Sida 1/8
Operation Guide 3451
E-9
Stopwatch Mode World Time Mode
Countdown Timer Mode Alarm Mode
E-8
General Guide
• The illustration below shows which buttons you need to press to navigate between
modes.
• In any mode (except when a setting screen is on the display), press
B to illuminate
the display.
• You can enter the Digital Compass/Thermometer Mode from the Timekeeping Mode
by pressing D. To enter from another mode, first use C to enter the Timekeeping
Mode, and then press D.
Press C.
Timekeeping Mode
Digital Compass/
Thermometer Mode
Press D.Press C.
E-7
To do this: Enter this mode: See:
Use the countdown timer Countdown Timer
Mode E-52
Set an alarm time Alarm Mode E-55
* Coordinated Universal Time (UTC) is the global time standard used to regulate time.
E-6
Mode Reference Guide
Your watch has 6 “modes”. The mode you should select depends on what you want to do.
To do this: Enter this mode: See:
• View the current time and date in your Home City and the
current time in the Local Time City
• Configure the Daylight Saving Time (DST) settings of your
Home City and Local Time City
• Configure the time and date settings of your Home City
and the time setting of the Local Time City
Timekeeping Mode E-10
• Determine north and the bearing to a destination
• Determine the temperature at your current location
Digital Compass/
Thermometer Mode E-23
• View the current time in one of 48 cities (31 time zones)
and UTC* time
• Simultaneously view the current time in your World Time
City, Home City, and Local Time City.
World Time Mode E-47
Use the stopwatch to measure elapsed time Stopwatch Mode E-50
E-5
Alarms ……………………………………………………………………………………E-55
To set an alarm time ……………………………………………………………E-56
To test the alarm ………………………………………………………………E-57
To turn an alarm and the hourly time signal on and off ……………………E-58
Illumination ……………………………………………………………………………E-59
To turn on illumination …………………………………………………………E-60
To change the illumination duration …………………………………………E-60
Reference ………………………………………………………………………………E-62
To turn the button operation tone on and off …………………………………E-63
Specifications …………………………………………………………………………E-67
E-4
To perform magnetic declination correction …………………………………E-37
To take a temperature reading ………………………………………………E-42
To calibrate the temperature sensor …………………………………………E-45
To specify the temperature display unit ………………………………………E-46
World Time ………………………………………………………………………………E-47
To view the time in another city ………………………………………………E-48
To toggle a city code time between Standard Time and
Daylight Saving Time ………………………………………………………E-48
To swap your World Time City and Local Time City ………………………E-49
Stopwatch ………………………………………………………………………………E-50
To measure times with the stopwatch ………………………………………E-51
Countdown Timer………………………………………………………………………E-52
To configure countdown start time and auto-repeat settings ………………E-53
To use the countdown timer ……………………………………………………E-54
E-3
Contents
Mode Reference Guide ……………………………………………………………… E-6
General Guide ………………………………………………………………………… E-8
Timekeeping ……………………………………………………………………………E-10
To set your Home City time and date …………………………………………E-12
To toggle the Timekeeping Mode time between DST and
Standard Time ………………………………………………………………E-16
To specify the Local Time City…………………………………………………E-18
To toggle a Local Time City time between Standard Time and
Daylight Saving Time ………………………………………………………E-19
To swap your Home City and Local Time City ………………………………E-20
Digital Compass/Thermometer ……………………………………………………E-23
To enter and exit the Digital Compass/Thermometer Mode ………………E-24
To take a direction reading ……………………………………………………E-27
To calibrate the bearing sensor ………………………………………………E-35
E-2
About This Manual
• Depending on the model of your watch, display text
appears either as dark figures on a light background or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
• Button operations are indicated using the letters shown
in the illustration.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
(Light)
(Light)
E-1
ENGLISH
Warning!
• The measurement functions built into this watch are not intended for use in
taking measurements that require professional or industrial precision. Values
produced by this watch should be considered as reasonably accurate
representations only.
