Daewoo FR146S Bruksanvisning

Daewoo kylskåp FR146S

Läs nedan 📖 manual på svenska för Daewoo FR146S (8 sidor) i kategorin kylskåp. Denna guide var användbar för 6 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/8

NAMES OF THE PARTS

10 11 2 1 7 3 5

8 9 6

1. EVAPORATOR

The heart of the refrigerator.

It evaporates the refrigerant fluid and thereby absorbs heat from the surrounding. Made of

pure aluminum.

2. DRAIN PAN (Use of Defrost Only)

Discards the water that drips of the evaporator when defrosting.

3. CONTROL BOX :

Regulates the operation of the motor and controls the inside temperature of the refrigerator.

4. SHELF

Has full width and can slide out.

5. RACK For butter, eggs, and small size goods.

6. MAGNETIC DOOR SEALS

Keeps the refrigerator virtually airtight all along the edge, but is nevertheless easy to open.

7. ICE CUBE TRAY Ice cubes are easy to remove from the tray.

8. USABLE RACK for cans or jars.

9. BOTTLE RACK for bottles, cans or jars.

10. CRISPER for vegetables and fruits.

11. SLIDE OUT CRISPER COVER.

HOW TO OPERATE

1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the inside

with a damp cloth.

2. Keep the door open and insert the power supply cord into the socket.

3. Turn the thermostat dial to “7”. Close the door and let the refrigerator operate for 15-

20 minutes.

The freezer should then show some traces of frost.

You can control the inside temperature by turning the

thermostat dial. Higher numbers mean greater cooling

power, smaller numbers mean less cooling power. To

make ice cubes in the freezer compartment, set the dial

to “7”. The dial does not have to be set exactly on the

numbers, but can be any place in between.

Defrost the refrigerator when the frost accumulated on the evaporator is about

5mm(1/5inch) thick.

Set the thermostat dial to “OFF”. Remove foods. Keep drip tray in place. Defrosting usually

takes a few hours. To defrost quickly remove all foods from the refrigerator and leave door

open. Never use a knife or other metal instrument to remove ice/frost from the evaporator.

After defrosting empty water from drip tray, return the thermostat dial to the desired position

to start refrigerating again.

OFF

TEMPERATURE

CONTROL

NOTE : Wait 3 to 5 minutes before restarting if you unplug the machine. Unit

may fail to operate properly if restarted too quickly.

Temperature control

Starting your new Refrigerator

How to defrost

HOW TO CLEAN

Cleaners: The cleaners noted below are available. Never use harsh, abrasive cleaners,

heavy-duty cleaners, or solvents on any surface.

Exterior: Wipe with damp, sudsy cloth, rinse and dry. For stubborn stains and for periodic

waxing, use silicon wax.

Evaporator: When refrigerator needs defrosting turn thermostat dial to “OFF”. Do not use

sharp instruments.

Refrigeration Section: Wash shelves and other removable parts in warm sudsy water,

rinse and dry. Wash interior with baking soda solution (3 table spoons to one quart of

water) or warm sudsy water, rinse and dry.

Magnetic Door Seals: Wash with warm sudsy water.

The Finishing Touch: Replace all parts and return thermostat dial to desired setting.

▶Install refrigerator in a convenient location away from extreme heat and cold.

Allow sufficient clearance between the refrigerator and side wall so the door

will open for a fully usable interior. Refrigerator is not designed for recessed

installation.

▶Select a place with strong level floor.

▶Allow 5 inches of space between the

refrigerator s side and the wall.’

HOW TO INSTALL

inches

WHAT TO DO...

1. When out of operating for a long time:

•Remove the power supply cord.

•Dry your refrigerator opening the door for 2-3 days.

2. When you get ready to move:

•Securely fasten removable interior parts (or move and package them separately)

•Do not lay your refrigerator horizontally, or compressor may be damaged.

When you need service: Before you call for service make sure

you need it, check a few things noted below for

yourself first.

If refrigerator is not operating:

•Is the power supply cord unplugged?

•Is home fuse blown or circuit breaker off?

If refrigerator is warmer than usual:

•Has the door been open frequently or for a long period?

•Is refrigerator overcrowded-preventing good air circulation?

•Is the hot thing stored without cooling?

•Is the clearance between refrigerator’s side and the wall allowed sufficiently?

If there are unusual sounds:

•Is refrigerator placed on the level?

•Are foreign objects behind the refrigerator?

•Are dishes on refrigerator shelves vibrating?

If so, rearrange the dishes.

If the supply cord is damaged, it must be replaced by the manufacturer or its service

agent or a simmilary qualified person in order to avoid a hazard.

DANGER

Risk of child entrapment. Before you throw away your old refrigerator

or freezer

: Take off the doors. Leave the shelves in place so that

children may not easily climb inside.
