Sida 1/12

The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC)

EN55014, EN60555-2 and EN60555-3 These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC

Burgate, Meribel

BRG20, MRB20

08/52406/0 Issue 6

OCN 10725

EN : This product is only suitable for well insulated rooms or occasional use. DE : Dieses Produkt ist nur für gut isolierte Bereiche oder gelegentli-

che Verwendung geeignet. FR : Ce produit convient uniquement à des endroits bien isolés ou pour un usage occasionnel. IT : Questo prodotto è

adatto solo per spazi ben isolati o per uso occasionale. ES : Este producto sólo es adecuado para espacios bien aislados o un uso ocasional. NL :

Dit product is uitsluitend geschikt voor goed geïsoleerde ruimten of voor sporadisch gebruik. PL : Produkt ten jest odpowiedni wyłącznie do dobrze

odizolowanych miejsc lub do okazjonalnego użytku. NO : Dette produktet egner seg kun for godt isolerte rom eller sporadisk bruk. RO : Acest

produs este adecvat exclusiv spaţiilor bine ventilate sau utilizării ocazionale. CZ : Tento výrobek je vhodný pouze do dobře izolovaných prostor

nebo k příležitostnému použití. DK : Dette produkt er kun egnet til velisolerede rum eller lejlighedsvis brug. PT : Este produto somente é adequado

para espaços bem isolados ou uso ocasional. SE : Denna produkt är endast avsedd för välisolerade utrymmen eller tillfällig användning. FI : Tämä

tuote soveltuu ainoastaan hyvin eristettyihin tiloihin tai satunnaiseen käyttöön. SK : Tento výrobok je vhodný len pre dobre izolované priestory alebo

na občasné použitie. SI : Ta izdelek je primeren le za dobro izolirane prostore ali za občasno uporabo. HR : Ovaj proizvod je pogodan samo za

dobro izolirane prostore ili povremenu upotrebu. HU : Ez a termék csak jól szigetelt terekhez vagy eseti használatra alkalmas.

Dimplex OPTIMYST Stove

Introduction

Thank you for choosing this Dimplex electric re. Please read this information guide carefully to be able to safely

install, use and maintain your product.

Important Safety Advice

When using electrical appliances, basic precautions should always be followed to reduce the risk

of re, electrical shock and injury to persons, including the following:

1. OVERHEATING

WARNING: In order to avoid overheating, do not cover the heater. Do not place material or

garments on the heater, or obstruct the air circulation around the heater. The heater carries a DO

NOT COVER warning.

2. DAMAGE.

If the appliance is damaged, check with the supplier before installation and operation.

If the supply cord is damaged it must be replaced by the manufacturer or service agent or a

similarly qualied person in order to avoid a hazard.

3. LOCATION

Do not use outdoors.

Do not use in the immediate surroundings of a bath, shower or swimming pool.

Do not locate the heater immediately below a xed socket outlet or connection box.

Ensure that furniture, curtains or other combustible material are positioned no closer than 1 metre

from the heater.

Although this heater conforms with safety standards, we do not recommend its use on deep pile

carpets or on long hair type of rugs.

4. PLUG POSITIONING

The appliance must be positioned so that the plug or point of isolation is accessible.

Keep the supply cord away from the front of the heater.

5. USE OF OTHER CONTROLS

Do not use this heater in series with a thermal control, a program controller, a timer or any

other device that switches on the heat automatically, since a re risk exists when the heater is

accidentally covered or displaced.

6. UNPLUGGING

In the event of a fault unplug or isolate the device.

Unplug or isolate the device when not required for long periods.

7. OWNER/USER

This appliance can be used by children aged form 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall

not be made by Children without supervision.

Children of less than 3 years should be kept away unless continuously supervised. Children aged

from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been

placed or installed in its intended normal operating position and they have been given supervision

or instruction concerning use of the appliance in a safe way and understanding the hazards

involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean

the appliance or perform user maintenance.

CAUTION - Some parts of this product can become very hot and cause burns. Particular

attention has to be given where children and vulnerable people are present.

8. ELECTRCITY

WARNING – THIS APPLIANCE MUST BE EARTHED.

This heater must be used on an AC ~ supply only and the voltage marked on the heater must

correspond to the supply voltage.

Before switching on, please read the safety advice and operating instructions.

General Information

Technical Information :

with mechanic thermostat room temperature control.

Only use ltered water in this appliance.

This model is designed to be free standing and is normally positioned near a wall.

Always ensure that the appliance is sitting on a level surface.

To reduce heat loss and to prevent any chimney up draft affecting the operation of your inset re we recommend they

the chimney ue is sealed off.

Please note: Used in an environment where background noise is very low, it may be possible to hear a sound which is

related to the operation of the ame effect. This is normal and should not be a cause for concern.

If this product experiences a power surge for whatever reason the product may cut-out. This is a normal safety feature

and the product will resume operation after 30 seconds.

Once installed, never move this appliance or lay on its back, without draining the water from sump and water tank.

If you intend not using the appliance for longer than 2 weeks, drain the water from sump and water tank and dry the

sump.

The water tank, sump, sump lid, tank cap and air lters must be cleaned once every two weeks, particularly in hard

water areas.

The appliance should never be operated if the lamps are not working.

The lamps should be regularly inspected as described under ‘Maintenance’ and ‘Changing lamps’.

If condensation occurs on the inside doors, reduce the amount of smoke and ames produced using Control Knob ‘D’

(see section ‘Operating the Fire’) and leave the door slightly ajar

The sump and the water tank in this product are treated with a biocidal product, Silver Biocide. This conforms with the

latest relevant ISO standard

Installation Instructions

This section describes how to set up your re.

Before installing this appliance in an existing chimney, we recommend that;

1. You have your chimney cleaned by a competent chimney sweep.

2. You block off the chimney ue.

This procedure is important for the efcient operation of the heating unit and will also reduce heat loss up the chimney.

BEFORE YOU START

1. Ensure that all packing items are removed (read any warning labels carefully) and retain all packing for possible future

use e.g. in the event of moving house or returning the appliance to your supplier.

2. Before connecting the stove, check that the supply voltage is the same as that stated on the heater.

INSTALLATION

Place the stove against a wall and connect the stove to your electricity supply.

Connect the power cable to the appropriate power connector at the back of the re

Plug the power cable into a 13amp/240volt outlet. Do not yet switch the appliance on.

Connecting the Transducer Unit + Lamps

1. Release the two red tabs by turning them by 90 degrees (see Fig 2)

2. Lift out the Sump Nozzle (Fig 3)

3. Insert lamps into lamp holders (Fig 4), carefully locating the pins into the holes (Fig 4a)

4. Push lamps rmly into place

5. Place the Transducer Unit into the sump and join the cable to the connector on the sump (Fig 5)

6. To ensure that the Transducer Unit is correctly placed in the sump, the tab on the Transducer Unit should be lined up

with the moulded recess in the sump (Fig 5a).

7. Ensure that the cable is not placed above the disc on the Transducer Unit (Fig 5b). To prevent the cable becoming

Model No: BRG20, MRB20.

Heat Output 230V 240V

Nominal Heat Output P Nom 1.8 - 2.0 kW

Minimum Heat Output P min 1.0 - 1.1 kW

Maximum Continous Heat Output P max,c 1.8 - 2.0 kW

Auxiliary Electricity Consumption 0.0 0.0 kW

In Standby mode el SB 0.45 - 0.48 W
