Sida 1/5

Operation Guide 3197

MO1004-EA

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out of your

purchase, be sure to read this manual carefully.

Keep the watch exposed to bright light

The electricity generated by the solar cell of the watch is

stored by a rechargeable battery. Leaving or using the

watch where it is not exposed to light causes the battery

to run down. Make sure the watch is exposed to light as

much as possible.

•When you are not wearing the watch on your wrist,

position the face so it is pointed at a source of bright

light.

•You should try to keep the watch outside of your sleeve

as much as possible. Charging is reduced significantly if

the face is covered only partially.

Bright Light

Solar cell

All

functions

enabled

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Charge

Rechargeable battery

Bright Light

Electrical

energy

Solar cell

(Converts light to

electrical power.)

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Some or all

functions

disabled

Dis-

charge

Battery charges in the light. Battery discharges in the dark.

•The watch continues to operate, even when it is not exposed to light. Leaving the

watch in the dark can cause the battery to run down, which will result in some watch

functions to be disabled. If the battery goes dead, you will have to re-configure watch

settings after recharging. To ensure normal watch operation, be sure to keep it

exposed to light as much as possible.

•The actual level at which some functions are disabled depends on the watch model.

•Frequent display illumination can run down the battery quickly and require charging.

The following guidelines give an idea of the charging time required to recover from a

single illumination operation.

Approximately 5 minutes exposure to bright sunlight coming in through a window

Approximately about 8 hours exposure to indoor fluorescent lighting

•Be sure to read “Power Supply” for important information you need to know

when exposing the watch to bright light.

If the display of the watch is blank...

If the display of the watch is blank, it means that the watch’s Power Saving function

has turned off the display to conserve power.

•See “Power Saving Function” for more information.

About This Manual

•Button operations are indicated using the letters shown in the illustration.

•Each section of this manual provides you with the information you need to perform

operations in each mode. Fur ther details and technical information can be found in

the “Reference” section.

Countdown Timer Mode

Alarm Mode

▲

World Time Mode

▲

General Guide

•Press C to change from mode to mode.

•In any mode (except when a setting screen is on the display), press B to illuminate

the display.

Timekeeping Mode

Press .C

▲

Stopwatch Mode

Recall Mode

Demo Mode

In the Timekeeping Mode, holding down C for about three seconds will enter the

demo mode. In the demo mode, the screen cycles through the normal timekeeping,

stopwatch, and World Time screens in five-second intervals.

To exit the demo mode

Press any button.

Timekeeping

Use the Timekeeping Mode to set and view the current time and date.

Read This Before You Set the Time and Date!

This watch is preset with a number of city codes, each of which represents the time

zone where that city is located. When setting the time, it is important that you first

select the correct city code for your Home City (the city where you normally use the

watch). If your location is not included in the preset city codes, select the preset city

code that is in the same time zone as your location.

•Note that all of the times for the World Time Mode city codes are displayed in

accordance with the time and date settings you configure in the Timekeeping Mode.

Hour : Minutes

Seconds

Day of week

Year – Month – Day

PM indicator

To set the time and date manually

1. In the Timekeeping Mode hold down A until the city

code starts to flash, which indicates the setting screen.

2. Use D and B to select the city code you want.

•Make sure you select your Home City code before

changing any other setting.

•For full information on city codes, see “City Code

Table”.

3. Press C to move the flashing in the sequence shown below to select the other

settings.

Seconds

12/24-Hour

Format Hour Minutes

DST

Month Year

City Code

DayPower Saving Illumination

Duration

Button

Operation Tone

4. When the timekeeping setting you want to change is flashing, use D or B to

change it as described below.

Change the city code

Toggle between Daylight Saving Time ( )

and Standard Time ( ).

Toggle between 12-hour ( ) and 24-

hour ( ) timekeeping

Reset the seconds to

Change the hour and minutes

Use D (east) and B

(west).

