Operation Guide 3311 5052

MO0806-EA

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out of your

purchase, be sure to carefully read this manual and keep it on hand for later reference

when necessary.

••••

•This watch does not have a time zone that corresponds to the Greenwich

Mean Time differential of –3.5 hours. Because of this, the radio-controlled

timekeeping and World Time functions will not display the correct time for

Newfoundland, Canada.

Keep the watch exposed to bright light

The electricity generated by the solar cell of the watch is

stored by a built-in battery. Leaving or using the watch

where it is not exposed to light causes the battery to run

down. Make sure the watch is exposed to light as much as

possible.

•

When you are not wearing the watch on your wrist,

position the face so it is pointed at a source of bright light.

•You should try to keep the watch outside of your sleeve

as much as possible. Charging is reduced significantly if

the face is only partially covered.

Bright Light

Solar cell

•The watch continues to operate, even when it is not exposed to light. Leaving the

watch in the dark can cause the battery to run down, which will result in some watch

functions to be disabled. If the battery goes dead, you will have to re-configure watch

settings after recharging. To ensure normal watch operation, be sure to keep it

exposed to light as much as possible.

All

functions

enabled

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Charge

Rechargeable battery

Bright Light

Electrical

energy

Solar cell

(Converts light to

electrical power.)

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Some or all

functions

disabled

Dis-

charge

Battery charges in the light. Battery discharges in the dark.

•The actual level at which some functions are disabled depends on the watch model.

•Frequent display illumination can run down the battery quickly and require charging.

The following guidelines give an idea of the charging time required to recover from a

single illumination operation.

Approximately 5 minutes exposure to bright sunlight coming in through a window

Approximately 50 minutes exposure to indoor fluorescent lighting

•Be sure to read “Power Supply” for important information you need to know

when exposing the watch to bright light.

If the digital display of the watch is blank...

If the Power Saving indicator (

) is flashing on the display,

it means that the display is blank because the watch’s

Power Saving function has turned it off to conserve power.

Power Saving automatically turns off the display and

enters a sleep state whenever your watch is left for a

certain period in an area where it is dark. If the watch is

kept in the dark for a longer period, the analog hands will

also stop moving after a few days.

•The initial factory default setting is Power Saving on.

•The watch will recover from the sleep state if you move it

to a well-lit area or if you press any button.

•See “Power Saving Function” for more information.

About This Manual

•The operational procedures for Modules 3311 and 5052

are identical. All of the illustrations in this manual show

Module 3311.

•Button operations are indicated using the letters shown

in the illustration.

•Each section of this manual provides you with the

information you need to perform operations in each

mode. Further details and technical information can be

found in the “Reference” section.

Module 3311

Module 5052

General Guide

•Press C to change from mode to mode.

•In any mode, press to illuminate the display.B

▲

Battery Level Indicator

Alarm ModeStopwatch Mode

▲

Timekeeping Mode

Press C.

▲

World Time Mode

Hand Setting Mode

Radio-controlled Atomic Timekeeping

This watch receives a time calibration signal and updates

its time setting accordingly. The time calibration signal

includes both Standard Time and Daylight Saving Time

(summer time) data.

•This watch is designed to pick up the time calibration

signal transmitted in the United States (Fort Collins,

Colorado) and the time calibration signals transmitted in

Japan.

•The U.S. time calibration signal can be picked up by the

watch while in North America.*

*The term “North America” in this manual refers to the

area that consists of Canada, the continental United

States, and Mexico.

Day

Day of week

Minute hand

Hour hand

Second hand

Current Time Setting

This watch automatically adjusts its time setting in accordance with a time calibration

signal. You can also perform a manual procedure to set the time and date, when

necessary.

•The first thing you should do after purchasing this watch is to set your Home City,

which is the city where you will normally use the watch. For more information, see

“To set your Home City” below.

•When using the watch outside the ranges of the U.S. and Japanese time signal

transmitters, you have to adjust the current time setting manually as required. See

“Timekeeping” for more information about manual time setting.

