MS50A

WIRELESS SPEAKER

User manual

• MS50A is an active speaker using both i-Fi and Bluetooth W

wireless technologies. The core application is online streaming

media playback based on Amazon Alexa (Work with Alexa). After

registering this speaker to Amazon Alexa with an Amazon account,

you will be able to use streaming services such as Spotify,

Amazon Music, Pandora, etc. The speaker can be controlled in

Alexa App as well as using interactive voice devices such as Echo.

With Alexa, you can create your personal playlist, control play/

pause, build a multi-room system with other devices, and build

two speakers to a stereo group.

Thank you for choosing EDIFIER! For correct operations,

please carefully read this manual before use.

• Information contained herein may be subject to change from time

to time without prior notice.

Note:

• The MS50A is compatible with Apple AirPlay.

• This speaker can be connected to phones, PC, etc. for wireless

playback via Bluetooth.

• You can refer to the Quickstart Guide (included in the box) to set

up and enjoy your music right away.

1. P d w ro uct overvie

Wireless Speaker

Haut-parleur Sans Fil

MS50A

Quickstart Guide

Guide de démarrage rapide

Open the box and ensure the following items are included:

Speaker Quickstart guide Power cable

• Please use the power cable included in the box.

2. Wha n th box t’s i e

Button controls:

① Mode switch:

Press: audio mode switch

Press and hold for 3s:

Wi-Fi connection

(Wi-Fi mode)

Bluetooth pairing

(Bluetooth mode)

② Previous track

③ Next track

④ Pause/play

Press and hold for 6s:

restore to factory settings

⑤ Power on/off / mute

Press: mute/unmute

Press and hold for 1.5s:

power on/off

⑥

Slide counter-clockwise:

volume down

⑦

Slide clockwise: volume up

②

①

③

④

⑦

⑥

⑤

3. O n peratio

Indicators:

State

Blink rapidly

Steady lit

Heartbeat

Blink

Description

3 blinks per

second

Steady lit

1 blink per second

Long and short

blinks alternatively

Functions

Ready to connect

to a new Wi-Fi

network

Wi-Fi

connected

Wi-Fi

disconnected

Mute

Blink rapidly

Steady lit

Blink

Steady lit

3 blinks per

second

1 blink per second

State Description Functions

Mute

Bluetooth pairing

Bluetooth

connected

(1) White LED: Wi-Fi mode

(2) Blue LED: Bluetooth mode

Blink rapidly

Blue and white

LED lit and off

alternately

and rapidly

State Description Functions

starting up / over

update

(3) Blue and white LED blinks alternately:

starting up/of re update

(1) Unconnected to network: low brightness;

(2) Connected to network:

Day time (7am to 9pm): full brightness

Night time (9pm to 7am): low brightness

Brightness of indicators

Connection:

Wi-Fi connection

Bluetooth connection

1. Power on this speaker and wait for it to start up (approximately

20 seconds). Press the " " button to switch to Bluetooth mode

(blue LED).

2. This speaker is in Bluetooth pairing mode when blue LED blinks

rapidly, please select "EDIFIER MS50A" to connect.

3. Blue LED will lit steadily after pairing is complete, now you can

play music on the paired device.

or tablet from the App Store/Google Play Store or from

www r.com;

2. When power

enter i-Fi connection mode (white LED blinking rapidly). To reset W

Wi-Fi connection, press the " " button to switch to i-Fi modeW

(white LED), then press and hold the " " button for 3s to enter

Wi-Fi connection mode again;

device, and connect the speaker to network;

4. Once connected, a steady white LED will be lit;

5. This speaker can work with alexa, after it is connected to

n rompt you to register this

speaker to your Amazon Alexa account, please follow the

instructions to complete the registration.

Stereo group and multi-room system setup:

Stereo group setup:

You can use two MS50A to build a stereo group for better music

experience.

