INSTALLATION MANUAL
BYCQ140E2P
BYCQ140E2PB
Designer Decoration panel
1
9
10
2
8
7
3 4
6
5
4 43 55
1
1
2
2
1
2 3
4
5
6
12
4
4
4
4
4
4+6 1
1
2
3
5
2
2
2
22
2
a
a
a
aa
b
b
b
bb
g
b
3
3
3
33
3
a
a
a
aa
a
b
b
b
bb
b
f
d
gg
1
h
6
≤
≤
≤
≤≤
5~8 mm
2 1
3
6 5
4
1
12 6
4×
8× 12
4×
2×
c
e
BYCQ140E2P + BYCQ140E2PB
Designer Decoration panel
4P561932-1 2018.12
Installation manual
1
The English text is the original instruction. Other languages are
translations of the original instructions.
Before installation
Leave the unit inside its packaging until you reach the
installation site.
Refer to the installation manual of the indoor unit for items not
described in this manual.
Accessories
Preparation before installation
For this unit, you are able to select air flow directions. To discharge
air in 2 or 3 directions, it is necessary to purchase the optional
blocking pad kit for sealing air discharge outlets.
Handling of the decoration panel
To prevent any damage to the decoration panel, take care of the
following:
- Never place the panel facing down.
- Never let the panel lean against a wall.
- Never put it down on a projecting object.
- Never touch or put pressure on the swing flap in order to
prevent malfunction of the swing flap.
- Be careful not to damage the 4 tabs at
the back of the corner decoration cover.
Preparing the decoration panel for installation
1Remove the suction grille from the decoration panel.
Unlock the suction grille knobs by pushing them inward (5).
Open the suction grille (2) while pushing the sliders (6)
inward. (See figure 1)
See figure 2. Remove the hooks (2) to detach the suction
grille from the decoration panel.
Remove all the transporting tapes and 2 brackets for
temporary installation attached on the suction grille.
Attach the brackets for temporary installation on locations (1)
if needed. (See figure 2)
2Remove the corner decoration cover on each corner by pulling it
up in the direction of the arrow. (See figure 3)
Installation of the decoration panel to the
indoor unit
Refer to the installation manual of the indoor unit for details on
installing the indoor unit.
1Install the decoration panel (See figure 5)
BYCQ140E2P
BYCQ140E2PB Designer Decoration panel Installation manual
Read this manual attentively before installation. Do
not throw it away. Keep it in your files for future
reference.
Improper installation or attachment of equipment or
accessories could result in electric shock, short-
circuit, leaks, fire or other damage to the equipment.
Be sure only to use accessories made by Daikin
which are specifically designed for the use with the
equipment and have them installed by a professional.
If unsure of installation procedures or use, always
contact your dealer for advice and information.
NOTE To the installer
Be sure to instruct the customer how to properly
operate the system showing him or her the
operation manual of the indoor unit.
1× 1×4× 4× 4×
1Decoration panel
2Suction grille
3Corner decoration cover
4Swing flaps
5Knobs
6Sliders
aMounting bracket
bHook
cPiping section
d"Piping side" marking
eDrain section
f"Drain side" marking
gTemporary latch
hSwing flap motor lead wire
1Hold the decoration panel against the indoor unit by matching the
piping side and drain side marks on the decoration panel with the
position of the piping section and drain section of the indoor unit.
2Temporarily install the decoration panel to the indoor unit by hanging
the temporary latch into the hooks of the indoor unit body. (2
locations)
3Hook the 4 mounting brackets on the corner sections of the
decoration panel onto the hooks around the indoor unit body.
Make sure that the swing flap motor lead wire is not caught between
the indoor unit and the decoration panel.
4Screw all 4 hexagon head screws located in the corner section in for
approximately 5 mm. The panel will rise.
5Adjust the decoration panel by turning it in the direction indicated by
the arrows on the figure so that the ceiling opening is completely
covered.
6See figure 6 (cross section of the air outlet) and tighten the hexagon
head screws until the thickness of the sealing material between the
decoration panel and the indoor unit reduces to 12 mm or less.
1Indoor unit
2Ceiling
3Sealing material
4Decoration panel
5Swing flap
6Air outlet
