The product complies with the European Safety Standards and the European Standard Electromagnetic Compatibility (EMC). These cover the essential requirements of
EMC Directives and the LVD Directive.
8/52620/0 (UK) Issue 7
OCN 11276
EN : This product is only suitable for well insulated rooms or occasional use. DE : Dieses Produkt ist nur für gut isolierte Bereiche oder gelegentli-
che Verwendung geeignet. FR : Ce produit convient uniquement à des endroits bien isolés ou pour un usage occasionnel. IT : Questo prodotto è
adatto solo per spazi ben isolati o per uso occasionale. ES : Este producto sólo es adecuado para espacios bien aislados o un uso ocasional. NL :
Dit product is uitsluitend geschikt voor goed geïsoleerde ruimten of voor sporadisch gebruik. PL : Produkt ten jest odpowiedni wyłącznie do dobrze
odizolowanych miejsc lub do okazjonalnego użytku. NO : Dette produktet egner seg kun for godt isolerte rom eller sporadisk bruk. RO : Acest
produs este adecvat exclusiv spaţiilor bine ventilate sau utilizării ocazionale. CZ : Tento výrobek je vhodný pouze do dobře izolovaných prostor
nebo k příležitostnému použití. DK : Dette produkt er kun egnet til velisolerede rum eller lejlighedsvis brug. PT : Este produto somente é ade-
quado para espaços bem isolados ou uso ocasional. SE : Denna produkt är endast avsedd för välisolerade utrymmen eller tillfällig användning.
FI : Tämä tuote soveltuu ainoastaan hyvin eristettyihin tiloihin tai satunnaiseen käyttöön. SK : Tento výrobok je vhodný len pre dobre izolované
priestory alebo na občasné použitie. SI : Ta izdelek je primeren le za dobro izolirane prostore ali za občasno uporabo. HR : Ovaj proizvod je
pogodan samo za dobro izolirane prostore ili povremenu upotrebu. HU : Ez a termék csak jól szigetelt terekhez vagy eseti használatra alkalmas.
Dimplex “Optiame” Electric Stove.
Models: Brayford BFD20E / Brayford Pebble BFD20PB / Brayford Burgundy BFD20BRG
Brayford Slate BFD20SL / Springborne SBN20E / Bari BAR20
OPERATING
INSTRUCTION MANUAL
1
23
123
I II
4
55
0
440 315
Stove Dimensions
Important Safety Advice
When using electrical appliances, basic
precautions should be followed to reduce
the risk of re, electric shock, and injury to
persons, including the following:
If the appliance is damaged, check immediately
with the supplier before installation and
operation.
Do not use this appliance in the immediate
surroundings of a bath, shower or swimming
pool.
Do not use outdoors.
This appliance must not be located immediately
above or below a fixed socket outlet or
connection box.
WARNING : The appliance carries
the Warning Symbol indicating that it
must not be covered or has a Do not
cover label. Do not cover or obstruct
in any way the heat outlet grille located
underneath the appliance Overheating
will result if the appliance is accidentally
covered. Do not place material or garments
on the appliance, or obstruct the air circulation
around the appliance, for instance by curtains
or furniturne, as this could cause overheating
and a re risk.
In the event of a fault unplug the heater.
Unplug the appliance when not required for
long periods.The supply cord must be placed
on the right hand side of the heater away from
the heat outlet underneath the appliance.
Although this appliance complies with safety
standards, we do not recommend its use on
deep pile carpets or on long hair type of rugs.
This appliance can be used by children
aged form 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experinence and
knowledge if they have been given supervision
or instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Children shall not play with the
appliance. Cleaning and user maintaince shall
not be made by Children without supervision.
Children of less than 3 years should be
kept away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed in
its intended normal operating position and they
have been given supervision or instruction
concerning use of the appliance in a safe
way and understanding the hazards involved.
Children aged from 3 years and less than 8
years shall not plug in, regulate nd clean the a
appliance or perform user maintaince.
The appliance must be positioned so that the
plug is accessible.
If the supply cord is damaged it must be
replaced by the manufacturer or service agent
or similarly qualied person in order to avoid
a hazard.
CAUTION: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an
external switching device, such as a timer, or
connected to a circuit that is regularly switched
on and off by the utility.
CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This instruction can be found at
www.dimplex.co.uk
IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Technical Information
With mechanic thermostat room temperature control.
General
Unpack the heater carefully and retain the packaging for possible
future use, in the event of moving or returning the re to your
supplier.
These models are designed to be free standing and are normally
positioned against a wall.
The re incorporates a ame effect, which can be used with or
without heating, so that the comforting effect may be enjoyed
at any time of the year. Using the ame effect on its own only
requires little electricity.
A choice of 1kW or 2kW heat output is provided by the fan heater,
which is located at the bottom of the unit.
Before connecting the heater check that the supply voltage is
the same as that stated on the heater.
On the Springborne model loose coals are packed separately
within the carton. When the heater is assembled the coals can
be placed on top of the fuel bed, as required.
Please note: Used in an environment where background noise
is very low, it may be possible to hear a sound which is related
to the operation of the ame effect. This is normal and should
not be a cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage
marked on the heater must correspond to the supply voltage.
Before switching on, please read the safety warnings and
operating instructions.
Controls Fig. 2- see
Three switches provide a choice of heat settings. The appliance is in
standby mode when the mains lead is plugged in. This is indicated by
the red neon behind the ame effect screen. The two selector switches
are in the ON position when the side with the markings on (i.e. I, or II)
are pushed in.
Push button switch 1 Controls the electricity supply to the heater
and ame effect. Press for ‘ON’ and ‘Stand-
by’. If both selector switches 2 and 3 are in
the OFF position, the product works on ame
effect only.
Selector switch 2 (I) Provides 1kW heat output
Selector switch 3 (II) Provides 2kW output with switch 2
Model No: BFD20,BFD20E,BFD20PB,SBN20,SBN20E,BFD20BRG, BFD20SL,
BAR20
Heat Output 230V 240V
Nominal Heat Output P Nom 1.7 - 1.8 kW
Minimum Heat Output P min 0.8 - 0.9 kW
Maximum Continous Heat Output P max,c 1.7 - 1.8 kW
Auxiliary Electricity Consumption
In Standby mode el SB 0.02 - 0.02 W
