Operation manual
Wall-mounted condensing boiler English
Operation manual
Wall-mounted condensing boiler
D2CNL024A1AA
Table of contents
Operation manual
2
D2CNL024A1AA
Wall-mounted condensing boiler
3P469438-12N – 2020.07
Table of contents
1 Introduction 2
1.1 About the unit ............................................................................ 2
1.2 About the documentation .......................................................... 2
1.2.1 Meaning of warnings and symbols.............................. 2
2 Safety instructions 2
2.1 Installation ................................................................................. 2
2.2 Smell of gas............................................................................... 3
2.3 Modifications on the unit............................................................ 3
2.4 For the user ............................................................................... 3
3 Operation 3
3.1 User interface ............................................................................ 3
3.1.1 Buttons........................................................................ 3
3.1.2 LCD screen ................................................................. 4
3.2 Operating the unit...................................................................... 4
3.2.1 To switch the unit ON.................................................. 4
3.2.2 About the low water temperature function .................. 4
3.3 Basic usage............................................................................... 4
3.3.1 About the home screen............................................... 4
3.3.2 To select the operation mode ..................................... 4
3.3.3 Possible operation modes........................................... 4
3.3.4 Changing temperature setpoints................................. 5
3.3.5 Possible central heating operation modes.................. 6
3.3.6 About the central heating ECO mode ......................... 6
3.3.7 About the domestic hot water operation ..................... 6
3.3.8 About the domestic hot water comfort mode .............. 6
3.3.9 About the boiler frost protection.................................. 6
3.4 Error handling............................................................................ 6
3.5 Menu functions .......................................................................... 7
3.5.1 To use menu level 1.................................................... 7
3.5.2 Info menu .................................................................... 7
3.5.3 User settings menu ..................................................... 7
3.5.4 Installer settings menu ................................................ 8
4 Maintenance and cleaning 8
4.1 To clean the outer surface of the unit........................................ 8
5 Energy saving tips 8
6 Contact 8
7 Error codes 8
1 Introduction
1.1 About the unit
This Daikin unit is a wall-mounted gas-fired condensing boiler that
can supply heat to central heating systems, as well as supply
domestic hot water. Depending on settings, it is possible to use the
unit solely for hot water or solely for central heating. Hot water
supply type can be or by means of a hot waterinstantaneous
storage tank Heating only. boilers do not supply domestic hot
water. The type of the boiler can be recognized from the model
name written on the identification label. See table below:
Model Type Domestic hot water
supply
Filling loop
D2CNL024A1AA D2CNL024 Instantaneous Internal
A control unit, which contains a user interface, controls the ignition,
safety systems, and other actuators. User interaction is provided via
that user interface, which is composed of an LCD screen and
buttons which is located on the front cover of the unit.
1.2 About the documentation
The instructions contained in this document are intended to guide
you through the operation of the unit. Damage caused by non-
observance of these instructions are not under the responsibility of
Daikin.
▪ The original documentation is written in English. All other
languages are translations.
▪ The precautions described in this document are written for users
and cover very important topics, follow them carefully.
▪ Please read the instructions in the manual carefully, for your
safety and health.
▪ Please keep this manual for future reference throughout the unit's
period of use.
▪ Request the installer to inform you about the settings that he
made to configure your system.
1.2.1 Meaning of warnings and symbols
DANGER
Indicates a situation that results in death or serious injury.
WARNING
Indicates a situation that could result in death or serious
injury.
CAUTION
Indicates a situation that could result in minor or moderate
injury.
NOTICE
Indicates a situation that could result in equipment or
property damage.
INFORMATION
Indicates useful tips or additional information.
2 Safety instructions
Always observe the following safety instructions and regulations.
2.1 Installation
WARNING
Installation, service, maintenance and repair of the boiler
can only be carried out by suitably qualified competent
persons, in accordance with the applicable legislation,
regulations, rules and guidelines.
WARNING
The unit may only be operated with its casing properly
mounted. Otherwise, in unfavourable conditions, material
damage or even injury or death can result.
CAUTION
A discharge pipe must be connected to the condensate
trap in order to prevent contact with the condensate.
In case your skin comes into contact with condensate, the contact
location should be washed with plenty of water. Condensate liquid
may NEVER be used for purposes of cleaning, watering plants, or
drinking.
3 Operation
Operation manual
3
D2CNL024A1AA
Wall-mounted condensing boiler
3P469438-12N – 2020.07
2.2 Smell of gas
DANGER
This is a gas unit. Gas leaks might lead to poisoning and
explosions.
If you smell gas:
▪ Do not use any electrical switches, including light switches.
▪ Do not use telephones in the affected area.
▪ Do not use naked flames, such as matches or lighters.
▪ Do not smoke.
▪ Turn off the main gas supply.
▪ Open windows and doors.
▪ Warn other people in the building.
▪ Get out of the building.
▪ Inform your gas supplier, service agent or other competent
person.
2.3 Modifications on the unit
DANGER
Malfunctions can lead to poisoning and explosions. Never
put the safety devices out of operation, nor tamper with
them so as to impair their function.
CAUTION
An inappropriate modification may cause damage. Never
tamper with the boiler or other parts of the system. Never
attempt to perform maintenance or repair yourself. Call a
qualified service agent.
CAUTION
Do not use sprays, solvents, chlorinated cleaning agents,
paint, and adhesives in the vicinity of the unit. These
substances can cause corrosion, even in the flue system.
DANGER
Do not damage or remove any seals on components. Only
qualified persons are allowed to alter sealed components.
Do not make any modifications on:
▪ Boiler
▪ Gas, water or power supply
▪ Flue system
2.4 For the user
CAUTION
Any misuse is forbidden. The manufacturer is not
responsible for any malfunctions and/or damage that may
occur due to misuse.
▪ Your unit is intended as a heater for central heating systems and
for domestic hot water generation. Any other use is considered as
"misuse".
▪ If you are not sure how to operate the unit, contact your service
agent.
▪ This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall
NOT play with the appliance. Cleaning and user maintenance
shall NOT be made by children without supervision.
CAUTION
Do NOT rinse the unit. This may cause electrical shock or
fire.
NOTICE
▪ Do not place any objects or equipment on top of the
unit.
▪ Do not sit, climb or stand on the unit.
WARNING
If the supply cord is damaged, it MUST be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
3 Operation
3.1 User interface
a
g
b
c d
e
f
aCH+
bCH-
cMode / Enter / Reset
dMenu / Back
eDHW-
fDHW+
gLCD Screen
3.1.1 Buttons
The 6 buttons on the user interface have various functions according
to different situations, which are stated in the table below:
Button/Dial Function Description
Mode /
Enter /
Reset
Mode Change mode between summer,
winter, central heating only and
standby.
Reset Reset the lockout error.
Enter Passing on to the next level in the
menu structure.
Confirm Confirmation of changes.
Menu / Back Menu Enter the menu function.
Back Go back to the parent menu.
Cancel Cancel changes.
