PX320ES1A

USER’S GUIDE

GUÍA DEL USUARIO

Please keep all information for future reference.

Guarde toda documentación para futuras consultas.

Safety Precautions

Before trying to use the piano, be sure to read

the separate “Safety Precautions”.

Precauciones de seguridad

Antes de intentar usar el piano, asegúrese de

leer las “Precauciones de seguridad” separadas.

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Impor tant!

Please note the following important information before using this product.

• Before using the AD-12 Adaptor to power the product, be sure to check the AC Adaptor for any damage first. Carefully check the power cord

for breakage, cuts, exposed wire and other serious damage. Never let children use an AC adaptor that is seriously damaged.

• The product is not intended for children under 3 years.

• Use only CASIO AD-12 adaptor.

• The AC adaptor is not a toy.

• Be sure to disconnect the AC adaptor before cleaning the product.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.

A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the

provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit

from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has been dropped.

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

The power indicator being unlit does not mean the apparatus is completely disconnected from the MAINS.

When you need to have the apparatus completely disconnected from the MAINS, you must unplug the power cord. For that purpose, locate

the apparatus in a way that secures easy access to the power cord.

Declaration of Conformity

Model Number: PX-320

Trade Name: CASIO COMPUTER CO., LTD.

Responsible party: CASIO AMERICA, INC.

Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801

Telephone number: 973-361-5400

This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that

may cause undesired operation.

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

Manufacturer:

CASIO COMPUTER CO.,LTD.

6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan

Responsible within the European Union:

CASIO EUROPE GmbH

Bornbarch 10, 22848 Norderstedt, Germany

This mark applies in EU countries only.

E-1

Contents

General Guide........................... E-2

Installing the Music Stand........................................... E-3

TONE, Area Buttons (1 through 12) ........................... E-4

Using the T/NO and S/YES Buttons ......................... E-5

Saving Settings and Using Operation Lock ................ E-5

Returning the Digital Piano to Its Factory

Default Settings .......................................................... E-5

Power Outlet ............................. E-6

Using an AC Adaptor .................................................. E-6

Connections.............................. E-7

Connecting Headphones ............................................ E-7

Connecting a Pedal .................................................... E-7

Connecting Audio Equipment or an Amplifier ............. E-8

Selecting and

Playing a Tone........................ E-10

To select a refined tone ............................................ E-10

To select a VARIOUS tone, GM tone, or drum set ... E-11

To adjust the brilliance of a tone ............................... E-11

Layering Two Tones ................................................. E-12

Splitting the Keyboard between Two Tones ............. E-12

Using Effects............................................................. E-13

Using the Metronome ............................................... E-14

Playing a Piano Duet ................................................ E-15

Playing a Rhythm ...................E-17

Selecting a Rhythm................................................... E-17

Using Auto Accompaniment ..................................... E-18

Playing Back Built-in

Songs ......................................E-22

Playing Back All of the Built-in Songs....................... E-22

Playing Back a Specific Music Library Song............. E-23

Practicing with a Music Library Song........................ E-24

Saving Digital Piano Setups

(Registration Memory) ........... E-25

To store a setup in registration memory ................... E-26

To recall a setup from registration memory .............. E-27

Recording and Play Back ...... E-28

Songs and Tracks..................................................... E-28

Recording Your Keyboard Play ................................ E-29

To play back from digital piano memory ................... E-31

To delete a specific track .......................................... E-31

Other Settings.........................E-32

To configure other settings........................................ E-32

Secondary Parameter Reference.............................. E-34

Connecting to a Computer ....E-38

Connecting to the MIDI Terminal .............................. E-38

Connecting to the USB Port...................................... E-38

USB Mode and MIDI Mode ....................................... E-39

Expanding the Selections in the Music Library ......... E-40

Using an SD Memory Card ....E-41

Inserting and Removing an SD Memory Card .......... E-42

Formatting an SD Memory Card ............................... E-43

Saving Recorded/Registration Data to an

SD Memory Card ...................................................... E-43

Transferring Data from an SD Memory Card to

Digital Piano Memory................................................ E-45

Playing Back a File Stored on an

SD Memory Card ...................................................... E-47

SD Memory Card Errors............................................ E-48

Reference ................................E-49

Troubleshooting ........................................................ E-49

Product Specifications............................................... E-51

Operating Precautions .............................................. E-52

Appendix ...................................A-1

Tone List .....................................................................A-1

Drum Assignment List ................................................. A-3

Rhythm List ................................................................. A-4

Song List ..................................................................... A-5

Fingered Chord Chart ................................................. A-6

MIDI Implementation Chart

Company and product names used in this

manual may be registered trademarks of others.
