Operation Guide 3147

MO1010-EC

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out

of your purchase, be sure to read this manual carefully.

Applications

The built-in sensors of this watch measure barometric pressure, temperature

and altitude. Measured values are then shown on the display. Such features

make this watch useful when hiking, mountain climbing, or when engaging in

other such outdoor activities.

Keep the watch exposed to bright light

The electricity generated by the solar cell of the

watch is stored by a built-in battery. Leaving or

using the watch where it is not exposed to light

causes the battery to run down. Make sure the

watch is exposed to light as much as possible.

•When you are not wearing the watch on your

wrist, position the face so it is pointed at a

source of bright light.

•You should try to keep the watch outside of

your sleeve as much as possible. Charging is

reduced significantly if the face is covered only

partially.

Bright light

Solar cell

•The watch continues to operate, even when it is not exposed to light.

Leaving the watch in the dark can cause the battery to run down, which will

cause some watch functions to be disabled. If the battery goes dead, you

will have to re-configure watch settings after recharging. To ensure normal

watch operation, be sure to keep it exposed to light as much as possible.

Bright light

Electrical

energy

All

functions

enabled

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Charge

Solar cell

(Converts light to

electrical power.)

Rechargeable battery

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Some

functions

disabled

Dis-

charge

Battery charges in the light. Battery discharges in the dark.

•The actual level at which some functions are disabled depends on the

watch model.

•Frequent display illumination can run down the battery quickly and require

charging. The following guidelines give an idea of the charging time

required to recover from a single illumination operation.

Approximately five minutes exposure to bright sunlight coming in through

a window

Approximately 50 minutes exposure to indoor fluorescent lighting

•Be sure to read “Power Supply” for important information you need to

know when exposing the watch to bright light.

If the display of the watch is blank...

If the display of the watch is blank, it means that the watch’s Power Saving

function has turned off the display to conserve power.

•See “Power Saving” for more information.

Warning!

•The measurement functions built into this watch are not intended for

taking measurements that require professional or industrial precision.

Values produced by this watch should be considered as reasonable

representations only.

•CASIO COMPUTER CO., LTD. assumes no responsibility for any loss,

or any claims by third parties that may arise through the use of this

watch.

About This Manual

•Button operations are indicated using the letters shown in the illustration.

•Each section of this manual provides you with the information you need to

perform operations in each mode. Further details and technical information

can be found in the “Reference” section.

(Light)(Light)

General Guide

•The illustration below shows which buttons you need to press to navigate

between modes.

•In any mode, press L to illuminate the display.

•You can press the button to go directly from the Timekeeping Mode toC

the Altimeter Mode. To go to the Altimeter Mode from the Barometer/

Thermometer, World Time, Stopwatch, Countdown Timer, Alarm, or Data

Recall Mode, first enter the Timekeeping Mode and then press the C

button. Timekeeping Mode

Altimeter Mode

World Time Mode

Data Recall Mode

Countdown

Timer Mode

Press D.

Stopwatch Mode

Barometer/

Thermometer Mode

Alarm Mode

▲

Press D.

▲

Press .C

▲

Radio-controlled Atomic Timekeeping

This watch receives a time calibration signal and updates its time setting

accordingly.

•This watch is designed to pick up the time calibration signals transmitted in

Germany (Mainflingen), England (Anthorn), the United States (Fort Collins),

China (Shangqiu), and Japan (Fukushima, Fukuoka/Saga).

Current Time Setting

This watch adjusts its time setting automatically in accordance with a time

calibration signal. You also can perform a manual procedure to set the time

and date, when necessary.

•The first thing you should do after purchasing this watch is to specify

your Home City (the city where you normally will use the watch). For

more information, see “To specify your Home City” below.

•When using the watch outside the areas covered by the time signal

transmitters, you will have to adjust the current time setting manually as

required. See

“Timekeeping” for more information about manual time

settings.

•The U.S. time calibration signal can be picked up by the watch while in

North America. The term “North America” in this manual refers to the area

that consists of Canada, the continental United States, and Mexico.

To specify your Home City

1. In the Timekeeping Mode, hold down untilA

the city code starts to flash, which indicates

the setting screen.

2. Press E (east) and B (west) to select the

city code you want to use as your Home City.

