Sida 1/20
A AB-19 800.1D
2
1. Introduction
2. Safety instructions
3. Typical installation sequence
4. Connection methods
5. Wiring diagrams
6. Selection of the diameter of power cables and speaker cables
7. Specifications
8. Possible faults and their solutions
9. Box contents
10. Warranty and maintenance info
11. Information on disposal of the electrical and electronic equipment (for the European countries with
separate waste collection)
C O N T E N T S EN
3
Thank you for purchasing this Deaf Bonce product! Deaf Bonce is committed to the creation of extremely high-profile
systems with no loss of quality.
To ensure proper use, please carefully read through this manual before using this product. It is especially important that you
read and observe CAUTION’s in this manual. Please keep the manual in a safe and accessible place for future reference.
1 . I N T R O D U C T I O N EN
2 . SA F E T Y I N S T R U C T I O N S
3 . T Y P I C A L I N S TA L L AT I O N S E Q U E N C E
1. Before installing the amplifier disconnect the battery from the electrical system.
2. To connect the amplifier it is necessary to stretch the power cable from the location of the battery to the place of installation
of the amplifier. Select the power cable with the appropriate regulations in AWG (see Table: Power cable)
3. Connect the power supply with the correct polarity. Connect all (+) terminals of the amplifier to the cable from the positive
terminal of the battery and the (-) terminals of the amplifier – to the cables running from the negative terminal of the battery.
4. Place the fuse holder for each positive cable within 40 cm from the positive terminal of the battery and connect one end of
the power cable to the holder after connecting the other end to the amplifier. Do not install the fuse.
5. Route all signal cables next to each other and separately from the power cables.
6. Connect the wires of RCA input. The input signal power must be between 0.5 VRMS and 8 VRMS.
7.To connect the power wire supply is necessary to use special power cables.
8. Fasten the amplifier properly when installing it in the vehicle. If the component is disconnected during driving, it may cause
serious damage to the passengers of the car or another vehicle. It is not recommended to screw the amplifier directly to the metal
it can lead to distorsions at the signal outputs.
9. After installation is complete, check the wiring of the system and make sure that all connections have been made correctly.
Before installing the fuses, disconnect the positive lead from the battery and then install the fuse in the fuse holder. Using the light
bulb 12 V 21 W, connect the positive lead to one contact of the bulb and the other contact of the bulb to the positive terminal of
the battery.
When properly connected, the bulb must briefly light up and go out. Now you may connect the positive lead to the (+)
battery. If the light does not go out, then something is wrong. This will prevent damage to the amplifier in case of reverse polarity
and unwanted sparks when connecting. Install the rest of the fuses.
10. To activate the amplifier, it is necessary to apply the positive potential of 12 volts to the control input of the amplifier
(REMOTE IN) through a switch or a corresponding control output (REMOTE OUT) with the head unit (HU).
11. LED indicator on the front panel lights up in , indicating that the device is turned on. LED indicator lights up in red
blue
when the outputs are overloaded, if the temperature protection is activated, if there is a short circuit in the system cables to the
heatsink and if the amplifier is faulty.
12. The sound level is calibrated by adjusting the volume of the source up to 3/4 of its maximum level. Then, adjust the
sensitivity level of the amplifier up until you hear distortions.
