Operation Guide 5146 5425

E-1

About This Manual

• Depending on the model of your watch, display text appears either as dark ﬁ gures

on a light background or light ﬁ gures on a dark background. All sample displays in

this manual are shown using dark ﬁ gures on a light background.

• Button operations are indicated using the letters shown in the illustration.

• Note that the product illustrations in this manual are intended for reference only,

and so the actual product may appear somewhat different than depicted by an

illustration.

Graphic (moves with seconds count)

Module 5146 only

Module 5425Module 5146

E-2

• Each section of this manual provides you with the information you need to perform

operations in each mode. Further details and technical information can be found in

the “Reference” section.

E-3

Contents

General Guide ………………………………………………………………………… E-6

Timekeeping …………………………………………………………………………… E-8

To set the digital time and date ……………………………………………… E-9

To change the Daylight Saving Time (summer time) setting ………………E-12

Stopwatch ………………………………………………………………………………E-14

To specify a distance value ……………………………………………………E-16

To specify lap time or split time readings ……………………………………E-18

To perform elapsed time measurement ………………………………………E-19

To set up the stopwatch to take lap time readings …………………………E-20

To perform a lap time measurement …………………………………………E-21

To set up the stopwatch to take split time readings …………………………E-22

To perform a split time measurement …………………………………………E-23

To measure times with the stopwatch ………………………………………E-24

E-4

Countdown Timer………………………………………………………………………E-25

To use the countdown timer ……………………………………………………E-26

To conﬁ gure countdown start time and auto-repeat settings ………………E-27

World Time ………………………………………………………………………………E-29

To view the current time in another time zone ………………………………E-30

To toggle a city code time between Standard Time and Daylight

Saving Time …………………………………………………………………E-31

To swap your Home City and World Time City ………………………………E-32

Alarms ……………………………………………………………………………………E-33

To set an alarm time ……………………………………………………………E-34

To turn an alarm on and off ……………………………………………………E-36

To turn the Hourly Time Signal on and off ……………………………………E-37

E-5

Illumination ……………………………………………………………………………E-38

To illuminate the display manually ……………………………………………E-38

To specify the illumination duration……………………………………………E-39

To turn the auto light switch on and off ………………………………………E-41

Hand Home Position Correction ……………………………………………………E-42

To adjust home positions ………………………………………………………E-42

Reference ………………………………………………………………………………E-44

Speciﬁ cations …………………………………………………………………………E-48

E-6

Timekeeping Mode

Press .&

General Guide

• Press & to change from mode to mode.

• In any mode (except a setting mode), press % to illuminate the display.

E-7

Alarm Mode (page E-33)

Countdown Timer Mode (page E-25)

World Time Mode (page E-29)

Stopwatch Mode (page E-14)

E-8

Timekeeping

You can adjust the Home Time city date and time in the Timekeeping Mode.

• The analog time of this watch is synchronized with the digital time. The analog time

setting is adjusted automatically whenever you change the digital time.

• If the analog time does not match the digital time for any reason, use the procedure

described under “To adjust home positions” (page E-42) to match the analog

setting to the digital setting.

• Pressing

' in the Timekeeping Mode toggles digital display between the Home

City Date and Home City Time.

Home City Date Home City Time

Month Day Seconds

Day of wee

Hour : Minutes Seconds

PM indicator

Day of week

E-9

To set the digital time and date

1. In the Timekeeping Mode, hold down $ for about three

seconds until the currently selected city code ﬂ ashes in

the upper digital display. This is the setting mode.

2. Use ' (east) and % (west) to select the city code you

want.

• Make sure you select your Home City code before

changing any other setting.

• For full information on city codes, see the “City

Code Table” at the back of this manual.

Hour : Minutes

City code

PM indicator Second

Operation Guide 5146 5425

E-10

3. Press & to change the ﬂ ashing screen content in the sequence shown below to

select the other settings.

Seconds

12/24-Hour

Format Hour

Minutes

DST

Month Year

City Code

Day

Illumination

Duration

4. When the setting you want to change is ﬂ ashing, use ' or % to change it as

described below.

