08/53409/0 Issue 1
OFRC10TFN(B)(W), OFRC15TFN(B)(W), OFRC20TFN(B)(W) &
OFRC24(B)(W),
OFRC15TFN
AUS/NZ
A
B
C
2
1
Cable Wrap
Turbo Switch
On/Off &
Heat Selection Switch
Thermostat
Neon
3 4
5
6
On/Off see
Table 1
5 Fin
7/9/11 Fin
OFRC10TFN
OFRC15TFN
OFRC20TFN
OFRC24TFN
B
A
B
A
B
A
B
A
I
O
Model Description Watts
OFRC10TFN(B)(W) 5 Fin, Thermostat, 2 Heat Settings, Neon 1000
OFRC15TFN(B)(W) 7 Fin, Thermostat, 2 Heat Settings, Neon 1500
OFRC20TFN(B)(W) 9 Fin, Thermostat, 2 Heat Settings, Neon 2000
OFRC24TFN(B)(W) 11 Fin, Thermostat, 2 Heat Settings, Neon 2400
Important Safety Advice
IMPORTANT: If the appliance is damaged,
check immediately with the supplier before
installation and operation.
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience or knowledge if they
have been given supervision or instruction
concerning the use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Children of less than 3 years should be kept
away unless continuously supervised. Children
aged from 3 years and less than 8 years shall
only switch on/off the appliance provided that
it has been placed or installed in its intended
normal operating position and they have been
given supervision or instruction concerning
the use of the appliance in a safe way and
understand the hazards involved. Children
aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance
or perform user maintenance.
CAUTION: Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This heater carries the warning symbol
indicating that it must not be covered.
DO NOT use the heater in the immediate
surroundings of a bath, a shower or a
swimming pool.
WARNING: This heater must not be used in
a bathroom.
DO NOT place the heater directly below a xed
socket outlet.
CAUTION: Avoid use of an extension cord
because the extension cord may overheat and
cause risk of re.
WARNING: In order to avoid overheating, do
not cover the heater.
We recommend that you open a window to
ventilate the room when using the heater for
the rst time.
Unplug the heater when not required for long
periods.
IMPORTANT: If the mains lead of this appliance
is damaged, it must be replaced by the
manufacturer or its service agent or a similarly
qualied person in order to avoid a hazard.
DO NOT use the heater where gas, petrol, paint
or other inammable goods are used or stored.
General
The heater is designed for operation on an AC electricity supply,
and is suitable for use in domestic dwellings and similar indoor
locations.
Always ensure that the appliance is stood on a rm, level base
near to, but not directly beneath, a suitable xed socket outlet.
The heater is fitted with castors and a handle for ease of
movement. Selector switches provide a choice of heat output, an
adjustable thermostat which enables the room temperature to be
controlled accordingly and a turbo Boost fan which is controlled
independently by the turbo switch. It is supplied with a cord and
plug ready for use.
The supply cord should be uncoiled before use (see ‘Storage’).
DO NOT pull the heater along by the mains lead.
Important - The heater must only be operated with the wheels
and castors tted and in the upright position as shown in Fig. 1.
Warning – The heater complies with stringent safety standards
but to ensure efcient operation SURFACES OF THE HEATER
WILL BECOME HOT AND CONTACT WITH THESE AREAS
SHOULD BE AVOIDED, particularly between the ns on the
top and sides.
The control panel area is designed to be at a far lower temperature
to allow the safe operation of the controls at any time.
WARNING – THIS APPLIANCE MUST BE EARTHED
Fitting the castors
Remove the carton containing the castor assemblies from the
packing.
Fit the castors to the stub axles by applying hand pressure until
each castor clicks into position - see . Note that the castors Fig. 3
are designed to be a tight t on the axles but will rotate in use.
The castors can only be tted between the outer ns (as shown
in ).Fig. 2
Turn the heater upside down on a carpet or other soft surface
to avoid damage
WARNING: THE HEATER IS HEAVY – ENSURE THAT IT
IS SUPPORTED TO PREVENT IT FROM TOPPLING. Ask a
second person to help with this if necessary. Position castor
bracket (see ) onto the threaded pins on the control panel. Fig. 3
Place the winged nut ‘C’ on the thread and tighten it securely.
Repeat the process for castor bracket ‘B’ onto the last n.
Note: The 5 n column heater models - OFRC10 & OFRC10TI
use curved castor brackets and must be tted as shown in Fig. 2.
Lift the heater clear of the oor, then turn it back upright and
stand it on its castors as shown in . It is now ready for use.Fig. 1
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Dimplex Dry Column Heater
Models : OFRC10TFN(B)(W), OFRC15TFN(B)(W), OFRC20TFN(B)(W) & OFRC24TFN(B)(W)
