us.dahuasecurity.com Intelligent Solutions for a Safer World

Dahua panoramic cameras provide 180° or 360° views that provide wide-area video surveillance for increased situational

awareness. Fisheye and Multi-sensor cameras replace multiple single-sensor cameras providing easier installation and a higher

return on investment. This Quick Guide presents the specications for all components necessary to create your own network

panoramic surveillance system from Dahua.

2x2MP Dual Sensor Congurations Fisheye

Stairwell Conguration Hallway Conguration Single Sensor 360 0

8x2MP Multi-sensor 4x2MP Multi-sensor Dome 4x2MP Multi-sensor Bullet

3600 Stitched 1800 Stitched 1800 Stitched

Unstitched Multi-ex Congurations

180º View 270º View 360º View

Position all four sensors toward the front

of the track for a 180º overview. Best when

required to mount where a lens may be

obstructed.

Position three of the sensors toward the front

of the track and one to the back for a 270º

overview. Best when required to mount where

a lens may be obstructed.

Position sensors evenly around track for

a full 360º overview. Best for applications

that will be mounted in an open area without

obstruction.

The IR LEDS and lenses are xed to the same bracket, so when the lenses move so do the LEDs.

IP PANORAMIC

SOLUTION QUICK GUIDE

Go from this: To this:

· Quicker installation

· Fewer cameras and cable

· One VMS license

· Lower total cost of ownership

us.dahuasecurity.com Intelligent Solutions for a Safer World

DH-IPC-PDBW8840N-A180 DH-PSDW81642M-A360 DH-IPC-PDBW5831N-B360 DH-IPC-PDBW82041N-B360

2MP IR 180° Panoramic Dome 8 x 2MP Panoramic + 4MP PTZ Multi-Flex Quad-sensor Dome Camera Multi-Flex Quad-sensor Dome Camera

UltraSeries

• Four (4) 1/2.8-in. CMOS Sensors

• 4096 x 1800 at 30 fps

• 180° Panoramic View

• 2.8 mm Lenses

• Starlight+ Technology

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+,

H.264, MJPEG

• Digital Wide Dynamic Range

• Max IR Distance 30 m (98 ft)

• Analytics+: (Vehicle Density, Crowd Den-

sity) IVS (Tripwire, Intrusion)

• IP67 and IK10

• Best for wide area surveillance

UltraSeries

• Panoramic Camera: Eight (8) 1/1.8-in.

2MP CMOS Sensors with Eight (8) 5 mm

Lenses for a 360° Panoramic View

• PTZ Camera: One (1) 1/1.8-in 4MP

CMOS Sensor with One (1) 5.6 mm to

223 mm Lens

• 8192 x 1800 at 30 fps (Panoramic) plus

2560 x 1440 at 30 fps (PTZ)

• Starlight Technology 0.008 lux Color

• Triple-stream Encoding

• Max IR Distance 400 m (1312.34 ft)

PTZ with Zoom Priority for Optimal IR

Coverage at Any Zoom Level

• Intelligent Video System (IVS) with Smart

Track, Crowd and Vehicle Density

• IP66

• Best for wide area surveillance

UltraSeries

• Four (4) 1/2.8-in. 2MP STARVIS™

CMOS Sensors

• Four (4) 2.7 mm to 12 mm Motorized

Zoom Lenses

• Dual-stream Encoding, per sensor

• 1920 x 1080 at 30 fps per Sensor

• Ultra-wide Dynamic Range (140 dB,

channel 1 only)

• Intelligent Video System: Motion, Trip-

wire, Intrusion,Scene Change, Aban-

doned/Missing Object

• Sensors Independently Positionable and

Configurable

• Enhanced Starlight Technology 0.005

lux Color

• Smart H.265+, H.265, Smart H.264+,

H.264, H.264B, H.264H, MJPEG (sub

stream)

• Max IR Distance 30 m (98 ft)

