MERCURY

FREE

LOW

MAINTENANCE

5 YEAR 

10,000 HOUR

WARRANTY

* Whichever comes ﬁrst

Discover more by visiting casio.co.uk/projectors or contact us

e: projectors@casio.co.uk 020 8208 9453 t:

An industry-leading 2x optical zoom means that a Green Slim model will replace almost

any installed projector seamlessly, without having to change ceiling brackets. This helps to keep

budgets under control and disruption to a minimum. The Green Slim series oﬀers brightness

levels up to 3,000 ANSI lumens, more than enough for even a large, bright meeting room.

They are light and portable, so can easily be moved between rooms if required.

The ideal replacement

projector

Slim.

See how much you can save with Casio Projectors

casio.co.uk/tco

Key features

Lamp-free

Up to 3,000 ANSI lumens

XGA and WXGA resolution

Flexible 2x optical zoom allowing

easy installation

Quick start and stop

WLAN and USB (selected models only)

HD ready

Portable

Less than A4 size

The DLP®-Logo is a registered

trademark of Texas Instruments.

Technical Speciﬁcations

HDMI

USB-A

USB-B

Computer / TCbCr / YPbPr

Model Slim

Speciﬁcation XJ-A142 / XJ-A147 XJ-A242 / XJ-A247 XJ-A252 / XJ-A257

Display Technology: 0.55" DLP®

chip 0.65” DLP® chip

Resolution: XGA WXGA

1,024 x 768 pixels 1,280 x 800 pixels

Brightness: 2,500 ANSI lumens 3,000 ANSI lumens

Light source Type: Laser & LED Hybrid technology

Life expectancy: Approx. 20,000 hours

Projected image Contrast ratio: 1,800 : 1

Colour depth: 16.7 million colours

Projection lens Type: 1.5x optical zoom

Projection ratio: 1.4-2.8 : 1 (distance : image width) 1.15-2.3 : 1 (distance : image width)

Oﬀset: 50% 33%

Min. distance: 0.84m

Focus: Manual

Projection Projection screen size: 15” to 300” 18” to 300”

60" screen (diagonal): 1.7 to 3.4m distance 1.4 to 2.8m distance

100" screen (diagonal): 2.8 to 5.6m distance 2.4 to 4.8m distance

Keystone correction Vertical (automatic/manual): +/- 30° (Auto)

Interface terminals Computer: Inputs: 1 x 15-pin RGB mini D-sub (VGA)

Digital input: 1 x HDMI type A (480p–1,080p)

Video: 1 x RCA (composite)

Component video: Via D Sub 15-pin

Audio: Output: From HDMI input only

RS-232C serial: YK-5 (optional accessory)

Additional functions Direct Power On, Direct Power Oﬀ, rear projection, image freeze, blank screen, ceiling mount

Audio Volume Speaker output: 1 W

Operating noise: 35 dB (default mode)

Power consumption Operating: 155 W (Bright mode)

115 W (Eco mode)

165 W (Bright mode)

120 W (Eco mode)

Standby: 0.4 W

Computer compatibility Max. resolution (compressed): UXGA (1,600 x 1,200 pixels)

Video compatibility Video standards: PAL, PAL-N, PAL-M, PAL 60, SECAM, NTSC

Signals: Composite video, YCbCr, YPbPr

On-screen menu Languages: Japanese, English, Spanish, German, Italian, French, Swedish, Chinese (simpliﬁed/traditional), Korean, Turkish, Portuguese, Russian

Included accessories Remote Control (YT-110), Audi / Composite Cable, RGB Cable, Power cable, Soft Carrying Case,

User Manual on CD

Other specs Dimensions (w x h x d): 297 x 43 x 210 mm

Weight: 2.3 kg

Body colour: White

Operating temperature: 5–35 °C

Warranty: Projector & Light source: 5 years or 10,000 hours (whichever comes ﬁrst. T&Cs apply)