•The analog time of this watch is synchronized with the digital time. Because of this,

the analog time setting is automatically adjusted whenever you change the digital

setting. See “Analog Timekeeping” for more information.

To set your Home City

1. In the Timekeeping Mode, hold down A until the

transmitter indicator (US) starts to flash, which

indicates the setting screen.

•The second hand will move at high speed to the 12

o’clock position, where it will stop.

2. Press C once so the city code is flashing on the display.

3. Use (east) and (west) to scroll through the cityD B

codes until the one you want to use as your Home City

is displayed.

Transmitter indicator

TYO: All cities in Japan

SEL: Seoul

HKG: Hong Kong

•Note that this watch does not have a city code that corresponds to Newfoundland.

4. Press A twice to exit the setting screen.

•The first press of A displays the 12/24-hour setting screen. Pressing again exitsA

the setting screen.

•The second hand will advance at high speed to the correct position in accordance

with seconds count of the digital time, and resume normal movement from there.

•Normally, your watch should show the correct time as soon as you select your Home

City Code. If it does not, it should adjust automatically after the next auto receive (in

the middle of the night). You can also perform manual receive or you can set the time

manually.

•If you are in an area that does not use Daylight Saving Time (summer time), turn off

the DST setting.

To display the digital time and last signal screen

•In the Timekeeping Mode, press to cycle through the digital time screens asA

shown below.

•In the Timekeeping Mode, press to display the last signal screen. The last signalD

screen shows the date and time of the last successful time calibration signal

reception.

Last Signal Screen

Reception date

Press .A

▲

Receiving indicator

2 seconds

Press D.

Hour : Minutes

PM indicator

Date Screen Receiving Indicator

and Seconds Count

Current Time Screen

▲

Seconds

Reception Time

2 seconds

▲

Day

Day of week

HNL : Honolulu

ANC : Anchorage

LAX : Los Angeles, San Francisco, Las Vegas, Seattle, Vancouver, Tijuana

DEN : Denver, El Paso, Edmonton, Culiacan

CHI : Chicago, Houston, Dallas/Fort Worth, New Orleans, Winnipeg, Mexico City

NYC : New York, Detroit, Miami, Boston, Montreal

Operation Guide 3311 5052

Time Calibration Signal Reception

There are two different methods you can use to receive the time calibration signal:

auto receive and manual receive.

•Auto Receive

With auto receive, the watch automatically picks up the time calibration signal five

times a day at 0:00 a.m., 1:00 a.m., 2:00 a.m., 3:00 a.m., and 4:00 a.m. For more

information, see “About Auto Receive”.

•Manual Receive

Manual receive lets you start time calibration signal reception with the press of a

button. For more information, see “To perform manual receive”.

Important!

•When getting ready to receive the time calibration signal, position the watch as

shown in the nearby illustration, with its 12 o’clock side facing towards a window.

This watch is designed to receive a time calibration signal late at night. Because of

this, you should place the watch near a window as shown in the illustration when you

take it off at night. Make sure there are no metal objects nearby.

Resin Band Metal Band

•Make sure the watch is facing the right way.

•Proper signal reception can be difficult or even impossible under the conditions listed

below.

•Signal reception is normally better at night than during the day.

•Time calibration signal reception takes from two to seven minutes. Take care that

you do not perform any button operations or move the watch during this time.

Inside or

among

buildings

Inside a

vehicle

Near

household

appliances,

office

equipment,

or a mobile

phone

Near a

construction

site, airport, or

other sources

of electrical

noise

Near high-

tension

power lines

Among or

behind

mountains

•When within range of the applicable transmitter, this watch can receive either the

U.S. (Fort Collins, Colorado) or Japanese (Fukushima or Fukuoka/Saga) time

calibration signal. The signal the watch will attempt to pick up depends on its current

Home City code setting as shown below.