• When engaging in mountain climbing or other activities in which losing your
way can create a dangerous or life-threatening situation, always be sure to use
a second compass to confirm direction readings.
• Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss suffered by you or any third party arising through the use of
your watch or its malfunction.
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
Applications
The built-in sensors of this watch measure direction and temperature. Measured
values are then shown on the display. Such features make this watch useful when
hiking, mountain climbing, or when engaging in other such outdoor activities.
E
MO1610-EA © 2016 CASIO COMPUTER CO., LTD.
Operation Guide 3451
E-19
To toggle a Local Time City time between Standard Time and Daylight Saving Time
1. In the Timekeeping Mode, hold down A for about four seconds until the time zone
of the currently selected Local Time City starts to flash on the world map. This is the
setting screen.
• Note that the Home City time zone will flash on the world map about two seconds
after you hold down A. Keep A depressed for about four seconds until the
Local Time zone flashes.
2. Press C once to display the DST setting screen.
3. Press D to toggle between Daylight Saving Time (
ON displayed) and Standard
Time (OFF displayed).
• Note that you cannot switch between Standard Time and Daylight Saving Time
(DST) while is selected as your Local Time City.UTC
4. Press A to exit the setting screen.
• The indicator will be in the upper left corner of the display while Daylight DST
Saving Time is enabled.
E-18
To specify the Local Time City
1. In the Timekeeping Mode, hold down A for about four
seconds until the time zone of the currently selected
Local Time City starts to flash on the world map. This is
the setting screen.
• Note that the Home City time zone will flash on the
world map about two seconds after you hold down
A. Keep A depressed for about four seconds until
the Local Time zone flashes.
2. Use D and B to scroll through city codes in the lower
display until the one you want is displayed.
• For full information on city codes, see the “City Code
Table” at the back of this manual.
• The time zone that is highlighted in the world map
will change in accordance with the Local Time City
code you select.
3. Press A to exit the setting screen.
Local Time City
Hour : Minutes
Map
Local Time City code
E-17
3. Press D to toggle between Daylight Saving Time (
ON displayed) and Standard
Time (OFF displayed).
• Note that you cannot switch between Standard Time and Daylight Saving Time
(DST) while is selected as your Home City.UTC
4. Press A to exit the setting screen.
• The DST indicator will be in the lower left corner of the display while Daylight
Saving Time is enabled.
Local Time
Local Time lets you separately display the current time in a specific time zone (Local
Time City). This feature is very handy for business professionals and others who need
to keep track of the current time in multiple time zones. A simple operation swaps your
Home City and Local Time City, which is great for travel between time zones.
E-16
Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle the Timekeeping Mode time between DST and Standard Time
1. In the Timekeeping Mode, hold down A for about two
seconds until the time zone of the currently selected
Home City starts to flash on the world map. This is the
setting screen.
• Release A immediately after the Home City code
appears. Keeping it depressed longer (about four
seconds) will switch to the Local Time City setting
screen.
2. Press C once to display the DST setting screen.
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
On/Off status
DST indicator
E-15
Screen To do this: Do this:
Change the year
Use D (+) and B (–).
Change the month or day
• For details about the above settings, see “Timekeeping” (page E-66).
5. Press A to exit the setting screen.
• For details about other settings, refer to the sections below.
– Button Operation Tone: “To turn the button operation tone on and off” (page E-63)
– Illumination Duration: “To change the illumination duration” (page E-60)
• See “Daylight Saving Time (DST) Setting” below for details about the DST setting.
E-14
4. When the timekeeping setting you want to change is flashing, use
D and/or B to
change it as described below.
Screen To do this: Do this:
Change the city code Use D
(east) and B
(west).
Toggle between Daylight Saving Time
(ON) and Standard Time (
OFF). Press D.
Toggle between 12-hour (
12H) and
24-hour (24H) timekeeping. Press D.
Reset the seconds to
00 Press D.
Change the hour or minute Use
D
(+) and B (–).
