Sida 1/13

E-7

2. Check the Home City and the daylight saving time (DST) setting.

Use the procedure under “To conﬁ gure Home City and summer time settings” (page E-24) to conﬁ gure your

Home City and daylight saving time settings.

Important!

• Proper World Time Mode data depends on correct Home City, time, and date settings in the

Timekeeping Mode. Make sure you conﬁ gure these settings correctly.

3. Set the current time.

See “Conﬁ guring Current Time and Date Settings” (page E-26).

The watch is now ready for use.

E-6

Things to check before using the watch

1. Check the battery power level.

Hold down B for at least two seconds to enter the Timekeeping Mode and display the battery power

level.

NO YES

YES

The battery power level will be indicated as

H or M on the left

side of the digital display.

Battery power

indicator

Does any one of the following conditions exist?

• L ﬂ ashing on the digital display.

• CHARGE is ﬂ ashing on the display.

The watch is charged

sufﬁ ciently.

For details about

charging, see

“Charging the Watch”

(page E-12).

Power is low. Charge the watch by placing it in a location

where it is exposed to light. For details, see “Charging the

Watch” (page E-12). Go to step 2.

• When L is ﬂ ashing, the second hand will jump at two-second intervals.

• When CHARGE is ﬂ ashing, all hands will move to and stop at 12 o’clock.

E-5

Note

• If you do not perform any operation for more than two minutes after pulling out the crown, the indicator

shown below will appear and crown operations will become disabled. If this happens, push the crown

back in and then pull it out again to re-enable crown operations.

• Pulling out the crown while the watch is in a mode that does not allow conﬁ guration of any settings will

cause the indicator shown below to appear. If this happens, push the crown back in and lock it.

• The indicator shown below also appears when performing hand home position adjustment. See “Hand

Home Position Adjustment” (page E-29) for more information.

1 second

• You can use high-speed movement in the following cases: when changing the time and/or date setting

in the Timekeeping Mode, World Time Mode, Countdown Timer Mode, or Alarm Mode, or when

performing magnetic declination angle calibration, altitude calibration, barometric pressure calibration,

or temperature calibration operations.

E-4

High-speed Movement

You can use either of the crown operations described below to move watch hands or indicators at high

speed.

HS1: Can be used to move both hands and display indicators.

HS2: Can be used when setting the hour and minute manually to move the hands at high speed.

To start HS1 high-speed movement

While the crown is pulled out, rotate it rapidly away from you (forward) or

towards you (reverse) until the desired HS1 high-speed movement starts.

To start HS2 high-speed movement

While HS1 high-speed movement is in progress, again rotate the crown rapidly,

away from you (forward) or towards you (reverse) in the same direction as the

HS1 movement until HS2 high-speed movement starts.

To stop high-speed movement

Rotate the crown in the direction that is opposite that of the current high-speed

movement or press any button.

E-3

Using the Crown

The crown of this watch is a screw in lock crown. Before using the crown,

you must ﬁ rst rotate it towards you to loosen it. After performing crown

operations, be sure to press the crown in lightly as you screw it back in.

Important!

• To maintain water resistance and avoid impact damage to the crown,

be sure to screw it back in when you are not using it.

The illustrations below show the different crown operations.

Pull out Rotate Push in

Crown

Loosen

E-2

About This Manual

• Depending on the model of your watch, digital display text appears

either as dark ﬁ gures on a light background, or light ﬁ gures on a dark

background. All examples in this manual are shown using dark ﬁ gures

on a light background.

• Button operations are indicated using the letters shown in the

illustration.

• Note that the product illustrations in this manual are intended for

reference only, and so the actual product may appear somewhat

different than depicted by an illustration.

Second Hand

CrownMode Hand

Hour Hand Minute Hand

E-1

ENGLISH

Important!

• The watch’s Altimeter Mode calculates and displays relative altitude based on barometric pressure

readings produced by its pressure sensor. This means that readings taken at different times at the

same location may produce different altitude values due to changes in barometric pressure. Also note

that the value displayed by the watch may be different from the actual elevation and/or sea level

elevation indicated for the area where you are located.

• When using the watch’s altimeter while mountain climbing, be sure to perform regular calibration in

accordance with the local altitude (elevation) indications. For more information, see “To specify a

reference altitude value” (page E-46).

• Whenever you use the digital compass of this watch for serious trekking, mountain climbing, or other

activities, be sure always to take along another compass to conﬁ rm readings. If the readings produced

by the digital compass of this watch are different from those of the other compass, perform bidirectional

calibration of the digital compass to ensure more accurate readings.

