OWNER’S

MANUAL

Before operating this oven, please read

this manual completely.

MICROWAVE

CONVECTION/GRILL OVEN

KOC-9U0TSL

TABLE OF CONTENTS

• INSTALLATION AND EARTHING INSTRUCTIONS...................... 2

• IMPORTANT SAFETY INSTRUCTIONS........................................ 3

• WHICH UTENSILS CAN BE USED IN THE OVEN?..................... 5

• COOKING INSTRUCTIONS .............................................................6

• CONTROL PANEL............................................................................ 7

• ACCESSORIES ................................................................................ 8

• BEFORE OPERATION..................................................................... 9

SETTING THE CLOCK.................................................................... 9

CHILD LOCK AND POWER SAVE MODE.................................. 10

• OPERATION.................................................................................... 11

MICROWAVE COOKING...............................................................11

GRILL COOKING........................................................................... 12

CONVECTION COOKING (WITH PRE-HEAT)........................... 13

CONVECTION COOKING (TRADITIONAL COOKING)............. 14

COMBINATION COOKING

(MICROWAVE+CONVECTION+UPPER GRILL)........................ 15

(1) WEIGHT DEFROST MODE..................................................... 16

(2) TIME DEFROST MODE............................................................16

AUTO COOK .................................................................................. 17

SPEEDY COOK ..............................................................................18

PIZZA COOK....................................................................................18

STEAM CLEANING.........................................................................19

REMINDER MODE

(FUNCTION TO REMIND COOKING COMPLETE).....................19

TO STOP THE OVEN WHILE THE OVEN IS OPERATING........19

ABNORMAL MESSAGE.................................................................19

ARCING............................................................................................19

• GENERAL GUIDE LINES................................................................20

• KEEP THE OVEN CLEAN ..............................................................21

• BEFORE CALLING FOR SERVICE...............................................22

• QUESTIONS AND ANSWERS.......................................................23

• SPECIFICATIONS...........................................................................24

• PRINCIPLE OF MICROWAVE........................................................24

• DISPOSAL OF USED ELECTRICAL &

ELECTRONIC EQUIPMENT..........................................................24

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since open-door operation

can result in harmful exposure to microwave energy. It is important not to defeat or

tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow soil or

cleaner residue to accumulate on sealing surfaces.

has been repaired by a competent person: (1) door (bent), (2) hinges and latches (broken

or loosened), (3) door seals and sealing surfaces.

(d) WARNING : It is hazardous for anyone other than a competent person to carry out any

service or repair operation which involves the removal of a cover which gives protection

against exposure to microwave energy.

(e) WARNING : Liquids and other foods must not be heated in sealed containers since

they are liable to explode.

(f) WARNING : Only allow children to use the oven without supervision when adequate

instructions have been given so that the child is able to use the oven in a safe way and

understands the hazards of improper use.

(g) WARNING : When the appliance is operated in the combination mode, children should only

use the oven under adult supervision due to the temperatures generated.

INSTALLATION AND EARTHING INSTRUCTIONS

How to examine your microwave oven after unpacking.

Unpack oven, remove all packing material, and examine the

oven for any damage such as dents, broken door, latches or

cracks in the door. Do not remove the film from inside the door.

Notify dealer immediately if the oven is damaged. Do not install if

the oven is damaged.

Where to place your microwave oven.

1. Place the oven on a flat and stable surface.

2. The microwave oven shall not be placed in a cabinet unless it

is a purpose built cabinet model.

3. The surface of the oven is protected by a plastic film which

should be removed before using.

4. Leave space behind and sides and upper of the oven. All air

vents should be kept clear.

If all vents are covered during operation, the oven may

overheat and, eventually, lead to oven failure.

5. Keep away from radio and TV sets. If the oven is located close

to a TV, radio interference may result.

6. Keep away from heating appliances and water taps. Keep the

oven away from hot air, steam or splashes when choosing a

place to position it, or the insulation might be adversely

affected and breakdowns occur.

7. The minimum height of free space necessary above the top

surface of the oven is 170mm minimum.

