Product Safety Guide
020-102422-05
Access Series LCD Panels
Important Safety
Information
Read this document carefully before installing or operating
UHD551-L, UHD651-L, UHD751-P, UHD861-P, and UHD861-LT
display panels. Store the document in a location close to
UHD551-L, UHD651-L, UHD751-P, UHD861-P, and UHD861-LT
display panels for future reference.
Product documentation
For installation, setup, and user information, see the product
documentation available on the Christie website. Read all
instructions before using or servicing this product.
1. Access the documentation from the Christie website:
• Go to this URL: .http://bit.ly/2iUdjFs
•Scan the QR code using a QR code reader app on a
smartphone or tablet.
2. On the product page, select the model and switch to the
Downloads tab.
Related documentation
Additional information on the LCD panels is available in the
following documents.
•Access Series LCD Panels Installation and Setup Guide
(P/N: 020-102404-XX)
•Installing the Touch Overlay (P/N: 020-102431-XX)
•Access Series LCD Panels External Controls (P/N:
020-102554-XX)
•UHD551-L Service Guide (P/N: 020-102683-XX)
•UHD651-L Service Guide (P/N: 020-102685-XX)
•UHD751-P Service Guide (P/N: 020-102686-XX)
•UHD861-P Service Guide (P/N: 020-102744-XX)
Notation
Learn the hazard and information symbols used in the product
documentation.
Danger messages indicate a hazardous situation
which, if not avoided, results in death or serious
injury.
Warning messages indicate a hazardous situation
which, if not avoided, could result in death or
serious injury.
Caution messages indicate a hazardous situation
which, if not avoided, could result in minor or
moderate injury.
Notice messages indicate a hazardous situation
which, if not avoided, may result in equipment or
property damage.
Information messages provide additional
information, emphasize or provide a useful tip.
Product labels
Learn about the labels that may be used on the product. Labels
on your product may be yellow or black and white.
General hazards
Hazard warnings also apply to accessories once they are
installed in a Christie product that is connected to power.
Fire and Shock Hazard
To prevent fire or shock hazards, do not expose this
product to rain or moisture.
Do not alter the power plug, overload the power
outlet, or use it with extension cords.
Do not remove the product enclosure.
Only Christie qualified technicians are authorized to
service the product.
Electrical Hazard
Risk of electric shock.
Do not remove the product enclosure.
Only Christie qualified technicians are authorized to
service the product.
Do not operate the product in tropical climate
regions.
Do not operate the product at an altitude exceeding
2000 m.
Electrical labels
Indicates the presence of a protective earth ground.
Access Series LCD Panels Product Safety Guide 2
020-102422-0 Rev. 1 (0 -201 )5 5 9
Copyright © 201 Christie Digital Systems USA, Inc. All rights reserved.9
Indicates the presence of an earth ground.
Important safeguards
To prevent personal injury and to protect the device from
damage, read and follow these safety precautions.
General safety warnings
Warning! If not avoided, the following could result in
death or serious injury.
• FIRE AND SHOCK HAZARD! Use only the attachments,
accessories, tools, and replacement parts specified by
Christie.
• Always provide proper ventilation for the product to
prevent overheating.
• FIRE HAZARD! Do not install near any devices that
produce heat such as amplifiers, radiators, heat
registers, or stoves.
Caution! If not avoided, the following could result in
minor or moderate injury.
• This product is intended for indoor use only.
• Do not operate the product at an altitude exceeding 2000
m.
• Do not operate the product in tropical climate regions.
•Only clean the components with Christie approved
products.
• Do not place objects containing liquids on the product.
•Do not spray cleaners or pour liquids directly onto the
surface of the product.
• Do not remove the protective housing.
AC power precautions
Warning! If not avoided, the following could result in
death or serious injury.
•SHOCK HAZARD! Disconnect the product from AC before
installing, moving, servicing, cleaning, removing
components, or opening any enclosure.
• FIRE AND SHOCK HAZARD! Do not attempt operation
unless the power cord, power socket, and power plug
meet the appropriate local rating standards.
• Never compromise the ground or earth connection of the
product.
•SHOCK HAZARD! The AC power cord must be inserted
into an outlet with grounding.
• The appliance coupler and main power supply plug must
be easily accessible for disconnecting the product from
the power source.
• FIRE OR SHOCK HAZARD! Do not overload power outlets
and extension cords.
• SHOCK HAZARD! Only use the AC power cord provided
with the product or recommended by Christie.
• FIRE HAZARD! Do not use a power cord, harness, or
cable that appears damaged.
• TRIP OR FIRE HAZARD! Position all cables where they
cannot contact hot surfaces, be pulled, be tripped over,
or damaged by persons walking on or objects rolling over
the cables.
Power specifications
UHD55
1-L
UHD65
1-L
UHD75
1-P
UHD86
1-P
UHD86
1-LT
Input
rating
110-240
V AC
50-60Hz
1300mA
110-240
V AC
50-60Hz
1400mA
110-240
V AC
50-60Hz
2500mA
110-240
V AC
50-60Hz
3200mA
110-240
V AC
50-60Hz
3600mA
Anatel
Este equipamento não tem direito à proteção contra interferência
prejudicial e não pode causar interferência em sistemas
devidamente autorizados.
Technical support
• North and South America: +1-800-221-8025 or
Support.Americas@christiedigital.com
• Europe, Middle East, and Africa: +44 (0) 1189 778111 or
Support.EMEA@christiedigital.com
• Asia Pacific: +65 6877-8737 or
Support.APAC@christiedigital.com
Important Safety Information
Access Series LCD Panels Product Safety Guide 3
020-102422-05 Rev. 1 (05-2019)
Copyright © 2019 Christie Digital Systems USA, Inc. All rights reserved.