• Direction readings and digital compass calibration will not be possible if the watch is in the vicinity of a

permanent magnet (magnetic accessory, etc.), metal objects, high-voltage wires, aerial wires, or

electrical household appliances (TV, computer, cellphone, etc.)

Congratulations upon your selection of this CASIO watch.

Applications

The built-in sensors of this watch measure direction, barometric pressure, temperature and altitude.

Measured values are then shown on the display. Such features make this watch useful when hiking,

mountain climbing, or when engaging in other such outdoor activities.

Warning !

• The measurement functions built into this watch are not intended for taking measurements that

require professional or industrial precision. Values produced by this watch should be considered

as reasonable representations only.

•

When engaging in mountain climbing or other activities in which losing your way can create a

dangerous or life-threatening situation, always use a second compass to conﬁ rm direction readings.

• Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss

suffered by you or any third party arising through the use of your watch or its malfunction.

Operation Guide 5497

E-15

• Leaving the watch exposed to direct sunlight or some other very strong light source can cause the

battery power indicator to show a reading temporarily that is higher than the actual battery level. The

correct battery level should be indicated after a few minutes.

• All data stored in memory is deleted, and the current time and all other settings return to their initial

factory defaults whenever battery power drops to Level 5 and when you have the battery replaced.

A dark environment while battery power is at Level 4 will cause the level to drop to Level 5. Expose the

watch to bright light whenever possible.

• The Home City setting reverts to the initial default of TYO (Tokyo) whenever the battery power level

drops to Level 5 or when you have the rechargeable battery replaced. If this happens, change the

Home City to the setting you want (page E-24).

Low battery alert

When battery power reaches Level 3, the second hand of the watch will

jump at 2-second intervals in the Timekeeping Mode to let you know that

charging is required.

Jumps at two-second

intervals

E-14

Level Battery Power Indicator Function Status

(L)

Illumination, beeper, and sensor operation

disabled.

Second hand jumps every two seconds.

(CHARGE)

All hands stopped at 12 o’clock.

All functions disabled.

5 – – –

All hands stopped at 12 o’clock.

All functions disabled and settings return

to their initial factory defaults.

• The ﬂ ashing L indicator at Level 3 (L) tells you that battery power is very low, and that exposure to

bright light for charging is required as soon as possible.

• Once the battery reaches Level 2 (M) after falling to Level 5, reconﬁ gure the current time, date, and

other settings.

• Display indicators reappear as soon as the battery is charged from Level 5 to Level 2 (M).

E-13

Important!

• Allowing the watch to become very hot can cause its liquid crystal display to go blank (totally black or

totally white, depending on the watch model). The appearance of the LCD should become normal

again when the watch returns to a lower temperature.

• Turn on the watch’s Power Saving function (page E-18) and keep it in an area normally exposed to bright

light when storing it for long periods. This helps to ensure that power does not run down.

• Storing the watch for long periods in an area where there is no light or wearing it in such a way that it is

blocked from exposure to light can cause power to run down. Expose the watch to bright light

whenever possible.

Power Levels

Hold down B for at least two seconds to enter the Timekeeping Mode.

You can get an idea of the watch’s power level by observing the battery power indicator on the display.

Level Battery Power Indicator Function Status

(H) All functions enabled.

(M) All functions enabled.

Battery power

indicator

E-12

Charging the Watch

The face of the watch is a solar panel that generates power from light. The generated power charges a

built-in rechargeable battery, which powers watch operations. The watch charges whenever it is exposed

to light.

Charging Guide

Whenever you are not wearing the

watch, leave it in a location where it

is exposed to light.

• Best charging performance is

achieved by exposing the watch to

the strongest light available.

When wearing the watch, make sure

that its face is not blocked from light

by the sleeve of your clothing.

• The watch may enter a sleep state

(page E-18) if its face is blocked by

your sleeve even only partially.

Warning!

Leaving the watch in bright light for charging can cause it to become quite hot.

Take care when handling the watch to avoid burn injury. The watch can become particularly hot

when exposed to the following conditions for long periods.

• On the dashboard of a car parked in direct sunlight

• Too close to an incandescent lamp

• Under direct sunlight

E-11

Checking the Current Time in a Different Time Zone ………………………………………………… E-81

To enter the World Time Mode …………………………………………………………………… E-81

To conﬁ gure World Time City and summer time settings ……………………………………… E-82

To swap your Home City and World Time City …………………………………………………… E-84

To access the UTC (Universal Time Coordinated) time zone ………………………………… E-84

Illumination ………………………………………………………………………………………………… E-85

To turn on illumination manually …………………………………………………………………… E-85

To change the illumination duration ……………………………………………………………… E-85

To enable or disable the auto light switch ………………………………………………………… E-87

Other Settings ……………………………………………………………………………………………… E-89

To turn the button operation tone on or off ……………………………………………………… E-89

To turn Power Saving on or off …………………………………………………………………… E-89

Troubleshooting …………………………………………………………………………………………… E-90

Speciﬁ cations ……………………………………………………………………………………………… E-95

E-10

Viewing Altitude Records ………………………………………………………………………………… E-70

To view altitude records …………………………………………………………………………… E-70

To delete all recorded data ………………………………………………………………………… E-73

To delete a speciﬁ c record ………………………………………………………………………… E-73

Using the Stopwatch ……………………………………………………………………………………… E-74

To enter the Stopwatch Mode ……………………………………………………………………… E-74

To perform an elapsed time operation …………………………………………………………… E-74

To pause at a split time ……………………………………………………………………………… E-74

To measure two ﬁ nishes …………………………………………………………………………… E-75

Using the Countdown Timer ……………………………………………………………………………… E-76

To enter the Countdown Timer Mode ……………………………………………………………… E-76

To specify the countdown start time ……………………………………………………………… E-76

To perform a countdown timer operation ………………………………………………………… E-77

To stop the alarm …………………………………………………………………………………… E-77

Using the Alarm …………………………………………………………………………………………… E-78

To enter the Alarm Mode …………………………………………………………………………… E-78

To set an alarm time ………………………………………………………………………………… E-79

To turn an alarm and the Hourly Time Signal on and off………………………………………… E-80

To stop the alarm …………………………………………………………………………………… E-80

To test the alarm …………………………………………………………………………………… E-80

E-9

Taking Direction Readings ……………………………………………………………………………… E-32

To take a direction reading ………………………………………………………………………… E-33

To perform bidirectional calibration ………………………………………………………………… E-37

To perform magnetic declination correction ……………………………………………………… E-38

Specifying Altitude, Barometric Pressure, and Temperature Units ……………………………… E-41

To specify altitude, barometric pressure, and temperature units ……………………………… E-41

Using the Altimeter Mode ………………………………………………………………………………… E-42

To specify the altitude auto reading interval ……………………………………………………… E-43

To take altitude readings …………………………………………………………………………… E-44

To specify a reference altitude value ……………………………………………………………… E-46

To specify the altitude differential measurement range ………………………………………… E-48

To use the altitude differential value ……………………………………………………………… E-49

To save a reading manually ………………………………………………………………………… E-51

Precautions Concerning Simultaneous Altitude and Temperature Readings ………………… E-57

Taking Barometric Pressure Readings ………………………………………………………………… E-58

To take barometric pressure readings …………………………………………………………… E-58

To show and hide barometric pressure differential ……………………………………………… E-61

To enable or disable the barometric pressure change indicator ……………………………… E-64

To calibrate the pressure sensor …………………………………………………………………… E-66

Taking Temperature Readings …………………………………………………………………………… E-67

To take temperature readings ……………………………………………………………………… E-67

To calibrate the temperature sensor ……………………………………………………………… E-68

E-8

Contents

About This Manual …………………………………………………………………………………………… E-2

Using the Crown ……………………………………………………………………………………………… E-3

Things to check before using the watch ………………………………………………………………… E-6

Charging the Watch ………………………………………………………………………………………… E-12

To recover from the sleep state …………………………………………………………………… E-18

Mode Reference Guide …………………………………………………………………………………… E-19

Timekeeping ………………………………………………………………………………………………… E-23

Conﬁ guring Home City Settings ………………………………………………………………………… E-24

To conﬁ gure Home City and summer time settings ……………………………………………… E-24

Conﬁ guring Current Time and Date Settings ………………………………………………………… E-26

To change the current time and date settings …………………………………………………… E-26

To switch between 12-hour and 24-hour timekeeping …………………………………………… E-28

Hand Home Position Adjustment ……………………………………………………………………… E-29

To adjust home positions …………………………………………………………………………… E-29

Moving the Hands for Easy Viewing of the Digital Dials …………………………………………… E-30

To shift the hands and view digital info …………………………………………………………… E-30

To return the hands to their normal positions …………………………………………………… E-31

Operation Guide 5497

E-23

Timekeeping

Use the Timekeeping Mode (TIME) to set and view the current time and date.

