Sida 1/11
Operation Guide 5311
E-9
2. Check the Home City.
Use the procedure under “To confi gure Home City settings” (page E-36) to confi gure your
Home City.
Important!
x Proper time calibration signal reception depends on correct Home City, time, and
day settings in the Timekeeping Mode. Make sure you confi gure these settings
correctly.
3. Set the current time.
x To set the time using a time calibration signal
See “To get ready for a receive operation” (page E-25).
x To set the time manually
See “Confi guring Current Time and Day Settings Manually” (page E-41).
The watch is now ready for use.
x For details about the watch’s radio controlled timekeeping feature, see “Radio
Controlled Atomic Timekeeping” (page E-20).
E-8
Things to check before using the watch
1. Hold down at least two seconds to enter the Timekeeping Mode, and C
then observe the movement of the
x
x
x
xx
.Second Hand
Is the
x
x
x
xx
moving smoothly at one-second intervals?Second Hand
Is the
x
x
x
xx
moving at Second Hand
two-second intervals or is it stopped
completely?
Go to step 2.
The watch is charged. For details
about charging, see “Charging the
Watch” (page E-14).
Power is low. Charge the watch by
placing it in a location where it is
exposed to light. For details, see
“Charging the Watch” (page E-14).
NO
YES
YES
NEXT
E-7
To stop high-speed movement
Rotate the crown in the direction that is opposite that of the
current high-speed movement or press any button.
Note
x If you do not perform any operation for more than two minutes after pulling out the
crown, crown operations will become disabled automatically. If this happens, push
the crown back in and then pull it out again to re-enable crown operations.
x You can use high-speed hand movement when confi guring time settings in the
Timekeeping Mode, Alarm Mode, or Countdown Timer Mode.
x Button operations become disabled after you perform a crown operation. If this
happens, rotate the crown slightly. This should restore button operations.
E-6
High-speed Movement
When rotating the crown to move the hands of the watch, you can use the operations
described below to move the hands at high speed, either forward or back. There are
two high-speed levels: HS1 and HS2 (faster than HS1).
To start HS1 high-speed movement
While the crown is pulled out, rotate it rapidly three turns away
from you (for forward movement) or towards you (for reverse
movement). High-speed movement will continue even if you
release the crown.
To start HS2 high-speed movement
While HS1 high-speed movement is in progress, again rotate
the crown rapidly three turns in the same direction as the
current HS1 movement (away from you for forward movement
or towards you for reverse movement).
E-5
4. Gently pull on the crown to make sure it is securely locked and does not come out.
To unlock the crown
Rotate the crown so the groove aligns with Mark 1.
To pull out, rotate, or push the crown in
Important!
x Before performing any of these operations, fi rst unlock the crown.
The illustrations below show the different crown operations.
Pull out Rotate Push in
E-4
Using the Crown
This watch has a lock-type crown.
Important!
x You should normally have the crown locked during normal daily use. Leaving the crown
unlocked creates the risk of unintended operations or even damage due to impact.
To lock the crown
1. Push the crown back in (see “To pull out, rotate, or push the
crown in” below).
x Note that attempting to lock the crown when it is not pushed
in can cause unexpected watch operation.
2. Rotate the crown so any one of its three grooves is aligned
with Mark 1.
3. While pushing in on the crown (a), rotate it to the right (b) until
it stops, and align the groove with Mark 2.
Mark 1
Groove
W
V
Mark 2
E-3
About This Manual
Operations are performed using the watch’s crown, and
the three buttons indicated by the letters , and in A B C
this manual.
Hands and Indicators
z
z
z
z z
Hour Hand
x
x
x
x x
Second Hand
c
c
c
c c
Minute Hand
v
v
v
v v
Upper Dial Hand: Indicates a time, in 24-hour format,
depending on the current mode.
b
b
b
b b
Lower Dial Hand: Indicates the current mode.
n
n
n
n n
Day Indicator
This User’s Guide uses numbers shown above to identify
watch hands and indicator.