Home City Code

HNL*, ANC*,

LAX, DEN,

CHI, NYC

TYO**, , SEL*HKG*

Frequency

60kHz

40kHz

60kHz

Transmitter

Fort Collins, Colorado

Fukushima

Fukuoka/Saga

The areas covered by the

SEL

HKG

HNL

, and

ANC

city codes

are quite far from the time calibration signal transmitters, and so

certain conditions may cause problems with signal reception.

With

TYO

, you can specify either 40kHz or 60kHz.

•Under good reception conditions, signal reception is possible within a radius of

about 2,000 miles (3,000 kilometers) from the Fort Collins transmitter.

•At distances further than about 600 miles (1,000 kilometers) from the Fort Collins

transmitter, signal reception may not be possible during certain times of year or

times of day. Radio interferance may also cause problems with reception.

•At distances further than about 500 kilometers from the Fukushima and Fukuoka/

Saga transmitter, signal reception may not be possible during certain times of year

or times of day. Radio interferance may also cause problems with reception.

1,000

kilometers

1,000

kilometers

Fukuoka/Saga

500

kilometers

Fukushima

500

kilometers

2,000 miles

Fort Collins

600 miles

•Even when the watch is within the reception range of the transmitter, signal

reception will be impossible if the signal is blocked by mountains or other geological

formations between the watch and signal source.

•Signal reception is affected by weather, atmospheric conditions, and seasonal changes.

•See the information under “Signal Reception Troubleshooting” if you experience

problems with time calibration signal reception.

About Auto Receive

When auto receive is turned on, the watch automatically starts to receive the time

calibration signal when the time in the Timekeeping Mode reaches 0:00 a.m., 1:00

a.m., 2:00 a.m., 3:00 a.m., and 4:00 a.m. each day (calibration times). The watch will

also perform an additional auto receive at 5:00 a.m. if none of the regularly scheduled

auto receive are successful.

Note

•Auto receive is performed only if the watch is in the Timekeeping Mode or World

Time Mode when one of the calibration times is reached. It is not performed if a

calibration time is reached while an alarm is sounding, or while you are configuring

settings (while settings are flashing on the display).

•When a reception starts, the second hand will move at high speed to the 12 o’clock

position where it will stop until the reception is complete.

•Auto receipt of the calibration signal is designed to be performed early in the

morning, while you sleep (provided that the Timekeeping Mode time is set correctly).

Before going to bed for the night, remove the watch from your wrist, and put it in a

location where it can easily receive the signal.

•When auto receive is turned on, the watch receives the calibration signal for two to

seven minutes everyday when the time in the Timekeeping Mode reaches each of

the five calibration times. Do not perform any button operation within seven minutes

before or after any of the five calibration times. Doing so can interfere with correct

calibration.

•Remember that reception of the calibration signal depends on the time kept in the

digital display. The reception will be performed whenever the display shows one of

the five calibration times, regardless of whether or not the displayed time is actually

the correct time.

•When two, three, four, or five receptions are successful, the watch uses the data of

the last reception for calibration. When only one reception is successful, the watch

uses the data of the successful reception.

About the Receiving Indicator

The receiving indicator shows the strength of the calibration signal being received. For

best reception, be sure to keep the watch in a location where signal strength is

strongest.

•Even in an area where signal strength is strong, it takes about 10 seconds for signal

reception to stabilize enough for the receiving indicator to indicate signal strength.

•Use the receiving indicator as a guide for checking signal strength and for finding the

best location for the watch during signal reception.

Receiving indicator

Weak Strong

(Level 1) (Level 4)

•The Level 4 receiving indicator appears on the Timekeeping Mode’s Receiving

Indicator and Seconds Count screen only.

The Level 4 receiving indicator is not displayed if signal reception was unsuccessful

or after manual adjustment of the current time setting.

•The Level 4 receiving indicator indicates that at least one of the five calibration

signal reception was successful. Note, however, that the Level 4 receiving indicator

is cleared from the display at 3:00 a.m. each day.

To perform manual receive

1. Place the watch on a stable surface so its top (12

o’clock side) is facing towards a window.

2. In the Timekeeping Mode, hold down D for about two

seconds until the watch beeps.

3. Release D and RC flashes to indicate that signal

reception has started.

•When a reception starts, the second hand will move at

high speed to the 12 o’clock position where it will stop

until the reception is complete.

Receiving indicator

•Time calibration signal reception normally takes from two to seven minutes. In

Japan, however, reception can take up to 14 minutes. Take care that you do not

perform any button operations or move the watch during this time.

•After signal reception is complete, the display of the watch changes to the last signal

screen.

Note

•To interrupt a reception and return to the Timekeeping Mode, press D.

•If the reception is unsuccessful, the message ERR appears on the display for about

one or two minutes. After that, the watch returns to the Timekeeping Mode.

•You can also change from the last signal or ERR screen to the normal timekeeping

screen by pressing D.

To turn auto receive on and off

1. In the Timekeeping Mode, hold down A until the

transmitter indicator starts to flash, which indicates the

setting screen.

•The second hand will move at high speed to the 12

o’clock position, where it will stop.

2. Press C three times to move the flashing to the auto

receive on/off setting.

3. Press D to toggle auto receive on (ON) and off (OF).

•If the current Home City setting is a city code that

does not support auto receive, “--” appears in

place of the on/off indicator. This means you cannot

turn auto receive on or off.

4. Press A twice to exit the setting screen.

•The second hand will advance at high speed to the correct position in accordance

with the digital time seconds count, and resume normal movement from there.

•For information about city codes that support signal reception, see “To set your

Home City”.

On/off status

Signal Reception Troubleshooting

Check the following points whenever you experience problems with signal reception.

Problem

Cannot perform

manual receive.

Auto receive is

turned on, but

the Level 4

receiving

indicator does

not appear on

the Timekeeping

Mode display.

Time setting is

incorrect

following signal

reception.

Probable Cause

•The watch is not in the Timekeeping

Mode.

•Your current Home City is not one of the

following city codes: HNL, ANC,

LAX DEN CHI NYC HKG, , , , ,

SEL TYO, or .

•You changed the time setting manually.

•The watch was not in the Timekeeping

or World Time Mode, or you were

performing some button operation

during the auto receive.

•Even if reception is successful, the

Level 4 receiving indicator disappears

every day at 3 a.m.

•Time data (hour, minutes, seconds) only

was received during the last reception.

The Level 4 receiving indicator appears

only when time data and date data

(year, month, day) are both received.

•If the time is one hour off, the DST

setting may be incorrect.

•The Home City code setting is not

correct for the area where you are using

the watch.

What you should do

•Enter the Timekeeping Mode

and try again.

•Select , , HNL ANC LAX,

DEN CHI NYC HKG, , , ,

SEL TYO, or as your Home

City.

•Perform manual receive or

wait until the next auto

receive is performed.

•Check to make sure the watch

is in a location where it can

receive the signal.

•Change the DST setting to

Auto DST.

•Select the correct Home City

code.

•For further information, see “Important!” under “Time Calibration Signal Reception”

and “Radio-controlled Atomic Timekeeping Precautions”.

Operation Guide 3311 5052

World Time

The World Time Mode digitally displays the current time in

30 cities (29 time zones) around the world.

•Pressing A in the World Time Mode causes the

applicable city code to appear on the digital display for

about two seconds.

•If the current time shown for a city is wrong, check your

Home City time settings and make the necessary

changes.

•The watch will perform a signal reception even if it is in

the World Time Mode when a calibration time is

reached. If this happens, the World Time Mode time

settings will be adjusted in accordance with the

Timekeeping Mode’s Home City time.

•All of the operations in this section are performed in the

World Time Mode, which you enter by pressing C.

City Code

Current time in the

selected city code

To view the time in another city

While in the World Time Mode, press D to scroll through the city codes (time zones).

•For full information on city codes, see the “City Code Table”.

To toggle a city code time between Standard Time and Daylight Saving Time

1. In the World Time Mode, use D to display the city code

(time zone) whose Standard Time/Daylight Saving Time

setting you want to change.

•Pressing A in the World Time Mode causes the

applicable city code to appear on the digital display for

about two seconds.

2. Hold down A to toggle Daylight Saving Time (DST

indicator displayed) and Standard Time (DST indicator

not displayed).

•Note that you cannot use the World Time Mode to

change the DST setting of the Home City code you

currently have selected in the Timekeeping Mode. See

“To change the Daylight Saving Time (summer time)

setting” for information about turning the Home City

code DST setting on and off.

DST indicator

•The DST indicator will appear on the display whenever you display a city code for

which Daylight Saving Time is turned on.

•Note that you cannot switch between Standard Time and Daylight Saving Time while

GMT is selected as the city code.

•Note that the DST/Standard Time setting affects only the currently displayed city

code. Other city codes are not affected.

Alarms

You can set three independent Daily Alarms. When an

alarm is turned on, the alarm tone sounds when the alarm

time is reached. You can also turn on an Hourly Time

Signal that causes the watch to beep twice every hour on

the hour.

•The alarm and Hourly Time Signal operate in

accordance with the current digital time.

•The alarm number (AL1 though AL3) indicates an alarm

screen. SIG appears in place of the alarm number when

the Hourly Time Signal screen is shown.

•All of the operations in this section are performed in the

Alarm Mode, which you enter by pressing C.

Alarm

number

Alarm time

(Hour : Minutes)

Mode

indicator

On/Off status

Alternate at

two-second

interval

To set an alarm time

1. In the Alarm Mode, press D to select the alarm whose

time you want to set.

AL1 AL2 AL3 SIG

2. Hold down A until the hour setting of the alarm time

starts to flash, which indicates the setting screen.

•This automatically turns on the alarm.

3. Press C to move the flashing between the hour and minute settings.

4. While a setting is flashing, use D B (+) and (–) to change it.

•When setting the alarm time using the 12-hour format, take care to set the time

correctly as a.m. (no indicator) or p.m. ( indicator).P

•If you have 24-hour timekeeping selected in the Timekeeping Mode, the alarm

time is also displayed in 24-hour format.

5. Press A to exit the setting screen.

Alarm Operation

The alarm sounds in all modes at the preset time for about 10 seconds, or until you

stop it by pressing any button.

To test the alarm

In the Alarm Mode, hold down to sound the alarm.D

To turn an alarm and the Hourly Time Signal on and off

1. In the Alarm Mode, press D to select an alarm or the Hourly Time Signal.

2. When the alarm or the Hourly Time Signal you want to set is selected, press A to

turn it on and off.

Stopwatch

The stopwatch lets you measure elapsed time, split times,

and two finishes.

•The display range of the stopwatch is 99 minutes, 59.99

seconds.

•The 1/100-second value appears while the elapsed time

operation is stopped or while a split time is frozen on the

display.

SecondsMinutes

Seconds

1/100

second

More than

one minute

Elapsed time

(Minutes : Seconds) 1/100 second

Elapsed Time Screen

•The stopwatch continues to run, restarting from zero after it reaches its limit, until

you stop it.

•Exiting the Stopwatch Mode while a split time is frozen on the display clears the split

time and returns to elapsed time measurement.

•The stopwatch measurement operation continues even if you exit the Stopwatch

Mode.

•All of the operations in this section are performed in the Stopwatch Mode, which you

enter by pressing C.

Split indicator

Split time

(Minutes : Seconds) 1/100 second

Split Time Screen

To measure times with the stopwatch

Start Stop

Elapsed Time

➤

Re-start Clear

D➤

Stop

D➤D➤A

Split Time

Start Split

➤

Split release Clear

A➤

Stop

A➤D➤A

Two Finishes

Start Split

➤

Stop Clear

A➤

Split release

D➤A➤A

First runner

finishes.