1. Make sure two MS50A speakers are connected to the same

network as your mobile device;

2. To setup stereo gr reo

group" on the home screen and click to add, then follow the

instructions to build a stereo group;

3. Set the two speakers as the left and right channel output

respectively and rename the stereo group.

4. To cancel the stereo gr

stereo group you want to cancel, and follow the instructions to

cancel the stereo group.

Multi-room system setup:

After this speaker is registered in the Amazon Alexa, you can add it to

a multi-room system through the Alexa App and play music/podcasts/

news on multiple speakers simultaneously.

1. Preparations: Connect this speaker to the same network as the

other "work with Alexa" speakers, and ensure they are logged in

to the same Amazon Alexa account.

2. Setup: Open the Alexa App, switch to the Device interface, follow

the instructions to join the existing multi-room system, or create a

new multi-room system. Please see relevant instructions of the

Alexa App for details.

Stereo group and multi-room system setup:

Music playback:

2. Local playback

Volume control:

1. Online steaming media playback

For local playback devices, you can connect them to this speaker

through Bluetooth for playback, or use Apple AirPlay or Spotify

Connect to play through i-Fi. W

The volume can be controlled in the following ways:

(1) Touch panel on this speaker: In i-Fi or Bluetooth mode, volume W

level can be controlled through the touch panel on this speaker,

please see the touch panel control instructions;

ready connected to network

and enter the playing control interface for volume control;

(3) Interactive voice devices: Under the same network, use the

interactive voice devices like Echo logging in the same Amazon

account to control volume through voice commands.

(1) For Amazon Music, Spotify, Pandora, Tuneln, iHeartRadio and

other music services linked to Alexa, after relevant accounts are

linked, you can play through Alexa and control this speaker by

using other interactive voice devices like Echo.

you

can select to play on this speaker in the Spotify App;

can be

air-played by using iPhone, iPad, iMac and other devices.

or the

re version code in the " " interface, and upgrade

relevant

System update and restore to factory settings

Restore to factory settings

Press and hold the " " button on this speaker for 6s or click

"Restor restore to

factory settings, please note that i-Fi connection, Bluetooth pairing W

and Amazon account registration information will all be cleared,

meanwhile, this speaker will return to i-Fi mode and the volume will W

resume to 50% level.

System update

Troubleshooting

1. Check if the speaker is ON.

2. Ensure the speaker is switched to Bluetooth mode.

3. Disconnect from any Bluetooth device by pressing and holding

the " " button, then search for "MS50A" again.

4. Turn off the speaker and restart it, then switch to Bluetooth

mode and search for "MS50A" again.

No sound

1. Check if main power is connected, or if the wall outlet is

switched on.

is set correctly on the speaker.

3. Check if there is a signal output from the audio source.

4. Try to turn up the volume using the volume control.

5. Turn off the speaker and restart it.

4. o lesho ng Tr ub oti

Power output: mid-bass+treble: 25W+15W

Frequency response: 52Hz-18KHz

Audio input: Wi-Fi, Bluetooth

Declaration for EU

Frequency Band (Bluetooth): 2.402GHz ~ 2.480GHz

Frequency Band (2.4G): 2.400GHz ~ 2.4835GHz

Frequency Band (5G): 5.15GHz ~ 5.35GHz, 5.47GHz ~ 5.725GHz,

5.725GHz ~ 5.85GHz

RF Power output: ≤20 dBm (EIRP) (5.725GHz~5.850GHz excluded)

RF Power output: ≤14 dBm (EIRP) (5.725GHz~5.850GHz)

Model: EDF100008

FCC ID: Z9G-EDF112

IC: 10004A-EDF112

P.O. Box 6264

Hong Kong

Tel: +852 2522 6989

Fax: +852 2522 1989

Printed in China

NOTICE:

For the need of technical improvement and system upgrade, information

contained herein may be subject to change from time to time without prior notice.

Products of EDIFIER will be customized for different applications. Pictures and

illustrations shown on this manual may be slightly different from actual product.

If any difference is found, the actual product prevails.

r.com/support

5. p dix Ap en

Note:
