USER’S GUIDE
Version:1.0 ®
Q470H6-M6 USER MANUAL
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected
under international copyright laws, with all rights reserved. Neither this manual, nor
any of the material contained herein, may be reproduced without written consent of
the author.
Version 1.0
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof
and specifically disclaims any implied warranties of merchantability or fitness for
any particular purpose. The manufacturer reserves the right to revise this publica-
tion and to make changes from time to time in the content hereof without obligation
of the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Windows® 10 are registered trademarks of Microsoft Corp.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and the receiver
•Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits govern-
ing this device. Changes or modifications not expressly approved by the system’s
manufacturer could void the user’s authority to operate the equipment.
ii
Q470H6-M6 USER MANUAL
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the
following conditions:
•This device may not cause harmful interference, and
•This device must accept any interference received, including interference
that may cause undesired operation.
Canadian Department of Communications
This class B digital apparatus meets all requirements of the Canadian Interference-
causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement
sur le matériel brouilieur du Canada.
The manual consists of the following:
Describes features of the
motherboard.
Hpage 1
Describes installation of
motherboard components.
Hpage 7
Hpage 27
Hpage 65
Installing the Motherboard
Introducing the Motherboard
Provides information on
using the BIOS Setup Utility.
Describes the motherboard
software.
About the Manual
This device is in conformity with the following EC/EMC directives:
Chapter 4
Chapter 1
Chapter 2
Chapter 3
Using BIOS
Using the Motherboard Software
Chapter 5
Trouble Shooting
Provides basic trouble
shooting tips.
page 69
H
Electromagnetic compatibility of multimedia equipment - Emission
requirements
EN 55032
EN 61000-3-2 Electromagnetic Compatibility(EMC)
Part 3-2: Limits-Limits for harmonic current emissions (equipment input
current 16A per phase)
EN 61000-3-3 Electromagnetic Compatibility(EMC)
Part 3-3: Limits-Limitation of voltage changes, voltage fluctuations and flicker
in public low-voltage supply systems, for equipment with rated current 16A
per phase and not subject to conditional connection
EN 55024 Information technology equipment-Immunity characteristics-Limits and
methods of measurement
EN 60950 Safety for information technology equipment including electrical business
equipment
CE marking
iii
Q470H6-M6 USER MANUAL
Chapter 2 7
Installing the Motherboard 7
Safety Precautions.............................................................................7
Installing the Motherboard in a Chassis......................................7
Checking Jumper Settings.................................................................8
Installing Hardware...................................................................9
Installing the Processor.............................................................9
Installing the CPU Cooler.........................................................11
Installing Memory Modules....................................................12
Installing Add-on Cards...........................................................14
Connecting Optional Devices..................................................17
Installing a SATA Hard Drive...................................................22
Connecting Case Components.......................................................23
Front Panel Header.................................................................26
TABLE OF CONTENTS
Preface i
Chapter 1 1
Introducing the Motherboard 1
Introduction...................................................................................1
Pakage Contents............................................................................1
Specifications................................................................................2
Motherboard Components..........................................................4
I/O Ports..............................................................................................6
Chapter 3 27
Using BIOS 27
About the Setup Utility................................................................27
The Standard Configuration....................................................27
Entering the Setup Utility........................................................27
Resetting the Default CMOS Values.....................................28
Using BIOS........................................................................................28
BIOS Navigation Keys..............................................................29
Main Menu.............................................................................30
Advanced Menu......................................................................31
Chipset Menu..........................................................................46
Tweak Menu.... .................. ......................................................53
Security Menu..........................................................................60
Boot Menu...............................................................................61
Exit Menu................................................................................62
iv
Q470H6-M6
USER MANUAL
Chapter 4 65
Using the Motherboard Software 65
Auto-installing under Windows 10.................................................65
Running Setup.........................................................................65
Manual Installation..........................................................................67
ECS Utility Software (Intelligent EZ Utility).....................................67
Chapter 5 69
Trouble Shooting 69
Start up problems during assembly..............................................69
Start up problems after prolong use............................................70
Maintenance and care tips..............................................................70
Basic Troubleshooting Flowchart...................................................71
Updating the BIOS.........................................................................63
1
Q470H6-M6
USER MANUAL
Chapter 1
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the Q470H6-M6 motherboard. This motherboard is a high
performance, enhanced function motherboard designed to support the LGA1200
socket for Intel® Comet Lake-S processor.
This motherboard is based on Intel®®®®
® Q470 Express Chipset for best desktop platform
solution. It supports up to 64 GB of system memory with dual channel DDR4 2666
MHz. High resolution graphics via two PCI Express x16 Gen3 slots, intended for Graph-
ics Interface, and two PCI Express p6-x1 Gen3 slots are supported. In addition, two M.2
slots are for extending usage.