Press D.

Use D (+) and B (–).

Screen: To do this: Do this:

•The following steps explain how to configure timekeeping settings only.

5. Press A to exit the setting screen.

•The day of the week is displayed automatically in accordance with the date (year,

month, and day) settings.

Change the year, month, or day

Toggle the button operation tone between

(on) and (off)

Toggle the illumination duration between

(approximately 1.5 seconds) and

(approximately 3 seconds).

Toggle between Power Saving on ( ) and

off ( )

Use D B (+) and (–).

Press D.

12-hour and 24-hour timekeeping

•With the 12-hour format, the P (PM) indicator appears to the left of the hour digits for

times in the range of noon to 11:59 p.m. and no indicator appears to the left of the

hour digits for times in the range of midnight to 11:59 a.m.

•With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without

any indicator.

•The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all other modes.

Daylight Saving Time (DST)

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

Operation Guide 3197

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down A until the city

code starts to flash, which indicates the setting screen.

2. Press C and the DST setting screen appears.

3. Use D to cycle through the DST settings in the

sequence shown below.

4. When the setting you want is selected, press A to exit

the setting screen.

• The DST indicator appears to indicate that Daylight

Saving Time is turned on.

DST indicator

Stopwatch

The 1/100-second stopwatch can measure elapsed time

and lap/split times. Stopwatch times are stored in memory.

•The stopwatch measurement operation continues even

if you exit the Stopwatch Mode.

•Exiting the Stopwatch Mode while a lap/split time is

frozen on the display clears the lap/split time and returns

to elapsed time measurement.

•All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing C.

Note

•See “How Stopwatch Data is Stored” for information

about the type of data the watch stores in memory when

you use the stopwatch.

•Use the Recall Mode to view data stored in memory.

Timekeeping

Mode time

1/100 second

Seconds

Hours

Minutes

Remaining memory

Lap time

Graphic Area

To measure times with the stopwatch

➤➤➤➤

ClearNext Lap/

Split

➤

Start Stop

Elapsed Time

Re-start Clear

Stop

D D A

Lap/Split Times

Start Lap/Split

Stop

AD➤A

➤➤

Note

•Pressing A to perform a lap/split time operation freezes the lap/split time at that

point on the display for about eight seconds. After that, the display returns to normal

stopwatch time measurement.

•During a stopwatch time measurement operation, the current lap/split number is

shown at the top of the display, and the lap time and split time are shown in the

middle and at the bottom. You can swap the positions of the lap time and split time

(between the middle and bottom of the display) by pressing A while the stopwatch

is reset to all zeros. For more information, see “To position the lap time and split time

on the display”.

Lap/Split indicator

Lap time

Lap/Split indicator

Split time

•A graphic animation plays on the display while a stopwatch timing operation is being

performed. You can toggle the animation on and off by holding down while theA

stopwatch is reset to all zeros.

•Whenever the elapsed time exceeds 10 hours, the measurement changes from

1/100-second units to 1-second units.

To position the lap time and split time on the display

•You can swap the positions of the lap time and split time (between the middle and

bottom of the display) by pressing A while the stopwatch is reset to all zeros.

Remaining memory

Lap/Split indicator

Lap time

Press A.

Split time

Lap/Split indicator

➤

Graphic Area

More than 10 hours

Hours Minutes Seconds

Recall Mode

Use the Recall Mode to recall and delete records stored

by the Stopwatch Mode.

•Stopwatch records are stored in “logs” that are created

automatically by the watch. See “Memory Management”

for more information.

•The title screen of the newest log appears first whenever

you enter the Recall Mode.

•Log numbers are automatically assigned in sequence,

starting from 01.

•All of the operations in this section are performed in the

Recall Mode, which you enter by pressing C.

Log number

Creation date

(Month – Day)

Log Title Screen

Time measurement

was performed

Press D.

