any other distance unit you want.

Specifying a distance value of 10.0, for example, can mean 10.0 kilometers or 10.0

miles.

•No speed calculation is performed when 0.0 is specified as the current distance

value.

•For lap time readings, you can specify either the lap distance (when all the laps are

the same distance) or the total race distance.

•For split time readings, you can specify the total race distance only. Though the

watch will indicate a speed each time you take a split reading, they will be based on

the total race distance, and so they will not indicate actual intermediate split speeds.

Operation Guide 5081

To specify a distance value

1. In the Stopwatch Mode, make sure the stopwatch is

stopped and reset to all zeros.

•If you need to reset the stopwatch to all zeros, press A.

2. Hold down A for about three seconds until the watch

beeps, DIST ( ) appears in the lower right display,

and the left digit of the current distance value setting

flashes in the lower left display.

•This is the distance value setting mode.

3. Press C to move the flashing between the values on

the left side and right side of the distance value digit

decimal point.

4. While either the left or right distance value is flashing,

use D (+) and B (–) to change it.

•You can specify a distance value in the range of 0.1 to

99.9.

5. After specifying the distance value you want, press A

to exit the setting mode.

How speed is indicated

•While an elapsed time measurement operation is being

performed in the Stopwatch Mode, the watch will display

a speed value, which is calculated based on the

distance you specified and the elapsed time. The speed

is indicated by the upper right dial, two indicators (1000

and MACH), and the speed hand.

•The upper right dial indicates the 100s digit value.

•1000 appears when the speed exceeds 1,000.

•MACH appears when the speed exceeds 1,226.

•The speed hand indicates speed values less than 100.

Only even-numbered values are indicated.

Example:

At a speed of 1,740, the upper right dial indicates 1000

and MACH is displayed.

The upper right dial indicates 700.

The speed hand indicates 40.

•Speed can be indicated from 0 to 1998. OVER is

indicated by the speed hand when the speed exceeds

1998.

Speed hand

Upper

right dial

OVER

Mach (MACH)

Speed (1000)

Time Measurement

You need to specify either lap time or split time measurement before you start a

stopwatch operation.

•If you want to measure total elapsed time, select split time measurement.

To specify lap time or split time readings

1. In the Stopwatch Mode, make sure the stopwatch is stopped and reset to all zeros.

•Make sure that LAP SPL (lap times) or (split times) is shown in the lower right

display.

•If you need to reset the stopwatch to all zeros, press A.

2. Press A to toggle between LAP (lap times) and SPL (split times) in the lower right

display.

▲

Elapsed Time Measurement

Use the following procedure to measure elapsed time, without taking lap time or split

time readings.

To perform elapsed time measurement

Select split time (SPL) measurement and then perform the following button operations.

D D A Start ➝ Stop ➝ Reset

•If you have a distance value specified for the current elapsed time measurement, the

upper right dial and speed hand will indicate the overall speed when you press D to

stop the elapsed time operation.

•After pressing D D to stop an elapsed time operation, you could press again to

restart from the point where you left off.

Lap Time

A lap time reading shows the time elapsed since the last

lap time reading was taken.

•If you want the watch to calculate the speed of each lap

(when all of the laps are the same distance), specify the

lap distance for the distance setting.

•If you want the watch to calculate the speed of the entire

race, specify the race distance for the distance setting. A

speed will be indicated each time you take a lap

reading, but these lap speeds will not indicate actual

speed of the entire race.

To set up the stopwatch to take lap time readings

1. In the Stopwatch Mode, make sure the stopwatch is stopped and reset to all zeros.

•If you need to reset the stopwatch to all zeros, press A.

2. Make sure that LAP (lap times) is shown in the lower right display.

•If SPL (split times) is displayed, press A to toggle it to LAP.

Lap time

To perform a lap time measurement

Select lap time (LAP) measurement and then perform the

following button operations.

D A A Start ➝ Lap* ➝ Lap* ➝

D A Stop ➝ Reset

* The lap time is released automatically in about 12

seconds.

•You can press to take lap readings as many times asA

you like. The LAP indicator flashes while a lap reading is

displayed.

