Installation Instructions
This spacer is suitable for use with the following Inset Fires;
Balmoral, Savena.
Introduction
Installation Place the spacer up againse the back of the re. Ensure that the large holes are to the
open end allowing the pozi-head screw driver though.
Using the 6 screws provided and a pozi-head screw driver, screw the spacer in place
ensuring that the top and side edges of the spacer line up with the top and sides of the
re frame - see diagram
Cleaning For general cleaning use a soft clean duster.
Never use abrasive cleaners
GDC Group Ltd.
Millbrook House,
Grange Drive,
Hedge End,
Southampton,
Hampshire,
SO30 2DF
Tel 0844 879 3588
Fax 0844 879 3583
Website www.valor.co.uk
Republic of Ireland
Tel 01 8424833
c
GDC Group Ltd.
All rights reserved. Material contained in this publication may not be reproduced in whole or part, without prior permission in writing of GDC Group Ltd.
Wall Fixing Select the area where the re is to be xed. mark a point on the centre line of the re
570mm o the oor. Hold the wall bracket against the wall with this mark centred on
the centre hole of the wall bracket, level the wall bracket and mark the 2 outer holes.
Drill the 3 holes with a suitable drill bit and x the bracket to the wall using suitable x-
ings.(the xings provided are only suited for brick/block built walls).
Hang the re on the bracket by the 2 rectangular shaped slots on the rear of the spacer.
570
08/52050/0 Issue 1