Split time

Lap/Split number BEST indicator

Press .A

Log Title Screen

Stopwatch Record

Screen

Best Lap Time

Screen

Lap time

▲

To recall stopwatch records

In the Recall Mode, use to scroll through the log titleA

screens, starting from the newest one, as shown below.

When the title screen of the log you want is displayed, use

D to cycle through the records contained in the log.

•The locations of the lap time and split time in the Stopwatch Record screen are

determined by the display format you last selected in the Stopwatch Mode.

•The BEST indicator identifies the record that contains the best lap time in the log.

•If a best lap time record is deleted automatically when the log becomes full, the

BEST indicator will not be transferred to the record with the next best lap time. See

“Memory Management” for more information about automatic deletion of records.

To delete a log

1. In the Recall Mode, display the title screen or one of the records of the log you want

to delete.

2. While holding down for about two seconds until the watch beeps.B, hold down D

•“CLR” will flash on the display for two seconds and then the watch will beep.

Release B and D at this time.

•You cannot delete the log of an ongoing elapsed time measurement operation.

To delete all logs

1. While holding down B D, hold down for about five seconds until the watch beeps

once and then a second time.

•“CLR” will flash on the display for two seconds and then the watch will beep once.

Keep B and D depressed and “ALL” will flash on the display for three seconds,

and then the watch will beep again. This indicates that all log data is cleared.

•You cannot delete logs while an elapsed timing operation is in progress.

Countdown Timer

Dual timers can be set with two different starting times.

The watch can be configured so the two timers alternate,

so when one reaches the end of its countdown, the other

timer starts. You can specify a “number of repeats” value,

which controls how many times the two-timer countdown

operation is performed (1 = once, 2 = twice, etc.). The

starting time of each timer can be set in five-second steps

up to 99 minutes, 55 seconds.

You can specify up to 10 repeats. The watch emits a short

beep whenever either of the timers reaches the end of its

countdown during an ongoing timer operation. The watch

emits a 5-second beep when the end of the final timer

operation (specified by the number of repeats) is reached.

Countdown End Beeper

The countdown end beeper lets you know when the countdown reaches zero. The

beeper stops after about 5 seconds or when you press any button.

Seconds

Minutes Timer 1

Number of Repeats

To configure the countdown timer

1. While the countdown start time is on the display in the

Countdown Timer Mode, hold down A until the current

countdown start time starts to flash, which indicates the

setting screen.

•If the countdown start time is not displayed, use the

procedure under “To use the countdown timer” to

display it.

2. Press C to move the flashing in the sequence shown

below to select other settings.

Timer 1

Minutes

Timer 1

Seconds

Timer 2

Seconds

Timer 2

Minutes

Number of Repeats

•To disable either timer, set 00'00" as its countdown start time.

4. Press A to exit the setting screen.

Button Operation

Use D (+) and B (–) to change the setting.

Setting

Minutes, Seconds

Number of Repeats

Screen

3. When the setting you want to change is flashing, use and D B to change it as

described below.

To use the countdown timer

Current timer time

Preset number of repeats

Current repeat count

Current time

Timer 1 or 2

(Reset)

(Start/Stop)

Press while in the Countdown Timer Mode to start the countdown timer.D

•The countdown is performed by alternating between Timer 1 and Timer 2. A short

beep is emitted to signal a changeover from one timer to the other.

•Pressing A while a countdown timer is stopped resets it to the start time specified

by you.

•Press to pause a countdown. Press again to resume.D D

•The watch emits a 5-second beep when the end of the final timer operation

(specified by the number of repeats) is reached.

•Even if you exit the Countdown Timer Mode, the countdown timer operation

continues and the watch beeps as required.

•To stop a countdown operation completely, first pause it (by pressing ), and thenD

press A. This returns the countdown time to its starting value.

Operation Guide 3197

World Time

World Time shows the current time in 48 cities (31 time

zones) around the world.