•A lap number (#01 through #99) alternates with the lap

hour value in the lower right display while a lap time

reading is displayed. If you take more than 99 lap

readings, the lap number will restart from following#00

lap .#99

•Pressing D to stop elapsed time measurement displays

the time (and speed if a distance is specified) of the final

lap.

Lap number

Speed

(calculated)

Minutes

Seconds

LAP

indicator

1/1000

seconds

Split Time

A split time reading shows the time elapsed since the

beginning of the current time measurement.

•If you want the watch to calculate the speed of the race,

specify the race distance for the distance setting.

•For split time readings, you can specify the total race

distance only. Though the watch will indicate a speed

each time you take a split reading, they will be based on

the total race distance, and so they will not indicate

actual intermediate split speeds.

To set up the stopwatch to take split time readings

1. In the Stopwatch Mode, make sure the stopwatch is stopped and reset to all zeros.

•If you need to reset the stopwatch to all zeros, press A.

2. Make sure that SPL (split times) is shown in the lower right display.

•If LAP (lap times) is displayed, press A to toggle it to SPL.

Split time

To perform a split time measurement

Select split time (SPL) measurement and then perform

the following button operations.

D A A Start ➝ Split ➝ Split Release* ➝

D A Stop ➝ Reset

* The split time is released automatically if you do not

press A within about 12 seconds.

•You can press to take split readings as many timesA

as you like. The SPLIT indicator flashes while a lap

reading is displayed.

•The stopwatch continues elapsed time measurement

internally while a split time reading is displayed.

Pressing A to release the split will switch the lower left

display to the elapsed time measurement, or you also

could press to stop elapsed time measurementD

instead.

•Pressing D to stop elapsed time measurement displays

the time (and speed if a distance is specified) of the final

split (which is the overall elapsed time).

Hour

1/1000

seconds

Minutes

Seconds

Speed (calculated)

SPLIT indicator

To measure times with the stopwatch

Elapsed Time

Lap Time

Split Time

Start Stop Reset

➤ ➤ A

Start

(SPL displayed)

Split Split release Stop

A DA

➤➤➤

Reset

➤

Start

(LAP displayed)

Lap

(Lap01)

Stop Reset

D A

➤ ➤ ➤

A➤

Lap

(Lap02)

Countdown Timer

You can set the countdown timer start time within a range

of one minute to 24 hours. An alarm sounds when the

countdown reaches zero.

•You also can select auto-repeat, which automatically

restarts the countdown from the original value you set

whenever zero is reached.

•All of the operations in this section are performed in the

Countdown Timer Mode, which you enter by pressing

Seconds

Auto-repeat off

Start time

(Hours

Minutes)

To use the countdown timer

Press while in the Countdown Timer Mode to start the countdown timer.D

•When the end of the countdown is reached, the alarm will sound for 10 seconds or

until you stop it by pressing any button.

•The countdown time is reset to its starting value automatically after the alarm stops

if auto-repeat is turned off.

•When auto-repeat is turned on, the countdown will restart automatically without

pausing when it reaches zero.

•The countdown timer measurement operation continues even if you exit the

Countdown Timer Mode.

•Press D while a countdown operation is in progress to pause it.

Press D again to resume the countdown.

•To stop a countdown timer operation completely, first pause it (by pressing ), andD

then press . This returns the countdown time to its starting value.A

To configure countdown start time and auto-repeat settings

1. While the countdown start time is on the display in the

Countdown Timer Mode, hold down A for about three

seconds until the hour setting of the countdown start

time star ts to flash. This is the setting mode.

•If the countdown start time is not displayed, use the

procedure under “To use the countdown timer” to

display it.

2. Press C to move the flashing in the sequence shown

below, and select the setting you want to change.

Start Time

(Minutes)

Auto-Repeat

On/Off

Start Time

(Hours)

3. Perform the following operations, depending on which setting currently is selected

on the display.

•While the start time setting is flashing, use D B (+) and (–) to change it.

•While the auto-repeat on/off setting is flashing on the display, press D to toggle

auto-repeat on (

) and off ( ).

