Operation Guide 3159

MO1005-EA

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out of your

purchase, be sure to read this manual carefully.

Keep the watch exposed to bright light

The electricity generated by the solar cell of the watch is

stored by a rechargeable battery. Leaving or using the

watch where it is not exposed to light causes the battery

to run down. Make sure the watch is exposed to light as

much as possible.

•When you are not wearing the watch on your wrist,

position the face so it is pointed at a source of bright

light.

•You should try to keep the watch outside of your sleeve

as much as possible. Charging is reduced significantly if

the face is covered only partially.

Bright Light

Solar cell

All

functions

enabled

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Charge

Rechargeable battery

Bright Light

Electrical

energy

Solar cell

(Converts light to

electrical power.)

Battery charges in the light. Battery discharges in the dark.

•The watch continues to operate, even when it is not exposed to light. Leaving the

watch in the dark can cause the battery to run down, which will result in some watch

functions to be disabled. If the battery goes dead, you will have to re-configure watch

settings after recharging. To ensure normal watch operation, be sure to keep it

exposed to light as much as possible.

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Some or all

functions

disabled

Dis-

charge

•The actual level at which some functions are disabled depends on the watch model.

•Frequent display illumination can run down the battery quickly and require charging.

The following guidelines give an idea of the charging time required to recover from a

single illumination operation.

Approximately 5 minutes exposure to bright sunlight coming in through a window

Approximately about 8 hours exposure to indoor fluorescent lighting

•Be sure to read “Power Supply” for important information you need to know

when exposing the watch to bright light.

If the display of the watch is blank...

If the display of the watch is blank, it means that the watch’s Power Saving function

has turned off the display to conserve power.

•See “Power Saving Function” for more information.

Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage

or loss suffered by you or any third party arising through the use of this product or

its malfunction.

About This Manual

•Depending on the model of your watch, display text appears either as dark figures

on a light background or light figures on a dark background. All sample displays in

this manual are shown using dark figures on a light background.

•Button operations are indicated using the letters shown in the illustration.

•Each section of this manual provides you with the information you need to perform

operations in each mode. Fur ther details and technical information can be found in

the “Reference” section.

General Guide

•Press C to change from mode to mode.

•In any mode (except when a setting screen is on the display), press B to illuminate

the display.

Timekeeping Mode

Press C.

Countdown Timer Mode Stopwatch Mode

Alarm Mode

▲

World Time Mode

▲

Radio-controlled Atomic Timekeeping

This watch receives a time calibration signal and updates its time setting accordingly.

•This watch is designed to pick up the time calibration signals transmitted in Germany

(Mainflingen), England (Anthorn), the United States (Fort Collins), China (Shangqiu),

and Japan (Fukushima, Fukuoka/Saga).

Current Time Setting

This watch adjusts its time setting automatically in accordance with a time calibration

signal. You also can perform a manual procedure to set the time and date, when

necessary.

•The first thing you should do after purchasing this watch is to specify your

Home City (the city where you normally will use the watch). For more

information, see “To specify your Home City”.

•When using the watch outside the areas covered by the time signal transmitters, you

will have to adjust the current time setting manually as required. See “Timekeeping”

for more information about manual time settings.

•The U.S. time calibration signal can be picked up by the watch while in North

America. The term “North America” in this manual refers to the area that consists of

Canada, the continental United States, and Mexico.

•As of December 2009, China does not use Daylight Saving Time (DST). If China

does go to the Daylight Saving Time system in the future, some functions of this

watch may no longer operate correctly.

•Using this watch in a country covered by a time calibration that is different from the

countries it supports may result in incorrect time indication due to local application of

summer time, etc.

To specify your Home City

1. In the Timekeeping Mode, hold down A until the city

code starts to flash, which indicates the setting screen.

2. Press D B (east) and (west) to select the city code

you want to use as your Home City.