E-13
2. Use D and B to scroll through city codes in the lower display until the one you
want is displayed.
• Make sure you select your Home City code before changing any other setting.
• For full information on city codes, see the “City Code Table” at the back of this
manual.
3. Press C to move the flashing in the sequence shown below to select the other
settings.
City Code DST 12/24-Hour
Format
Button Operation
Tone (page E-63)
Illumination Duration
(page E-60)
Second Hour
YearMonthDay
Minute
• After a city code is displayed, it will scroll once to show the full city name.
• The following steps explain how to configure timekeeping settings only.
E-12
Read This Before You Set the Time and Date!
This watch is preset with a number of city codes, each of which represents the time
zone where that city is located. When setting the time, it is important that you first
select the correct city code for your Home City (the city where you normally use the
watch). If your location is not included in the preset city codes, select the preset city
code that is in the same time zone as your location.
• Note that all of the times for the World Time Mode city codes (page E-48) and Local
Time city codes (page E-18) are displayed in accordance with the time and date
settings you configure in the Timekeeping Mode.
To set your Home City time and date
1. In the Timekeeping Mode, hold down A for about two seconds until the time zone
of the currently selected Home City starts to flash on the world map. This is the
setting screen.
• The Home City code will also appear on the display. Release
A immediately
after the Home City code appears. Keeping it depressed longer (about four
seconds) will switch to the Local Time City setting screen, which is indicated
when the Local Time City code is displayed.
E-11
You can adjust the Home Time city date and time in the
Timekeeping Mode. You also can simultaneously display
the current time in one other time zone, by specifying a
Local Time City.
• For information about selecting a Local Time City, see
“To specify the Local Time City” (page E-18).
Local Time City
Hour : Minutes
Map
Home City
Hour : Minutes, Seconds
Day of week, Month - Day
E-10
Timekeeping
This watch can keep track of the current time in up to three different time zones.
Home Time
• This is the time in the city where you normally use your watch (Home City). It is the
time displayed in the Timekeeping Mode.
Local Time
• This is the time in the city located in the time zone that is highlighted on the watch’s
world map (Local Time City).
World Time
• This is the time in the city you select in the World Time Mode (page E-47).
Operation Guide 3451
E-29
Note
• Note that taking a measurement
while the watch is not horizontal
(in relation to the horizon) can
result in large measurement error.
• The margin of error for the angle value and the direction indicator is ±15 degrees. If
the indicated direction is northwest (NW) and 315 degrees, for example, the actual
direction can be anywhere from 300 to 330 degrees.
• Any ongoing direction measurement operation is paused temporarily while the
watch is performing an alert operation (daily alarm, Hourly Time Signal, countdown
timer alarm) or while illumination is turned on (by pressing B). The measurement
operation resumes for its remaining duration after the operation that caused it to
pause is finished.
• The following table shows the meanings of each of the direction abbreviations that
appear on the display.
E-28
• While the watch is taking compass readings, it
displays a direction angle and a direction indicator,
both of which change dynamically when the watch is
moved. After the compass operation is complete, the
direction pointer disappears from the display, and
the direction angle and direction indicator both show
“- - -”. Use the direction indicators marked around
the compass dial to record the indicated direction.
For details, see “Example: Determining your current
position and your objective on a map” (page E-31).
• The
CAL
appearing on the display after a direction
reading is complete indicates that bearing sensor
calibration is required due to either of the reasons
described below. When this happens, perform the
procedure under “Calibrating the Bearing Sensor”
(page E-33).
• It’s been 100 days since the last bearing sensor
calibration.
• The watch’s battery was replaced.
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
E-27
To take a direction reading
1. While the watch is in the Digital Compass/Thermometer
Mode, place it on a flat surface, or if you are wearing
the watch, make sure that your wrist is horizontal (in
relation to the horizon).
2. Point the 12 o’clock position of the compass dial in the
direction you want to measure.
3. Press D to start a Digital Compass measurement
operation.
