H864 Instruction manual
Thank you for your purchase of this Citizen watch.
Before using the watch, read this instruction manual (PDF) carefully to ensure correct use.
Caliber No. of this watch: H864
You can access the web instruction manual in addition by using the QR code or the URL:
https://www.citizenwatch-global.com/support/html/en/h864/h864.html
Some models may be equipped with enhanced features functions such as slide rules and tachymeters. To see how to use such features and functions, which is
not covered with the instruction manual, and other information, access the CITIZEN support page (
https://www.citizenwatch-global.com/support/
).
ENGLISH
Safety precautions — IMPORTANT
This manual contains instructions that should be strictly followed at all times
not only for optimal use, but to prevent any injuries to yourself, other persons or
property. We encourage you to read the entire booklet (especially, pages
9
and
10
) and understand the meaning of the following symbols:
⿎Safety advisories are categorized and depicted in this manual as follows:
DANGER
Highly likely to cause death or serious injury
WARNING
Can cause serious injury or death
CAUTION
Can or will cause minor or moderate injury or damage
⿎Important instructions are categorized and depicted in this manual as follows:
(Following symbols are examples of Pictograms.)
Warning (caution) symbol followed by prohibited matters.
Warning (caution) symbol followed by instructions that should be followed or
precautions that should be observed.
Features
■
Radio controlled watch
Receives time signals from one of the five signal stations in four regions in
the world and automatically adjusts the time and calendar.
■
Eco-Drive
No periodical battery replacement is needed. This watch is fueled by light.
■
World time
Indicates the time around the world by choosing one of 26 time zones.
■
UTC indication
The arrow on the Northern hemisphere dial always indicates UTC
(Coordinated Universal Time).
■
Perpetual calendar
No need for monthly and leap-year date correction until February 28, 2100.
• “Eco-Drive” is an original technology of Citizen.
CONTENTS
Before using this watch ........................................................... 2
Band adjustment ....................................................................................2
Protective stickers ..................................................................................2
How to use a specially designed crown/button .......................................2
Component identification ....................................................... 2
Checking the power reserve .................................................... 3
World time ............................................................................. 3
Checking the time zone setting...............................................................3
Changing the time zone setting ..............................................................3
Summer time.......................................................................... 4
Checking the summer time setting .........................................................4
Changing the summer time setting ........................................................4
Receiving the time signal ........................................................ 5
Checking the previous signal reception result .........................................5
Receiving the time signal manually ........................................................5
About signal reception ............................................................ 5
Types of signal reception ........................................................................5
When receiving the time signal ..............................................................5
Poor reception areas ...............................................................................5
Note on the time signal ..........................................................................5
Adjusting the time and calendar manually .............................. 6
Charging your watch ............................................................... 7
When the watch reaches a low charge state
(insufficient charge warning function) .................................................7
Charging time by environment ...............................................................7
Power save function ...............................................................................7
Troubleshooting ..................................................................... 7
Checking and correcting the reference position ....................... 8
Resetting the watch - All Reset ...............................................................8
Eco-Drive watch handling precautions ..................................... 9
Water resistance ..................................................................... 9
Precautionary items and usage limitations .............................. 9
Specifications ........................................................................10
2/10
H864 Instruction manual
Before using this watch
The following three operations must be done before using the watch:
1 Checking the current power reserve (page )
3
2 Setting the time zone (page )
3
3 Checking the reception result of the time signal (page )
5
This watch has a rechargeable cell which is charged by exposing the dial
to light.
Expose the dial to direct sunlight regularly to charge the watch. For
details of charging, see page
7
.
Band adjustment
We recommend seeking the assistance of an experienced watch technician for sizing
of your watch. If adjustment is not done correctly, the bracelet may unexpectedly
become detached leading to loss of your watch or injury (excluding products
containing the band adjustment tool).
Consult an authorized service center. Other shops may charge for, or may not
provide, the service.
Protective stickers
Be sure to remove any protective stickers that may be on your watch (case back,
band, clasp, etc.). Otherwise, perspiration or moisture may enter the gaps between
the protective stickers and the parts, which may result in a skin rash and/or
corrosion of the metal parts.
How to use a specially designed crown/button
Some models are equipped with a specially designed crown and/or push button to
prevent accidental operation.
Screw down crown/button
Unlock the crown/button prior to operate your watch.
Unlock Lock
Screw down
crown
Rotate the crown
counterclockwise until
it releases from the case.
Push the crown in to
the case. With gentle
pressure towards the
case, rotate the crown
clockwise to secure it
to the case. Be sure to
tighten firmly.
