Sida 1/32
Quick Reference Guide
1
EN
QUICK REFERENCE GUIDE
EVE TF-20 QRG Rev. 1
About This Guide
The EVE TF-20 Quick Reference Guide (QRG) has basic product information such as mounting and technical
specifications.
Disclaimer
The information and specifications contained in this QRG are subject to change without notice.
Safety Notes
These Safety Notes include important information about installation, use, and maintenance.
Contact
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux, contact your distributor to request support or return a
product. Visit www.chauvetdj.com for contact information.
What is Included
• EVE TF-20
• Track Adapter
• Barn Doors
• Warranty Card
• Quick Reference Guide
To Begin
Unpack your EVE TF-20 and make sure you have received all parts in good condition. If the box or contents appear
damaged, notify the carrier immediately, not Chauvet.
• ONLY connect this product to a grounded and protected circuit.
• DO NOT look at the light source when the product is on.
• Make sure the power cord is not crimped or damaged.
• Never disconnect this product from power by pulling on the cord.
• When mounting this product overhead, ALWAYS use a safety cable.
• DO NOT allow flammable materials close to the product when it is operating.
• DO NOT touch the product’s housing when it is on because it will be hot.
• The voltage of the outlet to which you are connecting this product must be within the range stated on the
decal or rear panel of the product.
• This product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose this product to rain
or moisture.
• Always mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent
surfaces.
• Be sure that no ventilation slots on the unit’s housing are blocked.
• Never carry the product by the power cord. Use only the handle to carry this product.
• The maximum ambient temperature is 104 °F (40 °C). Do not operate this product at higher temperatures.
• In the event of a serious operating problem, stop using immediately.
• DO NOT open this product. It contains no user-serviceable parts.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect
the product from power via breaker or by unplugging it.
EN
2
EVE TF-20 QRG Rev. 1
QUICK REFERENCE GUIDE
Product Description
The EVE TF-20 is a high-powered, compact, and track-adaptable fresnel luminaire capable of running on a dimmer or
rheostat.
Overview
Dimensions
AC Power
This product has a fixed voltage power supply and it can work with an input voltage of either 120 VAC, 60 Hz or 230 VAC,
50 Hz, depending on the specific model.
This product can be connected to a dimmer or rheostat, by plugging in to a standard outlet controlled by a dimmer or
rheostat, or by splicing the power cable and connecting to the included track adapter.
To eliminate wear and improve its lifespan, during periods of disuse completely disconnect the
product from power via breaker or by unplugging it.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow/Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
Splicing to a commercial track lighting or dimmer setup should be completed by a licensed
professional.
Power
Cable
Barn
Doors
Barn Door
Attachment
Clip
7.25 in
184 mm
5.5 in
140 mm 6 in
154 mm
Produktspecifikationer
| Varumärke: | Chauvet |
| Kategori: | Lampa |
| Modell: | EVE TF-20X |