LIS, LON : Lisbon, London

MAD BER STO , PAR, ROM, , : Madrid, Paris,

Rome, Berlin, Stockholm

ATH : Athens

MOW : Moscow

HKG BJS TPE, , : Hong Kong, Beijing, Taipei

SEL, TYO : Seoul, Tokyo

HNL : Honolulu

ANC : Anchorage

YVR LAX, : Vancouver, Los Angeles

YEA DEN,

: Edmonton, Denver

MEX CHI, : Mexico City, Chicago

MIA YTO NYC, , : Miami, Toronto, New York

YHZ : Halifax

YYT : St.Johns

PM indicator

City code

Hour : Minutes Seconds

3. Press A to exit the setting screen.

•Normally, your watch should show the correct time as soon as you select your Home

City code. If it does not, it should adjust automatically after the next auto receive

operation (in the middle of the night). You also can perform manual receive or you

can set the time manually.

•The watch will receive the time calibration signal automatically from the applicable

transmitter (in the middle of the night) and update its settings accordingly. For

information about the relationship between city codes and transmitters, see

“Important!” under “Time Calibration Signal Reception” and “Transmitters”.

•See the maps under “Approximate Reception Ranges” for information about the

reception ranges of the watch.

•You can disable time signal reception, if you want. See “To turn auto receive on and

off” for more information.

•Under factory default settings, auto receive is turned off for all of the following city

codes: MOW HNL ANC (Moscow), (Honolulu), and (Anchorage). For details about

turning on auto receive for these city codes, see “To turn auto receive on and off”.

Time Calibration Signal Reception

There are two different methods you can use to receive the time calibration signal:

auto receive and manual receive.

•Auto Receive

With auto receive, the watch receives the time calibration signal automatically up to

six times a day (five times a day for the Chinese calibration signal). When any auto

receive is successful, the remaining auto receive operations are not performed. For

more information, see “About Auto Receive”.

•Manual Receive

Manual receive lets you start a time calibration receive operation with the press of a

button. For more information, see “To perform manual receive”.

Important!

•When getting ready to receive the time calibration signal, position the watch as

shown in the nearby illustration, with its 12 o’clock side pointing towards a window.

This watch is designed to receive a time calibration signal late at night. Because of

this, you should place the watch near a window as shown in the illustration when you

take it off at night. Make sure there are no metal objects nearby.

12 o’clock

•Make sure the watch is facing the right way.

Operation Guide 3159

•Proper signal reception can be difficult or even impossible under the conditions listed

below.

Inside or

among

buildings

Inside a

vehicle

Near a

construction

site, airport,

or other

sources of

electrical

noise

Near high-

tension power

lines

Near

household

appliances,

office

equipment,

or a mobile

phone

Among or

behind

mountains

•Signal reception normally is better at night than during the day.

•Time calibration signal reception takes from two to seven minutes, but in some

cases it can take as long as 14 minutes. Take care that you do not perform any

button operations or move the watch during this time.

•The time calibration signal the watch will attempt to pick up depends on its current

Home City code setting as shown below.

Home City Code

LIS, LON, MAD, PAR, ROM,

BER, STO, ATH, MOW*

HKG, BJS

TPE, SEL, TYO

HNL*, ANC*, YVR, LAX, YEA,

DEN, MEX, CHI, MIA, YTO,

NYC, YHZ, YYT

Frequency

60.0 kHz

77.5 kHz

68.5 kHz

40.0 kHz

60.0 kHz

Transmitter

Anthorn (England)

Mainflingen (Germany)

Shangqiu City (China)

Fukushima (Japan)

Fukuoka/Saga (Japan)

Fort Collins, Colorado

(the United States)

* The areas covered by the HNL, ANC, and MOW city codes are quite far from the

time calibration signal transmitters, and so certain conditions may cause problems

with signal reception.

•Calibration signal reception is disabled while a countdown timer operation is in

progress.

Approximate Reception Ranges

U.K. and German Signals

Anthorn

Mainflingen

1,500 kilometers

500 kilometers

The Anthorn signal

is receivable within

this area.

North American Signal

Fort Collins

2,000 miles

(3,000 kilometers)

600 miles

(1,000 kilometers)

Signals are receivable in the Taiwan area when reception conditions are good.

Shangqiu

1,000 kilometers

Fukuoka/Saga

500 kilometers

Fukushima

500 kilometers

Changchun

Beijing

1,500 kilometers

Shanghai

Chengdu

Japan Signals

China Signal

Hong Kong

•Signal reception may not be possible at the distances noted below during certain

times of the year or day. Radio interference also may cause problems with reception.