• Each press of D in the Timekeeping Mode will change screen contents as shown below.

Day of the week,

month/day screen

Barometric pressure change,

date (month/day) screen

Time (hour, minute,

second) screen

Hour Hand

Mode Hand

Second Hand

Minute Hand

Day of week Month Day

Barometric

pressure graph Month Day Hour : Minutes

E-22

General Functions (All Modes)

The functions and operations described in this section can be used in all of the modes.

Auto Return Features

• The watch automatically returns to the Timekeeping Mode from other modes if the crown is not pulled

out or if no button operation is performed for a preset amount of time.

Mode Name Approximate Elapsed Time

Digital Compass 1 minute

Data Recall, Alarm 3 minutes

Altimeter 1 hour minimum

12 hours maximum

Barometer, Thermometer 1 hour

Initial Screens

When you enter the Data Recall, Alarm, or World Time Mode, the data you were viewing when you last

exited the mode appears ﬁ rst.

E-21

• Button operations are provided for direct access to the Timekeeping, Digital Compass, and Altimeter

modes.

Timekeeping Mode

Digital Compass Mode Altimeter Mode

E-20

Selecting a Mode

• The illustration below shows which buttons you need to press to navigate between modes.

• To return to the Timekeeping Mode from any other mode, hold down B for about two seconds.

Countdown Timer Mode

Stopwatch Mode

Alarm Mode

Data Recall Mode

World Time Mode

Thermometer Mode Barometer Mode

E-19

Mode Reference Guide

Your watch has 10 “modes”. The mode you should select depends on what you want to do.

To do this: Enter this mode: See:

• View the current time and date in the Home City

• Conﬁ gure Home City and daylight saving time (DST) settings

• Conﬁ gure time and date settings

Timekeeping Mode E-23

Determine your current bearing or the direction from your current location to a

destination Digital Compass Mode E-32

• View the altitude at your current location

• Determine the altitude differential between two locations (reference point and

current location)

• Record an altitude reading with the reading time and date

Altimeter Mode E-42

• View the barometric pressure at your current location

• View a graph of barometric pressure readings

•

Enable alerts (display and beep) for noteworthy changes in barometric pressure

Barometer Mode E-58

View the temperature at your current location Thermometer Mode E-67

Recall records created in the Altimeter Mode Data Recall Mode E-70

Use the stopwatch to measure elapsed time Stopwatch Mode E-74

Use the countdown timer Countdown Timer Mode E-76

Set an alarm time Alarm Mode E-78

View the current time in 29 cities (29 time zones) and UTC (Universal Coordinated

Time) time World Time Mode E-81

E-18

Power Saving

When turned on, Power Saving enters a sleep state automatically whenever the watch is left for a certain

period in an area where it is dark. The table below shows how watch functions are affected by Power

Saving.

• For information about enabling and disabling power saving, see “To turn Power Saving on or off” (page

E-89).

• There actually are two sleep state levels: “display sleep” and “function sleep”.

Elapsed Time in Dark Hands and Display Operation

60 to 70 minutes (display sleep) Blank display, second hand

stopped.

Except for display and second hand, all

functions enabled.

6 or 7 days (function sleep) Blank display, all hands

stopped at 12 o’clock.

Except for timekeeping, all functions

disabled.

• The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is already in a sleep

state when 6:00 AM arrives, however, it will remain in the sleep state.

• The watch will not enter a sleep state while it is in the Stopwatch Mode or Countdown Timer Mode.

• The watch will not enter a sleep state while barometric pressure change indication is enabled (page E-63).

To recover from the sleep state

Move the watch to a well-lit area, press any button, or angle the watch towards your face for reading (page

E-86).

E-17

Charging Times

Exposure Level (Brightness)

Daily

Operation

Level Change *2

Level 5 Level 4 Level 3 Level 2 Level 1

Outdoor sunlight (50,000 lux) 8 min. 3 hours 25 hours 7 hours

Sunlight through a window (10,000 lux)

30 min. 7 hours 92 hours 25 hours

Daylight through a window on a

cloudy day (5,000 lux) 48 min. 11 hours 149 hours 40 hours

Indoor ﬂ uorescent lighting (500 lux) 8 hours 135 hours – – – – – –

*1 Approximate amount of exposure time required each day to generate enough power for normal daily

operation.

*2 Approximate amount of exposure time (in hours) required to take power from one level to the next.

• The above exposure times all are for reference only. Actual exposure times depend on lighting

conditions.