LON : London

PAR, BER : Paris, Berlin, Milan, Rome,

Amsterdam, Hamburg, Frankfurt,

Vienna, Barcelona, Madrid

ATH : Athens

HKG : Hong Kong

TPE TYO, : Taipei, Tokyo

LAX :Los Angeles, San Francisco, Las Vegas, Seattle/Tacoma,

Vancouver, Tijuana

City code

Hour : Minutes

indicator

Seconds

DEN :Denver, El Paso, Edmonton, Culiacan

CHI :Chicago, Houston, Dallas/Fort Worth, New Orleans, Winnipeg,

Mexico City

NYC :New York, Detroit, Miami, Boston, Montreal

Operation Guide 3147

3. Press A to exit the setting screen.

•Normally, your watch should show the correct time as soon as you select

your Home City code. If it does not, it should adjust automatically after the

next auto receive operation (in the middle of the night). You also can

perform manual receive or you can set the time manually.

•The watch will receive the time calibration signal automatically from the

applicable transmitter (in the middle of the night) and update its settings

accordingly. For information about the relationship between city codes and

transmitters, see “ ”Important! under “ ”Time Calibration Signal Reception

and Transmitters“ ”.

•See the maps under “Approximate Reception Ranges for information about”

the reception ranges of the watch.

•You can disable time signal reception, if you want. See “To turn auto receive

on and off for more information.”

Time Calibration Signal Reception

There are two different methods you can use to receive the time calibration

signal: auto receive and manual receive.

•Auto Receive

With auto receive, the watch receives the time calibration signal automatically

up to six times a day. When any auto receive is successful, the remaining

auto receive operations are not performed. For more information, see “About

Auto Receive”.

•Manual Receive

Manual receive lets you start a time calibration receive operation with the press

of a button. For more information, see To perform manual receive“ ”.

Important!

•When getting ready to receive the time calibration signal, position the watch

as shown in the nearby illustration, with its 12 o clock side facing towards a’

window. This watch is designed to receive a time calibration signal late at

night. Because of this, you should place the watch near a window as shown

in the illustration when you take it off at night. Make sure there are no metal

objects nearby.

12 o’clock

•Make sure the watch is facing the right way.

•Proper signal reception can be difficult or even impossible under the

conditions listed below.

•Signal reception normally is better at night than during the day.

•Time calibration signal reception takes from two to seven minutes, but in

some cases it can take as long as 14 minutes. Take care that you do not

perform any button operations or move the watch during this time.

Inside or

among

buildings

Inside a

vehicle

Near a

construction

site, airport,

or other

sources of

electrical

noise

Near high-

tension

power lines

Among or

behind

mountains

Near

household

appliances,

office

equipment,

or a mobile

phone

•The time calibration signal the watch will attempt to pick up depends on its

current Home City code setting as shown below.

Home City Code

LON BER, PAR, , ATH

HKG

TPE, TYO

HNL*, ANC*, LAX,

DEN, CHI, NYC

Frequency

60.0 kHz

77.5 kHz

68.5 kHz

40.0 kHz

60.0 kHz

Transmitter

Anthorn (England)

Mainflingen (Germany)

Shangqiu City (China)

Fukushima (Japan)

Fukuoka/Saga (Japan)

Fort Collins, Colorado

(the United States)

* The areas covered by the , and city codes are quite far fromHNL ANC

the time calibration signal transmitters, and so certain conditions may

cause problems with signal reception.

Approximate Reception Ranges

Anthorn

Mainflingen

1,500 kilometers

500 kilometers

Fort

Collins

2,000 miles

(3,000 kilometers)

600 miles

(1,000 kilometers)

The Anthorn

signal is

receivable within

this area.

1,000

kilometers

1,000

kilometers

Fukuoka/Saga

500

kilometers

Fukushima

500

kilometers

500 kilometers

Changchun

Beijing

1,500 kilometers

Shangqiu

Shanghai

Hong Kong

Chengdu

Signals are receivable in the Taiwan area when reception conditions are good.

•Signal reception may not be possible at the distances noted below during

certain times of the year or day. Radio interference may also cause

problems with reception.