Display time of

first runner.

Second runner

finishes.

Display time of

second runner.

Illumination

An LED (light-emitting diode) and a light guide panel

illuminate the digital display for easy reading in the dark.

•See “Illumination Precautions” for other important

information.

To illuminate the display

In any mode, press B to illuminate the display.

•You can specify 1.5 seconds or 2.5 seconds as the

illumination duration. See “To set the current digital time

and date manually” for more information.

Power Supply

This watch is equipped with a solar cell and a special rechargeable battery (secondary

battery) that is charged by the electrical power produced by the solar cell. The

illustration shown below shows how you should position the watch for charging.

Example: Orient the watch so its face

is pointing at a light source.

• The illustration shows how to position

a watch with a resin band.

• Note that charging efficiency drops

when any part of the solar cell is

blocked by clothing, etc.

•You should try to keep the watch

outside of your sleeve as much as

possible. Charging is reduced

significantly if the face is only partially

covered.

Solar cell

Important!

•Storing the watch for long periods in an area where there is no light or wearing it in

such a way that it is blocked from exposure to light can cause rechargeable battery

power to run down. Make sure that the watch is exposed to bright light whenever

possible.

•This watch uses a special rechargeable battery to store power produced by the solar

cell, so regular battery replacement is not required. However, after very long use, the

rechargeable battery may lose its ability to achieve a full charge. If you experience

problems getting the special rechargeable battery to charge fully, contact your dealer

or CASIO distributor about having it replaced.

•Never try to remove or replace the watch’s special battery yourself. Use of the wrong

type of battery can damage the watch.

•The current time and all other settings return to their initial factory defaults whenever

battery power drops to Level 4 and when you have the battery replaced.

•Turn on the watch’s Power Saving function and keep it in an area normally exposed

to bright light when storing it for long periods. This helps to keep the rechargeable

battery from going dead.

Produktspecifikationer

Varumärke:	Casio
Kategori:	Titta
Modell:	WVA470DJ-1A

Behöver du hjälp?

Om du behöver hjälp med Casio WVA470DJ-1A ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Titta Casio Manualer

Casio Edifice EQB-1000TR-2AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1259PD-7BEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GA-810B-1A9ER Bruksanvisning

24 Oktober 2024

Casio Collection SGW-450HD-1BER Bruksanvisning

24 Oktober 2024

Casio Edifice EQB-1000XD-1AER Bruksanvisning

24 Oktober 2024

Casio Collection MTP-1222A-2AVEF Bruksanvisning

24 Oktober 2024

Casio G-Shock GMW-B5000G-2ER Bruksanvisning

24 Oktober 2024

Casio Radio Controlled WV-200E-1AVEF Bruksanvisning

24 Oktober 2024

Casio Collection LWS-2000H-2AVEF Bruksanvisning

24 Oktober 2024

Casio Pro Trek PRW-60YBM-1AER Bruksanvisning

24 Oktober 2024

Titta Manualer

Nyaste Titta Manualer

Lorus W207 Bruksanvisning

27 Oktober 2024

Invicta Specialty 31308 Bruksanvisning

27 Oktober 2024

Timex Ironman TW5M244009J Bruksanvisning

26 Oktober 2024

Timex MK1 TW2R68800VQ Bruksanvisning

26 Oktober 2024

Braun BN0021 Bruksanvisning

24 Oktober 2024

Braun AW60 Bruksanvisning

24 Oktober 2024

Braun BN0042 Bruksanvisning

24 Oktober 2024

Skmei 0984A Bruksanvisning

22 Oktober 2024

Suunto SPARTAN ULTRA 1.2 Bruksanvisning

21 Oktober 2024

Skmei 0955 Bruksanvisning

21 Oktober 2024
