A58F2P-M4 USER MANUAL
The information in this document is subject to change without notice. The
manufacturer makes no representations or warranties with respect to the contents
hereof and specifically disclaims any implied warranties of merchantability or
fitness for any particular purpose. The manufacturer reserves the right to revise this
publication and to make changes from time to time in the content hereof without
obligation of the manufacturer to notify any person of such revision or changes.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and the receiver
•Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits
governing this device. Changes or modifications not expressly approved by the
system’s manufacturer could void the user’s authority to operate the equipment.
Federal Communications Commission (FCC)
Disclaimer
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the follow-
ing conditions:
•This device may not cause harmful interference.
•This device must accept any interference received, including interference
that may cause undesired operation.
Limits and methods of measurement of radio disturbance char-
acteristics of information technology equipment
EN 55022
EN 61000-3-2 Disturbances in supply systems caused
EN 61000-3-3 Disturbances in supply systems caused by household appli-
ances and similar electrical equipment “ Voltage fluctuations”
EN 55024 Information technology equipment-Immunity characteristics-
Limits and methods of measurement
EN 60950 Safety for information technology equipment including electri-
cal business equipment
CE marking
This device is in conformity with the following EC/EMC directives:
ii
A58F2P-M4 USER MANUAL
TABLE OF CONTENTS
Preface i
Brief Introduction 1
Specifications......................................................................................1
Motherboard Components................................................................3
Header Pin Definition and Jumper Settings.........................................4
I/O Ports...............................................................................................6
Multi-language Quick Installation Guide 7
English..................................................................................................7
Brazilian Portuguese..........................................................................9
Hindi....................................................................................................................11
French......................................................................................................13
Deutsch................................................................................................15
Russian................................................................................................17
Spanish................................................................................................19
Indonesian.............................................................................................21
Arabic.......................................................................................................23
Simplified Chinese...............................................................................25
Korean......................................................................................................27
A58F2P-M4 USER MANUAL
1
Brief Introduction
CPU
Specifications
• AMD A58 (Bolton) ChipsetChipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 32 GB
•
Memory
• 1 x PCI Express x16 Gen3* slot
• 1 x PCI Express p3-x1 slot
• Supported by AMD A58 (Bolton) Chipset
- 4 x Serial ATA 3Gb/s connectors
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-sub (VGA) port
• 1 x HDMI port (optional)
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone and Line out)
Rear Panel I/O
• Socket FM2+ for AMD A series processors
• Supports CPU up to 100W TDP
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 4 x Serial SATA 3Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x Clear CMOS jumper
• 1 x Front panel USB power select jumper
• 1 x Rear USB/PS2 power select jumper
• 1 x Debug Card header (LDC)
• 1 x SPDIF out header
Internal I/O
Connectors &
Headers
• Realtek ALC662 6-Ch High Definition audio CODEC
-Compliant with HD audio specification
Audio
LAN • Realtek RTL8111G Gigabit LAN
Supports DDR3 2133(FM2+)*/1866(FM2)*MHz DDR3 SDRAM
Note: *Due to the limitation of chipset spec, it supports up to
2133/1866 MHz, 1.5V memory with a single DIMM per channel.
Please go to ECS website for the latest Memory support list.
Note: *FM2+ supports PCI Express Gen3, FM2 supports PCI
Express Gen2.