Screen: To do this: Do this:

Change the city code Use

' (east) and % (west).

Toggle the DST setting between

Daylight Saving Time (

on ) and

Standard Time (OFF).

Press '.

Toggle between 12-hour (

12H) and

24-hour (24H) timekeeping Press '.

E-11

Screen: To do this: Do this:

Reset the seconds to 00 Press '.

Change the hour and minutes

Use ' (+) and % (–).

Change the year, month, or day

Toggle the display illumination

duration between 1.5 seconds (

LT1)

and three seconds (

LT3)

Press '.

5. Press $ to exit the setting mode.

• The day of the week is displayed automatically in accordance with the date (year,

month, and day) settings.

E-12

Daylight Saving Time (DST)

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down $ for about three

seconds until the currently selected city code ﬂ ashes in

the upper digital display. This is the setting mode.

2. Press &. This will display the DST setting screen.

3. Use ' to toggle the DST setting on ( on) and off (OFF).

• The default DST setting is off (OFF).

4. When the setting you want is selected, press $ to exit

the setting mode.

• The DST indicator appears to indicate that Daylight

Saving Time is turned on.

DST indicator

E-13

12-hour and 24-hour timekeeping

• With the 12-hour format, the PM indicator (

P) appears for times in the range of noon

to 11:59 p.m. and no indicator appears for times in the range of midnight to 11:59

a.m.

• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without

the PM indicator (P).

• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all other modes.

E-14

Stopwatch

You can use the stopwatch to measure elapsed time, lap

times and split times. If you specify a distance value, the

stopwatch also will calculate and display speeds.

• The digital display range of the stopwatch is 99 hours,

59 minutes, 59.999 seconds. The stopwatch continues

to run until you stop it. If it reaches the above limit, it will

restart the time measurement from zero.

• The stopwatch operation continues even if you exit the

Stopwatch Mode. If you exit the Stopwatch Mode while

a stopwatch operation is in progress, the segments

along the top of the upper digital display (upper display

segments) will indicate the seconds of the current time.

Each segment represents one second. This is to let you

know that a stopwatch operation is in progress.

• All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing

& (page

E-7).

Speed hand

Upper display

segments

E-15

Important!

• Check to make sure that the speed hand is not moving before you perform any

Stopwatch Mode button operation.

Specifying a Distance Value

You can use the procedure below to specify a distance value, if you want. If you

specify a distance value, the watch will calculate and indicate speed for certain

stopwatch operations.

• The distance value represents kilometers, miles, or any other distance unit you

want. Specifying a distance value of 10.0, for example, can mean 10.0 kilometers

or 10.0 miles.

• No speed calculation is performed when 0.0 is speciﬁ ed as the current distance

value.

• For lap time readings, you can specify either the lap distance (when all the laps are

the same distance) or the total race distance.

• For split time readings, you can specify the total race distance only. Though the

watch will indicate a speed each time you take a split reading, they will be based

on the total race distance, and so they will not indicate actual intermediate split

speeds.

E-16

To specify a distance value

1. In the Stopwatch Mode, make sure the stopwatch is

stopped and reset to all zeros.

• If you need to reset the stopwatch to all zeros, press $.

Hold down $

for about three seconds until the current

distance value setting ﬂ ashes in the lower digital display.

• This is the distance value setting mode.

3. Press & to move the ﬂ ashing between the values on

the left side and right side of the distance value decimal

point.

4. While a distance value is ﬂ ashing, use

' (+) and % (–)

to change it.

• You can specify a distance valu e in the range of 0.1

to 99.9.

5. After specifying the distance value you want, press $

to exit the setting mode.

E-17

How speed is indicated

• While an elapsed time measurement operation is being

performed in the Stopwatch Mode, the watch will

indicate a speed value, which is calculated based on

the distance you speciﬁ ed and the elapsed time.

The speed value is indicated as described below.

