Sida 1/2
WEB: corsair.com
PHONE: (888) 222-4346
SUPPORT: support.corsair.com
BLOG: corsair.com/blog
FORUM: forum.corsair.com
YOUTUBE: youtube.com/corsairhowto
© 2021 CORSAIR MEMORY, Inc. All rights reserved. CORSAIR and the sails
logo are registered trademarks in the United States and/or other countries.
All other trademarks are the property of their respective owners.
Product may vary slightly from those pictured. 49-002069 AD
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
TBT100
Thunderbolt™ 3 Dock
TBT100
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations. ICES-003(B)/NMB-003(B)
Cet appareil numérique de la class B respecte toutes les exigences du Règlement sur le materiel
brouilleur du Canada. ICES-003(B)/NMB-003(B)
EN
FR
PORTUGUÊSESPAÑOLENGLISH FRANÇAIS
GETTING TO KNOW THE DOCK PRÉSENTATION DE LA STATION
A — Power On/Off Button
B — USB-C SuperSpeed 10Gbps
C — SD Card Slot (Supports UHS II)
D — 3.5mm Combo Port
E — USB-A SuperSpeed 5Gbps
F — Gigabit Ethernet
G — HDMI 2.0
H — Thunderbolt™ 3 40Gbps
I — Power In
J — Kensington™
Security Slot
A — Bouton Marche/Arrêt
B — Port USB-C SuperSpeed 10Gbit/s
C — Lecteur De Carte SD
(Prend En Charge Les Cartes UHS-II)
D — Port Combiné 3,5mm
E — Port USB-A SuperSpeed 5Gbit/s
F — Port Gigabit Ethernet
G — Port HDMI 2.0
H — Port Thunderbolt™ 3 40Gbit/s
I — Entrée D'alimentation
J — Encoche De Sécurité Kensington™
Connect a wealth of devices to your Mac or PC with the CORSAIR TBT100 Thunderbolt™ 3 Dock, boasting up to
40Gbps bandwidth while efficiently charging your laptop with smart charging technology.
Connectez une foule d'appareils sur votre ordinateur Mac ou PC avec la station Thunderbolt 3 CORSAIR TBT100,
offrant un débit jusqu'à 40Gbit/s tout en rechargeant efficacement votre ordinateur portable grâce à la technologie
Smart Charging.
> Connect power supply to dock and plug into wall
> Connect the dock to an available Thunderbolt ™ 3 port on
your computer using the included Thunderbolt ™ 3 cable
> To turn power on/off, push power button for 3 seconds
(When plugging in power directly to dock, the dock will
automatically be in power “on” mode)
> Branchez le bloc d'alimentation sur une prise murale et reliez-le
à la station
> Branchez la station sur un port Thunderbolt ™ 3 disponible de
votre ordinateur à l'aide du câble Thunderbolt ™ 3 fourni
> Pour allumer ou éteindre la station, enfoncez le bouton
d'alimentation pendant 3 secondes (La station bascule
automatiquement en mode «Marche» lorsque vous branchez
directement l'alimentation)
LED DOCK POWER MODE
ON ON
OFF OFF
DEL MODE D'ALIMENTATION
DE L A STATION
ALLUMÉ ALLUMÉ
ÉTEINT ÉTEINT
E
A C D
F G H I J
B
E
A C D
F G H I J
B
CONOZCA LA BASE
Conecte una gran variedad de dispositivos a su Mac o PC con la base CORSAIR TBT100 Thunderbolt 3, que
proporciona un ancho de banda de 40Gbps y al mismo tiempo carga su computadora portátil con tecnología de
carga inteligente.
CONHEÇA A BASE
Conecte uma ampla variedade de dispositivos ao seu Mac ou PC com o CORSAIR TBT100 Thunderbolt 3 Dock,
que conta com até 40Gbps de largura de banda enquanto carrega o seu laptop de maneira eficiente usando a
tecnologia de carregamento inteligente Smart Charging.
E
A C D
F G H I J
B
E
A C D
F G H I J
B
A — Botão Liga/Desliga
B — USB-C SuperSpeed De 10Gbps
C — Slot De Cartão SD
(Compatível Com UHS II)
D — Porta Combo De 3,5mm
E — USB-A SuperSpeed De 5Gbps
F — Gigabit Ethernet
G — HDMI 2.0
H — Thunderbolt™ 3 De 40Gbps
I — Entrada De Alimentação
J — Slot De Segurança Kensington™
A — Botón De Encendido Y Apagado
B — USB-C SuperSpeed De 10Gbps
C — Ranura Para Tarjeta SD
(Compatible Con UHS II)
D — Puerto Combinado De 3.5mm
E — USB-A SuperSpeed De 5Gbps
F — Puerto Gigabit Ethernet
G — HDMI 2.0
H — Thunderbolt™ 3 De 40Gbps
I — Conector De Alimentación
J — Conector De Seguridad Kensington™
> Conecte la fuente de alimentación a la base y enchufe a la pared
> Conecte la base a un puerto Thunderbolt ™ 3 disponible en
su computadora mediante el cable Thunderbolt ™ 3 que
viene incluido
> Para encender y apagar la base, mantenga presionado el botón
de encendido por 3 segundos (cuando enchufe la fuente de
alimentación a la base, esta se encenderá automáticamente)
LED MODO DE
ENCENDIDO DE LA
BASE
ENCENDIDO ENCENDIDO
APAGADO APAGADO
> Conecte a fonte de alimentação ao dock e plugue-a na tomada
> Conecte a base a uma porta Thunderbolt ™ 3 disponível no
seu computador usando o cabo Thunderbolt ™ 3 incluído
na embalagem
> Para ligar/desligar, pressione o botão de energia por 3
segundos (Ao conectar a alimentação diretamente à base,
ela liga automaticamente)
LED MODO DE
ALIMENTAÇÃO DA
BASE
LIGADO LIGADO
DESLIGADO DESLIGADO