• IP67 and IK10

• Best for medium to large intersecting

areas for wide coverage

UltraSeries

• Four (4) 1/2.7-in. 5MP CMOS Sensors

• Four (4) 2.8 mm to 12 mm Motorized

Zoom Lenses

• Triple-stream Encoding per sensor

• FlexStream Consolidates Video from All

Channels into a Single Stream

• 2592(H) x 1944(V), per Sensor

• Wide Dynamic Range on all Channels

• Intelligent Video System: Abandoned/

Missing Object

• Analytics+: Perimeter Protection, Face

Detection

• Sensors Independently Positionable and

Configurable

• Enhanced Starlight Technology 0.005

lux Color

• Smart H.265+, H.265, Smart H.264+,

H.264, H.264B, H.264H, MJPEG (sub

stream)

• Max IR Distance 30 m (98 ft)

• IP67 and IK10

• Best for medium to large intersecting

areas for wide coverage

DH-IPC-EBW81242N N68BR4V N55CS5

12MP 360° IR Fisheye 6MP 360° IR Fisheye 5MP 360° Panoramic Fisheye

UltraSeries

• 1/1.7-in. STARVIS™ CMOS

• 12MP at 30 fps

• 1.98 mm Fixed Lens

• Multiple Dewarping Modes

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264

• Built-in Microphone

• Digital Wide Dynamic Range

• Max IR Distance 10 m (33 ft)

• Analytics+ (People Counting, Queue Managment) IVS

• IP67 and IK10

• Best for lowlight small applications where high resolu-

tion details are required

UltraSeries

• 1/1.8-in. STARVIS™ CMOS

• 6MP at 30 fps

• 1.3 mm Fixed Lens

• 0.005 lux Color

• Multiple Dewarping Modes

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264

• Digital Wide Dynamic Range

• Max IR Distance 10 m (33 ft)

• IVS: Motion, Tripwire, Intrusion, Scene Change, Abandoned/

Missing Object, Heat Map

• IP67 and IK10

• Best for lowlight small applications that require tight

intergration with numerous VMS platforms

ProSeries

• 1/2.7-in. CMOS

• 5MP at 30 fps

• 1.4 mm Fixed Lens

• Built-in Microphone

• Multiple Dewarping Modes

• Smart H.265+, H.265, Smart H.264+, H.264

• True Wide Dynamic Range (120 dB)

• Analytics+ (People Counting) IVS (Tripwire, Intrusion,

Abandoned/Missing Object, Heatmap)

• IP67

• Best for well lit small applications

N55CT5 DH-IPC-HDBW4231FN-E2-M DH-IPC-PFW8840N-A180

5MP 360° Panoramic Fisheye 2 x 2MP IR Dual-sensor Dome Camera 2MP IR 180° Panoramic Bullet

ProSeries

• 1/2.7-in. 5MP STARVIS™ CMOS

• 5MP at 30 fps

• 1.4 mm Fixed Lens

• Built-in Microphone

• Multiple Dewarping Modes

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264

• True Wide Dynamic Range (120 dB)

• Maximum IR Distance 10 m (33 ft)

• Analytics+ (People Counting) IVS (Tripwire, Intrusion,

Abandoned/Missing Object, Heat Map)

• Best for indoor lowlight small applications

ProSeries

• Two (2) Independent 1/2.8-in. STARVIS™ CMOS

• 2MP at 30 fps

• 2.8 mm Lenses

• Basic Starlight Technology 0.009 lux Color

• Dual-stream Encoding per Sensor

• H.265, H.264, MJPEG (Sub stream only)

• True Wide Dynamic Range (120 dB)

• Max IR Distance 20 m (66 ft)

• Intelligent Video System: Motion, Tripwire, Intrusion, Scene

Change, Abandoned/Missing Object, Facial Detection

• IP67 and IK10

• Best for Hallways and corridors

UltraSeries

• Four (4) 1/2.8-in. CMOS Sensors

• 4096 x 1800 at 30 fps

• 2.8 mm Lenses

• Starlight+ Technology

• Analytics+: (Vehicle Density, Crowd Density) IVS

(Tripwire, Intrusion) Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264, MJPEG