Speed hand: Up to 100

Upper display segments: 100 unit

A 1000 indicator points to 1000 (located to the right of

the upper display segments) when the speed value

exceeds 1000.

• The speed hand indicates speed values less than 100.

Only even-numbered values are indicated.

•

Speed can be indicated from 0 to 1998.

OVER is indicated

by the speed hand when the speed exceeds 1998.

Example:

When the speed value is 1,740.

Speed hand: Indicates 40.

Upper display segments: Indicate 700.

1000 indicator: Displayed

Speed hand

(Up to 100)

Segments

(100 unit)

OVER

1000 indicator

E-18

Time Measurement

You need to specify either lap time (page E-20) or split time (page E-22) measurement

before you start a stopwatch operation.

•If you want to measure total elapsed time, select split time measurement.

To specify lap time or split time readings

1. In the Stopwatch Mode, make sure the stopwatch is stopped and reset to all zeros.

• Make sure that LAP (lap times) or (split times) is shown in the lower digital SPL

display.

• If you need to reset the stopwatch to all zeros, press $.

2. You can toggle between LAP (lap times) and SPL (split times) by pressing $.

E-19

Elapsed Time Measurement

Use the following procedure to measure elapsed time, without taking lap time or split

time readings.

To perform elapsed time measurement

Select split time (SPL) measurement and then perform the following button operations.

' Start ➝' Stop ➝$ Reset

•If you have a distance value (page E-15) speciﬁ ed for the current elapsed time

measurement, the upper display segments and speed hand will indicate the speed

when you press ' to stop the elapsed time operation.

•After pressing ' to stop an elapsed time operation, you could press ' again to

restart from the point where you left off.

Operation Guide 5146 5425

E-20

Lap Time

A lap time reading shows the time elapsed since the last

lap time reading was taken.

•If you want the watch to calculate the speed of each lap

(when all of the laps are the same distance), specify the

lap distance for the distance setting (page E-15).

•If you want the watch to calculate the speed of the

entire race, specify the race distance for the distance

setting (page E-15). A speed will be indicated each

time you take a lap reading, but these lap speeds will

not indicate actual speed of the entire race.

To set up the stopwatch to take lap time readings

1. In the Stopwatch Mode, make sure the stopwatch is stopped and reset to all zeros.

• If you need to reset the stopwatch to all zeros, press $.

2. Make sure that (lap times) is shown in the lower digital display.LAP

• If (split times) is displayed, press SPL $ to toggle it to .LAP

Lap time

E-21

To perform a lap time measurement

Select lap time ( ) measurement and then perform the LAP

following button operations.

' Start ➝$ Lap* ➝$ Lap* ➝

' Stop ➝$ Reset

* Normal elapsed time measurement reappears after

about 12 seconds.

• You can press $ to take lap readings as many times

as you like.

• While a lap time is displayed, the upper digital display

will alternate between the lap number (

#01 to #99) and

the lap hour value. If you take more than 99 lap

readings, the lap number will restart from #00 following

lap #99.

• Pressing ' to stop elapsed time measurement

displays the time (and speed if a distance is speciﬁ ed)

of the ﬁ nal lap.

Lap number

Speed hand

(calculated)

Minutes

Seconds

1/1000

second

Hours

E-22

Split Time

A split time reading shows the time elapsed since the

beginning of the current time measurement.

• If you want the watch to calculate the speed of the race,

specify the race distance for the distance setting (page

E-15).

• For split time readings, you can specify the total race

distance only. Though the watch will indicate a speed

each time you take a split reading, they will be based

on the total race distance, and so they will not indicate

actual intermediate split speeds.

To set up the stopwatch to take split time readings

1. In the Stopwatch Mode, make sure the stopwatch is stopped and reset to all zeros.

• If you need to reset the stopwatch to all zeros, press $.

2. Make sure that (split times) is shown in the lower digital display.SPL

• If (lap times) is displayed, press LAP $ to toggle it to .SPL

Split time

E-23

To perform a split time measurement

Select split time ( ) measurement and then perform the SPL

following button operations.