Mainflingen (Germany) or Anthorn (England) transmitters: 500

kilometers (310 miles)

Fort Collins (United States) transmitter: 600 miles (1,000 kilometers)

Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310

miles)

Shangqiu (China) transmitter: 1500 kilometers (910 miles)

•Even when the watch is within the reception range of the transmitter, signal

reception will be impossible if the signal is blocked by mountains or other

geological formations between the watch and signal source.

•Signal reception is affected by weather, atmospheric conditions, and

seasonal changes.

•See the information under Signal Reception Troubleshooting“ ” if you

experience problems with time calibration signal reception.

About Auto Receive

The watch receives the time calibration signal automatically up to six times a

day. When any auto receive is successful, the remaining auto receive

operations are not performed. The reception schedule (calibration times)

depends on your currently selected Home City, and whether standard time or

Daylight Saving Time is selected for your Home City.

Your Home City Auto Receive Start Times

1 2 3 4 5 6

LON Standard Time

1:00 am 2:00 am 3:00 am 4:00 am 5:00 am Midnight*

Daylight Saving Time

2:00 am 3:00 am 4:00 am 5:00 am Midnight* 1:00 am

PAR Standard Time

2:00 am 3:00 am 4:00 am 5:00 am Midnight* 1:00 am

BER

Daylight Saving Time

3:00 am 4:00 am 5:00 am Midnight* 1:00 am

2:00 am

ATH Standard Time

3:00 am 4:00 am 5:00 am Midnight* 1:00 am

2:00 am

Daylight Saving Time

4:00 am 5:00 am Midnight* 1:00 am

2:00 am

3:00 am

HKG Standard Time

1:00 am 2:00 am 3:00 am 4:00 am 5:00 am

TYO Standard Time

Midnight 1:00 am 2:00 am 3:00 am 4:00 am 5:00 am

TPE

NYC Standard Time and

Midnight 1:00 am 2:00 am 3:00 am 4:00 am 5:00 am

CHI

Daylight Saving Time

DEN

LAX

*Next day

Operation Guide 3147

Note

•When a calibration time is reached, the watch will receive the calibration

signal only if it is in either the Timekeeping Mode or World Time Mode.

Reception is not performed if a calibration time is reached while you are

configuring settings.

•Auto receive of the calibration signal is designed to be performed early in

the morning, while you sleep (provided that the Timekeeping Mode time is

set correctly). Before going to bed for the night, remove the watch from your

wrist, and put it in a location where it can receive the signal easily.

•The watch receives the calibration signal for two to seven minutes everyday

when the time in the Timekeeping Mode reaches a calibration time. Do not

perform any button operation within seven minutes before or after the

calibration times. Doing so can interfere with correct calibration.

•Remember that reception of the calibration signal depends on the current

time in the Timekeeping Mode. The receive operation will be performed

whenever the display shows any one of the calibration times, regardless of

whether or not the displayed time actually is the correct time.

About the Signal Strength Indicator

The signal strength indicator shows the strength of the calibration signal

being received. For best reception, be sure to keep the watch in a location

where signal strength is strongest. The signal strength indicator is displayed

while an auto or manual receive operation is in progress.

•Even in an area where signal strength is strong, it takes about 10 seconds

for signal reception to stabilize enough for the signal strength indicator to

indicate signal strength.

Strong

(Level 3)

Signal strength indicator

Weak

•Use the signal strength indicator as a guide for checking signal strength

and for finding the best location for the watch during signal receive

operations.

•Following reception of the time calibration signal and calibration of the

watch’s time setting, the Level 3 signal strength indicator will remain on the

display in all modes. The Level 3 signal strength indicator will not be

displayed if signal reception was unsuccessful or after you adjust the

current time setting manually.

•The Level 3 signal strength indicator is displayed only when the watch is

able to receive both time and date data successfully. It does not appear

when only time data is received.

•The Level 3 signal strength indicator indicates that at least one of the auto

calibration signal receive operations was successful. Note, however, that

the Level 3 signal strength indicator disappears from the display each day

when the first auto receive operation of the day is performed.

To perform manual receive

1. In the Timekeeping Mode, press E to display

the last successful receive time and date

screen.

2. Press E to enter the Receive Mode.

3. Hold down E for about two seconds until

starts to flash on the display.