Mainflingen (Germany) or Anthorn (England) transmitters: 500 kilometers

(310 miles)

Fort Collins (United States) transmitter: 600 miles (1,000 kilometers)

Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310 miles)

Shangqiu (China) transmitter: 1,500 kilometers (910 miles)

•Even when the watch is within the reception range of the transmitter, signal

reception will be impossible if the signal is blocked by mountains or other geological

formations between the watch and signal source.

•Signal reception is affected by weather, atmospheric conditions, and seasonal

changes.

•See the information under “Signal Reception Troubleshooting” if you experience

problems with time calibration signal reception.

About Auto Receive

The watch receives the time calibration signal automatically up to six times a day

(five times a day for the Chinese calibration signal). When any auto receive is

successful, the remaining auto receive operations are not performed. The reception

schedule (calibration times) depends on your currently selected Home City, and

whether standard time or Daylight Saving Time is selected for your Home City.

2:00 am

3:00 am

4:00 am

5:00 am

Midnight*

3:00 am

4:00 am

5:00 am

Midnight*

1:00 am*

4:00 am

5:00 am

Midnight*

1:00 am*

2:00 am*

5:00 am

Midnight*

1:00 am*

2:00 am*

3:00 am*

Standard Time

Daylight Saving Time

Standard Time

Daylight Saving Time

Standard Time

Daylight Saving Time

Standard Time

Daylight Saving Time

1:00 am

2:00 am

3:00 am

4:00 am

5:00 am

Midnight*

1:00 am*

2:00 am*

3:00 am*

4:00 am*

LIS

LON

MAD

PAR

ROM

BER

STO

ATH

MOW

Your Home City Auto Receive Start Times

1 2 3 4 5 6

*Next day

HKG

BJS

TPE

SEL

TYO

HNL

ANC

YVR

LAX

YEA

DEN

MEX

CHI

MIA

YTO

NYC

YHZ

YYT

Standard Time and

Daylight Saving Time

Standard Time

Standard Time and

Daylight Saving Time

1:00 am

Midnight

2:00 am

1:00 am

3:00 am

2:00 am

4:00 am

3:00 am

5:00 am

4:00 am

5:00 am

Note

•When a calibration time is reached, the watch will receive the calibration signal only

if it is in either the Timekeeping Mode or World Time Mode. Reception is not

performed if a calibration time is reached while you are configuring settings.

•Auto receive of the calibration signal is designed to be performed early in the

morning, while you sleep (provided that the Timekeeping Mode time is set correctly).

Before going to bed for the night, remove the watch from your wrist, and put it in a

location where it can receive the signal easily.

•The watch receives the calibration signal for two to seven minutes everyday when

the time in the Timekeeping Mode reaches a calibration time. Do not perform any

button operation within seven minutes before or after the calibration times. Doing so

can interfere with correct calibration.

•Remember that reception of the calibration signal depends on the current time in the

Timekeeping Mode. The receive operation will be performed whenever the display

shows any one of the calibration times, regardless of whether or not the displayed

time actually is the correct time.

About the Signal Strength Indicator

The signal strength indicator shows the strength of the calibration signal being

received. For best reception, be sure to keep the watch in a location where signal

strength is strongest. The signal strength indicator is displayed while an auto or

manual receive operation is in progress.

StrongWeak

•Even in an area where signal strength is strong, it takes about 10 seconds for signal

reception to stabilize enough for the signal strength indicator to indicate signal

strength.

RCVD indicator

Signal strength indicator

•Use the signal strength indicator as a guide for checking signal strength and for

finding the best location for the watch during signal receive operations.

•Following reception of the time calibration signal and calibration of the watch’s time

setting, the indicator will remain on the display in all modes. The RCVD RCVD

indicator will not be displayed if signal reception was unsuccessful or after you adjust

the current time setting manually.

•The RCVD indicator is displayed only when the watch is able to receive both time

and date data successfully. It does not appear when only time data is received.

•The RCVD indicator indicates that at least one of the auto calibration signal receive

operations was successful. Note, however, that the RCVD indicator disappears from

the display each day when the first auto receive operation of the day is performed.

To perform manual receive

1. Enter the Timekeeping Mode.

2. Hold down D for about two seconds until the RCVD

indicator starts to flash on the display. This indicates

that manual receive is in progress.

•Time calibration signal reception takes from two to

seven minutes. Take care that you do not perform

any button operations or move the watch during this

time.