Screw down
push button
Rotate the locking screw
counterclockwise, and
loosen until it stops.
Rotate the locking
screw clockwise, and
tighten firmly.
Recessed button
Press the button with a non-marring narrow-tipped object.
• Metal objects may cause marring or scratching of the button.
Component identification
• The illustrations in this instruction manual may differ from the actual appearance
of your watch.
Hands and buttons
Minute hand
Function hand
Hour hand
24-hour hand
Second hand
Button
B
Button
A
Crown
Indication
Northern hemisphere
dial Date
Power reserve
Summer time setting
Reception result indicationReception-in-progress indication
Time zone
Day of week
• A solar cell is placed under the dial.
About the Northern hemisphere dial
• A map of the Northern hemisphere, which centers the north pole, is shown on the
dial.
• Synchronized with the watch, the dial turns fully around counterclockwise once a
day.
• You cannot adjust the dial separately.
• The arrow on the dial always indicates UTC (Coordinated Universal Time).
• You can find approximate times of places on the Northern hemisphere by using
the dial. For example, when the dial turns to the position as shown below,
approximate times of places are read as follows:
Point A (London): about 1:00 AM
Point B (Tokyo): about 10:00 AM
Point C (New York): about 8:00 PM
Crown's position
3/10
H864 Instruction manual
Checking the power reserve
For details of charging, see “Charging your watch” (page
7
).
1 Push the crown in to position 0.
2 Press and release the upper right button B.
The function hand indicates the power reserve in levels.
3 Press and release the upper right button B to finish the procedure.
• The hand returns to normal indication automatically in 10 seconds without pressing
the button.
Indication of power reserve in levels
Level
3210
Power
reserve
indication
Duration
(approx.) 180 - 130 days 130 - 70 days 70 - 2 days 2 days
Meaning
Power reserve is
sufficient.
Power reserve is
OK.
Power reserve is
getting low.
Insufficient
charge warning
has started.
OK for normal use Charge immediately.
• The function hand always indicates power reserve while power reserve level is “1”
or “0”.
World time
This watch can indicate the time around the world according to which of 26 time
zones (offsets from UTC — Coordinated Universal Time) is chosen.
• Signals to receive are different depending on the time zone you set.
Checking the time zone setting
1 Push the crown in to position 0.
2 Press and release the lower right button A.
The second hand indicates the current time zone setting.
Ex: when +9 is set as the time zone
• For time zones and positions of the second hand corresponding to them, see the
table.
3 Press and release the lower right button A to finish the procedure.
• The hand returns to normal indication automatically in 10 seconds without pressing
the button.
Changing the time zone setting
1 Pull the crown out to position 1.
The second hand indicates the current time zone setting.
2 Rotate the crown to select a time zone.
• For time zones and positions of the second hand corresponding to them, see the
table.
• When you chose a different time zone from the current one, the hands and
indication of the watch move corresponding to the new one.
3 Push the crown in to position 0 to finish the procedure.
The watch returns to normal indication.
Correspondence of time zones and positions of the second hands
Second hand position Time zone Area name Signal station
0 0 LON Germany
2 +1 PAR
4 +2 ATH
◆Germany7 +3 RUH
9 +4 DXB
11 +5 KHI
◆China
14 +5.5 DEL
16 +6 DAC
18 +7 BKK
21 +8 BJS China
23 +9 TYO Japan
25 +9.5 ADL
◆Japan
28 +10 SYD
30 +11 NOU
32 +12 AKL
35 –11 MDY
◆United States37 –10 HNL
39 ANC–9
42 –8 LAX
United States
44 –7 DEN
46 –6 CHI
49 –5 NYC
51 –4 MAO ◆United States
53 –3 RIO
56 FEN–2 ◆Germany
58 –1 PDL
• Values on the “Time zone” column mean time difference between UTC and the
standard time of time zones.
• Time zones whose “Signal station” has ◆ mark in the table are out of reception
range and cannot receive its signals. switching summer time and standard time
must be executed manually there.
• It may be difficult to receive the time signal properly under certain environmental
conditions which prevent signals to reach.
Produktspecifikationer
| Varumärke: | Citizen |
| Kategori: | Titta |
| Modell: | Promaster Air Geo Trekker BY3006-53H |
Behöver du hjälp?
