Sida 1/12
2-WAY COMPONENT SYSTEM
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
https://alphard.audio
MFC-615
2-Х КОМПОНЕНТНАЯ АКУСТИЧЕСКАЯ СИСТЕМА
2
C O N T E N T S EN
1. Introduction
2. Safety instructions
3. Filtering, recommended amplifier settings
4. Connection methods
5. Dimensions
6. Installation
7. Specifications
8. Box contents
9. Warranty and maintenance info
10. Information on disposal of the electrical and electronic equipment
(for the European countries with separate waste collection)
1 . I N T R O D U C T I O N
1. Fasten the speakers properly when installing it in the vehicle. If the component is disconnected during driving, it may cause
serious damage to the passengers of the vehicle or another vehicle.
2. Before installing the components, if possible store the product in it’s original package to avoid accidental damage to the
product.
3. Be careful when installing and dismantling the speaker! Do not let the speaker drop to avoid damage of its moving parts.
4. When working with tools follow safety rules.
5. Before the installation switch off the head unit and all other audio devices to avoid their damage.
6. Make sure that the location of the speaker does not hinder the proper operation of mechanical and electrical devices of the
vehicle.
7. Do not install components in places exposed to water, excessive humidity, high or low temperature, dust or dirt.
ATTENTION!!! The product may be operated at +5 °C (41F) to +40 °C (104F). In case of moisture condensation, let the product to
dry.
8. When performing plumbing, drilling or cutting works with the car, make sure that there is no wiring, brake lines, fuel pipe or
other structural elements under the place of work. Follow the safety rules! Use protective glasses and gloves.
9. When stretching back the speaker cables make sure that they are not in contact with sharp edges or moving mechanical
devices. Make sure that they are firmly fixed and protected over the entire length.
10. The diameter of the speaker cables must be selected in accordance with the length and applied power.
11. Never stretch the cables outside of the car and near the moving parts of the car. This can lead to destruction of the
insulating layer, short circuit and fire.
12. To protect the cables use rubber gaskets if the wire passes through a hole in the plate, or other similar materials if it lies
close to the parts exposed to heat.
CAUTION!!! High sound pressure can damage your health!
Please use the common sense when controlling volume!
2 . S A F E T Y I N S T R U C T I O N S
3
EN
Thank you for purchasing of this Deaf Bonce product! Our company is committed to the creation of extremely loud sound
systems with no loss of quality.
To ensure proper use, please carefully read through this manual before using this product. It is especially important that you
read and observe caution’s in this manual. Please keep the manual in a safe and accessible place for future reference.
The correct choice of amplifier, its settings, filtering and enclosure largely influence on the lifespan of your audio system. You
should select an amplifier with a nominal power, not exceeding the nominal power of the speakers. Proper coordination of the
head unit (HU) the amplifier will allow to get a clean, undistorted signal applied to the component to prevent overheating with
and voice coil damage. Recommended settings of the amplifier and HU: Volume of HU should not exceed 80%. The amplifier
sensitivity should be set to 50%.
The recommended filter settings:
The high pass filter HPF (the filter that cuts all frequencies below those set for the filter) should be set to 60-80 Hz
( dB/Oct)12 for mid-bass speaker and should be set to 6-8 k Hz ( dB/Oct)12 for tweeter.
Recommended amplifiers: AAB-1200.2D AAB-1 00.2D, 8 , AAP-500.2D, AAP-800.2D, AAP-400.4D.
3 . F I L T E R I N G , R E C O M M E N D E D A M P L I F I E R S E T T I N G S
MFC-615 mid-bass) 60-: HPF ( - 80 Hz (12 dB/Oct)
tweeter) 6-8 HPF ( - kHz (12 dB/Oct)