•If the receive operation is successful, the reception

date and time appear on the display, along with the

GET indicator.

3. After manual receive is complete, press D to return to

normal timekeeping.

•The watch also will return to normal timekeeping if you

do not perform any button operation for about one or

two minutes.

Receiving

Receive successful

Reception date

•If the latest reception fails but a previous reception was

successful during the current day, the indicatorRCVD

will be on the display.

Note

•To interrupt a receive operation and return to normal

timekeeping, press D.

If there was a previously

successful reception

Receive failed

Operation Guide 3159

To turn auto receive on and off

1. In the Timekeeping Mode, press D to display the latest

successful receive time and date screen.

2. Hold down A until the current auto receive setting (ON

or OFF) starts to flash. This is the setting screen.

•Note that the setting screen will not appear if the

currently selected Home City is one that does not

support time calibration reception.

On/Off status

3. Press D to toggle auto receive on (ON) and off (OFF).

4. Press A to exit the setting screen.

•For information about city codes that support signal receive, see “To specify your

Home City”.

To check the latest signal reception results

In the Timekeeping Mode, press to view the latestD

successful receive time and date. Press D again to

return to the previous screen.

•The watch also will return to normal timekeeping if you

do not perform any button operation for about one or two

minutes.

Signal Reception Troubleshooting

Check the following points whenever you experience problems with signal reception.

•The watch is not in the

Timekeeping Mode.

•Your current Home City is not

one of the following: LIS, , LON

MAD, PAR, ROM, BER, STO,

ATH, MOW, HKG, BJS, TPE,

SEL, TYO, HNL ANC, , YVR,

LAX, YEA, DEN, MEX CHI, ,

MIA, YTO, NYC, YHZ, or YYT

•A countdown timer operation is

in progress.

•You changed the time setting

manually.

•

The DST setting was changed

manually in the World Time Mode.

•You pressed a button while

signal receive was in progress.

•Even if receive is successful,

the RCVD indicator will

disappear from the display each

day when the first auto receive

operation of the day is

performed.

•Time data (hour, minutes,

seconds) only was received

during the last receive

operation. The RCVD indicator

appears only when time data

and date data (year, month,

day) are both received.

•Enter the Timekeeping Mode

and try again.

•Select LIS, LON, MAD, PAR,

ROM, BER, STO MOW, ATH, ,

HKG, BJS, TPE, SEL, TYO,

HNL, ANC, YVR, LAX, YEA,

DEN MEX CHI, , , MIA, YTO,

NYC, YHZ YYT, or as your

Home City.

•Enter the Countdown Timer

Mode and stop the countdown.

•Perform manual signal receive

or wait until the next auto

signal receive operation is

performed.

•Check to make sure the watch

is in a location where it can

receive the signal.

What you should doProblem Probable Cause

Cannot perform

manual receive.

Auto receive is

turned on, but

the RCVD

indicator does

not appear on

the display.

•If the time is one hour off, the

DST setting may be incorrect.

•The Home City code setting is

not correct for the area where

you are using the watch.

•Change the DST setting to

Auto DST.

•Select the correct Home City

code.

Time setting is

incorrect

following signal

reception.

•For further information, see “Important!” under “Time Calibration Signal Reception”

and “Radio-controlled Atomic Timekeeping Precautions”.

World Time

World Time shows the current time in 48 cities (29 time

zones) around the world.

•The times kept in the World Time Mode are

synchronized with the time being kept in the

Timekeeping Mode. If you feel that there is an error in

any World Time Mode time, check to make sure you

have the correct city selected as your Home City. Also

check to make sure that the current time as shown in

the Timekeeping Mode is correct.

•Select a city code in the World Time Mode to display the

current time in any particular time zone around the

globe. See the “City Code Table” for information about

the UTC differential settings that are supported.

•All of the operations in this section are performed in the

World Time Mode, which you enter by pressing C.

Current time in

selected city

City code

To view the time in another city

While in the World Time Mode, press D to scroll through the city codes (time zones).

•Pressing D and B at the same time will jump to the UTC time zone.

To toggle a city code time between Standard Time and Daylight Saving Time

1. In the World Time Mode, press D to display the city

code (time zone) whose Standard Time/Daylight Saving

Time setting you want to change.