' Start ➝$ Split ➝$ Split Release*

➝

' Stop ➝$ Reset

* The split time is released automatically if you do not

press $ within about 12 seconds.

• You can press $ to take split readings as many times

as you like.

• The stopwatch continues elapsed time measurement

internally while a split time reading is displayed.

• Pressing $ while a split time is displayed will switch

back to normal elapsed time measurement. The

elapsed time will appear in the lower digital display.

• You also could press ' to stop elapsed time

measurement instead.

• Pressing ' to stop elapsed time measurement

displays the time (and speed if a distance is speciﬁ ed)

of the ﬁ nal split (which is the overall elapsed time).

Hours

1/1000

second

Minutes

Seconds

Speed hand (calculated)

E-24

To measure times with the stopwatch

Elapsed Time

D D A

Start Stop Reset

Lap Time

D A A D A

Start

(LAP displayed)

Lap

(Lap01)

Lap

(Lap02)

Stop Reset

Split Time

D A A D A

Start

(SPL displayed)

Split Split release Stop Reset

E-25

Countdown Timer

You can set the countdown start time within a range of

one minute to 24 hours. An alarm sounds when the

countdown reaches zero.

• You also can select auto-repeat, which automatically

restarts the countdown from the original value you set

whenever zero is reached.

• All of the operations in this section are performed in the

Countdown Timer Mode, which you enter by pressing

& (page E-7).

Second

Auto-repeat off

Start time

(Hours : Minutes)

E-26

To use the countdown timer

Press ' while in the Countdown Timer Mode to start the countdown timer.

• When the end of the countdown is reached, the alarm will sound for 10 seconds or

until you stop it by pressing any button.

• The countdown time is reset to its starting value automatically after the alarm stops

if auto-repeat is turned off.

• When auto-repeat is turned on, the countdown will restart automatically without

pausing when it reaches zero.

• The countdown timer measurement operation continues even if you exit the

Countdown Timer Mode.

• Press ' while a countdown operation is in progress to pause it.

• Press ' again to resume the countdown.

• To stop a countdown timer operation completely, ﬁ rst pause it (by pressing '),

and then press $. This returns the countdown time to its starting value.

E-27

To conﬁ gure countdown start time and auto-repeat settings

1. While the countdown start time is on the display in the

Countdown Timer Mode, hold down $ for about three

seconds until the hour setting of the countdown start

time starts to ﬂ ash. This is the setting mode.

• If the countdown start time is not displayed, use

the procedure under “To use the countdown timer”

(page E-26) to display it.

2. Press & to move the ﬂ ashing in the sequence shown

below, and select the setting you want to change.

Start Time

(Minutes)

Auto-Repeat

On/Off

Start Time

(Hours)

3. Perform the following operations, depending on which setting currently is selected

on the display.

• While the start time setting is ﬂ ashing, use (+) and ' % (–) to change it.

• While the auto-repeat on/off setting is ﬂ ashing on the display, press ' to

toggle auto-repeat on ( ) and off ( ).

Start time

(Hours : Minutes)

Auto-repeat on

E-28

4. Press $ to exit the setting mode.

• The auto-repeat on ( ) is displayed on the Countdown Timer Mode screen while

this function is turned on.

E-29

World Time

World Time digitally displays the current time in one of

48 cities (29 time zones) around the world. A simple

operation swaps your Home City with the currently

selected World Time City.

• The times kept in the World Time Mode are

synchronized with the time being kept in the

Timekeeping Mode. If you feel that there is an error in

any World Time Mode time, check to make sure you

have the correct city selected as your Home City. Also

check to make sure that the current time as shown in

the Timekeeping Mode is correct.

• Times in the World Time Mode are based on UTC

offsets. See the “City Code Table” at the back of this

manual for information about the UTC offsets that are

supported.

• All of the operations in this section are performed in the World Time Mode, which

you enter by pressing & (page E-7).

Currently selected

World Time City

World Time

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	GA-110LN-2AER

Behöver du hjälp?

Om du behöver hjälp med Casio GA-110LN-2AER ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