•The times kept in the World Time Mode are

synchronized with the time being kept in the

Timekeeping Mode. If you feel that there is an error in

any World Time Mode time, check to make sure you

have the correct city selected as your Home City. Also

check to make sure that the current time as shown in

the Timekeeping Mode is correct.

•Select a city code in the World Time Mode to display the

current time in any particular time zone around the

globe. See “City Code Table” for information about the

UTC differential settings that are supported.

•All of the operations in this section are performed in the

World Time Mode, which you enter by pressing C.

Current time in

selected city

City code

To view the time in another city

While in the World Time Mode, use (eastward) to scroll through the city codesD

(time zones).

•Pressing D and B at the same time will jump to the UTC time zone.

To toggle a city code time between Standard Time and Daylight Saving Time

1. In the World Time Mode, use D to display the city code

(time zone) whose Standard Time/Daylight Saving Time

setting you want to change.

2. Hold down A to toggle between Daylight Saving Time

(DST indicator displayed) and Standard Time (DST

indicator not displayed).

•The DST indicator is shown on the World Time Mode

screen while Daylight Saving Time is turned on.

•Note that the Standard Time/Daylight Saving Time

setting affects only the currently displayed city code.

Other city codes are not affected.

•Note that you cannot switch between Standard Time

and Daylight Saving Time while UTC is selected as the

city code.

DST indicator

Alarms

The Alarm Mode gives you a choice of four one-time

alarms and one snooze alarm.

Also use the Alarm Mode to turn the Hourly Time Signal

(SIG) on and off.

•There are five alarm screens numbered AL1 AL2, ,

AL3 AL and 4 for the one-time alarm, and a snooze

alarm screen indicated by SNZ. The Hourly Time

Signal screen is indicated by SIG.

•All of the operations in this section are performed in the

Alarm Mode, which you enter by pressing C.

Alarm number

Alarm time

(Hour : Minutes)

To set an alarm time

1. In the Alarm Mode, use D to scroll through the alarm

screens until the one whose time you want to set is

displayed.

•To set a one-time alarm, display alarm screen AL1, , .AL2 AL3 or AL4

To set the snooze alar m, display the SNZ screen.

•The snooze alarm repeats ever y five minutes.

2. After you select an alarm, hold down A until the hour setting of the alarm time

starts to flash, which indicates the setting screen.

•This operation turns on the alarm automatically.

3. Press

C to move the flashing between the hour and minute settings.

4. While a setting is flashing, use D B (+) and (–) to change it.

•With the 12-hour format, set the time correctly as a.m. or p.m. ( indicator).P

5. Press A to exit the setting screen.

Alarm Operation

The alarm tone sounds at the preset time for 10 seconds, regardless of the mode the

watch is in. In the case of the snooze alarm, the alarm operation is performed a total

of seven times, every five minutes, until you turn the alarm off.

•Alarm and Hourly Time Signal operations are performed in accordance with the

Timekeeping Mode time.

•To stop the alarm tone after it starts to sound, press any button.

•Performing any one of the operations below during a 5-minute interval between

snooze alarms cancels the current snooze alarm operation.

Displaying the Timekeeping Mode setting screen

Displaying the

SNZ

setting screen

To test the alarm

In the Alarm Mode, hold down to sound the alarm.D

To turn an alarm on and off

1. In the Alarm Mode, use D to select an alarm.

2. Press to toggle it on and off.A

•Tur ning on an alarm (AL1 AL2 AL3 AL, , , 4 or

SNZ) displays the alarm on indicator on its Alarm Mode

screen.

•In all modes, the alarm on indicator is shown for any

alarm that currently is turned on.

•The alarm on indicator flashes while the alarm is

sounding.

•The snooze alarm indicator flashes while the snooze

alarm is sounding and during the 5-minute intervals

between alarms.