• Digital Wide Dynamic Range

• Max IR Distance 30 m (98 ft)

• IP67 and IK10

• Best for wide area surveillance

IP Panoramic Cameras

us.dahuasecurity.com Intelligent Solutions for a Safer World

DISPLAY NETWORK VIDEO RECORDERS

DHI-LM32-F200 DHI-NVR5216-16P-I 4TB N54B3P N54A4P

31.5-in. Full HD LED Monitor 16CH ePoE NVR 16CH 4K ePoE NVR 24CH 4K PoE NVR

• 31.5’’ Full HD 1920*1080 Resolution

LED Monitor

• • Plastic Housing

• • Input: VGAx1, HDMIx1

• • Output: Speakers x2

UltraSeries

• Analytics+ NVR, 320Mbps

• 160Mbps when Analytics+ function is

enabled, (16 channel IP Video Inputs)

• 16 Ports PoE, 8 ports ePoE

• 16CH IP cameras: 2CH @12MP, 4CH @

8MP and 16CH @ 2MP

• Includes perimeter protection, Analytics+

search and license plate recognition with

compatible LPR cameras

• 4TB included

ProSeries

• Smart H.265+, Smart H.264+ Decoding

• Maximum 320 Mbps Incoming

Bandwidth

• Up to 12MP Resolution Preview and

Playback

• 4 SATA III Ports, up to 10TB per port

• 16 PoE Ports (8 of which are ePoE Ports)

• 4CH@8MP, 16CH@1080P

• 120 W Total Rated PoE Power, 25.5 W

maximum per port

• IVS Recording on all IP Channels

ProSeries

• Smart H.265+, Smart H.264+ Decoding

• Maximum 320 Mbps Incoming

Bandwidth

• Up to 12MP Resolution Preview and

Playback

• Supports IPC UPnP

• 24 PoE/PoE+ Ports

• HDMI/VGA Simultaneous Video Output

• 220 W Total Rated PoE Power, 25.5 W

maximum per port

• 3D Intelligent Positioning (Dahua

cameras)

• IVS Recording on all IP Channels

SWITCHES MANAGEMENT SOFTWARE

DH-PFS3010-8ET-96 DH-PFS4218-16ET-240 SmartPSS DSS

8-port Fast Ethernet PoE Switch 16-port Managed Gigabit Switch Smart Professional Surveillance System Digital Surveillance Management Center

• Layer 2 Commercial Switch

• Long-distance PoE (LD PoE) Transmits

Power and Data 250 m (820 ft)

• Conforms to IEEE802.3, IEEE802.3u and

IEEE802.3X

• Conforms to IEEE802.3af and

EEE803.3at

• Two (2) 10/100/1000 Mbps Uplink Ports

• Supports Hi-PoE (60 W)

• MAC Auto-learning and Aging; 16K MAC

Address Capacity

• MDI/MDIX Self-adaptation

• Metal Enclosure

• Layer 2 Managed PoE Switch

• Supports the IEEE802.3af, IEEE802.3at,

and Hi-PoE Standards

• Two (2) 1000 Base-X (Combo Port)

• Two (2) 10/100/1000 Base-T (Combo

Port)

• 240 W PoE Budget

• 250 m (820 ft ) PoE Transmission

• PoE Management, PoE Setting, Event

Statistics, Green PoE

• Supports Hi-PoE (60 W)

• High Lightning Protection Design

• Non-blocking Video Transmission

• Efficient Device Management

• Manage up to 64 Devices over a

Maximum of 256 Channels

• Supports H.265 and H.264 Dual Video

Compression Codecs

• Live Video Monitoring and Playback

• Configure Video Wall Layout and

Scheme

• Configure NVR Recording

• PTZ Camera Control

• Intelligent Video System (IVS) with

People Counting and Heat Map

• Complete Organization, Device, and

Event Centralized Management

• Manages up to 20,000 channels with

DSS Pro.