Prior to use (If your oven has a grill element)

In order to protect your oven during transportation and storage,

the grill element is covered with a protective coating. To remove

this coating the grill element must be heated for 10 minutes. This

procedure will produce some bad odours as the protective

coating on the element disappears.

To remove the coating, use the following procedures:

1. Place an ovenproof or microwave safe bowl, containing 200cc

of water or more, in the oven.

2. Press the convection button.

3. Set the time to 10 minutes.

4. Press the start button.

5. When the 10 minutes has elapsed, an acoustic signal sounds.

Note:

The protective coating has now been removed and the oven is

ready to use. Please be aware that your oven is now very hot.

6. Open the oven door and remove the bowl of water (use oven

gloves when removing the bowl).

CHILD LOCK

To prevent a child from operating the oven, install the childlock key.

1. Touch Stop/Clear button for 3 seconds.

Indicator lock is indicated and all buttons do not operate.

2. Touch Stop/Clear button for 3 seconds once again, then

childlock is canceled.

-WARNING: Only allow children to use the oven without

supervision when adequate instructions have been given so

that the child is able to use the oven in a safe way and

understands the hazards of improper use.

Electrical Connection

WARNING-THIS APPLIANCE MUST BE EARTHED.

REFER TO THE RATING PLATE FOR VOLTAGE AND

CHECK THAT THE APPLIANCE VOLTAGE CORRESPONDS

WITH THE SUPPLY VOLTAGE IN YOUR HOME.

The flexible mains lead must be correctly re-connected, as below,

to a three pin plug of not less than 13 AMP capacity. You must

use a 3 pin plug which should be marked with the number BS

1363 and it should be fitted with 13 AMP fuse marked with the

number BS 1362.

We recommend the use of good quality plugs and wall sockets

that can be switched off when the machine is not in use.

IMPORTANT-The wires in the mains lead fitted to this appliance

are coloured in accordance with the following code

GREEN AND YELLOW-EARTH

BLUE-NEUTRAL

BROWN-LIVE

As the colour of the wires in the mains lead of this appliance may

not correspond with the coloured markings identifying the

terminals in your plug, proceed as follows:

Power supply

• Check your local power source. This oven requires a current of

approximately 8.5amperes, 230V 50Hz.

• Power supply cord is about 1.2 meters long.

• The voltage used must be the same as specified on this oven.

Using a higher voltage may result in a fire or other accident

causing oven damage. Using low voltage will cause slow

cooking. We are not responsible for damage resulting from use

of this oven with a voltage of ampere fuse other than those

specified.

• If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified person

in order to avoid a hazard.

The wire which is coloured GREEN AND YELLOW must be

connected to the terminal in the plug which is marked with the

letter "E" or the earth symbol or coloured GREEN AND

YELLOW, or GREEN.

The wire which is coloured BLUE must be connected to the

terminal which is marked with the letter "N" or coloured BLACK,

or BLUE.

The wire which is coloured BROWN must be connected to the

terminal which is marked with the letter "L" or coloured RED , or

BROWN.

If the terminals in the plug are unmarked or you are in any doubt

as to the correct connections, consult a qualified electrician.

If you do not make the proper electrical connections you will

damage your microwave oven and possibly injure yourself.

Neither the manufacturer nor the supplier are liable if this

happens.

MOULDED PLUGS

Should it be necessary to remove a moulded on plug from the

mains cable, it should be cut off and replaced with a suitable

replacement.

The moulded plug cannot be used for any other appliance,

therefore remove the fuse and dispose immediately and safely to

prevent anyone, especially children from plugging it in to a wall

socket, which will create a safety hazard.

Should the mains lead ever require replacement, it is essential

that this operation be carried out by a qualified electrician and

should only be replaced with a flexible cord obtained from the

manufacturer.

Applicable only if moulded plug is fitted.

After replacement of a fuse in the plug, the fuse cover must be

refitted. If the fuse cover is lost, a replacement cover must be

obtained. The colour of the correct replacement fuse cover is that

of the coloured insert in the base of the plug or the colour that is

embossed in words in the base of the plug recess or elsewhere

on the plug. Always state this colour when ordering a

replacement fuse cover.

Only 13 amp replacement fuses which are ASTA approved to BS

1362 should be fitted
