Installation and Operating Instructions

The product complies with the European Safety Standards EN60335:2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014:1,

EN55014:2, EN61000:3-2 and EN61000:3-3 which cover the essential requirements of EMC Directive 2014/30/EU and the LVD Directive 2014/35/EU.

08/53249/0 Issue 2

DDF250

As with all portable heang appliances: This product is suitable only for well insulated spaces or occasional use.

Dimensions

(millimetres)

Specication

DDF250 250W, Thermostat, Neon & USB Charge Port

H W D

164 120 126

Fig. 1

IMPORTANT : THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

IMPORTANT SAFETY ADVICE

DO NOT use the heater in the immediate

surroundings of a bath, a shower or a swimming

pool.

The heater must not be located immediately below

a socket-outlet.

DO NOT COVER or obstruct the air inlet and

outlet openings in any way.

WARNING: In order to avoid overheating, do not

cover the heater.

IMPORTANT: If the supply cord is damaged, it

must be replaced by the manufacture or its service

agent or a similarity qualied person in order to

avoid a hazard.

WARNING: In order to avoid a hazard due to

inadvertent resetting of the thermal cut-out,

this appliance must not be supplied through an

external switching device, such as a timer, or

connected to a circuit that is regularly switched

on and off by the utility.

This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of

experience or knowledge if they have been given

supervision or instruction concerning the use of

the appliance in a safe way and understand the

hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall

not be made by children without supervision.

Children of less than 3 years should be kept away

unless continuously supervised.

Children aged from 3 years and less than 8 years

shall only switch on/off the appliance provided

that it has been placed or installed in its intended

normal operating position and they have been

given supervision or instruction concerning the

use of the appliance in a safe way and understand

the hazards involved. Children aged from 3

years and less than 8 years shall not plug in,

regulate and clean the appliance or perform user

maintenance.

CAUTION: Some parts of this product can

become very hot and cause burns. Particular

attention has to be given where children and

vulnerable people are present.

DO NOT operate the heater with the mains lead

overhanging the front outlet grille.

DO NOT use the heater on deep pile carpets or

the long hair type of rugs, or less than 750mm

(30”) away from any overhanging surface. Keep

combustible materials such as drapes and other

furnishings clear from the front, sides and rear of

the heater. Do not use heater to dry your laundry.

IMPORTANT: The socket-outlet must be

accessible at all times to enable the mains plug

to be disconnected as quickly as possible.

IMPORTANT: The instruction leaet belongs to

the appliance and must be kept in a safe place. If

changing owners, the leaet must be surrendered

to the new owner.

IMPORTANT: The heater must be on a at stable

surface when in use.

WARNING: To avoid danger of suffocation please

remove all packaging materials particularly plastic

and EPS and keep these away from vulnerable

people,children and babies.

WARNING: To avoid the risk of accidental

strangulation from the supply cord all children and

vulnerable people must be supervised when in the

vicinity of the product whether it is working or not.

Electrical connection

This heater must be used on an supply only and A.C.~

the voltage marked on the heater must correspond to the

supply voltage. This heater is tted with a plug incorporating

a 13-amp fuse. When replacing the fuse, a 13-amp fuse

approved by ASTA to BS 1362 must be used.

If the plug is not suitable for the socket outlets in your home,

the plug must be cut off and an appropriate one tted. A

plug cut off from a mains lead will give a shock hazard if

inserted into a 13-amp socket elsewhere in the house. To

avoid this, it should be disposed of immediately.

Ceramic Fan Heater

Model: DDF250

NOTE: The fuse cover of a non-rewirable plug must be

retted when changing the fuse. Should the cover become

lost, the plug must not be used until the correct replacement

fuse cover is obtained from your supplier or by contacting

our customer helpline.

IMPORTANT: The wires in this mains lead are coloured in

accordance with the following code:

BLUE: NEUTRAL

BROWN: LIVE

As the colours of the wires in the mains lead may not

correspond with the coloured markings in your plug, proceed

as follows:

Connect the wire to the terminal marked ‘ ’ or BROWN L

coloured RED. Connect the BLUE wire to the terminal

marked ‘ ’ or coloured ‘ ’ or ‘ ’ must not N BLACK. Note: L N

be connected to the terminal marked ‘ ’ or ‘ ’ or EARTH E

coloured or . GREEN GREEN AND YELLOW

If in doubt, consult your electrician.

Using the Heater

Main Elements - See Fig 1.

1. Power indicator light

2. Standby thermostat

3. Air outlet grille

4. USB charge port

5. Safety tilt switch

Standby Thermostat - see Fig. 2

The heat output is controlled by the

thermostat, according to the local

area temperature.

Turn the thermostat knob fully

clockwise to maximum setting

initially. When the area is warm

enough, reduce the setting slowly

until the heater just clicks off.

The heater will now cycle on and off to maintain your local

area temperature. An audible click may be heard when the

thermostat operates - this is normal.

Note: If the heater does not come on when the thermostat

is at a low setting, this is normally because the local area

is warmer than the thermostat setting and is not a fault.

Position ‘ ’ will put the heater into standby mode (unless

the temperature is approximately 5°C). This is a special

setting to enable the product to be used as a charger

throughout the year.

Safety - Overheat Protection and Tilt Switch

For your safety, this appliance is tted with a thermal cut-out.

In the event that the product overheats, the cut-out switches

the heater off automatically. To bring the heater back into

operation, remove the cause of overheating, then turn off

the electrical supply to the heater for a few minutes.

When the heater has cooled sufciently reconnect and

switch on the heater.

If the cut-out operates repeatedly, contact your supplier.

The heater is also tted with a tilt switch, so in the event

the heater gets accidentally knocked over the product will

not operate.

USB Charge Port

This product also has the facility of a USB charge port which

supplies a 5V 2.1A supply. Please ensure that your device

is suitable before connecting to the USB port. It is designed

to charge the majority of tablets and smartphones.

Cleaning

WARNING ALWAYS DISCONNECT FROM THE POWER

SUPPLY BEFORE CLEANING THE HEATER.

Do not use detergents, abrasive cleaning powders or polish

of any kind on the heater.

Wipe with a dry cloth to remove dust and a damp cloth (not

wet) to clean off stains. Be careful not to allow moisture

into the heater.

Ensure that dust or uff does not accumulate inside the

heater as this could lead to overheating of the element.

Use a vacuum cleaner to remove any uff which does

accumulate.

Recycling

This marking indicates that this product

should not be disposed with other household

wastes throughout the EU. To prevent possible

harm to the environment or human health

from uncontrolled waste disposal, recycle it

responsibly to promote the sustainable reuse

of material resources. To return your used device, please

use the return and collection systems or contact the retailer

where the product was purchased. They can take this

product for environmental safe recycling.

Model Identier(s): DDF250

Heat output

Nominal heat output Pnom 0.25 kW

Minimum heat output (indicative) Pmin 0.25 kW

Maximum continuous heat output Pmax,c 0.25 kW

Auxiliary electricity Consumption

At nominal heat output elmax 0.0 kW

At minimum heat output elmin 0.0 kW

In standby mode elSB 0.0 kW

Type of heat output/ room temperature control

Mechanical thermostat room temperature control Yes

Contact details

GDHV

Millbrook House, Grange Drive, Hedge

End, Southampton.

SO30 2DF

Fig. 2