2. Hold down A to toggle between Daylight Saving Time

(DST indicator displayed) and Standard Time (DST

indicator not displayed).

•The DST indicator is shown on the World Time Mode

screen while Daylight Saving Time is turned on.

•Note that the Standard Time/Daylight Saving Time

setting affects only the currently displayed city code.

Other city codes are not affected.

•Note that you cannot switch between Standard Time

and Daylight Saving Time while UTC is selected as the

city code.

DST indicator

Alarms

The Alarm Mode gives you a choice of four one-time

alarms and one snooze alarm.

Also use the Alarm Mode to turn the Hourly Time Signal

(SIG) on and off.

•There are five alarm screens numbered AL1 AL2, ,

AL3 AL and 4 for the one-time alarm, and a snooze

alarm screen indicated by SNZ. The Hourly Time

Signal screen is indicated by SIG.

•All of the operations in this section are performed in the

Alarm Mode, which you enter by pressing C.

Alarm number

Alarm time

(Hour : Minutes)

To set an alarm time

1. In the Alarm Mode, press D to scroll through the alarm

screens until the one whose time you want to set is

displayed.

•To set a one-time alarm, display alarm screen AL1, , .AL2 AL3 or AL4

To set the snooze alarm, display the SNZ screen.

•The snooze alarm repeats every five minutes.

2. After you select an alarm, hold down A until the hour setting of the alarm time

starts to flash, which indicates the setting screen.

•This operation turns on the alarm automatically.

3. Press C to move the flashing between the hour and minute settings.

4. While a setting is flashing, use D B (+) and (–) to change it.

•With the 12-hour format, set the time correctly as a.m. or p.m. ( indicator).P

5. Press A to exit the setting screen.

Alarm Operation

The alarm tone sounds at the preset time for 10 seconds, regardless of the mode the

watch is in. In the case of the snooze alarm, the alarm operation is performed a total

of seven times, every five minutes, until you turn the alarm off.

•Alarm and Hourly Time Signal operations are performed in accordance with the

Timekeeping Mode time.

•To stop the alarm tone after it starts to sound, press any button.

•Performing any one of the operations below during a 5-minute interval between

snooze alarms cancels the current snooze alarm operation.

Displaying the Timekeeping Mode setting screen

Displaying the

SNZ

setting screen

To test the alarm

In the Alarm Mode, hold down to sound the alarm.D

To turn an alarm on and off

1. In the Alarm Mode, use D to select an alarm.

2. Press to toggle it on (A) and off ( ).

•Turning on a alarm (AL1 AL2 AL3 AL, , , 4 or

SNZ) displays the alarm on indicator on its Alarm Mode

screen.

•In all modes, the alarm on indicator is shown for any

alarm that currently is turned on.

•The alarm on indicator flashes while the alarm is

sounding.

•The snooze alarm indicator flashes while the snooze

alarm is sounding and during the 5-minute intervals

between alarms.

On/Off status

Alarm on indicator

Snooze alarm indicator

To turn the Hourly Time Signal on and off

1. In the Alarm Mode, use D to select the Hourly Time

Signal (SIG).

2. Press to toggle it on (A) and off ( ).

•The Hourly Time Signal on indicator is shown on the

display in all modes while this function is turned on.

On/Off status

Hourly time signal

on indicator

Stopwatch

The stopwatch lets you measure elapsed time, split times,

and two finishes.

•The display range of the stopwatch is 23 hours, 59

minutes, 59.99 seconds.

•The stopwatch continues to run, restarting from zero

after it reaches its limit, until you stop it.

•The stopwatch measurement operation continues even

if you exit the Stopwatch Mode.

•Exiting the Stopwatch Mode while a split time is frozen

on the display clears the split time and returns to

elapsed time measurement.

•All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing C.

1/100 second

Seconds

Minutes

Hours

To measure times with the stopwatch

Elapsed Time

Split Time

Two Finishes

Start

Stop Re-start Stop

D DD

Split

(SPL displayed)

Split release Stop

A D

Split

First runner finishes.

Display time of first

runner.

Stop

Second runner

finishes.

Split release

Display time of

second runner.

D AA

➤➤➤

➤

Clear

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	GW-M5610LY-1

Behöver du hjälp?

Om du behöver hjälp med Casio GW-M5610LY-1 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