• For details about the operating time and daily operating conditions, see the “Power Supply” section of

the Speciﬁ cations (page E-98).

E-16

Power Recovery Mode

• Performing multiple sensor, illumination, or beeper operations during a short period may cause the

recovery indicator (RECOVER) to start ﬂ ashing on the display. This indicates that the watch is in the

power recovery mode. Illumination, alarm, countdown timer alarm, hourly time signal, and sensor

operations will be disabled until battery power recovers.

• Battery power will recover in about 15 minutes. At this time, the recovery indicator (

RECOVER) will stop

ﬂ ashing. This indicates that the functions listed above are enabled again.

• Frequent ﬂ ashing of the recovery indicator (RECOVER) indicates that battery power is low. Expose the

watch to bright light as soon as possible.

• Even if battery power is at Level 1 (

H) or Level 2 (M), the Digital Compass Mode, Barometer Mode,

Thermometer Mode or Altimeter Mode sensor may be disabled if there is not enough power available.

This is indicated when the recovery indicator (

RECOVER) is ﬂ ashing.

• Frequent ﬂ ashing of the recovery indicator (RECOVER) probably means that remaining battery power

is low. Leave the watch in bright light to allow it to charge.

Operation Guide 5497

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	Pro Trek PRG-600Y-1ER
Färg på produkten:	Zwart
Vikt:	2480 g
Bredd:	376 mm
Djup:	244 mm
Höjd:	36.3 mm
Snäll:	PC
Användarmanual:	Ja
AC-adapterfrekvens:	50 - 60 Hz
AC-adapterns inspänning:	100 - 240 V
Blåtand:	Ja
Skärm diagonal:	15.6 "
Upplösning:	1366 x 768 Pixels
Pekskärm:	Nee
Original bildförhållande:	16:9
Processorfrekvens:	2.3 GHz
Processorfamilj:	Intel® Core™ i3
Processormodel:	i3-2350M
Antal processorkärnor:	2
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Vormfaktor:	Clamshell
Inkluderar operativsystem:	Windows 7 Home Premium
Typ av anslutningskontakt:	3,5 mm
Ethernet LAN:	Ja
Medföljande kablar:	AC
Integrerad minneskortläsare:	Ja
Typiskt kontrastförhållande:	300:1
Ljusstyrka:	200 cd/m²
Processor litografi:	32 nm
Snabbstartsguide:	Ja
Inkluderar AC-adapter:	Ja
Ursprungsland:	China
LED-bakgrundsbelysning:	Ja
Antal USB 2.0-portar:	1
VGA (D-Sub) port(ar):	1
Antal HDMI-portar:	1
Mikrofon, linjeingång:	Ja
DVI-port:	Nee
Antal Ethernet LAN (RJ-45)-portar:	1
Monteringsalternativ för kabellås:	Ja
Inbyggda högtalare:	Ja
Antal inbyggda högtalare:	2
Antal högtalare:	2
Hörlursutgångar:	1
Display, antal färger:	16.78 miljoen kleuren
AC-adapter, ström:	65 W
Inbyggd mikrofon:	Ja
Internminne:	4 GB
Förvarings media:	HDD
Batteritid/batteritid:	- uur
Internminnestyp:	DDR3-SDRAM
Hållbarhetscertifikat:	EPEAT Silver, ENERGY STAR
Skärmdiameter i centimeter:	39.6 cm
Ethernet LAN, dataöverföringshastigheter:	10, 100 Mbit/s
Kabelteknik:	10/100Base-T(X)
Typ av mat:	AC/DC
Förvaringstemperatur:	-20 - 60 °C
Intel® Wireless Display (Intel® WiDi):	Ja
Antal portar USB 3.2 Gen 1 (3.1 Gen 1) Typ A:	2
Processoruttag:	Socket 988
Stepping:	J1
Systembuss:	5 GT/s
Processor antal trådar:	4
PCI Express-kortplatsversion:	2.0
Processorns driftlägen:	64-bit
Processorns cache:	3 MB
Tjunction:	85 °C
Busstyp:	DMI
PCI Express-konfigurationer:	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP):	35 W
Kodnamnsprocessor:	Sandy Bridge
Maximalt antal PCI Express-linjer:	16
