Sida 1/12
CAS1000
The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC)
EN55014, EN60555-2 and EN60555-3 These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
08/52886/0 Issue 2
CAS500
Dimplex CAS500, CAS1000
Important Safety Advice
Introduction
Please read this information guide carefully to be able to safely install, use and maintain your product.
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fi re, electrical shock and injury to persons, including the following:
If the appliance is damaged, check with the supplier before installation and operation.
Do not use outdoors.
Do not use in the immediate surroundings of a bath, shower or swimming pool.
Do not locate the appliance immediately below a fi xed socket outlet or connection box.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children with out supervision.
Children of less than 3 years should be kept away unless continuously supervised.
Children aged from 3 years and less than 8 years shall only switch on/o the appliance provided
that it has been placed or installed in its intended normal operating position and they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children aged from 3 years and less than 8 years shall not plug in,
regulate and clean the appliance or perform user maintenance.
CAUTION: Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
Do not use this appliance in series with a thermal control, a program controller, a timer or any
other device that switches on the heat automatically, since a fi re risk exists when the heater is
accidentally covered or displaced.
Ensure that furniture, curtains or other combustible material are positioned no closer than 1
meter from the appliance.
In the event of a fault unplug the appliance.
Unplug the appliance when not required for long periods.
Although this appliance complies with safety standards, we do not recommend its use on deep
pile carpets or on long hair type of rugs.
The appliance must be positioned so that the plug is accessible.
If the supply cord is damaged it must be replaced by the manufacturer or service agent or a
similarly qualifi ed person in order to avoid a hazard.
Keep the supply cord away from the front of the appliance.
WARNING: In order to avoid overheating, do not cover the appliance. Do not place material or
garments on the appliance, or obstruct the air circulation around the appliance.
The appliance carries a DO NOT COVER warning symbol.
This appliance is not equipped with a device to control the room temperature. Do not use this
appliance in small rooms when they are occupied by persons not capable of leaving the room
on their own, unless constant supervision is provided.
General Information
Only use fi ltered water in this appliance.
Unpack the appliance carefully and retain the packaging for possible future use, in the event of moving or returning the
fi re to your supplier.
Always ensure that the appliance is sitting on a level surface.
The appliance is a fl ame eect only.
The appliance is designed to be built into a surround or built into a wall.
Before connecting the appliance, check that the supply voltage is the same as that stated on the appliance.
Please note: Used in an environment where background noise is very low, it may be possible to hear a sound which is
related to the operation of the fl ame eect. This is normal and should not be a cause for concern.
Once installed, never move this appliance or lay on its back, without draining the water from sump and water tank.
The water tank, sump, sump lid, tank cap and air fi lters must be cleaned once every 2 weeks, particularly in hard water
areas.
If you intend not using the appliance for longer than 2 weeks, drain the water from sump and water tank and dry the
sump.
The sump and the water tank in this product are treated with a biocidal product, Silver Biocide. This conforms with the
latest relevant ISO standard
Do not drink the water from the sump or from the water tank(s)
This appliance is intended to be permanently connected to the water mains and not connected by a hose-set
Installation Instructions
This section describes how to set up your fi re.
BEFORE YOU START
1. Ensure that all packing items are removed (read any warning labels carefully) and retain all packing for possible
future use.
2. Before connecting the appliance, check that the supply voltage is the same as that stated on the appliance.
3. Ensure that the appliance is sitting on a level surface
4. Lift o the metal top plate to gain access to the appliance. Keep the top plate with the packing for possible future
use. (Fig.2)
Installation Guide
This product can be built into a wall, surround or structure. Please take note of the product dimensions in Fig.1 and
build your wall, surround or structure accordingly. You are required to leave a minimum of 400mm from the base of the
fuelbed to any shelf/enclosure above the product. This will allow enough space above the product to allow the fl ames to
form fully and not to be obstructed.
This product needs free ventilation from underneath to operate correctly. The free ventilation helps keep the electronic
components cool, allow the mist to evacuate the sump and lift out of the product eortlessly.
THE AREA OF FREE VENTILATION THE CAS500 REQUIRES IS A MINIMUM OF 210CM 2.
THE AREA OF FREE VENTILATION THE CAS1000 REQUIRES IS A MINIMUM OF 420CM 2.
Surround Design
The CAS500 and CAS1000 are designed to be built into a surround/wall. Using the dimensions provided in Fig1. you
can design a cavity for the appliance. Be sure to allow room under and around the appliance for the water connection
and the electrical connection. Once the surround/wall is prepared you can put the appliance in place. Fit the LED Log
Fuelbed so you ensure that the appliance is centered, see section ‘Assembling the LED Log Fuelbed’. When you have
settled on a position, lift o the Fuelbed and using appropriate screws for the surround/wall, screw through the formed
holes in the left and right side panels securing the appliance in place.
Water Supply
The appliance can operate by using the water tank(s) provided or by connecting up mains water.
Water Tank(s): You will need to remove the ‘Fill Cap’ from the sump. (Fig.3a and Fig.3b). Place the Water Tank(s)
(Fig.3C) in your sink and remove the cap (turn anti-clockwise). Fill the Water Tank with fi ltered tap water only. This is
necessary to prolong the life of the fl ame and smoke producing unit. The water should be fi ltered through a conventional
domestic water fi lter unit and the fi lter should be replaced regularly. Distilled water must be used.not
Mains Water: If you choose to supply mains water to the appliance store the bottle(s) with the metal top plate and
packaging. You can use the Piercing Valve (supplied) to connect into your mains water supply by;
1. Clamp the Piercing Valve onto you water pipe: maximum 1/2” (12.7mm) pipe
2. Connect a 1/4” (6.35mm) PVC tube (not supplied) from the piercing valve into the water fi lter supplied and then in
to the product (Fig.4).
3. Turn the tap on the valve clockwise to pierce into the water pipe. Turn the tap anti-clockwise to allow the water to
fl ow through the valve. You can shut o the water to the product by turning the tap on the valve clockwise until the
fl ow stops.