• After about two seconds, the direction that the 12
o’clock position of the compass dial is pointing
appears on the display.
• The compass dial’s pointer indicates magnetic north.
• After the first reading is obtained, the watch
continues to take direction readings automatically
each second, for up to 10 seconds.
• To perform direction readings for another 10
seconds, press D again.
NW
0°
WNW
W
WSW
SW
SSW
S
SSE
SE
ESE
E
ENE
NE
NNE
N
NNW
90°180°
270°
12 o’clock
North pointer
Angle value
(in degrees)
Direction
indicator
E-26
Digital Compass
The watch takes digital compass readings automatically whenever you enter the
Digital Compass/Thermometer Mode. In addition, you can take readings manually by
performing the procedure below.
• See “Magnetic North and True North” (page E-39) for information about the two types of
north. For information about maximizing digital compass accuracy, see “Calibrating
the Bearing Sensor” (page E-33) and “Digital Compass Precautions” (page E-39).
E-25
2. Press C to return to the Timekeeping Mode.
• For information about using the digital compass, see “To take a direction
reading” on page E-27.
• For information about using the thermometer, see “To take a temperature
reading” on page E-42.
E-24
To enter and exit the Digital Compass/Thermometer Mode
1. While in the Timekeeping Mode, press D to enter the
Digital Compass/Thermometer Mode.
• The watch will start to take direction and temperature
readings. After about two seconds, the angle that the
12 o’clock position of the compass dial is facing and
the current temperature reading will appear on the
display.
• Direction readings will be taken each second for
about 10 seconds, and then stop automatically.
• Temperature readings will be taken every two
seconds for about 10 seconds, and then stop
automatically.
• To perform direction and temperature readings for
another 10 seconds, press D again.
During readings
12 o’clock
Home time About two
seconds
E-23
Digital Compass/Thermometer
You can take direction readings and temperature readings in the Digital Compass/
Thermometer Mode. Direction readings are taken by the watch’s built-in magnetic
bearing sensor and displayed as one of 16 directions. A temperature sensor is used
for temperature readings.
• See “Digital Compass” on page E-26 for more information about the digital compass.
• See “Thermometer” on page E-41 for more information about the thermometer.
E-22
Before Arriving at Your Destination
Swap your place of departure (Home City) and Local Time City.
Current time at place of departure Current time at destination
• For information about selecting a Local Time City, see “To specify the Local Time
City” (page E-18).
E-21
Before Setting Out
Set your destination city as the Local Time City.
Current time at place
of departure
Current time at destination
• For information about selecting a Local Time City, see “To specify the Local Time
City” (page E-18).
E-20
Swapping your Home City and Local Time City
You can use the procedure below to swap your Home City and Local Time City. This
capability can come in handy when you travel frequently between two cities in different
time zones.
To swap your Home City and Local Time City
1. In the Timekeeping Mode, select the Local Time City you want.
• For information about selecting a Local Time City, see “To specify the Local Time
City” (page E-18).
2. Hold down B for at least four seconds.
• This will make the Local Time City (which you selected in step 1) your Home City.
At the same time, it will change the Home City you had selected prior to step 2 to
your Local Time City.
Using the Watch when Travelling Between Time Zones
You can use the procedures below for smooth switching between time zones as
required.
Produktspecifikationer
| Varumärke: | Casio |
| Kategori: | Titta |
| Modell: | SGW600H-1B |
Behöver du hjälp?
Om du behöver hjälp med Casio SGW600H-1B ställ en fråga nedan och andra användare kommer att svara dig
Titta Casio Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
Titta Manualer
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Lorus
- Titta Stuhrling
- Titta Swatch
- Titta Citizen
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Krontaler
- Titta Lucien Picard
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta Naitica
- Titta Kogan
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Raketa
- Titta Marc Jacobs
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta Rodania
- Titta Bruno Sohnle
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
Nyaste Titta Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
22 Oktober 2024
21 Oktober 2024
21 Oktober 2024