Start time

(Hours

Minutes)

Auto-repeat on

4. Press A to exit the setting mode.

•The auto-repeat on ( ) is displayed on the Countdown Timer Mode screen while

this function is turned on.

Operation Guide 5081

World Time

World Time digitally displays the current time in one of

48 cities (29 time zones) around the world. A simple

operation swaps your Home City with the currently

selected World Time City.

•The times kept in the World Time Mode are

synchronized with the time being kept in the

Timekeeping Mode. If you feel that there is an error in

any World Time Mode time, check to make sure you

have the correct city selected as your Home City. Also

check to make sure that the current time as shown in

the Timekeeping Mode is correct.

•Times in the World Time Mode are based on UTC

offsets. See the “City Code Table” for information about

the UTC offsets that are supported.

•All of the operations in this section are performed in the World Time Mode, which

you enter by pressing C.

Currently selected

World Time City

World Time

▲

Press A.

One second

Hour

Minutes

To view the current time in another time zone

In the World Time Mode, use D to scroll through available city codes (time zones).

Holding down the button scrolls at high speed.

•The lower left display shows the current time in the World Time City.

•Between the noon and midnight in the World Time Mode, a PM indicator (PM)

appears above the hour digits in the lower left display.

•When the city code (time zone) you want is selected, you can press to displayA

the date. After about one second, the watch will resume regular timekeeping for the

currently selected city.

Seconds Date

PM indicator

To toggle a city code time between Standard Time and Daylight Saving Time

1. In the World Time Mode, press D to display the city

code (time zone) whose Standard Time/Daylight Saving

Time setting you want to change.

2. Hold down A for about three seconds to toggle

between Daylight Saving Time ( DST indicator

displayed) and Standard Time ( indicator notDST

displayed).

•The DST indicator is shown in the lower left display

while Daylight Saving Time is turned on.

•You can turn on DST individually for each city code,

except UTC.

•Turning on DST for the city code that is currently

selected as your Home City will turn on DST for normal

timekeeping.

DST indicator

Swapping your Home City and World Time City

You can use the procedure below to swap your Home City and World Time City. This

changes your Home City to your World Time City, and your World Time City to your

Home City. This capability can come in handy when you frequently travel between two

cities in different time zones.

To swap your Home City and World Time City

1. In the World Time Mode, use D to select the World Time City you want.

2. Hold down A B and until the watch beeps.

• This will make the World Time City you selected in step 1 your Home City, and cause

the hour and minute hands to move to the current time in that city. At the same time,

it will change the Home City you had selected prior to step 2 your World Time City,

and cause the content of lower left display to change accordingly.

• After swapping the Home City and World Time City, the watch stays in the World

Time Mode with the city that was selected as the Home City prior to step 2 now

displayed as the World Time City.

Alarms

When an alarm is turned on, the alarm tone will sound

when its alarm time is reached. One of the alarms is a

snooze alarm, while the other four are daily alarms.

You also can turn on an Hourly Time Signal that causes

the watch to beep twice every hour on the hour.

•There are five alarm screens numbered AL1 AL2, ,

AL3 AL4 and for the daily alarm, and a snooze alarm

screen indicated by SNZ. The Hourly Time Signal

screen is indicated by SIG.

•All of the operations in this section are performed in the

Alarm Mode, which you enter by pressing C.

Alarm number

Alarm time

(Hour

Minutes)

To set an alarm time

1. In the Alarm Mode, use D to scroll through the alarm

screens until the one whose time you want to set is

displayed.

•To set a daily alarm, display alarm screen AL1,

AL2 AL3 AL4, or . To set the snooze alarm,

display the SNZ screen.

•SIG is the hourly time signal setting.

•The snooze alarm repeats every five minutes.

2. After you select an alarm, hold down A for about three seconds until the hour

setting of the alarm time starts to flash. This is the setting mode.

•This operation turns on the alarm automatically.

3. Press C to move the flashing between the hour and minute settings.

4. While a setting is flashing, use D B (+) and (–) to change it.

5. Press A to exit the setting mode.

OFF

Alarm Operation

The alarm tone sounds at the preset time for 10 seconds, regardless of the mode the

watch is in. In the case of the snooze alarm, the alarm operation is performed a total

of seven times, every five minutes, or until you turn the alarm off.