• Supports H.265 and H.264 Dual Video

Compression Codecs

• Support for Video Wall Configuration and

Display

• Live Video Monitoring and Playback

• PTZ Camera Control and Smart Track

• Intelligent Video System (IVS) with

Business Analysis

MOBILE APPLICATION STORAGE

DMSS DHI-TF-P100/128GB DHI-TF-P100/256G STx000VX000X

128 GB Micro SD Card 256 GB Micro SD Card Skyhawk Series Hard Drives

• IOS and Android

• Relay Out Functionality

• MJPEG Video Decoding

• Multi-language Interface (Chinese,

Dutch, English, French, German, Italian,

Portuguese, Russian, and Spanish)

• SD Card Slot up to 128 GB

• Cost-effective TLC Storage Medium

• High-transmission Speed of up to 100

MB/s

• Write speed is up to 60 MB/s

• Waterproof, Shockproof, and X-ray Proof

• High and Low Temperature Resistance

• SD Card Slot up to 256 GB

• Cost-effective TLC Storage Medium

• High-transmission Speed of up to 100

MB/s

• Write speed is up to 880 MB/s

• Waterproof, Shockproof, and X-ray Proof

• High and Low Temperature Resistance

• Designed for 24/7 Surveillance-optimized

Applications

• Firmware Optimized for Continuous

Recording; 90% Write and 10% Read

• Engineered for Workloads up to 180 TB/

year

• Capacity Up to 10 TB, Supports 64

Cameras per Drive

• Low Power Consumption and Startup

Current

• Tarnish-resistant Components to

Minimize Environmental Effects

IP Recorders & Accessories

Produktspecifikationer

Varumärke:	Dahua Technology
Kategori:	övervakningskamera
Modell:	DH-IPC-PDBW82041N-B360

Behöver du hjälp?

Om du behöver hjälp med Dahua Technology DH-IPC-PDBW82041N-B360 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

övervakningskamera Dahua Technology Manualer

Dahua Technology Ultra IPC-HFW7442H-Z4 Bruksanvisning

21 Oktober 2024

Dahua Technology IPC-HFW7842H-Z Bruksanvisning

19 Oktober 2024

Dahua Technology Ultra IPC-HF7842F Bruksanvisning

8 Oktober 2024

Dahua Technology SD6C230I-HC Bruksanvisning

7 Oktober 2024

Dahua Technology Lite IPC-HDW1320S Bruksanvisning

4 Oktober 2024

Dahua Technology Ultra IPC-HF7442F-FR Bruksanvisning

4 Oktober 2024

Dahua Technology N83BU82 Bruksanvisning

23 September 2024

Dahua Technology N45EFN2 Bruksanvisning

23 September 2024

Dahua Technology N45EJN2 Bruksanvisning

23 September 2024

Dahua Technology SD49225T-HN-W Bruksanvisning

23 September 2024

övervakningskamera Manualer

Nyaste övervakningskamera Manualer

Speco Technologies WDRB11H Bruksanvisning

27 Oktober 2024

Vivotek AI-108 Bruksanvisning

27 Oktober 2024

Acti E88 Bruksanvisning

27 Oktober 2024

Yale WIPC-303W Bruksanvisning

27 Oktober 2024

Grandstream GXV3611IR_HD Bruksanvisning

27 Oktober 2024

Airlive DM-720 Bruksanvisning

27 Oktober 2024

Speco Technologies O8B7M Bruksanvisning

27 Oktober 2024

Grandstream GXV3615W Bruksanvisning

27 Oktober 2024

Vivotek IP8133 Bruksanvisning

27 Oktober 2024

Olympia OC 1280P Bruksanvisning

27 Oktober 2024