>
>
>
>>
B
B
B
BB @
@
@
@@
6
6
6
66
*
*
*
**
+
+
+
++
E-2
Warning!
x The measurement functions built into this watch are not intended for taking
measurements that require professional or industrial precision. Values produced
by this watch should be considered as reasonable representations only.
x To ensure correct direction readings by this watch, be sure to perform
bidirectional calibration before using it. The watch may produce incorrect
direction readings if you do not perform bidirectional calibration. For more
information, see “To perform bidirectional calibration” (page E-56).
x Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss suffered by you or any third party arising through the use of this
product or its malfunction.
E-1
ENGLISH
Congratulations upon your selection of this CASIO watch.
x Note that the product illustrations in this manual are intended for reference only, and
so the actual product may appear somewhat different than depicted by an illustration.
This watch does not have a city code that corresponds to the UTC offset of –3.5
hours. Because of this, the radio-controlled atomic timekeeping function will not
display the correct time for Newfoundland, Canada.
MA1303-EA
Ú
#!3)/#/-054%2#/,4$
Operation Guide 5311
E-19
Power Saving
Power Saving enters a sleep state (second hand sleep or function sleep) whenever
the watch is left for a certain period in an area where it is dark.
Elapsed Time in Dark Operation
60 to 70 minutes (second
hand sleep)
x
x
x
x
x
only stopped at 12 o’clock, all other functions Second Hand
enabled
6 or 7 days (function sleep) x All functions, including analog timekeeping, disabled
x Internal timekeeping maintained
x The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is
already in a sleep state when 6:00 AM arrives, however, it will remain there.
x The watch will not enter a sleep state while it is in the Stopwatch Mode or
Countdown Timer Mode.
To recover from the sleep state
Move the watch to a well-lit area or press any button.
E-18
Charging Times
Exposure Level (Brightness) Daily
Operation *1
Level Change *2
Level 3 Level 2 Level 1
Outdoor sunlight (50,000 lux) 8 minutes 2 hours 27 hours
Window sunlight (10,000 lux) 30 minutes 6 hours 99 hours
Window sunlight on cloudy day
(5,000 lux) 48 minutes 10 hours 161 hours
Indoor fl uorescent lighting
(500 lux) 8 hours 111 hours – – –
* 1 Approximate exposure each day to generate power for normal daily operation.
* 2 Approximate exposure to take power up one level.
x The above times are for reference only. Actual times depend on lighting conditions.
x For details about the operating time and daily operating conditions, see the “Power
Supply” section of the Specifi cations (page E-97).
E-17
x When power drops to Level 3, all settings (including timekeeping) will be cleared.
Recharging the battery will reset all settings to their initial factory defaults.
x When the watch is at Level 3, exposing it to light for a while will cause the
x
x
x
xx
Second
Hand to move to the position of second 57. This indicates that charging has started.
Power Recovery Mode
The watch is designed to go into a power recovery mode that stops hand operation
temporarily whenever power suddenly drops below a certain level due to continuous
signal reception or other operations over a short period. Note that all operations are
disabled while the watch is in the power recovery mode.
The hands will move to the correct positions and the watch will resume normal
operation after power recovers (in about 15 minutes). Putting the watch in a location
where it is exposed to light will help power to recover sooner.
E-16
Low Power
Low power conditions are indicated by the movement of
the
x
x
x
xx
in the Timekeeping Mode.Second Hand
x If the
x
x
x
xx
is moving normally at one-second Second Hand
intervals, power is at Level 1.
x If the
x
x
x
xx
is moving at two-second intervals, Second Hand
power is at Level 2, which is quite low. Expose the watch
to light as soon as possible so it can charge.
Low Battery Alert (Hand Movement and Function
Status)
Level Hand Movement Function Status
1 Normal. All functions enabled
2x
x
x
x
x
moves at Second Hand
two-second intervals.
Beeper and time
calibration signal
reception disabled.
3x
x
x
x
x
stopped.Second Hand All functions disabled
Moves at two-second
intervals.
@
@
@
@@
E-15
Warning!
Leaving the watch in bright light for charging can cause it to become quite hot.
Take care when handling the watch to avoid burn injury. The watch can become
particularly hot when exposed to the following conditions for long periods.
x On the dashboard of a car parked in direct sunlight
x Too close to an incandescent lamp
x Under direct sunlight
Important!
x Keep the watch in an area normally exposed to bright light when storing it for long
periods. This helps to ensure that power does not run down.
x Storing the watch for long periods in an area where there is no light or wearing it in
such a way that it is blocked from exposure to light can cause power to run down.