It integrates USB 2.0 and USB 3.2 interface, supporting up to six USB 2.0 ports (two
USB 2.0 ports at the rear panel, two 10-pin USB 2.0 headers support additional four
USB 2.0 ports), four USB 3.2 Gen1x1 ports (two USB 3.2 Gen1x1 ports at the rear panel
and one USB 3.2 Gen1x1 header supports additional two USB 3.2 Gen1x1 ports), and
three USB 3.2 Gen2x1 ports (two USB 3.2 Gen2x1 ports at the rear panel and one USB
3.2 Gen2x1 header supports additional one USB 3.2 Gen2x1 port) .
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including PS/2 keyboard and mouse connectors, one HDMI port, two DP ports, one D-
sub port (VGA port), two USB 3.2 Gen1x1 ports, two USB 3.2 Gen2x1 ports (Type A+C),
one RJ45 LAN connector, two USB 2.0 ports, and 6-ch audio jacks for line-in, line-out
and microphone.
In addition, this motherboard supports four SATA 6Gb/s connectors for expansion.
Your motherboard package ships with the following items:
Package Contents
Q470H6-M6 Motherboard
Quick Installation Guide
User Manual
DVD
I/O Shield
2 SATA 6Gb/s cable
The package contents above are for reference only, please take the actual package items as
standard.
Chapter 1
2
Q470H6-M6
USER MANUAL
Brief Introduction
Specifications
CPU
• Intel® Q470 Chipset
Chipset
• Supported by Intel® Q470 Express Chipset
- 4 x Serial ATA 6Gb/s devices
Storage
• LGA1200 socket for Intel® Comet Lake-S processor
• Supports CPU up to 65W
Note: Please go to our website for the latest CPU support list.
• 1 x PS/2 mouse & keyboard connector
• 1 x HDMI port
• 2 x DP port
• 1 x D-sub port (VGA port)
• 2 x USB 2.0 ports
• 2 x USB 3.2 Gen1x1 ports
• 2 x USB 3.2 Gen2x1 ports (Type A+C)
• 1 x RJ45 LAN connector
• 1 x Audio 6-ch jacks (line-in, line-out, microphone)
Rear Panel I/O
LAN • Intel WGI 219LM Gigabit Lan
• Realtek ALC892 + ALC105 (Amplifier) 6-CH High Definition
audio CODEC
- Compliant with HD audio specification
Audio
Expansion
Slots
• 2 x PCI Express p7-x16 Gen3 slots (one slot runs x16, one slot runs
x4)
• 2 x PCI Express p7-x1 Gen3 slots
• 2 x M.2 slots
- 1 x M.2 socket (Key E) type 2230 supports Wifi / BT and Intel®
CNVi JFP1 card
- 1 x M.2 socket (Key M) type 2242/2260/2280 supports PCIe
Gen3 p7-x4 & SATA SSD & Intel
® OptaneΤΜ Technology
• Dual-channel DDR4 memory architecture
• 4 x 288-pin DDR4 LONG DIMM sockets support up to 64 GB
• Supports DDR4 2666 MHz DDR4 SDRAM
Memory
Note: Please go to our website for the latest Memory support list.
Internal I/O
Connectors &
Headers
• 1 x 24-pin ATX Power Supply connector
• 1 x 8-pin ATX 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x Front USB 3.2 Gen2x1 header (1 Port)
• 2 x Front USB 2.0 headers (4 Ports)
• 4 x SATA 6Gb/s connectors
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x onboard parallel port header (LPT)
• 1 x Clear CMOS jumper
• 1 x Case open header
• 1 x Front USB 3.2 Gen1x1 header (2 Ports)
Chapter 1
4
Q470H6-M6
USER MANUAL
Motherboard Components
Produktspecifikationer
| Varumärke: | ECS |
| Kategori: | moderkort |
| Modell: | Q470H6-M6 |
Behöver du hjälp?
Om du behöver hjälp med ECS Q470H6-M6 ställ en fråga nedan och andra användare kommer att svara dig
moderkort ECS Manualer
8 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
8 Januari 2025
7 Januari 2025
27 Oktober 2024
27 Oktober 2024
27 Oktober 2024
moderkort Manualer
- moderkort Asus
- moderkort Sharkoon
- moderkort Gigabyte
- moderkort Asrock
- moderkort Supermicro
- moderkort Evga
- moderkort Intel
- moderkort MSI
- moderkort NZXT
- moderkort Foxconn
- moderkort Advantech
- moderkort Elitegroup
- moderkort EPoX
- moderkort Biostar
Nyaste moderkort Manualer
8 April 2025
8 April 2025
3 April 2025
3 April 2025
3 April 2025
3 April 2025
2 April 2025
2 April 2025
1 April 2025
30 Mars 2025
