Notice:

1 Instructions

Please read the user handbook carefully and then keep it in a safe place for future

consultation and maintenance.

1.1 Important Notice

(1) This product is not a toy, it's a piece of complicated equipment which integrated with

professional knowledge by mechanic, electric, air mechanics high-frequency ,

transmitter and so on, so it should be installed correctly and adjusted to avoid any

accidents. The owner must always operate in a safe manner, if improper operation

that caused human injured or property damage, then we DENVER ELECTRONICS

A/S accept no liability for any safety duties from operation. As we have no control over

the way they maintained, used and operated.

(2) This product is not suitable for users under 14 years of age.

(3) The use of the drone may be prohibited in some areas like train stations, airports,

aircrafts, inhabited areas etc. You should check with the authorities whether the use of

the drone is permitted in some public or private areas. Always use the drone bearing

in mind not to breach people's privacy. We exclude liability for any wrong use of the

drone.

(4) We DENVER accept no liability for any safety duties or nes arising from operation,

usage or mis-control after the sale of products. Warranty does not cover if drone

crashes and get damaged.

1.2 Safety Precautions

Keep away from crowd when ying, since drone ight is a high risk hobby. Mis-assemblied

or broken main frame or defective electronic equipment or unskilled operation may cause

accidents of machine damaged or injured. Please pay special attention to safety operation.

(1) Keep away from people and obstacles

"The ying speed and status of the drone is uncertain, so it may cause potential danger."

When choosing a ying site should stay clear of buildings, trees and power lines. AVOID

ying in or near crowded areas. Meanwhile avoid ying in rain, storms, thunder and

lightening to protect machinery and parts out of damage.

(2) Keep away from humid environments

Inside of drone is made up of precise electronic components. Stay away from humidity or

water vapor to protect machinery and parts.

(3) Safety operation

Please y your drone according to your physical status and ight skill. Fatigue, listlessness

and mis-operation will increase possibilities of accidental hazard.

(4) Keep away from rotating blades

Keep your face and body as well as all spectators away from the rotating blades. The

spinning blades of a model of this type can cause serious injury.

(5) We recommend flying the drone below 10 meters of height.

(6) Keep away from heat

A drone is made up of metal, ber, plastic, electronic components, etc. So keep it away from

heat and sunshine to avoid distortion, and damage.

1.3 Check List Before First Flight

(1) Flying eld should be in an open space and we suggest at least 5M length *5M wide

*3M height.

English

(2) Make sure the receiver and transmitter is fully charged.

(3) Please strictly obey the order of tum-on, turn-off before operation. When starting your

ight. rst turn on the transmitter, and connect power cable of drone last; When

nishing your ight, please disconnect the power cable of your drone rst tum off ,

transmitter last. An upset in the order of connection may cause your drone loose

control to threaten yourself and others safely. Please follow a correct habit of tum-on

and tum-off.

(4) Make sure the connection is solid between battery or motor. The ongoing vibration may

cause bad connection of power terminal and make the drone uncontrollable.

Name for parts:

1. DRONE

2. Transmitter

Body Cover Black blade

Came Black blade ra

Orange blade Red LED

Orange blade Blue LED

Transmitter battery installation

Open the battery compartment cover of transmitter, install the battery into box according to

electrode instructions (Batteries not included).

Battery cover

4X AA 1.5V batteries (NOT INCL.)

Notice:

1. When install the battery, you must insert the batteries correct according the diagram

2. Please don't mix new and old battery together.

3. Please don't use dierent kinds of batteries.

Charger notice:

1. Connect 1 or 2 batteries (only one battery incl.) connect USB to computer.

Antenna

Speed Button

Flip Button

Left Stick(Up/Down and Turn Left/Righ t)

Take Photo

Take Video

Power Switch

Right Stick(Forward/Backward and Left/Right de Flying) Si

Left/ Right Side Trimmer

Forward/Backward Trimmer