Make sure that the watch is exposed to bright light whenever possible.
Checking the Current Power Level
Certain functions will be disabled when the power level is low. If the power level is
low, leave the watch in a location where its face (solar panel) is exposed to light.
E-14
Charging the Watch
The face of the watch is a solar panel that generates power from light. The generated
power charges a built-in rechargeable battery, which powers watch operations. The
watch charges whenever it is exposed to light.
Charging Guide
Whenever you are not
wearing the watch, be sure
to leave it in a location
where it is exposed to light.
x Best charging
performance is achieved
by exposing the watch to
light that is as strong as
possible.
When wearing the watch,
makes sure that its face is
not blocked from light by
the sleeve of your clothing.
x The watch may enter a
sleep state (page E-19) if its
face is blocked by your
sleeve even only partially.
E-13
E-79 Adjusting Home Positions
E-81 To adjust home positions
E-83 Troubleshooting
E-95 Specifi cations
E-12
E-63 Checking the Current Time in a Different Time Zone
E-64 To view the time in another time zone
E-67 To swap your Home City and World Time City
E-69 Using the Stopwatch
E-70 To enter and exit the Stopwatch Mode
E-70 To perform an elapsed time operation
E-70 To perform fl yback timing
E-72 Using the Countdown Timer
E-73 To specify the countdown start time
E-74 To perform a countdown timer operation
E-74 To stop the alarm
E-75 Using the Alarm
E-76 To change the alarm time setting
E-78 To turn the alarm on or off
E-78 To stop the alarm
E-11
E-32 Mode Reference Guide
E-33 To determine the watch’s current mode
E-33 To return to the Timekeeping Mode from any other mode
E-34 To select a mode
E-35 Timekeeping
E-36 Confi guring Home City Settings
E-36 To confi gure Home City settings
E-39 To switch between standard time and summer time manually
E-41 Confi guring Current Time and Day Settings Manually
E-41 To change the current time setting manually
E-44 To change the current day setting manually
E-48 Taking Direction Readings
E-50 To take a direction reading
E-56 To perform bidirectional calibration
E-58 To perform northerly calibration
E-10
Contents
E-3 About This Manual
E-4 Using the Crown
E-4 To lock the crown
E-5 To unlock the crown
E-5 To pull out, rotate, or push the crown in
E-8 Things to check before using the watch
E-14 Charging the Watch
E-19 To recover from the sleep state
E-20 Radio Controlled Atomic Timekeeping
E-25 To get ready for a receive operation
E-28 To perform manual receive
E-29 To check the result of the latest receive operation
E-30 To turn auto receive on and off
Operation Guide 5311
E-29
Note
x To interrupt a receive operation and return to the Timekeeping Mode, press any
button.
To check the result of the latest receive operation
In the Timekeeping Mode, press . The B
x
x
x
xx
Second
Hand will move to ( ) or ( ) to indicate the last Y YES N NO
calibration signal receive result.
x The
x
x
x
xx
will move to ( ) if the latest Second Hand Y YES
receive operation was successful, or ( ) if it was N NO
not. After about 10 seconds, regular timekeeping will
resume.
x Press to return to regular timekeeping. The watch will B
also return to regular timekeeping if you do not perform
any operation for about 10 seconds.
@
@
@
@@
E-28
To perform manual receive
1. In the Timekeeping Mode (page E-35), keep B depressed (for about two seconds) as
the
x
x
x
xx
goes through the following sequence.Second Hand
x Moves to ( ) or ( ) to indicate the last signal reception result, then to Y YES N NO
R (READY).
2. The
x
x
x
xx
indicates the operations the watch is currently performing.Second Hand
When the x
x
x
x
x
is Second Hand
pointed here: It means this:
R (READY)
Watch is setting up for reception.
W (WORK) Reception is in progress.
x If signal reception is unstable, the x
x
x
x
x
may Second Hand
move between ( ) and ( ).W WORK R READY
x When the receive operation is successful, the watch
adjusts the time setting accordingly, and then resumes
regular timekeeping. It does not adjust the setting if the
operation failed.
@
@
@
@@
E-27
3. What you should do next depends on whether you are using Auto Receive or
Manual Receive.
x Auto Receive: Leave the watch over night in the location you selected in step 2.