•Alarm and Hourly Time Signal operations are performed in accordance with the

current time in your Home City, as kept in the Timekeeping Mode.

•To stop the alarm tone after it starts to sound, press any button.

•Performing any one of the following operations during a 5-minute interval between

snooze alarms cancels the current snooze alarm operation.

Displaying the Timekeeping Mode setting screen

Displaying the

SNZ

setting screen

To turn an alarm on and off

1. In the Alarm Mode, use to select an alarm.D

2. Press to toggle it on and off.A

•Turning on a alarm (AL1 AL2 AL3 AL4, , , or

SNZ) displays the alarm on indicator on its Alarm

Mode screen.

•In all modes, the alarm on indicator is shown for any

alarm that currently is turned on.

•The alarm on indicator flashes while the alarm is

sounding.

•The snooze alarm indicator flashes while the snooze

alarm is sounding and during the 5-minute intervals

between alarms.

Alarm on

indicator

Snooze

alarm

indicator

To turn the Hourly Time Signal on and off

1. In the Alarm Mode, use D to select the Hourly Time

Signal (SIG).

2. Press to toggle it on and off.A

•The Hourly Time Signal on indicator is shown on the

display in all modes while this function is turned on.

Hourly time signal

on indicator

Illumination

An LED (light-emitting diode) illuminates the face of the

watch for easy reading in the dark. The watch’s auto light

switch turns on illumination automatically when you angle

the watch towards your face.

•The auto light switch must be turned on (indicated by

the auto light switch indicator) for it to operate.

•See “Illumination Precautions” for other important

information about using illumination.

To illuminate the display manually

In any mode, press to turn on illumination.B

•The above operation turns on illumination regardless of

the current auto light switch setting.

•You can use the procedure below to select either 1.5

seconds or 3 seconds as the illumination duration. When

you press , the illumination will remain on for aboutB

1.5 seconds or 3 seconds, depending on the current

illumination duration setting.

Auto light switch

indicator

To specify the illumination duration

1. In the Timekeeping Mode, hold down A until the

display contents start to flash. This is the setting screen.

2. Press C nine times to display the current illumination

duration LT1 (LT1) or LT3 (LT3).

3. Press D to toggle the setting between LT1(1.5

seconds) and LT3 (three seconds).

4. Press A to exit the setting screen.

About the Auto Light Switch

Turning on the auto light switch causes illumination to turn on, whenever you position

your wrist as described below in any mode.

Moving the watch to a position that is parallel to the ground and then tilting it towards

you more than 40 degrees causes illumination to turn on.

• Wear the watch on the outside of your wrist.

Parallel to

ground More than

40°

Warning!

••

•Always make sure you are in a safe place whenever you are reading the

display of the watch using the auto light switch. Be especially careful when

running or engaged in any other activity that can result in accident or injury.

Also take care that sudden illumination by the auto light switch does not

startle or distract others around you.

••••

•When you are wearing the watch, make sure that its auto light switch is turned

off before riding a bicycle or operating a motorcycle or any other motor

vehicle. Sudden and unintended operation of the auto light switch can create a

distraction, which can result in a traffic accident and serious personal injury.

To turn the auto light switch on and off

In the Timekeeping Mode, hold down B for about three seconds to toggle the auto

light switch on (auto light switch indicator displayed) and off (auto light switch indicator

not displayed).

•The auto light switch indicator remains in all modes while the auto light switch is

turned on.

•In order to protect against running down the battery, the auto light switch will turn off

automatically approximately six hours after you turn it on. Repeat the above

procedure to turn the auto light switch back on if you want.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	GA-100L-7A
Djup:	70 mm
Höjd:	115 mm
Nuvarande:	6 A
Certifiering:	EN 61009-1, IEC 61009-1
Frekvens:	50 Hz
Spänningsklassificering:	240 V
Antal stolpar:	1
Tripskurva typ:	Type C
Antal moduler (max):	1 module(s)
Märkström (30 °C):	6 A
Typ av restflöde:	Type A
