Quick Reference Guide
Model ID: OVATIONH605FC
1
EN
QUICK REFERENCE GUIDE
Ovation H-605FC QRG Rev. 8
About This Guide
The Ovation H-605FC Quick Reference Guide (QRG) has basic product information such as connection, mounting, menu
options, and DMX values. Download the User Manual from www.chauvetprofessional.com for more details.
Disclaimer
The information and specifications contained in this QRG are subject to change without notice.
LIMITED WARRANTY
FOR WARRANTY REGISTRATION AND COMPLETE TERMS AND CONDITIONS PLEASE VISIT OUR WEBSITE.
For Customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration.
For Customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and
Germany: www.chauvetlighting.eu/warranty-registration.
Chauvet warrants that this product shall be free from defects in material and workmanship under normal use, for the
period specified in, and subject to the exclusions and limitations set forth in the full limited warranty on our website. This
warranty extends only to the original purchaser of the product and is not transferable. To exercise rights under this
warranty, you must provide proof of purchase in the form of an original sales receipt from an authorized dealer that shows
the product name and date of purchase. THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES. This
warranty gives you specific legal rights. You may also have other rights that vary from state to state and country to
country. This warranty is valid only in the United States, United Kingdom, Republic of Ireland, Belgium, the Netherlands,
Luxembourg, France, Germany and Mexico. For warranty terms in other countries, please consult your local distributor.
Safety Notes
• DO NOT open this product. It contains no user-serviceable parts.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect the
product from power via breaker or by unplugging it.
• DO NOT look at the light source when the product is on.
• CAUTION: This product’s housing may be hot when lights are operating.
• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent surfaces.
• DO NOT operate this product outdoors or in any location where dust, excessive heat, water, or humidity may affect
it. (IP20)
• DO NOT leave any flammable material within 50 cm of this product while operating or connected to power.
• CAUTION: When transferring product from extreme temperature environments, (e.g., cold truck to warm humid
ballroom) condensation may form on the internal electronics of the product. To avoid causing a failure, allow
product to fully acclimate to the surrounding environment before connecting it to power.
• USE a safety cable when mounting this product overhead.
• DO NOT operate this product if the housing, lenses, or cables appear damaged.
• DO NOT connect this product to a dimmer or rheostat.
• ONLY connect this product to a grounded and protected circuit.
• ONLY use the hanging/mounting bracket to carry this product.
• In the event of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 113 °F (45 °C). Do not operate this product at higher temperatures.
FCC Compliance
This device complies with Part 15 Part B of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Contact
Outside the US, UK, Ireland, Mexico, or Benelux, contact your distributor to request support or return a product. From
inside the US, UK, Ireland, Mexico, or Benelux, use the information in Contact Us at the end of this QRG.
What is Included
• Ovation H-605FC
• 65°, 45° and 25° lenses
• 80° Filter
• Egg Crate
• Quick Reference Guide
AC Power
This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC, 50/60 Hz.
EN
2
Ovation H-605FC QRG Rev. 8
QUICK REFERENCE GUIDE
AC Plug
Replacing The Fuse
1. Disconnect this product from power.
2. Using a flat-head screwdriver, unscrew the fuse holder cap from the housing.
3. Remove blown fuse and replace with a good fuse of the same type and rating.
4. Screw the fuse holder cap back in place and reconnect power.
DMX Linking
The Ovation H-605FC will work with a DMX controller using a 5-pin DMX serial or a hard wire connection. A DMX Primer
is available from www.chauvetprofessional.com.
DMX Connection
The Ovation H-605FC uses a 5-pin DMX or a hard wire data connection for its DMX personalities: 1 3 5 7, , , , 10 12 13, , ,
16, or HSV. See the User Manual for information about connecting and configuring the product for DMX operation.
Master/Slave Connection
The Ovation H-605FC uses the DMX data connection for its Master/Slave mode. See the User Manual for information
about how to connect and configure the product for master/slave operation.
RDM (Remote Device Management)
Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate bi-directionally
along existing DMX cabling. Check the DMX controller’s User Manual or with the manufacturer as not all DMX controllers
have this capability. The Ovation H-605FC supports RDM protocol that allows feedback to make changes to menu map
options. Download the User Manual from www.chauvetprofessional.com for more details.
Wireless Operation
In optimal conditions, the Ovation H-605FC can operate up to 300 m (900 ft) away from the W-DMX transmitter. The W-
DMX receiver in the Ovation H-605FC must be paired with the W-DMX transmitter for wireless operation.
Initial Setup
1. Turn the W-DMX transmitter on.
2. Connect the W-DMX transmitter to a DMX controller.
3. Place the Ovation H-605FC within 300 m from the W-DMX transmitter. Disconnect any DMX cable from the
Ovation H-605FC.
4. Turn the Ovation H-605FC on.
Configuration
1. From the Ovation H-605FC control panel, go to DMX Address.
2. Select the start address, as with any other DMX compatible product.
3. Go to Wireless Setting > Receive On/Off.
4. Select On. (The Signal Strength Indicator will show a ? in front of the bars)
5. Press the reset button on the W-DMX transmitter. (The Signal Strength Indicator on the Ovation H-605FC will
show a ϟ in front of the bars for 3 seconds while a connection is established.)
Product Pairing
If the Ovation H-605FC has already been paired with the W-DMX transmitter, the Signal Strength Indicator in the middle
of the LCD screen will show the strength of the signal. In this case, the Ovation H-605FC is ready to work in Wireless
mode. Pairing the Ovation H-605FC and a new W-DMX transmitter
1. From the Ovation H-605FC’s control panel, go to Wireless Setting.
2. Select Receive Reset. The Signal Strength Indicator on the Ovation H-605FC will show a ? in front of the bars.
3. From the W-DMX transmitter, press <RESET> (the Signal Indicator on the transmitter will flash).
4. Once the transmitter has found the Ovation H-605FC, the Signal indicator on the W-DMX transmitter will
illuminate solid.
5.
The Signal Strength Indicator in the middle of the LCD screen on the Ovation H-605FC will show the strength of
the signal
.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow/Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it.
W-DMX operation can be interrupted or inhibited by liquid masses between the transmitter and
receiver such as water, snow, or people. For best results, keep the area between the transmitter
and receiver clear of any liquid mass.
!
!
