Model:

DCSS09 (2.5kW Cooling / 2.6kW Heating)

DCSS12 (3.2kW Cooling / 3.2kW Heating)

DCSS18 (5.0kW Cooling / 5.2kW Heating)

DCSS24 (7.0kW Cooling / 7.5kW Heating)

DCSS28 (7.8kW Cooling / 8.0kW Heating)

CONTENTS

SAFETY PRECAUTIONS

NAMES OF PARTS

INDOOR UNIT DISPLAY

OPERATING INSTRUCTIONS

PROTECTION

INSTALLATION MANUAL

MAINTENANCE

TROUBLESHOOTING

EMERGENCY FUNCTION & AUTO-RESTART FUNCTION

REMOTE CONTROLLER

....................................................................................................1

.................................................................................................................4

.........................................................................................................5

..............................................6

........................................................................................................7

.............................................................................................10

.........................................................................................................................15

....................................................................................................16

....................................................................................................................25

..........................................................................................................26

During the installation of the indoor and outd-

oor units the access to the working area should

be forbidden to children.

Unforeseeable accidents could happen.

Make sure that the base of the outdoor unit is

firmly fixed.

Check that air cannot enter the refrigerant sys-

tem and check for refrigerant leaks when mo-

ving the air conditioner.

SAFETY RULES AND RECOMMENDATIONS FOR THE INSTALLER

Carry out a test cycle after installing the air co-

nditioner and record the operating data.

The ratings of the fuse installed in the built in-

control unit are T 5A / 250V .

The user must protect the indoor unit with a

fuse of suitable capacity for the maximum in-

put current or with another overload protection

device.

Check that the socket is suitable for the plug ,

otherwise have the socket changed.

Do not install the appliance at a distance of

less than 50 cm from inflammable substances

(alcohol, etc.) Or from pressurised containers

(e.g. spray cans).

If the appliance is used in areas without the

possibility of ventilation, precautions must be

taken to prevent any leaks of refrigerant gas

from remaining in the environment and creat-

ing a danger of fire

Read this guide before installing and using the

appliance.

The appliance must be fitted with means for

disconnection from the supply mains having

a contact separation in all poles that provide

full disconnection under overvoltage

category III conditions, and these means

must be incorporated in the fixed wiring in

accordance with the wiring rules.

This appliance can be used by children a-

ged from 8 years and above and persons

with reduced physical, sensory or mental

capabilities or lack of experience and kn-

owledge if they have been given supervis-

ion or instruction concerning use of the a-

ppliance in a safe way and understand the

hazards involved. Children shall not play

with the appliance. Cleaning and user ma-

intenance shall not be made by children

without supervision.

The air conditioner must be installed by

professional or qualified persons.