Alarm on indicator

Alarm on/off

: Alarm on

: Alarm off

Snooze alarm

indicator

To turn the Hourly Time Signal on and off

1. In the Alarm Mode, use D to select the Hourly Time

Signal (SIG).

2. Press to toggle it on and off.A

•The Hourly Time Signal on indicator is shown on the

display in all modes while this function is turned on.

Hourly time signal

on indicator

Illumination

An LED (light-emitting diode) illuminate the display for

easy reading in the dark.

Illumination Precautions

•The illumination provided by the light may be hard to see

when viewed under direct sunlight.

•Illumination automatically turns off whenever an alarm

sounds.

•Frequent use of illumination runs down the battery.

To illuminate the display manually

In any mode (except when a setting screen is on the

display), press B to turn on illumination.

•You can use the procedure below to select either 1.5 seconds or 3 seconds as the

illumination duration. When you press , the illumination will remain on for aboutB

1.5 seconds or 3 seconds, depending on the current illumination duration setting.

To specify the illumination duration

1. In the Timekeeping Mode, hold down A until the

display contents start to flash. This is the setting screen.

2. Press C 10 times until the current illumination duration

setting ( or ) appears.

3. Press D to toggle the setting between

(approximately 1.5 seconds) and (approximately

3 seconds).

4. Press to exit the setting screen.A

Power Supply

This watch is equipped with a solar cell and a rechargeable battery that is charged by

the electrical power produced by the solar cell. The illustration shown below shows

how you should position the watch for charging.

Example: Orient the watch so its face is

pointing at a light source.

•The illustration shows how to position a

watch with a resin band.

•Note that charging efficiency drops when

any part of the solar cell is blocked by

clothing, etc.

•You should try to keep the watch outside of

your sleeve as much as possible. Charging

is reduced significantly if the face is

covered only partially.

Solar cell

Important!

•Storing the watch for long periods in an area where there is no light or wearing it in

such a way that it is blocked from exposure to light can cause rechargeable battery

power to run down. Be sure that the watch is exposed to bright light whenever

possible.

•This watch uses a rechargeable battery to store power produced by the solar cell, so

regular battery replacement is not required. However, after ver y long use, the

rechargeable battery may lose its ability to achieve a full charge. If you experience

problems getting the rechargeable battery to charge fully, contact your dealer or

CASIO distributor about having it replaced.

•Never try to remove or replace the watch’s rechargeable battery yourself. Use of the

wrong type of battery can damage the watch.

•All data stored in memory is deleted, and the current time and all other settings

return to their initial factory defaults whenever battery power drops to Level 5 and

when you have the battery replaced.

•Tur n on the watch’s Power Saving function and keep it in an area normally exposed

to bright light when storing it for long periods. This helps to keep the rechargeable

battery from going dead.

Level

Battery Power Indicator Function Status

All functions enabled.

Illumination, and beeper

disabled.

Except for timekeeping and

the CHG (charge) indicator,

all functions and display

indicators disabled.

All functions disabled.

Battery Power Indicator and Recover Indicator

The battery power indicator on the display shows you the current status of the

rechargeable battery’s power.

Battery power

indicator

•The flashing indicator at Level 3 tells you that battery power is very low, and thatL

exposure to bright light for charging is required as soon as possible.

•At Level 5, all functions are disabled and settings return to their initial factory

defaults. Once the battery reaches Level 2 after falling to Level 5, reconfigure the

current time, date, and other settings.

•The watch’s Home City code setting will change automatically to TYO (Tokyo)

whenever the battery drops to Level 5.

•

Display indicators reappear as soon as the battery is charged from Level 5 to Level 2.

•Leaving the watch exposed to direct sunlight or some other very strong light source

can cause the battery power indicator to show a reading temporarily that is higher

than the actual battery level. The correct battery level should be indicated after a few

minutes.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	LW-S200H-8AEF

Behöver du hjälp?

Om du behöver hjälp med Casio LW-S200H-8AEF ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