•Time calibration signal reception takes from

two to seven minutes. Take care that you do

not perform any button operations or move

the watch during this time.

•If the receive operation is successful, the

reception date and time appear on the

display, along with the GET indicator.

4. After manual receive is complete, press E

twice to return to the Timekeeping mode.

•The watch also will exit the Receive Mode if

you do not perform any button operation for

about one or two minutes.

Receiving

Receive successful

•If the latest reception fails but a previous

reception was successful, an indicator ( ) will

be on the display.

The watch will enter the Receive Mode without

changing the time setting if you press or ifE

you do not perform any button operation for

about one or two minutes.

Note

•To interrupt a receive operation and return to

the Receive Mode, press E.

Receive failed

If there was a previously

successful reception

If no reception was

successful

To turn auto receive on and off

1. In the Timekeeping Mode, press E to display

the last successful receive time and date

screen.

2. Hold down A until the current auto receive

setting (ON OFF or ) starts to flash. This is the

setting screen.

•Note that the setting screen will not appear if

the currently selected Home City is one that

does not support time calibration reception.

3. Press E to toggle auto receive on (ON) and

off (OFF).

4. Press A to exit the setting screen.

•For information about city codes that support

signal receive, see “To specify your Home City”.

On/Off

status

To check the latest signal reception results

Press E to view the last successful receive time

and date. Press again to return to theE

previous screen.

Signal Reception Troubleshooting

Check the following points whenever you experience problems with signal

reception.

•The watch is not in the Receive

Mode.

•Your current Home City is not one

of the following: LON, , PAR BER,

ATH, HKG, TPE TYO, , LAX,

DEN CHI, , or NYC

•You changed the time setting

manually.

•The DST setting was changed

manually in the World Time Mode.

•

You pressed a button while signal

receive was in progress.

•Even if receive is successful, the

Level 3 signal strength indicator

disappears from the display each

day when the first auto receive

operation of the day is performed.

•Time data (hour, minutes,

seconds) only was received

during the last receive operation.

The Level 3 signal strength

indicator appears only when time

data and date data (year, month,

day) are both received.

Cannot perform

manual receive.

Auto receive is

turned on, but

the Level 3

signal strength

indicator does

not appear on

the display.

•Enter the Receive

Mode and try again.

•Select , LON PAR,

BER HKG, ATH, ,

TPE, TYO, LAX DEN, ,

CHI, or NYC as your

Home City.

•Perform manual signal

receive or wait until the

next auto signal

receive operation is

performed.

•Check to make sure

the watch is in a

location where it can

receive the signal.

What you should doProblem Probable Cause

•If the time is one hour off, the

DST setting may be incorrect.

•The Home City code setting is

not correct for the area where you

are using the watch.

•

Change the DST

setting to Auto DST.

•Select the correct

Home City code.

Time setting is

incorrect

following signal

reception.

•For further information, see under “Important!” “Time Calibration Signal

Reception” and “Radio-controlled Atomic Timekeeping Precautions”.

Altimeter

The watch’s altimeter uses a pressure sensor to detect current air pressure,

which is then used to estimate the current altitude based on ISA (International

Standard Atmosphere) preset values. You can specify a reference altitude,

which the watch will use to calculate your current altitude based on the value

you specify. Altimeter functions also include storage of measurement readings

in memory.

Important!

•This watch estimates altitude based on air pressure. This means that

altitude readings for the same location may vary if air pressure changes.

•The semiconductor pressure sensor used by the watch for altitude readings

is also affected by temperature. When taking altitude readings, make sure

the watch is not subjected to temperature changes.

•To avoid the effect of sudden temperature changes during readings, keep

the watch on your wrist in direct contact with your skin.

•Do not rely upon this watch for altitude readings or perform button

operations while sky diving, hang gliding, or paragliding, while riding a

gyrocopter, glider, or any other aircraft, or while engaging in any other

activity where there is the chance of sudden altitude changes.

•Do not use this watch for taking altitude readings in applications that

demand professional or industrial level precision.

•Remember that the air inside of a commercial aircraft is pressurized.

Because of this, the readings produced by this watch will not match the

altitude readings announced or indicated the flight crew.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	GW-9200-1ER

Behöver du hjälp?

Om du behöver hjälp med Casio GW-9200-1ER ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
