B450AM4-M USER MANUAL
i
TABLE OF CONTENTS
Preface i
Brief Introduction 1
Specifications......................................................................................1
Motherboard Components................................................................3
Header Pin Definition and Jumper Settings.........................................5
I/O Ports...............................................................................................8
Multi-language Quick Installation Guide 9
English...................................................................................................9
Simplified Chinese...............................................................................11
Korean......................................................................................................13
Indonesian.............................................................................................15
Japanese.................................................................................................17
Vietnamese.............................................................................................19
ii
B450AM4-M USER MANUAL
Memo
B450AM4-M USER MANUAL
1
Brief Introduction
CPU
Specifications
• AMD B450 ChipsetChipset
• Dual-channel DDR4 memory architecture
• 4 x 288-pin DDR4 Long-DIMM sockets support up to 64 GB
• Supports 2400 MHz DDR4 Long-DRAM (by CPU)
Memory
• 2 x PCI Express x16 slots (one slot runs x16 Gen3, the other
runs p3-x4 Gen2)
• 1 x PCI Express p3-x1 Gen2 slot
• 1 x PCI slot
• 2 x M.2 slot (socket 1 key E 2230 supports wifi + BT, socket 3 key
M 2242/2280 supports SSD/SATA)
• Supported by AMD B450 Chipset
- 4 x Serial ATA 6Gb/s devices
- RAID 0, 1, 10
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x VGA port
• 1 x DVI port
• 1 x HDMI port
• 1 x DP port
• 2 x USB 3.1 ports
• 2 x USB 2.0 ports
• 4 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)
Rear Panel I/O
• Realtek RTL8111GN
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
•AMD® RYZENTM Series processors Gen2 for socket AM4
• Supports CPU up to 95W TDP
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 2 x 4-pin SYS_FAN connectors
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
Internal I/O
Connectors &
Headers
• Realtek ALC662
• Realtek ALC1304 Amplifier IC
- 6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
LAN
Note: Please go to ECS website for the latest Menory support list.
Note: If HDMI and DP are connected simultaneously, the HDMI
will show preferentially.