Om du behöver hjälp med Citizen Promaster Air Geo Trekker BY3006-53H ställ en fråga nedan och andra användare kommer att svara dig
Titta Citizen Manualer
13 Mars 2025
Titta Manualer
- Titta Casio
- Titta IKEA
- Titta Huawei
- Titta Braun
- Titta Epson
- Titta Garmin
- Titta Medion
- Titta Ade
- Titta Adidas
- Titta Alpina
- Titta Akai
- Titta Armani
- Titta Ascot
- Titta Invicta
- Titta Skmei
- Titta Suunto
- Titta Alessi
- Titta Omega
- Titta Nedis
- Titta Pyle
- Titta Timex
- Titta Lotus
- Titta Lars Larsen
- Titta Orient
- Titta Jacques Lemans
- Titta Calypso
- Titta Renkforce
- Titta Bushnell
- Titta Olivia Burton
- Titta Victorinox
- Titta Lambretta
- Titta Tudor
- Titta Holzkern
- Titta Hublot
- Titta Ebel
- Titta Christopher Ward
- Titta Edox
- Titta Gc
- Titta So & Co
- Titta Diesel
- Titta Tissot
- Titta Bulova
- Titta Lorus
- Titta Stuhrling
- Titta Beper
- Titta Swatch
- Titta Luminox
- Titta Festina
- Titta Emporio Armani
- Titta Girard-Perregaux
- Titta Certina
- Titta TMI
- Titta Mitsubishi
- Titta Velleman
- Titta Detomaso
- Titta La Crosse Technology
- Titta Skagen
- Titta Marquant
- Titta Dugena
- Titta Rolex
- Titta Seiko
- Titta Polar
- Titta Fitbit
- Titta Auriol
- Titta ETA
- Titta TW Steel
- Titta Breitling
- Titta Timberland
- Titta Spinnaker
- Titta Jaguar
- Titta Pulsar
- Titta Pilgrim
- Titta Davis
- Titta Boss
- Titta TFA
- Titta Habitat
- Titta Clas Ohlson
- Titta TomTom
- Titta Irox
- Titta Michael Kors
- Titta ELYSEE
- Titta Zenith
- Titta Danish Design
- Titta Daniel Steiger
- Titta Torgoen
- Titta WoodWatch
- Titta Executive
- Titta Tommy Hilfiger
- Titta Nautica
- Titta Technaxx
- Titta Christiaan Van Der Klaauw
- Titta Klaus Kobec
- Titta Obaku
- Titta Hugo Boss
- Titta Fossil
- Titta Shinola
- Titta Spin Master
- Titta Tikkers
- Titta Krontaler
- Titta Sinn
- Titta Brera
- Titta Lucien Picard
- Titta Nike
- Titta Swiza
- Titta Mondaine
- Titta Geemarc
- Titta Ticwatch
- Titta Bering
- Titta Leff
- Titta DMC
- Titta Lynx
- Titta Maurice Lacroix
- Titta ICE Watch
- Titta Dakota
- Titta Eurochron
- Titta La Crosse
- Titta Rado
- Titta Puma
- Titta Gant
- Titta Westfalia
- Titta Just
- Titta Sempre
- Titta IWC
- Titta Digi-tech
- Titta Freestyle
- Titta Oregon Scientific
- Titta Misfit
- Titta Breo
- Titta BML
- Titta Inter-Quartz
- Titta Haffstreuner
- Titta Hamilton
- Titta Kalenji
- Titta Longines
- Titta Junghans
- Titta Meister Anker
- Titta GC Watches
- Titta Speedo
- Titta Naitica
- Titta TCM
- Titta Kogan
- Titta Uri Minkoff
- Titta Guess
- Titta ESQ
- Titta ETT
- Titta Triwa
- Titta Raketa
- Titta Balmain
- Titta Wonky Monkey
- Titta Audemars Piguet
- Titta Timer
- Titta Marc Jacobs
- Titta Iron Annie
- Titta Julie Julsen
- Titta Xonix
- Titta KRAEK
- Titta World Timer Chronograph
- Titta Ferrari
- Titta X-WATCH
- Titta Versace
- Titta PAUL HEWITT
- Titta Rodania
- Titta Bruno Sohnle
- Titta Naviforce
- Titta Movado
- Titta Lacoste
- Titta Fromanteel
- Titta MICHELE
- Titta Philip Watch
- Titta QQ
- Titta Fila
- Titta Ronda
- Titta TimeStyle
- Titta Radley London
- Titta PANERAI
- Titta Prologue
- Titta Zeppelin
- Titta Hype
- Titta HYT
- Titta Grand Seiko
- Titta AMS
Nyaste Titta Manualer
12 Mars 2025
11 Mars 2025
11 Mars 2025
11 Mars 2025
11 Mars 2025
11 Mars 2025
11 Mars 2025
11 Mars 2025
27 Februari 2025
27 Februari 2025
