PU-1106-KIT
v1.3 HDMI over CAT6 Extender
Set with IR Pass-through
OPERATION MANUAL
Table of Contents
1
1
1
1
2
3
4
4
5
6
6
6
7
9
1. Introduction ……………………..……………………...…........….…….
2. Applications …………………..………………….……...................…..
3. Package Contents ………………………...........……….................…
4. System Requirements ……………..……….........………............…….
5. Features …………………………………………......……........…...……
6. Specifi cations ………………………………...……..........………....….
7. Operation Controls and Functions ……………...……..............……
7.1 Front Panel ..............................................................................
7.2 Rear Panel .…………………………………..…….......…...….…
8. Pin Assignment .............................……………..........…......…....…...
8.1 IR Cable Pin Assignment .......................................................
8.2 RJ-45 Pin De nitions ................................................................
10. Connection and Installation ….………………….........…..…..…......
11. Acronyms …......................................................................................
1. Introduction
The HDMI 1.3 transmitter and receiver over CAT6 is the ideal device to send
your HDMI signals over long distances. Instead of using expensive HDMI
cables, your existing CAT6 cables/sockets can replace HDMI cables while
performing the same functions like transferring Deep Color (12 bits/color)
video and lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-
HD Master Audio) digital audio. Moreover, you can use the existing remote
to control the source and connect it to another transmitter and receiver to
extend your HDMI signal to distances you never thought possible. This HDMI
1.3 Transmitter and receiver is your only choice when looking for an HDMI
extender.
2. Applications
Showroom display/control
Home entertainment systems
Commercial displays
Lecture room display/control
3. Package Contents
HDMI 1.3 Transmitter x 1
HDMI 1.3 Receiver x 1
IR Receiver x 1
IR Blaster x 1
5V DC power supply adaptor x 2
Operation Manual x 1
4. System Requirements
HDMI input source equipment, output HDMI displayer, two CAT6 cables and
source equipments remote control.
1