Typ av processorcache:	Smart Cache
ECC stöds av processor:	Nee
Processorfabrikant:	Intel
Operativsystems arkitektur:	64-bit
Maximalt internminne:	6 GB
Total lagringskapacitet:	500 GB
Typ av optisk enhet:	DVD Super Multi DL
Inbyggd grafikadapter:	Ja
Separat grafikadapter:	Nee
Familjens inbyggda grafikadapter:	Intel® HD Graphics
Inbyggd grafikadaptermodell:	Intel® HD Graphics 3000
Grundläggande frekvens inbyggd grafikadapter:	650 MHz
Inbyggd grafikadapter dynamisk frekvens (max):	1150 MHz
Inbyggt grafikkort-ID:	0x116
Numerisk knappsats:	Ja
Instruktionsuppsättningar som stöds:	AVX
Intel® My WiFi Technology (Intel® MWT):	Ja
Intel® Hyper Threading Technology (Intel® HT Technology):	Ja
Intel® Turbo Boost-teknik:	Nee
Intel® Quick Sync-videoteknik:	Ja
Intel® InTru™ 3D-teknik:	Ja
Intel® Clear Video HD-teknik (Intel® CVT HD):	Ja
Intel® Insider™:	Ja
Intel® Flex Memory Access:	Ja
Intel® AES nya instruktioner (Intel® AES-NI):	Nee
Förbättrad Intel SpeedStep-teknik:	Ja
Kör Disable Bit:	Ja
Idle stater:	Ja
Termisk övervakningsteknik:	Ja
CPU-konfiguration (max):	1
Intel® Enhanced Halt State:	Ja
Intel® Clear Video Technology för mobila internetenheter (Intel® CVT för MID):	Nee
Intel® VT-x med utökade sidtabeller (EPT):	Ja
Inbyggda alternativ tillgängliga:	Nee
Grafik & IMC litografi:	32 nm
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Nee
Intel® Clear Video-teknik:	Nee
Intel® Virtualization Technology (VT-x):	Ja
Processorpaketstorlek:	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Konfliktfri processor:	Nee
Intel® Identity Protection Technology (Intel® IPT):	Ja
Versie Intel® Identity Protection Technology:	1.00
ARK ID-processor:	53438
Intel® Trusted Execution Technology:	Nee
Intel® Anti-Theft Technology (Intel® AT):	Ja
SmartCard-kortplats:	Nee
Förvaringsfuktighet:	5 - 95 procent
Nätverksfunktioner:	Fast Ethernet, WLAN
Processorkod:	SR0DN
Diskret grafikadaptermodell:	Niet beschikbaar
Pekdon:	Touchpad
Windows-tangenter:	Ja
Märke av högtalare:	Altec Lansing
Minnesplatser:	2x SO-DIMM
Ethernet-gränssnittstyp:	Fast Ethernet
Tangentbord i full storlek:	Ja
Keyboard i ö-stil:	Ja
Höjd, drift:	-15 - 3048 m
Höjd vid förvaring:	-15 - 12192 m
Antalet installerade hårddiskar:	1
HDD kapacitet:	500 GB
HDD-gränssnitt:	SATA
HDD rotationshastighet:	5400 RPM
CPU-multiplikator (bus/kärnförhållande):	23
FSB-paritet:	Nee
Bussprocessor på framsidan:	- MHz
Intel® efterfrågebaserad växling:	Nee
Typ av laddningsport:	DC-in ingang
Medföljande drivrutiner:	Ja
Typ CardBus PCMCIA-slot:	Nee
Processorserie:	Intel Core i3-2300 Mobile Series
Grafikkortsfamilj:	Intel
ExpressCard-kortplats:	Nee
S/PDIF-utgång:	Nee
Intel® Dual Display Capable Technology:	Ja
Intel® FDI-teknik:	Ja
Intel® Rapid Storage Technology:	Nee
Intel® Fast Memory Access:	Ja
Intel® Smart Cache:	Ja
Automatisk kraftavkänning:	Ja
Maximalt internminne (64-bitars):	6 GB
Antal processorer som stöds:	1
Microfoonaansluiting:	3,5 mm
Wifi:	Ja
Drifttemperatur (TT):	5 - 35 °C
Relativ luftfuktighet i drift (VV):	10 - 90 procent
Typ produkt:	Notebook
Antal-produkter-ingår:	1 stuk(s)
Batteriteknik:	Lithium-Ion (Li-Ion)
Antal battericeller:	6
Kartläggning av bildtyp:	<div><img src="https://ark.intel.com/inc/images/diagrams/diagram-18.gif" title="Block Diagram" /></div>
Integrerad 4G WiMAX:	Ja
Processorgenerering:	Tweede generatie Intel® Core™ i3