See “Auto Receive” on page E-27 for details.
x Manual Receive: Perform the operation under “To perform manual receive” on
page E-28.
Auto Receive
x With Auto Receive, the watch performs the receive operation each day
automatically up to six times (up to fi ve times for the Chinese calibration signal)
between the hours of midnight and 5 a.m. (according to the Timekeeping Mode
time). When any receive operation is successful, none of the other receive
operations for that day are performed.
x When a calibration time is reached, the watch will perform the receive operation
only if it is in the Timekeeping Mode. The receive operation is not performed if a
calibration time is reached while you are confi guring settings.
E-26
x Signal reception may be diffi cult or even impossible under the conditions
described below.
Inside or
among
buildings
Inside a
vehicle
Near
household
appliances,
offi ce
equipment,
or a mobile
phone
Near a
construction
site, airport,
or other
sources of
electrical
noise
Near
high-tension
power lines
Among
or behind
mountains
E-25
To get ready for a receive operation
1. Confi rm that the watch is in the Timekeeping Mode. If it isn’t, hold down for at C
least two seconds to enter the Timekeeping Mode.
2. Place the watch in a location where signal reception is good.
12 o’clock
or
x Position the watch as shown in the
nearby illustration, with 12 o’clock
pointed towards a window. Make
sure there are no metal objects
nearby.
x Signal reception normally is better
at night.
x The receive operation takes from
two to 10 minutes, but in some
cases it can take as long as
20 minutes. Take care that you do
not perform any button operation or
move the watch during this time.
E-24
x Signal reception may not be possible at the distances noted below during certain
times of the year or day. Radio interference may also cause problems with reception.
− Mainfl ingen (Germany) or Anthorn (England) transmitters: 500 kilometers
(310 miles)
− Fort Collins (United States) transmitter: 600 miles (1,000 kilometers)
− Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310 miles)
− Shangqiu (China) transmitter: 500 kilometers (310 miles)
x As of December 2012, China does not use Daylight Saving Time (DST). If China
does go to the Daylight Saving Time system in the future, some functions of this
watch may no longer operate correctly.
x Using this watch in a country covered by a time calibration signal that is different
from the countries it supports may result in incorrect time indication due to local
application of daylight saving time (summer time), etc.
E-23
Japanese Signals Chinese Signal
Fukushima
500 kilometers
Fukuoka/Saga
1,000 kilometers 1,500 kilometers
Changchun500 kilometers
Beijing
Shangqiu
Shanghai
Chengdu
Hong Kong
E-22
Approximate Reception Ranges
UK and German Signals North American Signal
Anthorn
500 kilometers
1,500 kilometers
Mainfl ingen
The Anthorn signal is receivable
within this area.
2,000 miles
(3,000 kilometers)
600 miles
(1,000 kilometers)
Fort Collins
E-21
If your Home City Code setting is this: The watch can receive the signal from
the transmitter located here:
LON (LONDON), PAR (PARIS), ATH (ATHENS) Anthorn (England), Mainfl ingen
(Germany)
HKG (HONG KONG) Shangqiu City (China)
TYO (TOKYO) Fukushima (Japan), Fukuoka/Saga
(Japan)
HNL (HONOLULU), ANC (ANCHORAGE),
LAX (LOS ANGELES), DEN (DENVER), CHI
(CHICAGO), NYC (NEW YORK)
Fort Collins, Colorado (United States)
Important!
x The areas covered by ( ) and ( ) are quite far HNL HONOLULU ANC ANCHORAGE
from the calibration signal transmitters, so certain conditions may cause reception
problems.
E-20
Radio Controlled Atomic Timekeeping
This watch receives a time calibration signal and updates its time setting accordingly.
However, when using the watch outside of areas covered by time calibration signals,
you will have to adjust the settings manually as required. See “Confi guring Current
Time and Day Settings Manually” (page E-41) for more information.
This section explains how the watch updates its time settings when the city code
selected as the Home City is in Japan, North America, Europe, or China, and is one
that supports time calibration signal reception.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | GW-A1100-1A3ER |
Behöver du hjälp?
Om du behöver hjälp med Casio GW-A1100-1A3ER ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
